Maintenance
Instrument panel fuse panel
Fuse Name Symbol
ROOM LAMP
AUDIO
RR HTD
A/CON 1
SAFETY POWER
WINDOW
STOP
STOP LAMP
LAMP
P/WDW LH
P/WDW RH
SENSOR S
START
BRAKE SWITCH
TCU T
7 62
Fuse rating
10A Luggage Lamp, Room Lamp
20A Auido
30A RR HTD Relay
7.5A A/C Control Module (Auto)
25A Driver Safety Power Window Module
15A Stop Signal Electronic Module, Data Link Connector
Power Window Main Switch, Driver Safety Power Window Module (LHD), Passenger Power
25A
Window Switch (RHD)
Power Window Main Switch, Driver Safety Power Window Module (RHD), Passenger
25A
Power Window Switch (LHD)
10A PCB Fuse & Relay Box (Vacuum Pump Relay)
B/Alarm Relay, PCB Fuse & Relay Box (Start Relay), PCM, Smart Key Control Module,
7.5A
Transaxle Range Switch
10A Smart Key Control Module, Stop Lamp Switch
A/T : Transaxle Range Switch, Pulse Generator 'A'/'B'
15A
M/T : Vehicle Speed Sensor, PCB Fuse & Relay Box (F34)
Circuit Protected
