4. Use Table 7–3 to convert each binary number to the equivalent ASCII
character.
Table 7–3 lists the results of steps 3 and 4 for each possible binary value. All
you have to do is find the 6-digit binary number for each sixel bit pattern in
your character design.
Figure 7–4 shows this conversion for the uppercase D in this example.
You use this procedure to convert each character of your soft character set into a
string of sixel bit patterns. Then you can download your DRCS characters into
the terminal, using the DECDLD device control string described in Chapter 5.
Table 7–3 Converting Binary Code to an ASCII Character
Binary Value Hex. Value
000000 00
000001 01
000010 02
000011 03
000100 04
000101 05
000110 06
000111 07
001000 08
001001 09
001010 A
001011 B
001100 C
001101 D
001110 E
001111 F
010000 10
010001 11
010010 12
010011 13
010100 14
010101 15
010110 16
010111 17
011000 18
011001 19
011010 1A
011011 1B
011100 1C
011101 1D
011110 1E
011111 1F
100000 20
Hex. Value + 3F Character
Offset Equivalent
3F ?
40 @
41 A
42 B
43 C
44 D
45 E
46 F
47 G
48 H
49 I
4A J
4B K
4C L
4D M
4E N
4F O
50 P
51 Q
52 R
53 S
54 T
55 U
56 V
57 W
58 X
59 Y
5A Z
5B [
5C \
5D ]
5E ^
5F _
Character Sets
7.6 Soft Character Sets
(continued on next page)
