Character Body Sizes For 24-Line By 80- And 132-Column Fonts; Guidelines For Designing Soft Characters - Digital Equipment VT520 Programming Manual

Character Sets
7.6 Soft Character Sets
Figure 7–2 Character Body Sizes for 24-Line by 80- and 132-Column Fonts
C h a ra c t e r
B o d y
He ig h t 1 0
Table 7–2 Guidelines for Designing Soft Characters
Character Dimension
24 Lines/Screen
Cell width
Cell height
Body width
Body height
Ascender height
Descender height
Spacing before character
Spacing after character
7–8 Character Sets
C h a r a ct e r
S p a c i n g B o d y Wi d t h
2
7
A ll v a lu e s a r e i n p i xe l s.
S p a c i n g Sp a c i n g
1 1
H e i g h t
1 0
80-Column Font
10 pixels
16
8
10
3
3
1
1
W i d th
S p a c i n g
5 1
G S F _ 0 5 9 9 _ 8 9 _ R . D G
132-Column Font
6 pixels
16
4
9
3
3
1
1
(continued on next page)
