Sony KV-21FQ10K Service Manual page 41

C BOARD VOLTAGE LIST AND WAVEFORM
Ref Pin No. Voltage[v]
IC751 1 1.7
1
1.56Vp-p
2 1.6
2
1.66Vp-p
3 1.7
3
1.64Vp-p
4 0
5 4.2
6 197.7
KV-21FQ10B/21FQ10E/21FQ10K/21CL10B
KV-21CL10E/21CL10K/21CL10U/21CL1K
Ref Pin No. Voltage[v]
7 139.2
4
108.0Vp-p
8 149.0
5
98.0Vp-p
9 138.4
6
98.0Vp-p
J751 5
6
8 138.2
9 150.0
10 140.0
– 53 –
0
0
RM-W100
