Video Interface

Package
Interface
Supports ZV (Zoomed Video) port

Video Memory

Chipset
Memory size
Interface
USB Port
Chipset
USB Compliancy Level
OHCI
Number of USB port
Location
Serial port function control
PCMCIA Port
PCMCIA controller
Supports card type
Number of slots
Access location
Supports ZV (Zoomed Video) port
Supports 32 bit CardBus

System Board Major Chips

Core logic
VGA
LAN
USB 2.0
Super I/O controller
MODEM
Bluetooth
42
Item
Item
Item
Item
Item
®
FCBGA 1466-pin for Intel
BGA 533 pin for Nvidia G7300
internal PCIE
Yes
®
Intel 945GM (for Aspire 5570/5580 UMA models) and Intel
940GML (Aspire 3680)
Nvidia G7300 (G72M-V) (for Aspire 5570/5580 discrete models)
up to 128MB
DDR2
Built-in ICH7M
2.0
USB 1.1 and USB 2.0 Host controller
3
One on the left side/two on the rear side
Enable/Disable by BIOS Setup
TI PCI8412/PCI6412
Type-II
One type-II
Left panel
No ZV support
Yes
®
Intel 945GM/945PM/940GML+ICH7M
®
Intel 945GM (for Aspire 5570/5580 UMA models) and Intel
940GML (Aspire 3680)
Nvidia G7300 (G72M-V) (for Aspire 5570/5580 discrete models)
Marvell 88E8055 for GigaLAN for future advanced models, not
launch yet
Marvell 88E8038 for 10/100 LAN
Built in ICH7M
NS PC87383
ALC 883
Built-in ICH7M
Specification
®
945GM and Intel 940GML
Specification
Specification
Specification
Controller
®
®
