Acer ASPIRE 5570 Service Manual page 49

DVD-Super Multi Interface
Item
Applicable disc format
Loading mechanism
Power Requirement
Input Voltage
Audio Interface
Audio Controller
Audio onboard or optional
Mono or Stereo
Resolution
Compatibility
Sampling rate
Internal microphone
Internal speaker / Quantity
Video Interface
Chipset
Chapter 1
For PANASONIC UJ-850:
Applicable disc format
CD: CD-DA, CD-ROM, CD-ROM XA, PhotoCD (multi-session), Video CD, Cd-
Extra (CD+), CD-text
DVD: DVD-VIDEO, DVD-ROM, DVD-R (3.9GB, 4.7GB) DVD-R DL, DVD-RW,
DVD-RAM, DVD+R, DVD+R DL, DVD+RW
For Toshiba TSST TS-L632D
CD:
CD-DA (Red Book) - Standard Audio CD & CD-TEXT
CD-ROM (Yellow Book Mode1 & 2) - Standard Data
CD-ROM XA (Mode2 Form1 & 2) - Photo CD, Multi-Session
CD-I (Green Book, Mode2 Form1 & 2, Ready, Bridge)
CD-Extra/ CD-Plus (Blue Book) - Audio & Text/Video
Video-CD (White Book) - MPEG1 Video
CD-R (Orange Book Part )
CD-RW & HSRW (Orange Book Part Volume1 & Volume 2
Super Audio CD (SACD) Hybrid type
US & US+ RW
DVD:
DVD-ROM (Book 1.02), DVD-Dual
DVD-Video (Book 1.1)
DVD-R (Book 1.0, 3.9G)
DVD-R (Book 2.0, 4.7G) - General & Authoring
DVD+R (Version 1.0)
DVD+RW
DVD-RW (Non CPRM & CPRM)
DVD°"R Dual
Load: Manual
Release: (a) Electrical Release (Release Button)
(b) Release by ATAPI command
(c) Emergency Release
5 V +/- 5 % (Operating)
Item
Item
Specification
Realtek ALC883D Azalia and Amplifier Maxim MAX9710 &
MAZ4411
Built-in
Stereo
18 bit stereo full duplex
HD audio Interface; S/PDIF output for PCM or AC-3 content
1Hz resolution VSR (Variable Sampling Rate)
Yes
Yes/2 (1.5W speakers)
®
Intel 945GM (for Aspire 5570/5580 UMA models) and Intel
940GML (Aspire 3680)
Nvidia G7300 (G72M-V) (for Aspire 5570/5580 discrete models)
Specification
Specification
®
41
