The front panel indicators are visible even when the computer cover is closed up.
Icon
Icon Function
NOTE: 1. Charging: The light shows amber when the battery is charging. 2. Fully charged: The light shows
green when in AC mode.
Chapter 1
Function
Cap lock Lights when Cap Lock is activated
Description
Num lock Lights when Num Lock is activated.
HDD Indicates when the hard disc or optical
drive is active.
Bluetooth Indicates the status of Bluetooth
communication.
Wireless LAN Indicates the status of wireless LAN
communication.
Power Lights up when the computer is on.
Battery Lights up when the battery is being
charged.
Description
13
