Offline Status Description - Foison C12 User Manual

Setting Mode Menu Definition
Button
Menu
Set Per Menu Definition
Button
Menu

6.3 Offline Status Description

Offline Keyboard Function Definition
Button
Online
Test
Test
Pause
Repeat
The left and right herein refer to the person stands in front of the
cutter. The object is subject to the person's direction.
22
Function
Menu Switch
Baud Rate Increase
Baud Rate Decrease
Idle Speed Increase
Idle Speed Decrease
Function
Menu Switch
Increase Yp Scale
Decrease Yp Scale
Increase Xp Scale
Decrease Xp Scale
Function
Online/Offline
Y+, Left Direction Key
Y-, Right Direction Key
X+, Backwards Direction Key
X-, Forwards Direction Key
Original Position Setting Key
Press for One Second
Press for Two Seconds
Pause/Resume
Repeat Last Time Work
C SERIES USER'S MANUAL
Description
Press once and enter into Set Per menu
Press once and increase to a defined baud rate
Press once and decrease to a defined baud rate
Press once the Idle Speed will increase by 50mm/s
Press once the Idle Speed will decrease by 50mm/s
Description
Press once and enter into Foison status
If the actual cutting scale is smaller than the image size
from Y position, press this button will increase the size.
If the actual cutting scale is larger than the image size
from Y position, press this button will decrease the size
If actual cutting size is smaller than the image size, press
this button will increase the size.
If actual cutting size is larger than the image size, press
this button will decrease the size.
Description
Press once to switch to Foison status
Press and realize carriage move to left position
Press and realize carriage move to right position
Press and realize main bearing move backwards
Press and realize main bearing move forwards
Press once will reset X,Y to "0", the current
position will be the original position
Draw/cut a tiny square
Draw/cut a test pattern
When the cutter finish working, press this key on
offline status will repeat the same job
