Summary of Contents for DB Audio DS10
- Page 1 DS10 Manual 1.5 en...
- Page 2 General information DS10 Manual Version: 1.5 en, 01/2016, D2027.EN .01 Copyright © 2016 by d&b audiotechnik GmbH; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this manual.
- Page 3 When a rack on wheels is used, exercise caution when moving the loaded rack to avoid injury from tipping over. 10. Unplug this apparatus during lightning storms or when unused for long periods of time. d&b DS10 Manual 1.5 en...
-
Page 4: Table Of Contents
Contents DS10 Audio network bridge........5 1.1. Intended use................5 1.2. Scope of supply..............5 Technical specifications..........7 Startup.................. 8 3.1. Overview................. 8 3.2. Rack mounting................. 9 3.3. Mains connection..............9 3.4. Front panel................10 3.4.1. BYPASS/NETWORK............10 3.4.2. DIGITAL OUT 1 – 4............10 3.4.3. -
Page 5: Ds10 Audio Network Bridge
Dante Controller software, which enables networkwide routing from one single software platform. The software is available for free download at www.audinate.com. The DS10 is mainly intended for use within the d&b Touring rack assemblies. NOTICE! The device complies with the electromagnetic compatibility... - Page 6 Z5563 DS10 Rack upgrade kit Pos. Qty. d&b Code Description Z4010 d&b DS10 Audio network bridge. Including: Z2610.130 Power cord (powerCON/ powerCON. Used to connect the device to auxiliary powerCON socket at the rear of the mains distributor. E7500.024 AES/EBU XLR cable.
-
Page 7: Technical Specifications
LED indicator red SUBSCRIBED (RX Subscription) LED indicator green Dimensions and weight Height x width x depth 1 RU x 19" x 232 mm 1 RU x 19" x 9.1" Weight 3.75 kg / 8.26 lb d&b DS10 Manual 1.5 en... -
Page 8: Startup
Refer to Þ Chapter 3.5.2. "DIGITAL Refer to Þ Chapter 3.5.1. "ETH 5/ Refer toÞ Chapter 3.3. "Mains OUT 5 – 16" on page 13. connection" on page 9. MODE ETH 3" on page 13. d&b DS10 Manual 1.5 en... -
Page 9: Rack Mounting
A powerCON ® mains connector socket [7] is fitted on the rear panel and an appropriate power cord [2] is supplied. d&b DS10 Manual 1.5 en... -
Page 10: Front Panel
9-12 and 13-16 as shown in the graphic opposite. In “BYPASS” mode, the network switch is still fully operative (for example for use in control traffic), and the DS10 is shown in Dante Controller. However, no Dante routing is allowed from or into the device, and the device does not participate in the Dante master clock algorithm (i.e., it cannot act as Clock Master). -
Page 11: Eth1 - Eth4
3.4.4. ETH1 - ETH4 The DS10 provides a 5-port Ethernet switch for different network topologies, redundancy and advanced functions. Four connectors (ETH1 - ETH4) are provided on the front panel while a fifth port (ETH 5) is provided on the rear panel. -
Page 12: Sync Error/Subscribed
Dante Controller, the SYNC ERROR LED will flash rapidly for 2 seconds. This allows you to physically identify each DS10 when there is more than one device on the network (for more details, please refer to the Dante Controller User Guide). -
Page 13: Rear Panel
AES channels to be used if more than four AES channels are required. 3.6. Meta data The DS10 sends meta data (Dante channel labels, cabling information...) via the AES3 outputs alongside the digital audio samples, using the AES3 User bits. -
Page 14: Rack Connections
2. Connect the two digital outputs at the front of the DS10 to the digital inputs D1/2 and D3/4 of the I/O panel. 3. Connect the ETH 3 port of the DS10 to the ETH 1 port of the I/O panel in order to bridge the R1 control for the amplifiers over the Dante network. -
Page 15: Application Examples
5. Application examples In the following sections some example network topologies are described, each with the recommended DS10 switch modes. These examples are for illustration purposes only, and do not aim to cover every possible application, nor describe comprehensive PA Systems. -
Page 16: Redundant
If one fails, audio will continue to pass without any kind of interruption on the other network. Note: For remote control, applicable d&b amplifiers will normally be connected to the Primary network. Redundant control of applicable d&b amplifiers is not supported. d&b DS10 Manual 1.5 en... -
Page 17: Foh
Switch mode configuration: "Switched". The DS10 can also be used as a break-in box with a maximum of four AES3 Input channels per DS10 (additional DS10 can be used, if more channels are required at the FoH). A star wired configuration is shown below, but the same principles apply to a Redundant configuration. -
Page 18: Wireless Control With External Switches
However, this can also filter out some desired multicast traffic, such as mDNS (aka Bonjour), which is required by R1 V2 in order to detect applicable d&b amplifiers on the network. d&b DS10 Manual 1.5 en... -
Page 19: Wireless Control Without External Switches
IGMP Snooping. Switch mode configuration: The DS10 in the left and central Touring racks are set to "Redundant" and the DS10 in right Touring rack is set to "Redundant + Multicast Filter" mode. -
Page 20: Ds10 Firmware Update
NOTICE! Only use firmware files provided by d&b. Using firmware files not provided by d&b can result in the DS10 becoming unusable. Firmware update files are provided by d&b at www.dbaudio.com. We recommend you to regularly check the d&b website for the latest firmware version together with the update procedure instructions. -
Page 21: Manufacturer's Declarations
7.1. EU declaration of conformity (CE symbol) This declaration applies to: d&b DS10, Z4010 All products of type DS10 starting from variant Z4010 .000 are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications. - Page 22 www.dbaudio.com...
