Read this manual carefully before operating this vehicle. OWNER’S MANUAL FJR1300AS 2D2-28199-E3...
Page 2
Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. DECLARATION of CONFORMITY Company: YAMAHA MOTOR ELECTRONICS CO., LTD. Address: 1450-6, Mori, Mori-Machi, Shuchi-gun, Shizuoka-Ken, 437-0292 Japan Hereby declare that the product:...
Page 3
Yamaha a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your FJR1300AS. The Owner’s Manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.
IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
TABLE OF CONTENTS SAFETY INFORMATION ....1-1 Accessory box ......3-27 General maintenance and Adjusting the headlight beams ..3-27 lubrication chart ......6-3 DESCRIPTION ........2-1 Handlebar position ....... 3-28 Removing and installing panels ..6-7 Left view ..........2-1 Opening and closing the Checking the spark plugs ....
Page 7
TABLE OF CONTENTS Checking and lubricating the centerstand and sidestand ..6-25 Lubricating the swingarm pivots ...6-26 Lubricating the rear suspension ...6-26 Checking the front fork ....6-27 Checking the steering ....6-27 Checking the wheel bearings ..6-28 Battery ..........6-28 Replacing the fuses ......6-29 Headlight bulb ......6-31 Front turn signal light ....6-31 Replacing a rear turn signal light...
SAFETY INFORMATION EAU10283 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly...
Page 9
SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective apparel...
Page 10
Yamaha accessories, which are avail- of the motorcycle is changed. To avoid to minimize imbalance or instabili- able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved treme caution when adding cargo or Shifting weights can create a sud- by Yamaha for use on your vehicle.
• Accessories fitted to the handle- Use caution when adding electri- genuine Yamaha accessories, recog- bar or the front fork area can cal accessories. If electrical acces- nize that some aftermarket accessories...
Immobilizer system This is not an automatic transmission, This vehicle features the YCC-S only the clutch system is automatic. (Yamaha Chip Controlled-Shift) sys- The gears must be shifted by the rider. tem. The basic function of this system allows the rider to shift gears without the use of a clutch lever.
Page 16
Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.
INSTRUMENT AND CONTROL FUNCTIONS EAU10471 EAU26811 To lock the steering Main switch/steering lock All electrical circuits are supplied with power; the meter lighting, taillights, li- cense plate light and auxiliary lights come on, and the engine can be start- ed. The key cannot be removed. The headlights come on automatically when the engine is started and stay on until the key is turned to “OFF”.
INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering ECA11020 EAU11003 Indicator and warning lights NOTICE Do not use the parking position for an extended length of time, other- wise the battery may discharge. 1. Push. 1. Left turn signal indicator light “ ”...
Page 19
Stop the vehicle when it is safe to do so, Even if the oil level is sufficient, the curs, have a Yamaha dealer check the and park it away from traffic. Have a warning light may flicker when riding on self-diagnosis system.
Page 20
ABS may not work cor- Yamaha dealer check the electrical cir- then while rotating the rear wheel, push rectly. If this occurs, have a Yamaha cuit. the shift pedal rod and pivot forward un- til the transmission is in the neutral po- dealer check the system as soon as When the key is turned to “OFF”...
INSTRUMENT AND CONTROL FUNCTIONS EAU11601 EAU11872 EAU40537 Speedometer Tachometer Multi-function display 1. Tachometer 1. Tachometer 1. Multi-function display 2. Speedometer 2. Tachometer red zone 2. Select button 3. Multi-function display 3. Reset button The electric tachometer allows the rider The speedometer shows the riding EWA14431 to monitor the engine speed and keep it WARNING...
Page 22
INSTRUMENT AND CONTROL FUNCTIONS a fuel reserve tripmeter (which Odometer and tripmeter modes case, pushing the select button switch- shows the distance traveled on the es the display between the various trip- fuel reserve) meter and odometer modes in the a clock following order: Trip F →...
Page 23
INSTRUMENT AND CONTROL FUNCTIONS Clock Fuel meter play segments will start flashing. If this occurs, have a Yamaha dealer check the electrical circuit. Coolant temperature meter 1. Clock 1. Fuel meter 2. Select button The fuel meter indicates the amount of 3.
Page 24
INSTRUMENT AND CONTROL FUNCTIONS ECA10021 Ambient temperature, instanta- Ambient temperature mode NOTICE neous fuel consumption and aver- fuel consumption modes Do not continue to operate the en- (except for the UK) gine if it is overheating. Transmission gear display 1. Ambient temperature This display shows the ambient tem- perature from –9 °C to 50 °C in 1 °C in- 1.
Page 25
INSTRUMENT AND CONTROL FUNCTIONS The accuracy of the temperature When the display is set to “L/100 The average fuel consumption display reading may be affected when km”, the amount of fuel necessary can be set to either “AV_ _._ km/L” or riding slowly (approximately under to travel 100 km under the current “AV_ _._ L/100 km”.
Page 26
50 °C will not be displayed. If there is a malfunction, “– –.–” will Air → MPG → AV_ _._ MPG → Air The accuracy of the temperature be displayed. Have a Yamaha dealer reading may be affected when check the vehicle. Ambient temperature mode riding slowly [approximately under 20 km/h (12.5 mi/h)] or when...
Page 27
When the average fuel consumption such an error code, note the code num- mode is selected, the display flashes ber, and then have a Yamaha dealer for five seconds, and then “AV_ _._ check the vehicle. MPG” (average distance that can be traveled using 1.0 Imp.gal of fuel) is...
If the multi-function display indicates error code when the key is turned to any error codes, note the code number, “ON”. and then have a Yamaha dealer check the vehicle. If the multi-function display indicates er- ror code 52, this could be caused by transponder interference.
INSTRUMENT AND CONTROL FUNCTIONS EAU12347 Right position. To cancel the turn signal Handlebar switches lights, push the switch in after it has re- turned to the center position. Left EAU12493 Windshield position adjusting switch “ ” To move the windshield up, push this switch in direction (a).
Page 30
INSTRUMENT AND CONTROL FUNCTIONS EAU12500 EAU12733 EAU40381 Horn switch “ ” Hazard switch “ ” Hand shift control switch Press this switch to sound the horn. With the key in the “ON” or “ ” posi- tion, use this switch to turn on the haz- EAU12660 ard lights (simultaneous flashing of all Engine stop switch “...
INSTRUMENT AND CONTROL FUNCTIONS and release this switch after start- EAU40493 Shift pedal ing the engine to enable hand shifting. 1. Shift pedal 2. Bolt 1. Shift pedal 3. Standard position This vehicle is equipped with a con- 2. Move the shift pedal to the desired stant-mesh 5-speed transmission.
INSTRUMENT AND CONTROL FUNCTIONS EAU40481 EAU26823 EAU39540 Hand shift lever “ ”/“ ” Brake lever Brake pedal The brake lever is located at the right handlebar grip. To apply the front brake, pull the lever toward the handle- bar grip. 1.
INSTRUMENT AND CONTROL FUNCTIONS EAU39531 al are even slightly applied, a vi- bration can be felt at the lever and The Yamaha ABS (Anti-lock Brake pedal, but these do not indicate a System) features a dual electronic con- malfunction. trol system, which acts on the front and When the ABS is activated, the rear brakes independently.
INSTRUMENT AND CONTROL FUNCTIONS EAU13074 EAU13221 Fuel tank cap Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10881 WARNING not properly closed and locked.
Page 35
EWA15151 WARNING as well as to the exhaust system. Gasoline is poisonous and can Your Yamaha engine has been de- cause injury or death. Handle gaso- signed to use regular unleaded gaso- line with care. Never siphon gaso- line with a research octane number of line by mouth.
INSTRUMENT AND CONTROL FUNCTIONS EAU39451 EAU13445 ECA10701 Fuel tank breather/overflow Catalytic converters NOTICE hose This vehicle is equipped with catalytic Use only unleaded gasoline. The use converters in the exhaust system. of leaded gasoline will cause unre- EWA10862 pairable damage to the catalytic WARNING converter.
INSTRUMENT AND CONTROL FUNCTIONS EAU39492 To install the passenger seat Seats 1. Insert the projections on the rear of the passenger seat into the seat Passenger seat holders as shown, and then push the front of the seat down to lock it To remove the passenger seat in place.
INSTRUMENT AND CONTROL FUNCTIONS 2. Install the passenger seat. EAU39632 Adjusting the rider seat height The rider seat height can be adjusted to Make sure that the seats are prop- one of two positions to suit the rider’s erly secured before riding. preference.
Page 39
INSTRUMENT AND CONTROL FUNCTIONS 6. Align the projection on the bottom of the rider seat with the “H” posi- tion slot, and then push the rear of the seat down to lock it in place as shown. 1. Rider seat height position adjuster 1.
208 kg (459 lb) for the ve- tion slot, and then push the rear of hicle. the seat down to lock it in place as shown. 1. Storage compartment 2. Yamaha CYCLELOK (optional) This storage compartment is designed 1. “L” position slot hold genuine Yamaha CYCLELOK.
INSTRUMENT AND CONTROL FUNCTIONS EAU39480 2. Remove the key. EAU39611 Accessory box Adjusting the headlight ECA11800 The accessory box is located beside beams NOTICE the meter panel. The headlight beam adjusting knobs Do not place heat-sensitive items in are used to raise or lower the height of the accessory box.
The handlebars can be adjusted to one ings of three positions to suit the rider’s pref- The cowlings can be tilted back 30 mm erence. Have a Yamaha dealer adjust (1.18 in) for added ventilation to suit the the position of the handlebars. riding conditions.
INSTRUMENT AND CONTROL FUNCTIONS EAU39671 EAU14732 Rear view mirrors Adjusting the front fork The rear view mirrors of this vehicle can EWA10180 WARNING be folded forward or backward for park- ing in narrow spaces. Fold the mirrors Always adjust both fork legs equal- back to their original position before ly, otherwise poor handling and loss riding.
Page 44
INSTRUMENT AND CONTROL FUNCTIONS To increase the spring preload and Rebound damping force Compression damping force thereby harden the suspension, turn the adjusting bolt on each fork leg in di- rection (a). To decrease the spring pre- load thereby soften suspension, turn the adjusting bolt on each fork leg in direction (b).
INSTRUMENT AND CONTROL FUNCTIONS EAU14914 For riding solo, move the spring preload Adjusting the shock absorber adjusting lever in direction (b). For Although the total number of clicks of a assembly riding with a passenger, move the damping force adjusting mechanism This shock absorber assembly is spring preload adjusting lever in direc- may not exactly match the above spec-...
Take the shock the grip warmer adjusting knob of clicks or turns of the damping force absorber assembly to a Yamaha to the “HI” position. adjusting mechanism. This adjustment dealer for any service.
INSTRUMENT AND CONTROL FUNCTIONS EAU15301 below and have a Yamaha dealer re- Sidestand pair it if it does not function proper- The sidestand is located on the left side of the frame. Raise the sidestand or lower it with your foot while holding the vehicle upright.
INSTRUMENT AND CONTROL FUNCTIONS EAU40524 Ignition circuit cut-off system The ignition circuit cut-off system (com- prising the sidestand switch and brake light switches) has the following func- tions. It prevents starting when the side- stand is up, but neither brake is ap- plied.
Page 49
• 3. Turn the key on. If a malfunction is noted, have a Yamaha 4. Shift the transmission into the neutral position. dealer check the system before riding. 5. Keep the front or rear brake applied.
INSTRUMENT AND CONTROL FUNCTIONS EAU39652 Auxiliary DC jack ECA15430 NOTICE The accessory connected to the auxiliary DC jack should not be used with the engine turned off, and the load must never exceed 30 W (2.5 A), otherwise the battery may dis- charge.
• If necessary, add recommended coolant to specified level. 6-15 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
Page 52
• Make sure that operation is smooth. • Check cable free play. Throttle grip 6-17, 6-24 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-24 •...
Page 53
FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE • Check operation of ignition circuit cut-off system. Sidestand switch 3-33 • If system is not working correctly, have Yamaha dealer check vehicle.
(see page 5-2) with the front or rear brake applied. The neutral indicator light should come on. If not, ask a Yamaha dealer to check the electrical circuit. 3. Start the engine by pushing the start switch. NOTICE: For maxi-...
OPERATION AND IMPORTANT RIDING POINTS The gears can be shifted using either Always return the throttle to the EAU16810 Tips for reducing fuel con- the shift pedal or the hand shift lever. closed position while changing sumption The hand shift lever has to be enabled gears to avoid damaging the en- Fuel consumption depends largely on by pressing the hand shift control...
When the en- period, immediately have a result in engine overheating must be gine stop switch has been used Yamaha dealer check the vehi- avoided. in an emergency, be sure to ap- cle. ply the front or rear brake while...
Page 58
OPERATION AND IMPORTANT RIDING POINTS Do not park on a slope or on soft ground, otherwise the vehicle may overturn, increasing the risk of a fuel leak and fire. Do not park near grass or other flammable materials which might catch fire.
If If you do not have the tools or experi- you are not familiar with vehicle ser- ence required for a particular job, have vice, have a Yamaha dealer perform a Yamaha dealer perform it for you. service.
From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
PERIODIC MAINTENANCE AND ADJUSTMENT EAU1770B General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ √...
Page 62
PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check bearing play and steering √ √...
Page 63
PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Engine oil filter car- √ √ √ •...
Page 64
PERIODIC MAINTENANCE AND ADJUSTMENT • Every two years replace the internal components of the brake master cylinders and calipers as well as YCC-S clutch master and release cylinders, and change the brake and YCC-S clutch fluids. • Replace the brake and YCC-S clutch hoses every four years and if cracked or damaged.
PERIODIC MAINTENANCE AND ADJUSTMENT EAU18771 Removing and installing pan- The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1.
Page 66
PERIODIC MAINTENANCE AND ADJUSTMENT 3. Pull the bottom of the panel out- ward, pull the front of the panel downward, and then slide the pan- el forward to release it in the rear as shown. 1. Panel B 1. Panel B 2.
Page 67
PERIODIC MAINTENANCE AND ADJUSTMENT 1. Panel C 1. Panel B 1. Panel B 2. Rear cowling 1. Panel C 1. Panel C 1. Panel B 2. Rear cowling 2. Fuel tank side cover To install the panel 1. Insert the rear of the panel into the 2.
0.7–0.8 mm (0.028–0.031 in) such problems yourself. Instead, have 1. Panel C a Yamaha dealer check the vehicle. Clean the surface of the spark plug 3. Install the bolts and the quick fas- If a spark plug shows signs of electrode gasket and its mating surface, and then tener screws.
PERIODIC MAINTENANCE AND ADJUSTMENT EAU19885 Tightening torque: Engine oil and oil filter car- Spark plug: tridge 12.5 Nm (1.25 m·kgf, 9.0 ft·lbf) The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- If a torque wrench is not available when tridge replaced at the intervals speci- installing a spark plug, a good estimate...
Page 70
An oil filter wrench is available at a 2. Oil filter cartridge seated. 3. Engine oil drain bolt Yamaha dealer. 7. Install the new oil filter cartridge, 6. Apply a thin coat of clean engine and then tighten it to the specified oil to the O-ring of the new oil filter torque with a torque wrench.
Page 71
If the oil level warning light flickers 3.80 L (4.02 US qt, 3.34 Imp.qt) or remains on, immediately turn the With oil filter cartridge replacement: engine off and have a Yamaha dealer 4.00 L (4.23 US qt, 3.52 Imp.qt) check the vehicle. 6-13...
The final gear case must be checked necessary. final gear case. for oil leakage before each ride. If any leakage is found, have a Yamaha deal- The oil level should be at the brim of the er check and repair the vehicle. In addi- filler hole.
PERIODIC MAINTENANCE AND ADJUSTMENT 6. Install the oil filler bolt, and then EAU20070 Tightening torque: Coolant tighten it to the specified torque. Final gear oil filler bolt: The coolant level should be checked 23 Nm (2.3 m·kgf, 17 ft·lbf) before each ride. In addition, the cool- Tightening torque: ant must be changed at the intervals Final gear oil filler bolt:...
Page 74
Have a hot. NOTICE: If coolant is [EWA15161] Yamaha dealer change the coolant. not available, use distilled water WARNING! Never attempt to remove or soft tap water instead. Do not the radiator cap when the engine is use hard water or salt water hot.
Check the engine idling speed and, if the periodic maintenance and lubrica- necessary, have it corrected by a tion chart. Have a Yamaha dealer clean Yamaha dealer. or replace the air filter element. Engine idling speed: 1000–1100 r/min...
270 kPa (2.70 kgf/cm², 39 psi) Rear: from occurring, the valve clearance regarding the specified tires. 290 kPa (2.90 kgf/cm², 42 psi) must be adjusted by a Yamaha dealer 90–208 kg (198–459 lb): at the intervals specified in the periodic Tire air pressure Front: maintenance and lubrication chart.
Page 77
Tire information glass fragments in it, or if the sidewall is high-speed ride. cracked, have a Yamaha dealer re- After extensive tests, only the tires list- place the tire immediately. ed below have been approved for this model by Yamaha Motor Co., Ltd.
Always adjust the tire air pres- 180/55 ZR17M/C (73W) fore each ride. If any damage is Manufacturer/model: sure according to the operating found, have a Yamaha dealer re- METZELER/Roadtec Z6C conditions. BRIDGESTONE/BT021R F place the wheel. Do not attempt FRONT and REAR:...
If neces- checked for wear at the intervals spec- check the hydraulic system for leakage sary, have a Yamaha dealer adjust the ified in the periodic maintenance and before each ride. If the YCC-S clutch brake light switch.
PERIODIC MAINTENANCE AND ADJUSTMENT cator groove has almost disappeared, EAU40591 YCC-S clutch Checking the brake and have a Yamaha dealer replace the YCC-S clutch fluid levels brake pads as a set. Front brake EAU22500 Rear brake pads 1. Minimum level mark...
YCC-S clutch fluids 6-7.) stalling them. Have a Yamaha dealer change the Be careful that water or dust does Observe these precautions: brake and YCC-S clutch fluids at the in- not enter the brake and YCC-S...
If a cable is damaged maintenance chart. or does not move smoothly, have a Yamaha dealer check or replace it. WARNING! Damage to the outer sheath may interfere with proper ca- ble operation and will cause the in- cable rust.
Silicone grease WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground and distract the operator, resulting in a possible loss of control.
PERIODIC MAINTENANCE AND ADJUSTMENT EAUM1650 EAU23250 Recommended lubricant: Lubricating the swingarm piv- Lubricating the rear suspen- Lithium-soap-based grease sion The swingarm pivots must be lubricat- The pivoting points of the rear suspen- ed at the intervals specified in the peri- sion must be lubricated at the intervals odic maintenance and lubrication chart.
2. Hold the lower ends of the front fork does not operate smoothly, tion. WARNING! To avoid injury, fork legs and try to move them for- have a Yamaha dealer check or re- securely support the vehicle so ward and backward. If any free pair it.
WARNING Electrolyte is poisonous and To charge the battery dangerous since it contains sul- Have a Yamaha dealer charge the bat- furic acid, which causes severe tery as soon as possible if it seems to burns. Avoid any contact with have discharged.
NOTICE you do not have access to a con- stant-voltage battery charger, have a Always keep the battery charged. Yamaha dealer charge your battery. Storing a discharged battery can cause permanent battery damage. 1. Main fuse To store the battery 2.
Page 88
PERIODIC MAINTENANCE AND ADJUSTMENT 2. Remove the blown fuse, and then Specified fuses: install a new fuse of the specified Main fuse: amperage. WARNING! Do not 50.0 A Headlight fuse: use a fuse of a higher amperage 25.0 A rating than recommended to Signaling system fuse: avoid causing extensive dam- 15.0 A...
If a headlight does not come on, have a If a front turn signal light does not come check the electrical system. Yamaha dealer check its electrical cir- on, have a Yamaha dealer check its cuit or replace the bulb. electrical circuit or replace the bulb. ECA16580...
PERIODIC MAINTENANCE AND ADJUSTMENT EAU27003 6. Install the passenger seat. EAU24312 Replacing a rear turn signal Replacing the license plate light bulb or a tail/brake light light bulb bulb 1. Remove the license plate light unit by removing the screws. 1.
The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.
Page 92
PERIODIC MAINTENANCE AND ADJUSTMENT heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or property damage. 6-34...
Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
Page 94
Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.
Rust and corrosion can develop matte colored finished parts. Be ECA10772 even if high-quality components are sure to consult a Yamaha dealer for NOTICE advice on what products to use be- used. A rusty exhaust pipe may go un- Avoid using strong acidic wheel fore cleaning the vehicle.
Page 96
MOTORCYCLE CARE AND STORAGE off any detergent residue using Test the product on a small hid- plenty of water, as it is harmful den part of the windshield to Salt sprayed on roads in the winter may to plastic parts. make sure that it does not leave remain well into spring.
WARNING To prevent corrosion, avoid Contaminants on the brakes or tires Consult a Yamaha dealer for ad- damp cellars, stables (because vice on what products to use. can cause loss of control. of the presence of ammonia)
Page 98
MOTORCYCLE CARE AND STORAGE 3. Perform the following steps to pro- 4. Lubricate all control cables and the tect the cylinders, piston rings, etc. pivoting points of all levers and from corrosion. pedals as well as of the side- a. Remove the spark plug caps stand/centerstand.
Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
Page 103
The model label is affixed to the frame under the passenger seat. (See page 3-23.) Record the information on this la- bel in the space provided. This informa- tion will be needed when ordering spare parts from a Yamaha dealer.
Page 104
INDEX Engine trouble/YCC-S indicators and warning light ......... 3-5 ABS............3-19 License plate light bulb, replacing ..6-32 ABS warning light........3-6 Accessory box........3-27 Final gear oil ......... 6-14 Main switch/steering lock ......3-3 Air filter element ........6-17 Front and rear brake pads, checking..
