Summary of Contents for Siemens SINUMERIK ONE KB 1500
Page 1
Introduction Fundamental safety instructions Description SINUMERIK Operating and display elements SINUMERIK ONE Full CNC keyboards: KB 1500 and Interfaces KB 1900 Dimension drawings Equipment Manual Service and maintenance Technical specifications Accessories Valid for: Control system SINUMERIK ONE SINUMERIK 840D sl/840DE sl 09/2022 A5E52185085B AB...
Page 2
Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
Table of contents Introduction ............................5 About SINUMERIK ........................ 5 About this documentation ....................5 Documentation on the internet .................... 6 1.3.1 Documentation overview SINUMERIK operator components ..........6 Feedback on the technical documentation ................6 mySupport documentation ....................7 Service and Support......................
Page 4
Table of contents Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
– SINUMERIK is the highly dynamic automation solution, integrated for all areas of production. From prototype construction and tool design to mold making, all the way to large-scale series production. Visit our website for more information SINUMERIK (https://www.siemens.com/sinumerik). About this documentation Validity This Equipment Manual handles full CNC keyboards KB 1500 and KB 1900.
This document may contain hyperlinks to third-party websites. Siemens is not responsible for and shall not be liable for these websites and their content. Siemens has no control over the information which appears on these websites and is not responsible for the content and information provided there.
With the "mySupport documentation" web-based system you can compile your own individual documentation based on Siemens content, and adapt it for your own machine documentation. To start the application, click on the "My Documentation" tile on the mySupport homepage (https://support.industry.siemens.com/cs/ww/en/my):...
Page 8
Siemens support on the go With the award-winning "Siemens Industry Online Support" app, you can access more than 300,000 documents for Siemens Industry products – any time and from anywhere. The app can support you in areas including: • Resolving problems when implementing a project •...
• OpenSSL (https://www.openssl.org) • Cryptsoft (https://www.cryptsoft.com) Compliance with the General Data Protection Regulation Siemens observes standard data protection principles, in particular the data minimization rules (privacy by design). For this product, this means: The product does not process or store any personal data, only technical function data (e.g. time stamps).
Page 10
Introduction 1.7 Important product information Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
Fundamental safety instructions General safety instructions WARNING Electric shock and danger to life due to other energy sources Touching live components can result in death or severe injury. • Only work on electrical devices when you are qualified for this job. •...
Page 12
Fundamental safety instructions 2.1 General safety instructions WARNING Electric shock due to equipment damage Improper handling may cause damage to equipment. For damaged devices, hazardous voltages can be present at the enclosure or at exposed components; if touched, this can result in death or severe injury.
Page 13
• Therefore, if you move closer than 20 cm to the components, be sure to switch off radio devices, cellphones or WLAN devices. • Use the "SIEMENS Industry Online Support app" only on equipment that has already been switched off.
Page 14
Fundamental safety instructions 2.1 General safety instructions NOTICE Overheating due to inadmissible mounting position The device may overheat and therefore be damaged if mounted in an inadmissible position. • Only operate the device in admissible mounting positions. WARNING Unexpected movement of machines caused by inactive safety functions Inactive or non-adapted safety functions can trigger unexpected machine movements that may result in serious injury or death.
Security information Siemens provides products and solutions with industrial security functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement –...
Page 16
Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber...
Fundamental safety instructions 2.5 Residual risks of power drive systems Residual risks of power drive systems When assessing the machine- or system-related risk in accordance with the respective local regulations (e.g., EC Machinery Directive), the machine manufacturer or system installer must take into account the following residual risks emanating from the control and drive components of a drive system: 1.
Page 18
Fundamental safety instructions 2.5 Residual risks of power drive systems Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
Description SINUMERIK full CNC keyboards KB 1500 and KB 1900 facilitate user-friendly input of programs and text. It is fitted with short-stroke keys. The key layout is predefined and cannot be modified, i.e. the key covers cannot be transposed. The keyboard is secured from the rear using special clamps supplied with the panel. Validity The following description applies to the components: Designation...
Page 20
Description Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
Operating and display elements Key assignments ① KB 1500 ② KB 1900 Figure 4-1 Key layout of full CNC keyboards KB 1500 and KB 1900 Note that the following keys on the KB 1500/ 1900 always correspond to the left-hand keys on the standard keyboard: Shift, Ctrl, Alt The key functions of the SINUMERIK keyboard depend on the used operating software and...
Page 22
Operating and display elements Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
Interfaces ① USB upstream port X125 ② Protective conductor connection, threaded bolts M5 Figure 5-1 Rear side, diagram showing the KB 1900 as example The protective conductor connection must be in compliance with national regulations. As a minimum, the cross-section required is the cross-section of the line feeder cable of the assigned devices.
Page 24
Interfaces Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
Dimension drawings Dimension drawings KB 1500 Dimension drawing Device mounting depth without taking into account the mounting clamps. As a result of the clamps, the mounting depth can increase depending on the mounting plate thickness. Mounting the panel with clamping elements provided in the device accessory pack at the openings provided in the frame Figure 6-1 Dimension drawing for installing the full CNC keyboard KB 1500...
Page 26
Dimension drawings 6.1 Dimension drawings KB 1500 Panel cutout ① All corner radii R5 or 5x45° chamfer Figure 6-2 Panel cutout for full CNC keyboard KB 1500 (sheet metal thickness 1.5 - 6.0 mm) Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
Dimension drawings 6.2 Dimension drawings KB 1900 Dimension drawings KB 1900 Dimension drawing Device mounting depth without taking into account the mounting clamps. As a result of the clamps, the mounting depth can increase depending on the mounting plate thickness. Mounting the panel with clamping elements provided in the device accessory pack at the openings provided in the frame Figure 6-3...
Page 28
Dimension drawings 6.2 Dimension drawings KB 1900 Panel cutout ① All corner radii R5 or 5x45° chamfer Figure 6-4 Panel cutout for full CNC keyboard KB 1900 (sheet metal thickness 1.5 - 6.0 mm) Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
Service and maintenance Cleaning the device Use a soft cloth moistened either with water or a mild cleaning agent to clean the housing and operator controls of the device. Note Switch the device off for cleaning Clean the device only when it is switched off. This way, you ensure that you cannot unintentionally trigger any functions by touching the keys.
Page 30
Service and maintenance Suspected malfunction If you suspect a malfunction due to unusual product reactions, isolate the device from power. Immediately inform qualified personnel to check the function and ensure that the product functions correctly. The following signs can indicate a malfunction: •...
Technical specifications KB 1500 KB 1900 Safety Protective class according to EN 50178 III; PELV Degree of protection according to EN Front: IP 65 60529 Rear: IP00 Approvals CE / UL / EAC Flame resistance UL 94 V-1 UL identifier MCPS2103-398135E-064000 MCPS2104-464135E-064000 0AA0...
Technical specifications 8.2 Standards and approvals KB 1500 KB 1900 Classification of the mechanical environ‐ Class 3M2 according to EN 60721-3-3 ment Vibratory load during operation Frequency range: 10 – 200 Hz Deflection at 9 – 18 Hz: 1.5 mm Acceleration at 18 –...
The products comply with the China RoHs regulation. Further information can be found on the Internet at the following link: SIOS (https:// support.industry.siemens.com/cs/document/109773373/ccc-fm?dti=0&lc=en-US) Recycling and disposal For environmentally friendly recycling and disposal of your old equipment, please contact a company certified for the disposal of waste electrical and electronic equipment and dispose of the equipment in accordance with the regulations in your country.
Page 34
Technical specifications 8.3 Recycling and disposal Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
Accessories Set of tension jacks Component Description Quanti‐ Article number Set of tension jacks For supplementary operator com‐ Set of 9 6FC5248-0AF14-0AA0 ponents with 2.5 mm profile, length: 20 mm Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
Page 36
Accessories Full CNC keyboards: KB 1500 and KB 1900 Equipment Manual, 09/2022, A5E52185085B AB...
