Page 2
Copyright Notice This document is copyrighted, 2019. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.
Page 3
Acknowledgement All other products’ name or trademarks are properties of their respective owners. Microsoft Windows is a registered trademark of Microsoft Corp. Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel Corporation Core, Atom are trademarks of Intel Corporation ...
Page 4
Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity FWS-2273 SATA cable SATA power cable Power adapter Rubber foot If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
Page 5
About this Document This User’s Manual contains all the essential information, such as detailed descriptions and explanations on the product’s hardware and software features (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the AAEON.com for the latest version of this document.
Page 6
Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. All cables and adapters supplied by AAEON are certified and in accordance with the material safety laws and regulations of the country of sale.
Page 7
As most electronic components are sensitive to static electrical charge, be sure to ground yourself to prevent static charge when installing the internal components. Use a grounding wrist strap and contain all electronic components in any static-shielded containers. If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii.
Page 8
FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Caution: There is a danger of explosion if the battery is incorrectly replaced.
Page 10
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products AAEON Embedded Box PC/ Industrial System Poisonous or Hazardous Substances or Elements Hexavalent Polybrominated Polybrominated Component Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...
Specifications System Desktop Network Appliance Form Factor Intel® Celeron® N3350 Processor SoC Processor Intel® Celeron® N3350 Processor SoC Chipset 204-pin DDR3L SODIMM x 1, up to 8GB System Memory Network Ethernet Intel® i211, Gigabit Ethernet x 4 Intel® i210, SFP Bypass Supports up to 2 pairs bypass function Display...
Page 15
Internal/ Expansion Interface PCIe Slot — Mini-PCIe Slot Mini-Card socket (full-size) with SIM socket x 2 KB Mouse Reserve pin-header USB 3.0 x 2 Miscellaneous Internal RTC Watchdog Timer 1~255 steps by software programmable (TPM v1.2 9660/TPM2.0 9665 Optional) GPIO Reserve internal pin header 8-bit Digital I/O interface (4-in /4-out) Fanless, reserved pin header for system fan...
Page 16
Environmental Parameters and Dimension 12V DC Power in connector Power Requirement 32°F ~ 104°F (0°C ~ 40°C ) Operating Temperature -4°F ~ 140°F (-20°C ~ 60°C) Storage Temperature 10%~80% relative humidity, non-condensing Operating Humidity 10%~80% @40°C; non-condensing Storage Humidity 0.5 Grms/ 5 ~ 500Hz / operation (2.5" HDD) Vibration 1.5 Grms/ 5 ~ 500Hz / non operation 10 G peak acceleration (11 m sec.
List of Jumpers Please refer to the table below for all of the board’s jumpers that you can configure for your application Label Function CF POWER Selection Auto PWRBTN Selection CMOS Setting Selection Chapter 2 – Hardware Information...
2.3.1 CFD Voltage 3.3V/5V Selection (JP1) 3.3V (Default) 2.3.2 Auto PWRBTN Selection (JP2) Don’t use Auto PWRBTN (Default) Use Auto PWRBTN 2.3.3 CMOS Setting Selection (CN1) Normal (Default) Clear CMOS Chapter 2 – Hardware Information...
List of Connectors Please refer to the table below for all of the board’s connectors that you can configure for your application Label Function DIMM1 DDR3L SODIMM SOCKET CPU_FAN1 4P SMART FAN CON1 COM PORT CN12 SATA6G INTERFACE SATA POWER CN13 Mini PCIe socket (Only USB2.0) CN30...
Page 25
LED4-LED7 RJ45 LAN Link Stats LED LED9-LED10 SFP LAN Link Stats LED Chapter 2 – Hardware Information...
2.4.1 Digital I/O (CN6) This connector offers 4-pair of digital I/O functions and address is 801H. The pin definitions are illustrated below: Signal Signal Digital- IN/OUT(Port1 Bit 1) Digital- IN/OUT (Port1 Bit 2) Digital- IN/OUT (Port1 Bit 4) Digital- IN/OUT (Port1 Bit 5) Digital- IN/OUT (Port3 Bit 4) Digital- IN/OUT (Port3 Bit 5) Digital- IN/OUT (Port6 Bit 3)
2.5” Hard Disk Drive Installation Loosen the screw and remove the top case from the lower side. Loosen the screw and remove the mother board module. Chapter 2 – Hardware Information...
Page 28
Loosen the four screws and remove the mother board. Put the assembled cushions on the hard disk driver bracket. Chapter 2 – Hardware Information...
Page 29
Lock the HDD onto the cushions with the four screws Chapter 2 – Hardware Information...
Page 30
Connect the SATA cable and power cable into the Hard Disk, and lock in the cable with the cable ties. Connect the SATA cable and the power cable onto the mother board, and lock in the mother board with the four screws. Chapter 2 –...
Page 31
Put the assembled mother board module onto the bottom case, and lock the screw. Put the assembled top case onto the bottom case. Chapter 2 – Hardware Information...
System Test and Initialization These routines test and initialize board hardware. If the routines encounter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal. The system can usually continue the boot up sequence with non-fatal errors.
AMI BIOS Setup The AMI BIOS ROM has a pre-installed Setup program that allows users to modify basic system configurations, which is stored in the battery-backed CMOS RAM and BIOS NVRAM so that the information is retained when the power is turned off. To enter BIOS Setup, press <Del>...
3.4.1 Advanced: Trusted Computing Options summary: Security Device Support Disabled Enabled Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. SHA-1 PCR Bank Disabled Enabled Enable or Disable SHA-1 PCR Bank SHA256 PCR Bank Disabled...
Page 41
Storage Hierarchy Disabled Enabled Enable or Disable Storage Hierarchy Endorsement Hierarchy Disabled Enabled Enable or Disable Endorsement Hierarchy TPM2.0 UEFI Spec Version TCG_1_2 TCG_2 Select the TCG2 Spec Version Support, TCG_1_2: the Compatible mode for Win8/Win10, TCG_2: Support new TCG2 protocol and event format for Win10 or later Physical Presence Spec Version Select to Tell O.S.
3.4.3 Advanced: SATA Drives Options summary : Chipset SATA Disabled Enabled Enables or Disables the Chipset SATA Controller. The Chipset SATA controller supports the 2 black internal SATA ports (up to 3Gb/s supported per port). Chapter 3 – AMI BIOS Setup...
3.4.4 Advanced: USB Configuration Options summary : Legacy USB Support Disabled Enabled Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. Chapter 3 – AMI BIOS Setup...
3.4.5 Advanced: Hardware Monitor Options summary: System Fan Smart Control Disabled Enabled For En/Disable Fan 1 Smart Control. Enabled: FAN is running in accordance with user settings. Disabled: FAN is always running with full speed Fan Control Mode Automatic Mode Manual Mode Manual Mode: Depends on PWM Duty.
Page 46
Full Speed Temperature Temperature Limit Value of FAN Full Speed PWM Slope 5 (1-15) Slope PWM value/Degree C for FAN Speed Control Range:[1-15] Chapter 3 – AMI BIOS Setup...
3.4.6.1 SIO Configuration: Serial Port Configuration Options summary: Use This Device Disabled Enabled Enable or Disable this Logical Device. Possible: Use Automatic Settings IO=2F8h; IRQ=3; IO=3F8h; IRQ=4; Allows user to change Device's Resource settings. New settings will be reflected on This Setup Page after System restarts.
Page 49
3.4.6.1.1 Serial Port Configuration: Serial Port Console Redirection Options summary: Console Redirection Disabled Enabled Console Redirection Enabled or Disabled. Chapter 3 – AMI BIOS Setup...
3.4.6.1.2 Console Redirection Settings Options summary: Terminal Type VT100 VT100+ VT-UTF8 ANSI Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes. Bits per second 9600 19200...
Page 51
Parity None Even Mark Space A parity bit can be sent with the data bits to detect some transmission errors. Even: parity bit is 0 if the num of 1’s in the data bits is even. Odd: parity bit is 0 if num of 1’s in the data bits is odd.
Page 52
The Setting Specify if BootLoader is selected than Legacy console redirection is disabled before booting to Legacy OS. Default value is Always Enable which means Legacy console Redirection is enabled for Legacy OS. Chapter 3 – AMI BIOS Setup...
Page 53
3.4.6.1.3 Serial Port for Out-of-Band Management/Windows Emergency Management Services(EMS) Options summary: Terminal Type VT100 VT100+ VT-UTF8 ANSI VT-UTF8 is the preferred terminal type for out-of-band management. The next best choice is VT100+ and then VT100. See above, in Console Redirection Settings page, for more Help with Terminal Type/Emulation.
Page 54
Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a ‘stop’ signal can be sent to stop the data flow. Once the buffers are empty, a ‘start’ signal can be sent to re-start the flow. Hardware flow control uses two wires to send start/stop signals.
Page 55
3.4.6.1.4 LAN Bypass Configuration Options summary : STATUS LED CTRL LED OFF RED LED ON RED LED BLINK RED LED FAST BLINK GREEN LED ON GREEN LED BLINK GREEN LED FAST BLINK Configure LAN Bypass Status LED. LAN kit Power ON Bypass PassTru Setting LAN kit function behavior when power on.(Bypass/Pass Through)
Page 56
WDT configuration Force Bypass SystemReset Configure WDT behavior , System Reset Force Bypass Chapter 3 – AMI BIOS Setup...
3.4.7 Advanced: Power Management Options summary: Power Mode ATX Type AT Type Select Power Supply Mode. Restore AC Power Loss Power Off Power On Last State Select AC power state when power is re-applied after a power failure. RTC Wake system from S5 Disabled Fixed time Dynamic time...
Page 58
Wake up minute (Fixed time option) 0-59 Wake up second (Fixed time option) 0-59 Wake up minute increase (Dynamic time option) Chapter 3 – AMI BIOS Setup...
3.4.8 Digital IO Port Configuration DIO_P#1~4 Input Output Set DIO as Input or Output DIO_P#5~8 Input Output Set DIO as Input or Output DIO_P#1~4 Direction High Set output level when DIO pin is output Chapter 3 – AMI BIOS Setup...
3.5.1 Chipset: North Bridge Options summary: Primary Display PCIe Select which of IGD/PCI Graphics device should be Primary Display Chapter 3 – AMI BIOS Setup...
Setup submenu: Security Change User/Supervisor Password You can install a Supervisor password, and if you install a supervisor password, you can then install a user password. A user password does not provide access to many of the features in the Setup utility. If you highlight these items and press Enter, a dialog box appears which lets you enter a password.
Driver Installation Please download the driver from AAEON website. It contains all the drivers and utilities you need to setup your product. Follow the steps below to install the drivers. http://www.aaeon.com/en/p/desktop-network-appliance-fws-2273 Step 1 – Open the Step 1 - LAN folder and select the OS folder your system is. Step 2 –...
Introduction to LED FWS-2273 provides a LED indicator which can change the LED status by AAEON SDK. User is able to program the LED status to express different status. Appendix C – Standard LAN Bypass Platform Setting...
C.1.1 Status LED Configuration The LED status indicator of FWS-2273 is programmable with AAEON SDK for your application. Table1: LED Status STA_LED2 STA_LED1 STA_LED0 LED Off Red Blinking (Slowly) Red Blinking (Quickly) Reserved Green Blinking (Slowly) Green Blinking (Quickly) Green Table2: Status LED and register mapping table CPLD Slave Address 0x90 (Note1) Attribute...
C.2 Introduction to LAN Bypass FWS-2273 provides LAN Bypass kit and allow uninterrupted network traffic even if a single in-line appliance is shut down or hangs. Appendix C – Standard LAN Bypass Platform Setting...
C.2.1 LAN Bypass Table1: LAN Kit ID Select LAN_ID2 LAN_ID1 LAN_ID0 LAN kit selected LAN Kit 1 Selected LAN Kit 2 Selected Table2: LAN Bypass register table Function Description LAN_ID3 Use for selecting which LAN kit will be LAN_ID2 configured, refert to Table 1 of ID Select table of LAN kit.
C.3 Introduction to Software Reset Button Configuration FWS-2273 provides a general propose input button which status get by AAEON SDK. Appendix C – Standard LAN Bypass Platform Setting...
C.3.1 Soft Reset Button Configuration Table 2 : LAN Bypass relative register table Function Description Reading this register returns the pin level status which is normal high active low. BTN_STS 0: Pin Level States Low. 1: Pin Level States High. Table 1 : Soft Reset Button register mapping table Attribute Register(I/O)
