HUAWEI DP300 Desktop Presence V500R002C00 User Guide Issue Date 2015-09-15 HUAWEI TECHNOLOGIES CO., LTD.
Page 2
All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope.
About This Document About This Document Overview This guide describes features of the HUAWEI DP300 desktop presence (DP300 or endpoint for short), as well as its routine operations, for example, using the touchscreen to hold, join, or control conferences. In a video conference, users can interact with the videoconferencing system through the DP300 display using the touchscreen or remote control.
Contents About This Document........................ii 1 Safety Precautions.........................1 2 Overview............................7 3 Understanding the Display and Remote Control..............9 4 Powering On the DP300......................13 5 Understanding the UI.........................17 5.1 Understanding the Touchscreen...........................18 5.2 Understanding the Web Interface..........................21 5.3 Understanding the Remote Control Screen........................23 6 Initiating a Conference.......................25...
Page 6
HUAWEI DP300 Desktop Presence User Guide Contents 6.17 Ending or Exiting a Conference..........................49 7 Using the DP300 Display as the PC Monitor.................50 7.1 Switching to the PC Mode............................51 7.2 Answering a Call................................51 7.3 Holding a Call................................51 7.4 Adjusting the Video Position of a Remote Site......................51 A Glossary............................53...
Page 9
Unplug the wireless device from the DP300 and turn off the DP300 close to a high-precision controlled electronic device, such as an audio phone, a pacemaker, fire alarm, or an automatic gate.
Page 10
Huawei WEEE stratagem in the word. Most of the materials in the DP300 are recyclable, and our packaging is designed to be recycled and should be handled in accordance with your local recycling policies.
Page 11
This device must accept any interference received, including interference that may cause undesired operation. If this device is modified without authorization from Huawei, the device may no longer comply with FCC requirements for Class A digital devices. In that a case, your right to use the device may be limited by FCC regulations.
It is ready for video communication as soon as it is powered on and connected to a network. The DP300 is suitable for executive personnel who want to attend video conferences from their offices or conference rooms, as well as home users.
Page 14
The DP300 allows you to share local manuscripts, documents, and books with remote sites in real time, improving communication efficiency. Multi-View The DP300 is able to combine two or more local inputs and share them over one channel with remote participants to reduce network bandwidth. Wireless Data Sharing You can download the air content sharing client from the DP300 web interface.
3 Understanding the Display and Remote Control Understanding the Display and Remote Control Before using the DP300, it is necessary for you to understand the parts on the DP300 display and keys on the DP300 remote control. Display Appearance Figure 3-1...
Page 17
Power button NOTE l For details, see the HUAWEI DP300 Desktop Presence V500R002C00 Quick Installation Guide. l To deliver satisfying conferencing experience consistently, it is recommended that you clean the display (including the lens and text reflector) periodically. For the operation precautions, see 1 Safety Precautions.
DP300 properly. If you power on the DP300 for the first time, connect the power adapter to the power supply and switch the power switch on the right panel to the ON position. Or tap the power button in the lower right corner of the display and power on the DP300 as prompted.
Page 20
Tap the power button in the lower right corner of the display twice or turn the power switch on the right panel to OFF. Placing the DP300 in Sleep Mode in the lower right corner of the display and place the DP300 in sleep mode as prompted. Press on the remote control, select Sleep, and confirm as prompted.
Page 21
4 Powering On the DP300 When the Status Indicator The DP300 Is... Is... Blinking blue twice per second HUAWEI DP300 is being started. Steady blue HUAWEI DP300 is running properly. Blinking blue once every ten HUAWEI DP300 is in sleep state.
Page 22
HUAWEI DP300 Desktop Presence User Guide 4 Powering On the DP300 Touch Button Operation Function Indicator Status Microphone button The local microphone is The indicator blinks muted or unmuted. once. Choose to turn off the The indicator blinks Power button display, hibernate the once.
However, the remote control has buttons corresponding to the menu items. Home Screen After switching to the videoconferencing mode, the DP300 displays the touchscreen shown in Figure 5-1. The buttons available on the main menu are described in Table 5-1.
Page 26
Tap it to end the conference or remove the local site from a conference. NOTE The status icons displayed on the home screen can be customized. For details, see "Customizing Onscreen Status Icons" in the HUAWEI DP300 Desktop Presence V500R002C00 Administrator Guide. Call Screen to display the call screen shown in Figure 5-2.
DP300 web interface is displayed, as shown in Figure 5-3. NOTE You need to enter User name and Password on the login page of the DP300 web interface, which can be obtained from the DP300 administrator. Issue 01 (2015-09-15) Huawei Proprietary and Confidential...
Conferencing Screen After the DP300 switches to the videoconferencing mode, press any key on the remote control to access the conferencing screen. The conferencing screen, as shown in the following figure, appears after the startup. All call operations are completed on the conferencing screen.
See related chapters in HUAWEI DP300 Desktop Presence V500R002C00 Administrator Guide to perform the following operations: l Add participants to the address on the DP300 web interface by referring to section "Managing the Local Address Book". l Register the GK server by referring to section "Setting H.323 Parameters".
Initiating a Multipoint Conference Using the MCU. The following describes the other method and assumes that you want to invite sites A, B, and C to a multipoint conference on a DP300 with a built-in MCU. Step 1 Tap to display the Call screen.
Step 2 In the text box, enter the access code of the conference. Step 3 Tap If the conference is password-protected, the DP300 plays an interactive voice response (IVR), asking you to enter the password. Tap the password input box to display the main menu at the bottom.
Page 37
Control Recording For details about how to use all conference control functions, see section "Controlling a Conference" in the HUAWEI DP300 Desktop Presence V500R002C00 Administrator Guide. User-defined conference control function items can be displayed on the remote control screen, rather than on the touchscreen.
Page 43
After the Lock Conference operation is performed, the DP300 whose built-in MCU is being used can call other endpoints to join the conference, but other endpoints cannot attend the conference by calling that DP300. To enable other endpoints to attend the conference by calling that DP300, perform the Unlock Conference operation.
Prerequisites The endpoint has been connected to the presentation source. Wired connection The video output port of the presentation source is connected to the DP300 VGA IN port using a VGA cable. Air content sharing client (Optional) In the address box, enter the endpoint IP address and press Enter.
Alternatively, ignore the dialog box and watch for the message An air content sharing source device requests to connect to your endpoint. Accept? that will be displayed on the DP300 touch panel UI. When the message is displayed, tap Accept. The client then successfully connects to the endpoint without any passwords.
Step 3 Tap The DP300 automatically scans the wireless microphone. Step 4 Tap and hold the button in the center of the microphone. If this is the first time the microphone is powered on or if the Wi-Fi settings have been changed, tap and hold the button in the center of the microphone for 3 seconds or more.
6.12.1 Selecting a Camera To control a local or remote camera, select the camera first. If the DP300 is not in a conference, you can select only local cameras. After the DP300 joins a conference, you can select both local and remote cameras.
Normal, and set Multipoint call mode to Hold call. Procedure The DP300 is in a point to point conference. When the local site receives a call from another remote site, you can place the active call on hold as prompted and answer the new call or directly reject the new call.
Page 58
HUAWEI DP300 Desktop Presence User Guide 7 Using the DP300 Display as the PC Monitor Prerequisites You can adjust the video position of a remote site in a conference only after enabling the Display PiP window in PC mode function before the conference starts.
Page 61
A frame used to support and fix a cabinet on the ESD floor. The support raises a cabinet above floor level, allowing cable access from underneath the cabinet. telepresence The Huawei telepresence system provides users a comfortable videoconferencing environment in which they can have true-to-life and face to face remote conferences. two-stage dialing An operation that is performed when an extension number must be dialed during the process of making a call, forwarding a call, and initiating external appeal.
