Installation Instructions for
FACE MOUNTED
ROLLING STEEL STORM SHELTER DOOR
with
NON-TENSION RELEASE AUTOMATIC CLOSURE
GOVERNOR CONTROLLED
Model 610F, FE
Rolling Steel Storm Shelter Doors may be mounted on steel or
masonry construction.
READ COMPLETE INSTRUCTIONS BEFORE INSTALLING DOORS
This document also refers to the following other documents or specifications:
Expansion Anchor Requirement 500436-0001
RHX Commercial Operator Installation Manual 111593.500141
830871-0001
REV 02/20/2023
© 2023 Overhead Door Corporation
1
Advertisement
Table of Contents
Related Manuals for Overhead door 610F
Summary of Contents for Overhead door 610F
- Page 1 Rolling Steel Storm Shelter Doors may be mounted on steel or masonry construction. READ COMPLETE INSTRUCTIONS BEFORE INSTALLING DOORS This document also refers to the following other documents or specifications: Expansion Anchor Requirement 500436-0001 RHX Commercial Operator Installation Manual 111593.500141 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
-
Page 2: Safety Information
Could Result In Death Installations, repairs and adjustments must be made by a trained door system technician using Or Serious Injury proper tools and instructions. HIGH SPRING TENSION 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation... -
Page 3: Table Of Contents
Warranty ..........25 RHX® OPERATOR Stop Pin 1. Read manual and warnings carefully. 2. Keep the door in good working condition. 3. Keep instructions in a prominent location near the door system. 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation... -
Page 4: Data Sheet
Your “DATA SHEET” is shown below. It is found inside the door hardware box. You will need to refer to the data on this sheet during installation. Verify that the “Factory Order Number” on the door components matches the one shown on the DATA SHEET. 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation... -
Page 5: Pre-Installation
UNCRACKED, 3000 PSI MIN., 8” THICK NORMAL STEEL JAMB WEIGHT CONCRETE 5/16” THICK 36 KSI MIN. BOLT AND 1 WASHER WEDGE ANCHOR AND 1 FLAT WASHER 1/4” SETBACK 1/4” SETBACK Figure 2 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation... -
Page 6: Pre-Door Install
Angle after the curtain installation is complete in Step 13. ROLLED ANGLE “S” Distance GUIDES Location “E” GUIDE “S” Distance Location Figure 4 “Z” GUIDE Masonry jambs shown, non-masonry jamb Installation is similar. 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation... - Page 7 Instruction 500436.0001. HEADPLATE BRACKETS 2. IDENTIFY HEADPLATE BRACKETS RH Drive shown, LH Drive opposite See Figure 6. Right Hand Drive shown; Left Hand Drive is opposite. Tension Headplate Drive Side Headplate Figure 6 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
- Page 8 Figure 8. Figure 7 TOWARDS CENTER OF PIPE TENSION DRIVE SHAFT SHAFT RIGHT HAND DRIVE " PINS SEVERAL INCHES DRIVE TENSION SHAFT SHAFT LEFT HAND DRIVE " PINS Figure 8 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
- Page 9 NOTE: The drive sprocket will be fully tightened after the operator Wheel Set Collar is installed and aligned with it. (Required for 11” dia. wheel ONLY) Drive Shaft Figure 12 Figure 11b Sprocket 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
- Page 10 • Barrel must be level. • Tighten set screws in drive headplate bearing and slide set collar on tension shaft against inside of tension headplate and tighten setscrews to lock counterbalance between headplates. Figure 13 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
-
Page 11: Operator Install Mounting Options
8. OPERATOR MOUNTING OPTIONS • For Additional Installation Details, Refer To Provided Operator Installation Manual (111593.500141). Top Of Hood Bench Mount Figure 16 Figure 14 Front Of Hood Wall Mount Figure 15 Figure 17 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation... -
Page 12: Final Door Install
1/2” Phillips Pan Head Screws. Refer to provided install manual inside of wireless module kit. Figure 19 Sensing Edge Wireless Module Sensing Edge Wireless Converter Bottom Bar Assembly (4) #8 x 1/2” Phillips Pan Head Screws 9” Figure 20 Bottom Bar Angle 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation... - Page 13 Rapidly closing curtain could result in death or serious injury. Use slings/ ropes and locking pliers on both guides to keep curtain in the open position until spring tension is applied to the barrel assembly. Figure 23 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
- Page 14 Exercise caution when applying or adjusting spring tension. Contact with rapidly in curtain damage, serious injury and/or death rotating Tension Wheel or expelled winding rod can cause serious injury or death. 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
- Page 15 NOTE: If the door has wind locks there may be some stacking interference in the wind locks as the door is wrapping during operation. This is a normal characteristic. For wind lock applications the doors bottom bar should be level at the open position. 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
- Page 16 Fail-safe operation can only be provided once input power has been applied. Do not install this unit without factory training. WARNING To prevent possible serious injury or death, keep the door opening clear of all personnel. RSX® FDO operated Storm Shelter doors could drop at any time. 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
- Page 17 Do NOT remove, cover, or paint over label. This label should be inspected periodically for legibility, and a replacement label should be ordered from the door manufac- turer as needed. 05/12/2022 301603-0003 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
- Page 18 Flame baffle must be free to drop without • Re-check all bolted connections to verify all are securely tightened. interference with hood support. Models 610F and 610FE will have no flame • Clean up the area and make sure it is secure, with the handle baffle.
- Page 19 Final Door Install (continued) 24. HAND CHAIN KEEPER The emergency hand chain for this door can be locked. • Instruct door users to wrap hand chain, as shown in Figure 28. Figure 28 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
-
Page 20: Maintenance
• Attach the stops to the top of the guide angles. • Remove locking pliers. • Open and close the door to verify proper operation. • Remove barricades or warning cones and notify customer that the repair is complete. 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation... -
Page 21: Troubleshooting
With the variety of the product and the field conditions, other factors may be involved. If assistance beyond this troubleshooting chart is needed, please contact your Overhead Door Distributor. Factory support is available to them, should it be necessary, in order to resolve your problem. -
Page 22: Breakdown Of Parts
This label periodica should be inspecte replacem lly for legibility, ordered ent label should and a manufac from the door turer as needed. 10/01/2015 301603-0002 PARTS LIST on next page 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation... - Page 23 Operator Sprocket (If Req.) 601061-1220 LBL,WARNING,ROLLING,DOORS 301603 LBL,WARNING,SEN EDGE,ELEC/PNEU (not shown) 607873-0001 OPTIONAL ACCESSORIES "Built to Order" parts are speci c to each door manufactured, and may be subject to manufacturer’s standard lead-times. 830871-0001 REV 02/20/2023 © 2023 Overhead Door Corporation...
-
Page 24: Return Goods Policy
If it is determined there is a defect, the Overhead Door Distributor will be credited the cost of the part. If it is determined there is not a defect in material and/or workmanship, no credit will be issued. -
Page 25: Warranty
Limited Warranty...
