- Page 1 Mini MEGA Bass Amplifier ® Operating Manual www.peavey.com...
- Page 2 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, that may cause undesired operation. Warning: Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the user’s authority to use the equipment.
- Page 3 ® Congratulations on the purchase of your new Peavey® MiniMEGA™ bass head! You have made a wise decision! This compact amplifier will absolutely rattle your teeth! Delivering power and tone not available in any other micro bass head, the MiniMEGA features 1,000 Watts of power and produces incredibly full and rich sound in a compact package.
-
Page 4: Front Panel Layout
8 KHz. -3dB; the shelf corner frequency is 5 KHz. Kosmos One of the exciting features of the miniMEGA™ is the inclusion of Peavey's patented KOSMOS® bass enhancement technology. The miniMEGA has two separate Kosmos processors combinded into one, giving you maximum bass performance from an array of large and small speaker cabinets. - Page 5 Front Panel cont. Volume This knob controls the overall volume of the amplifier. Headphone jack 1/8" headphone output for personal monitoring. Crunch Button Depressing this button activates the Crunch effect, which boosts the amp's gain enough to overdrive the preamp. When activated, you can adjust the Gain control to dial in the desired amount of saturation.
-
Page 6: Aux Input
Rear Panel Layout SPEAKER OUTS DIRECT INTERFACE FX LOOP 50/60 Hz 150 WATTS SEND TUNER Consumo de energia 150Wh POWER SPEAKER JACKS PARALLELED D.I. OUTPUTS 4 MIN 63.2V RMS 1000W RMS 4 OHMS PRE/ POST RETURN FUSE FOR 120V OPERATION, FUSE MUST BE CHANGED TO T10AH/250V mini GRND... -
Page 7: Tuner Output
Rear Panel cont. XLR DIRECT OUTPUT This XLR output allows the signal from the mini MEGA to be connected directly to a mixing console. TRS BALANCED OUTPUT Another output option for the miniMEGA is the TRS output connection. A 1/4" balanced TRS cable can be con- nected directly into a rack-mount FX processor or outboard recording device. - Page 8 LOW EQUALIZER CONTROL: The mini MEGA features an EQ to help you dial in your tone and cut through the mix. The first of the EQ controls is the Low EQ. The Low EQ control is a detented knob and controls the frequency range from 20Hz to 200Hz.
- Page 9 QUASI-PARAMETRIC MIDDLE EQUALIZER: The Mini Mega features two quasi-parametric EQ filters labeled “LO MID” and “HI MID”. We’ve attempted to provide a very detailed description of this feature because while parametric EQ’s are extremely powerful, they can be a bit confusing to those who are not familiar.
- Page 10 Kosmos is Peavey’s exclusive bass enhancement processing technology that adds percieved bass to the bass signal without overloading the amplifier. The Mini Mega features two separate Kosmos processors combined into one for the first time. This is so the user can get maximum performance from full size bass cabs all the way down to smaller mini cabs.
- Page 11 5 second delay. The Mini Mega will display a color wheel light show when there is no instrument cable plugged into the input jack. To disable the light show, press the KOSMOS ENABLE BUTTON.
-
Page 12: Midi Programming
MIDI Programming MIDI Control Continuous Controllers (on MIDI channel 1): B0 cc dd cc [dd: 0-63=off ; 64-127=on] 01 - crunch 02 - compressor 03 - punch 04 - lo narrow q 05 - hi narrow q 06 - bright 07 - kosmos 08 - mute 09 - effects loop... - Page 13 Sheet1 MIDI Program Change on channel 1 C0 PRG PRG (dec) PRG (hex) Mute FX Loop Kosmos Bright Punch Compressor Crunch PRG bits: Sheet1 Page 1 64-127 0x40-0x7f MUTED! Page 2...
- Page 15 Mini MEGA® Specifications Mini MEGA NOTE: All specifications tested with Weight: mains voltage maintained at nominal 9 lbs. / 5.4 Kg Headphone Amplifier Specifications: level. Stereo 8 ohm minimum load Dimensions (h x w x d): Line Voltage: (h x w x d): 12"W x 3.125"H x 11"D...
