Summary of Contents for Contec IPC-CDD-02
- Page 1 IPC Series CD-ROM/DVD-ROM Drive Unit IPC-CDD-02 User’s Manual...
-
Page 2: Check Your Package
Check Your Package Thank you for purchasing the CONTEC product. The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. Product Configuration List - Drive Unit [IPC-CDD-02] …1... -
Page 3: Trademarks
No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. The information in this document is subject to change without notice. -
Page 4: Table Of Contents
Copyright ................ii Trademarks............... ii 1.Before Using the Product ........... 1 About the Drive Unit............1 Customer Support ............2 Web Site http://www.contec.co.jp/en/......2 Limited One-Year Warranty ..........2 How to Obtain Service ............. 2 Liability................2 Safety Precautions............3 Safety Information ............ - Page 5 CONTEC CO., LTD. IPC-CDD-02...
-
Page 6: Before Using The Product
This chapter provides information you should know before using the product. About the Drive Unit This product is a CD-ROM/DVD-ROM drive unit dedicated to the CONTEC box computers [IPC- BX/M630 Series, IPC-BX/M600 Series], CONTEC panel computers [IPC-PT/x630x Series, IPC- PT/x600x Series], and to the personal computer CPU unit [PPC-CPU686(MS)-128] compatible with the Mitsubishi Programmable Logic Controller MELSEC-Q series. -
Page 7: Customer Support
You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC Interface boards are warranted by CONTEC CO., LTD. -
Page 8: Safety Precautions
Do not use chemicals or a volatile solvent, such as benzene or thinner, to prevent pealing or discoloration of the paint. CONTEC reserves the right to refuse to service a product modified by the user. In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord immediately and contact the sales representative you purchased the product from or the CONTEC Information Center. -
Page 9: Environment
-Do not block the exhaust fan. Storage When storing this product, keep it in its original packing form. (1) Put the module in the storage bag. (2) Wrap it in the packing material, then put it in the box. CONTEC CO., LTD. IPC-CDD-02... -
Page 10: About Hardware
Weight Approx. 2.8kg The drive unit can read only discs formatted in UDF 1.02 or 1.5; it cannot read those formatted in FAT or FAT32. The drive unit can only read but cannot write to DVD-RAM. CONTEC CO., LTD. IPC-CDD-02... - Page 11 *2 The index indicating the degree to which conductive substances are generated in the operating environment. Pollution level 2 indicates the environment that generates only nonconductive pollutants while allowing accidental condensation to cause temporary conduction. *3 The drive unit cannot be mounted vertically. CONTEC CO., LTD. IPC-CDD-02...
-
Page 12: External Dimensions
2. About Hardware External Dimensions [ mm ] Figure 2.1. External Dimensions CONTEC CO., LTD. IPC-CDD-02... -
Page 13: Hardware Setup
Attach the supplied cable cover or clamp using the supplied screw (M3 x 8) or it that has been installed on the main unit. Don’t remove this screw(two point). Attach the cable cover using the screws that have been installed on the main unit. Figure 2.2. Attachment of an IDE cable cover CONTEC CO., LTD. IPC-CDD-02... -
Page 14: Functions Of Components
1: Master 2: Slave 0, 3 to 6: Invalid Use the up and down buttons to switch between master and slave. Default 1: Master AC inlet Connect the attached AC cable. IDE connector Connect the attached IDE cable. CONTEC CO., LTD. IPC-CDD-02... -
Page 15: Ide Interface
RESET# Output … DD10 DD11 DD12 DD13 DD14 DD15 N.C. DDRQ Input DIOW# Output DIOR# Output IO CHRDY# Input DALE Output DDACK# Output INTRQ Input Reserve Output Reserve Output Output CS1# CS3# Output Output DACT# Output CONTEC CO., LTD. IPC-CDD-02...
