CW-C180EF-W / CW-C240EF / CW-C180EF-M / CW-SC180EF

7 Operating Instructions

7.1. Parts Identification.
7.1.1. Vertical Airflow Direction Vane.
7.1.2. Ventilation Lever.
When the slide lever is in the:
Airflow direction adjustment Up-and-Down.
• The vertical airflow direction vane is
controlled by positioning the vane to
discharge the air upwards, downwards
or straight out.
• "OPEN" position, the ventilation door
opens to allow air, smoke or odours to be
expelled from the room.
• "CLOSE" position, the ventilation door is
closed and the air will be circulated inside
the room and conditioned.
7.1.3. Neon Lamp Indicator.
Neon Lamp Indicator.
7.1.4. Recommended.
Use the air conditioner under the following conditions:
• When
humidity does
temperature is above 21°C.
− Continuous operation at humidities of over 90% may
cause condensation to form on the intake and outlet
vanes.
8
• The green neon light mounted above
the control panel indicates compressor
operation under cooling mode.
not exceed 90% and room
