Service
Manual
MULTI
STANDBY
POWER ON/OFF
SECTION
1. TECHNICAL SPECIFICATIONS ........................................................................................... 1
2. TECHNICAL DESCRIPTION ............................................................................................... 3
3. POWER AMPLIFIER ADJUSTMENT .................................................................................. 6
4. SERVICE MODE .................................................................................................................. 7
5. SYSTEM ERROR ................................................................................................................. 9
6. UPDATE FIRMWARE .........................................................................................................12
7. WIRING DIAGRAM .............................................................................................................19
8. BLOCK DIAGRAM ............................................................................................................. 23
9. SCHEMATIC DIAGRAM .................................................................................................... 25
10. PARTS LOCATION ............................................................................................................ 45
11. EXPLODED VIEW AND PARTS LIST ............................................................................... 65
12. MICROPROCESSOR AND IC DATA .................................................................................. 69
13. ELECTRICAL PARTS LIST ................................................................................................ 95
14. ABOUT REPLACE THE MICROPROCESSOR WITH A NEW ONE .............................144
Please use this service manual with referring to the user guide ( D.F.U. ) without fail.
AV SURROUND RECEIVER SR5002
INPUT SELECTOR
DISP
MULTI
AUTO
TUNED
SLEEP
AUTO
SURR
DIRECT
SURROUND
PURE
SIMPLE
MODE
DIRECT
SETUP
MULTI SPEAKER
AUTO
HT-EQ
MENU
SETUP MIC
PHONES
TABLE OF CONTENTS
SR5002
SR5002 /
AV Surround Receiver
SURROUND
ST
V – OFF
NIGHT
PEAK
ATT
ANALOG
DIGITAL
DIGITAL
DISC 6.1
MT X 6.1
SPKR B
EQ
L
C
R
LFE
PCM
SL
S
SR
DOWN
DISPLAY
MEMORY
CLEAR
MUTE
ENTER
EXIT
BAND
T-MODE
DIGITAL
N1B/N1S/U1B
VOLUME
UP
ATT
AUX 1 INPUT
S-VIDEO
VIDEO
L
AUDIO
R
PAGE
Part no. 90M33CW855010
First Issue 2007.08
MZ

Advertisement

Table of Contents
loading

Related Manuals for Marantz SR5002N1B

Summary of Contents for Marantz SR5002N1B

  • Page 1 Service SR5002 / N1B/N1S/U1B Manual AV Surround Receiver AV SURROUND RECEIVER SR5002 INPUT SELECTOR VOLUME SURROUND DISP MULTI AUTO TUNED V – OFF NIGHT PEAK ANALOG DIGITAL DIGITAL SLEEP AUTO SURR DIRECT DISC 6.1 MT X 6.1 SPKR B DOWN SURROUND PURE SIMPLE...

  • Page 2: Ordering Parts

    Parts for your MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent. ORDERING PARTS : Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specifi ed.

  • Page 3: Technical Specifications

    1. TECHNICAL SPECIFICATIONS AUDIO SECTION FM TUNER SECTION Frequency Range ......87.5 - 108.0 MHz [ /N /U ] Power Output (20 Hz - 20 kHz/THD=0.08%) Usable Sensitivity ........IHF 1.8 µV/16.4 dBf Front L&R ..........8 ohms 90 W / Ch Signal to Noise Ratio ......Mono/Stereo 75/70 dB Center ............
  • Page 4 The relation between the selected surround mode and the input signal The surround mode is selected with the surround mode buttons on SR5002 or the remote control unit. However, the sound you hear is subject to the relationship between the selected surround mode and input signal. That relationship is as follows; Output Channel Front information display Surround...

  • Page 5: Technical Description

    2. TECHNICAL DESCRIPTION • Neo:6 technology allows various sound elements DESCRIPTION within a channel or channels to be steered separately, and in a way which follows naturally from the original presentation. • Neo:6 offers a music mode to expand stereo nonmatrix recordings into the fi...
  • Page 6 2. Full backward compatibility with all existing Dolby Pro Logic IIx is fully compatible with Dolby decoders. (Existing decoders will output a 48 kHz Surround Pro Logic technology and can optimally signal) decode the thousands of commercially available Dolby Surround encoded video cassettes and 3.
  • Page 7 CS-II is packed with other useful feature like dialog clarity (SRS Dialog) for movies and cinema-like bass XM Satellite Radio Ready enrichment (TruBass). CS-II can enable the dialog to become clearer and more discernable in movies and it enables the bass frequencies contained in the original programming to more closely achieve low frequencies –...

  • Page 8: Power Amplifier Adjustment

    3. POWER AMPLIFIER ADJUSTMENT Idling Current Alignment アイドリング電流調整 Each of the measurement points are provided with the 電源を する前にそれぞれの "+" 端子と "-" 端子間にデ two test points. Set a digital Voltage meter to DC voltage ジタルボルトメーターを接続します。デジタルボルトメー input, connect the meter to the test points at both ターを...

  • Page 9: Service Mode

    4. SERVICE MODE 4. SERVICE MODE Microprocessor (IC11), DSP(IC40 )Version and FLD Segment Microprocessor (IC11), DSP(IC40 ) の Version 表示及び Check Mode. 点燈を確認するモードです。 While the power is on, ATT, EXIT and MULTI buttons セットの電源を入れます。 ATT , EXIT , MULTI のボタンを 同時に約...
  • Page 10 Note: Step4, 5 is to check if CPU software is capable of Personal notes: DSP code. "Software Type No" is to show what "DSP Code Group" CPU is capable of. And vice versa. Step 9 is to manage the 16 codes for DSP. •...

  • Page 11: System Error

    5. SYSTEM ERROR 1. Trouble in EEP-ROM (INPUT PWB / IC12) Interface C H E C K E 2 P • If the communication error that ACK did not return by communication with EEP-ROM(INPUT PWB / IC12) occurred 2 seconds and more. CHECK POINTS OF SCHEMATIC 1.
  • Page 12 Less than 200msec Power Amp Fail SPK Relay Relay off FL Display 2 sec "PROTECT" Display on FL STANDBY STANDBY LED STANDBY LED OFF 0.5sec blinking CHECK POINTS OF SCHEMATIC 1. When trouble is caused in Power Amp, it repairs. 2.
  • Page 13 SR5002 : MULTI SPK + ATT + EXIT Press button 3sec A set is broken in the flash state of the 0.125sec interval, so please never make the user do this release operation. Power Line Fail SPK Relay Relay off STANDBY STANDBY LED STANDBY LED OFF...

  • Page 14: Update Firmware

    6. UPDATE FIRMWARE 6. UPDATE FIRMWARE Software for CPU and DSP can be updated. および ソフトウェアのアップデートを行います Have update application software. ("UpgradeDSP.exe" and ソフトウェアのアップデートには UpgradeDSP.exe と H8Download.exe "H8Download.exe") が必要です。 There are two mode of download, regarding to the target of アップデートには次の二つのモードがあります。 software as bellow.
  • Page 15 Press ENTER, MUTE and T-MODE buttons 4. ENTER, MUTE, T-MODE の つのボタンを同時に 秒以 simultaneously more than 5 seconds to turn the unit into 上押し続けて Loading Mode にします。 Loading Mode. "LOADING MODE" will be shown on FLD. 5. FL ディスプレイに "LOADING MODE" と表示されます。...
  • Page 16 Set the Baud rate to 38400 then click Start 8. Baud rate を 38400 に設定し、 Start communication を クリックします。 communication button. If the connection is made successfully, a dialog 通信接続に成功すると下記のダイアログボックスが表示さ "CONNECTED" box saying "Success to connect" appears and れ、 ディスプレイには が表示されます。...
  • Page 17 Download Firmware for CPU (Mode 2) のアップデート方法 (Mode 2) Put the "CPU update" folder into anywhere on your PC’s 1. "CPU update" フォルダを のハードディスクにコピーし hard disc. ます。 本機と を RS-232C で接続します。 Connect PC and the unit with the RS-232C cable. SW99 INPUT INPUT...
  • Page 18 Launch "H8Download.exe" on PC. 5. PC から "H8Download.exe" をダブルクリックして起動し ます。 H8FW2505 H8FW2505 H8FW2505 6. Set Ports をクリックし、 ポート番号を選択します。 Click Set Ports, and select the COM Port No. 7. other files …をクリックして、アップデートファイル Click other fi les... button in the dialog box to specify the (SR5002_yymmdd.mot) を選択し開きます。...
  • Page 19 Click Connect button. If the connection with the H8 µ-P 8. Connect をクリックします。 H8 u-P と通信接続に成功す ると "Success to the H8 micro processor connection" の is successfully made, a dialogue box saying "Success to the H8 micro processor connection" appears. (If the ダイアログが表示されます。...
  • Page 20 11. Click Close button to close the application. 11. Close をクリックしてアプリケーションを閉じます。 h82505_38400.inf 12. Disconnect Mains power cord. 本機の電源を切ります。 13. Turn off the internal switch (SW99) that has been turned 手順 のスイッチ（ SW99 ）を押してブートモードを解除 on at step 3. します。 電源を入れます。 14. Turn on the unit. バージョンの確認...

  • Page 21: Wiring Diagram

    7. WIRING DIAGRAM Except PS5072 TUNER MODULE SR5002 Only COMPONENT 2 SR5002 [ /U ] Ver. VIDEO PWB AC INLET XM RADIO PWB HDMI PWB SR4002 / PS5072 Only SR5002 Only DOWNLOADER DOWNLOADER CONNECTOR CONNECTOR (RC232C) MULTI OUT PWB INPUT PWB BN30 FLASHER CN30...
  • Page 22 SR4002/SR5002 WIRING DIAGRAM with DC VOLTAGE SR5002 Only TUNER MODULE SR5002/U Only COMPONENT2 Except PS5072 BN95 CN99 XM RADIO PWB CN42 CN42 VIDEO PWB 1pin: +7.5V 7pin: +5VD 4pin: +5VV1(+5VD) 1pin: +5V CN90 8pin: +12VA 5pin: +5VV1(+5VD) 2pin: +6V 9pin: -12VA CN96 CN97 SR5002 Only...

  • Page 23: Block Diagram

    8. BLOCK DIAGRAM PRE OUT SR5002 Only 7.1 CH INPUT (AUX 2) VCR IN VCR OUT TUNER PS5072 Only TAPE IN TAPE OUT CD/CDR IN CD/CDR OUT SR5002 Only SR5002/U Only R2S15205FP SR4002 [/L/N] ver. and PS5072 Y/C SEPARATER MONITOR 1 MONITOR 2 SR5002 Only...

  • Page 24: Schematic Diagram

    9. SCHEMATIC DIAGRAM TO FRONT PWB TO VIDEO PWB INPUT PWB - 1/ 3 SR4002/U Only, SR5002 Only SR5002 Only [ /K ] Ver. >> PS5072 HD64F2506 INPUT PWB - 3 / 3 SR5002 [ /U ] Ver. : 32K SR4002/PS5072/SR5002 ALL : 8k FROM REGULATOR PWB TO INPUT...
  • Page 25 INPUT PWB - 2 / 3 SR5002 Only MULTI PRE OUT / SPK FROM INPUT PWB - 1 / 3 SR5002 [ /U ] Ver. MULTI OUT PWB TO INPUT PWB - 3 / 3 PRE10 : MULTI_SPK-L PRE09 : MULTI_SPK-R MULTI SPK PWB SR5002...
  • Page 26 INPUT PWB - 3 / 3 TO INPUT PWB - 2 / 3 FROM INPUT PWB - 2 / 3 TO INPUT PWB - 2 / 3 FROM INPUT PWB - 2 / 3 TO INPUT PWB - 2 / 3 FROM INPUT PWB - 1 / 3 SR5002 Only...
  • Page 27 SR4002/L/N ver. and PS5072 only HDMI PWB...
  • Page 28 4002/U and SR5002 only HDMI PWB...
  • Page 29 VIDEO PWB IC73 IC72 IC48 SR5002 Only IC45 IC45 IC48 COMPONENT SR5002 Only...
  • Page 30 SR5002/U only XM RADIO PWB XMDT...
  • Page 31 FROM INPUT PWB - 1 / 3 MAIN SELECTOR TRANSF. PWB TRANSF. ENCODER PWB FRONT TRANSF. PWB FRONT PWB PS5072 : BAND >> A/D, MEMORY >> NIGHT, CLEAR >> SLEEP, T-MODE >> V-OFF BRIDGE DIODE TACT SW PWB [ /U ] Ver. COMPONENT 2 PWB DOWNLOADER CONNECTOR PWB...
  • Page 32 MAIN PWB SR5001 Only T. P. T. P. PTC Term. TO TRANAF. PWB T. P. T. P. T. P. T. P. SR5002 Only TRANAF. T. P. /U Only AC INLET TO POWER TRANAF. TO PUSH SW PWB...
  • Page 33 TR BIAS PWB TR BIAS PWB TR BIAS PWB TR BIAS PWB TR BIAS PWB TR BIAS PWB TR BIAS PWB REGULATOR PWB REGULATOR 2 PWB SR5002 /U Only SR5002 /U Only...

  • Page 34: Parts Location

    10. PARTS LOCATION...
  • Page 35 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 36 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 37 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 38 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 39 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 40 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 41 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 42 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 43 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).

  • Page 44: Exploded View And Parts List

    11. EXPLODED VIEW AND PARTS LIST AC INLET RC91 HDMI PWB XM RADIO PWB [ /U ] Ver. TRANSF. [ /U ] Ver. COMPONENT 2 FRONT [ /N ] Ver. TRANSF. T901 [ /U ] Ver. IR FLASHER REGULATOR BRIDGE DIODE VIDEO PWB INPUT PWB...
  • Page 45 PWB ASSY BRIDGE DIODE PWB ASSY COP11994D-7 35 /U1B PWB ASSY BRIDGE DIODE PWB ASSY COP11994C-7 36 /N1B PWB ASSY TR BIAS PWB ASSY COP12000B NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 46 CSA1A020Z /N1B 90M-ZA000210R ANTENNA ANT FM WIRE (PIGTAIL) CSA1A007 /N1S 90M-ZA000210R ANTENNA ANT FM WIRE (PIGTAIL) CSA1A007 /U1B 90M-ZA000290R ANTENNA FM 1 POL ANT(UL) CSA1A033Z NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.

  • Page 47: Microprocessor And Ic Data

    12. MICROPROCESSOR AND IC DATA IC11 : HD64F2506 Port Setting Port Name Mode7 STBY Name Note Act. init HINBSY DSP Busy Signal EV_DATA EV_CLK HDMI_RST RESET for HDMI HD+5V SW +5V SW for HPD MULTIMUTE MULTI ROOM MUTE SWMUTE SUB W MUTE CNTMUTE CENTER SP MUTE SBMUTE...
  • Page 48 IC11 : HD64F2506 Port Setting Port Name Mode7 STBY Name Note Act. init 62 P90/AN8 AD MODEL_SEL Model Select 63 P47/AN7 AD TV_AUTO TV Video Detect 64 P46/AN6 MIC_IN MIC IN 65 P45/AN5 AD VER_SEL VERSION SELECT 66 P44/AN4 AD P_LINE_FAIL Emergency Protection 67 AVss AVSS...
  • Page 49 IC11 : HD64F2506 Port Setting Port Name Mode7 STBY Name Note Act. init UART for RS232C, Flash WR 126 P30/TxD0 I/O,O Pull UP FrontFL,Video(OSD),Y/C&Sepa, 127 P77/TxD3 I/O,O OSDDATA 4094,SAA,AK 128 P76/RxD3 I/O,I PULL DOWN FrontFL,Video(OSD),Y/C&Sepa, 129 P75/TMO3/SCK3 I/O,I/O,I/O OSDCLK 4094,SAA,AK 130 P74/TMO2/~MRES I/O,O _RSTFL...
  • Page 50 IC17 : R2S15205FP Multi Multi Rch Tone Lch Tone CLOCK DATA MCU I/F Tone Volume Volume Bass& Lout Treble Volume Volume Bass& Treble Rout Volume Input Volume Multi SBLout mono Out L SBLin Volume Volume Multi SBRout SBRin Multi PRELIMINARY Volume Cout Input...
  • Page 51 IC17 : R2S15205FP PIN No. Function Name 19,17, FROUT,FLOUT, 14,12, 6-OUT,5-OUT, Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel 9,7, 4-OUT, 3-OUT, 2-OUT,1-OUT 20,16, FRC,FLC, 15,11, 6-C,5-C, Connects capacitor for reducing click noise of 10,6, 4-C,3-C, L/R/C/SW/SL/SR/SBL/SBR channel volume 2-C,1-C 3,8, Analog ground of internal circuit AGND 13,18 23,27...
  • Page 52 IC21 : BD3812F IC27 : CS4900 Family Electrical Characteristics (Unless otherwise noted, Ta=25 C, V =7V, V =-7V, f=1kHz, V =1Vrms, RL=10k Rg=600 Master volume=0dB, Output gain=0dB) I/O Function Description Parameter Conditions Symbol Min. Typ. Max. Unit 7pin − Circuit current No signal 1 I/O UHS0, GPIO18 Mode Select Bit 0, General Purpose I/O 5pin...
  • Page 53 IC27 : CS4900 Family SAI 0 Serial External Memory SAI 1 Audio Interface SAI 3 Interface SAI 2 Compressed DSP C Audio Digital DAO 0 Interface Frame Audio 32-Bit DSP Programmable Shifter Interface DAO 1 Digital Multistandard Audio Audio Decoder Interface GPIO and I/O Input...
  • Page 54 IC28 : LC89057WVF4E EMPHA/UO AUDIO XMODE LC89057W-VF4-E RXOUT Microcontroller C bit , Ubit SDIN RERR SLRCK SBCK Input Demodulation Data Selector & RDATA RDATA Selector Lock detect RX5/VI XMODE RLRCK RX6/UI SDIN DGND DVDD LC89057W-VF4-E DVDD DGND RMCK TMCK/PIO0 RBCK RBCK RLRCK TBCK/PIO1...

  • Page 55: General Description

    IC29 : CS42528-CQ 114 dB, 192 kHz 8-Ch Codec with S/PDIF Receiver Features General Description The CS42528 codec provides two analog-to-digital and eight Eight 24-bit D/A, two 24-bit A/D Converters digital-to-analog delta-sigma converters, as well as an integrat- 114 dB DAC / 114 dB ADC Dynamic Range ed S/PDIF receiver, in a 64-pin LQFP package.
  • Page 56 IC29 : CS42528-CQ 2. PIN DESCRIPTIONS 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 CX_SDIN1 RXP1/G PO 1 CX_SCLK RXP2/G PO 2 CX_LRCK RXP3/G PO 3 RXP4/G PO 4 DGND RXP5/G PO 5 RXP6/G PO 6 SCL/CCLK RXP7/G PO 7...
  • Page 57 IC29 : CS42528-CQ AD0/CS Address Bit 0 (I C)/Control Port Chip Select (SPI) (Input ) - AD0 is a chip address pin in I C mode; CS is the chip select signal in SPI mode. Interrupt (Output ) - The CS42528 will generate an interrupt condition as per the Interrupt Mask register. See “Interrupts”...
  • Page 58 IC30 : M74HC4053 PIN No SYMBOL NAME AND FUNCTION 2, 1 bx, by Independent Input/Outputs 5, 3 cx, cy Independent Input/Outputs INHIBIT Input Negative Supply Voltage 11, 10, 9 A, B, C Select Inputs 12, 13 ax, ay Independent Input/Outputs 14, 15, 4 ax TO cy Common Output/input...
  • Page 59 IC41 : 57V161610ET7 Self Refresh Counter Refresh Refresh Interval Timer Counter 512Kx16 Bank 0 Address[0:10] Sense AMP & I/O gates Column Decoder Address Precharge Register Row Active BA(A11) Column Addr. Column Active Latch & Counter Overflow Burst Length Counter DQ10 DQ11 DQ12 DQ13...
  • Page 60 IC44 : NJM2535MTE1 IC45 : NJM2264MTE1 IC46 : NJM2244MTE1 IC48 : NJM2244MTE1...
  • Page 61 IC47 : LC74781W Pin No. Symbol Function Description Ground Ground connection (digital system ground) Xtal Used to connect the crystal oscillator and capacitor used to generate the internal Crystal oscillator connection synchronization signal, or to input an external clock (2fsc or 4fsc). Xtal Switches between external clock input mode and crystal oscillator mode.
  • Page 62 IC51 : XMDT (SR5002/U only) I2S_OCLK (Mstr only) Inter-IC I2S_LRCLK (M=o; S=i) Sound I2S_SCLK (M=o; S=i) (I2S) I2S_DATA (M=o; S=i) High Spd HSDP_EN (M=o; S=i) Data Port HSDP_CLK (M=o; S=i) (HSDP) HSDP_DATA (M=o; S=i) LSDP_TXRX HSDP_EN SC_TX_OUT HSDP_CLK Low Spd TX+ / TX- Data Port LSDP_TXRX (M=o;...
  • Page 63 IC52 :AK4384ET (SR5002/U only) FEATURES Sampling Rate Ranging from 8kHz to 192kHz 128 times Oversampling (Normal Speed Mode) 64 times Oversampling (Double Speed Mode) 32 times Oversampling (Quad Speed Mode) 24-Bit 8 times FIR Digital Filter SCF with High Tolerance to Clock Jitter 2nd order Analog LPF Single Ended Output Buffer Digital de-emphasis for 32k, 44.1k and 48kHz sampling...
  • Page 64 IC71 : TC90A49PG IC72 : NJM2285MTE1 IC73 : MM1511XNRE...
  • Page 65 IC74 : TA1270BF...
  • Page 66 IC81 : Sil 9185...
  • Page 67 IC81 : Sil 9185 Differential Signal Data Pins System Switching Pins Pin Name Pin # Type Description Pin Name Pin # Type Description R0X0+ TMDS Input TMDS input Port 0 data pairs. DSDA0, LVTTL, Input/ DDC I C Data for respective port. Note 1. DSDA1, Schmitt Trigger, Output...
  • Page 68 IC81 : NJU3430F R S T R ESET Instruction M K R AM Icon D ec oder 16x2 bit D r i v e r 8bits Line Shift C L K Address R e g . Counter C G R AM Segment 35x8 bit D r i v e r...
  • Page 69 IC82, IC83 : TC74VHCT14AFT IC83 : ST202EBW PIN CONFIGURATION PIN DESCRIPTION PlN N° SYMBOL NAME AND FUNCTION Positive Terminal for the first Charge Pump Capacitor Doubled Voltage Terminal Negative Terminal for the first Charge Pump Capacitor Positive Terminal for the second Charge Pump Capacitor Negative Terminal for the second Charge Pump Capacitor Inverted Voltage Terminal Second Transmitter Output Voltage...
  • Page 70 IC95 : TC7MZ4052FK IC96 : TC7MZ4052FK X-COM Y-COM Control Inputs “ON” Channel Inhibit MZ4051FK MZ4052FK MZ4053FK 0X, 0Y 0X, 0Y, 0Z 1X, 1Y 1X, 0Y, 0Z 2X, 2Y 0X, 1Y, 0Z 3X, 3Y 1X, 1Y, 0Z ¾ 0X, 0Y, 1Z ¾...
  • Page 71 IC98 : SiI9033CTU DSDA0 RESET# Registers Port DSCL0 ---------------- Slave Configuration DSDA1 CSDA Logic Block DSCL1 Slave CSCL HDCP Embedded Keys MCLK MCLKOUT R1XC± Data PanelLink XTALIN TMDS R1X0± 24-Bit XTALOUT Digital Data R1X1± HDCP & Core HS,VS, Repeater R1X2± HDMI Decryption Mode...
  • Page 72 IC99 : SiI9030CTU7 Si I 9030 Si I 9030 Features RESET# PanelLink Cinema Transmitter DSCL Master DSDA Registers CSDA Industry-Standard HDCP Configuration Slave CSCL HDCP Keys Logic Encryption Compliance PROM Engine • HDMI 1.0 EXT_SWING VSYNC • DVI 1.0 Video HSYNC Data •...

  • Page 73: Electrical Parts List

    13. ELECTRICAL PARTS LIST NOTE ON SAFETY FOR FUSIBLE RESISTOR : PARTS INFORMATION The suppliers and their type numbers of fusible resistors RESISTORS 1) 00MGD05 × × × 140, Carbon fi lm fi xed resistor, ±5% 1/4W are as follows; 2) 00MGD05 ×...
  • Page 74 4.7 OHM 1/5W J CRD20TJ4R7T F TRANS R962 RES. 47K OHM 1/5W J CRD20TJ473T F TRANS R963 RES. 1.2K OHM 1/5W J CRD20TJ122T FRONT PWB (CUP11994Z) NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 75 IC82 90M-HC700550R 90M-HC700550R IC TC74HCU04AFNG HVI74HCU04AFNG FRONT IC84 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1 FRONT J801 CORD SN95/PB5, 0.6 C3A206 FRONT J805 CORD SN95/PB5, 0.6 C3A206 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 76 CRD20TJ472T FRONT R803 RES. 10 OHM 1/5W J CRD20TJ100T FRONT R805 RES. 100 OHM 1/5W J CRD20TJ101T FRONT R806 RES. 10K OHM 1/5W J CRD20TJ103T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 77 CRD20TJ103T FRONT R916 RES. 10K OHM 1/5W J CRD20TJ103T FRONT R917 RES. 47K OHM 1/5W J CRD20TJ473T FRONT R918 RES. 47K OHM 1/5W J CRD20TJ473T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 78 90M-YT004500R TERMINAL JACK HEADPHONE(SILVER) CJJ2E026Z JK81 /U1B 90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z JW13 CORD WIRE ASSY CWE8202110RV R846 RES. 4.7K OHM 1/5W J CRD20TJ472T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 79 00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC HDMI C945 00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC HDMI C946 00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 80 100 OHM 1/10W J CRJ10DJ101T HDMI R819 00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T HDMI R851 00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 81 100 OHM 1/10W J CRJ10DJ101T HDMI R966 00MNN05222610 CHIP RES. 2.2K OHM 1/10W J CRJ10DJ222T HDMI R967 00MNN05222610 CHIP RES. 2.2K OHM 1/10W J CRJ10DJ222T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 82 00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC INPUT C154 00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC INPUT C157 00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 83 C229 00MDD95391370 CER. CAP. 390PF 50V JA CCUS1H391JA INPUT C230 00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC INPUT C231 00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 84 INPUT C318 00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA INPUT C319 00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T INPUT C320 00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 85 INPUT C389 00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T INPUT C390 00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T INPUT C391 00MDK96473300 CER. CAP. 0.043UF 50V KC CCUS1H473KC NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 86 INPUT C470 00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T INPUT C471 00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T INPUT C474 00MDK96473300 CER. CAP. 0.043UF 50V KC CCUS1H473KC NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 87 21P FPC WAFER CJP21GA115ZY INPUT CN30 CONN. MOLEX35336-0910 CJP09GA98ZM INPUT CN31 CONN. MOLEX35336-0910 CJP09GA98ZM INPUT CN43 CONN. 21P FPC WAFER CJP21GA117ZY INPUT CN54 CONN. 5P STRAIGHT CJP05GA19ZY NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 88 90M-HC108910R IC 74VHC08 HVI74VHC08TTR INPUT IC39 90M-HC108930R 90M-HC108930R IC 74LCX32 HVI74LCX32TTR INPUT IC40 90M-HS32CW20R 90M-HS32CW20R UPRO M29W400DT70N SR4002 HVIM29W400DT70N INPUT IC41 90M-HC108970R 90M-HC108970R IC HY57V161610ET-7 HVI57V161610ET7 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 89 KRC102S HVTKRC102S INPUT Q347 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S INPUT Q348 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S INPUT Q349 00MHF201171D0 00MHF201171D0 TRS. 2SK117-BL HVT2SK117-BL NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 90 4.7K OHM 1/10W J CRJ10DJ472T INPUT R161 00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T INPUT R162 00MNN05562610 CHIP RES. 5.6K OHM 1/10W J CRJ10DJ562T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 91 0 OHM 1/10W J CRJ10DJ0R0T INPUT R232 00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T INPUT R235 00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 92 1.5K OHM 1/10W J CRJ10DJ152T INPUT R301 00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T INPUT R302 00MNN05104610 CHIP RES. 100K OHM 1/10W J CRJ10DJ104T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 93 82K OHM 1/10W J CRJ10DJ823T INPUT R385 00MNN05832610 CHIP RES. 82K OHM 1/10W J CRJ10DJ823T INPUT R386 00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 94 220 OHM 1/10W J CRJ10DJ221T INPUT R472 00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T INPUT R473 00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 95 22K OHM 1/10W J CRJ10DJ223T INPUT R820 00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T INPUT R821 00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 96 20MHZ HOX20000E220TF FRONT BRACKET BRACKET SHIELD CMD1A512 FRONT BUFFER STOPPER IR SENSOR CHG1A262 IR FLASHER PWB (CUP11994Z-11) IR FLASH BK86 BRACKET BRACKET FOR PWB CMD1A569 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 97 CCKT1H221KB MAIN C587 FILM CAP. 220PF 50V KB CCKT1H221KB MAIN C601 CER. CAP. 12PF 50V JC CCCT1H120JC MAIN C602 CER. CAP. 12PF 50V JC CCCT1H120JC NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 98 CCEA1EH101T MAIN C954 CER. CAP. 1000PF 50V B HCBS1H102KBT MAIN C955 CER. CAP. 1000PF 50V B HCBS1H102KBT MAIN C956 CER. CAP. 1000PF 50V B HCBS1H102KBT NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 99 MAIN D981 00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT MAIN D982 00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT MAIN D983 00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT MAIN ET01 BRACKET BRACKET FOR PWB CMD1A569 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 100 MAIN J204 CORD SN95/PB5, 0.6 C3A206 MAIN J205 CORD SN95/PB5, 0.6 C3A206 MAIN J206 CORD SN95/PB5, 0.6 C3A206 MAIN J207 /U1B CORD SN95/PB5, 0.6 C3A206 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 101 C3A206 MAIN J519 CORD SN95/PB5, 0.6 C3A206 MAIN J520 CORD SN95/PB5, 0.6 C3A206 MAIN J521 CORD SN95/PB5, 0.6 C3A206 MAIN J522 CORD SN95/PB5, 0.6 C3A206 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 102 C3A206 MAIN J812 CORD SN95/PB5, 0.6 C3A206 MAIN J813 CORD SN95/PB5, 0.6 C3A206 MAIN J814 CORD SN95/PB5, 0.6 C3A206 MAIN J815 CORD SN95/PB5, 0.6 C3A206 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 103 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT MAIN Q519 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT MAIN Q520 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT MAIN Q541 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 104 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y MAIN Q886 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y MAIN Q887 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y MAIN Q901 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 105 CRD20TJ473T MAIN R556 RES. 33K OHM 1/4W J CRD25TJ333T MAIN R557 RES. 33K OHM 1/4W J CRD25TJ333T MAIN R558 RES. 33K OHM 1/4W J CRD25TJ333T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 106 18 OHM 1/4W CRD25FJ180T MAIN R646 RES. 3.3 OHM 1/4W CRD25FJ3R3T MAIN R647 RES. 3.3 OHM 1/4W CRD25FJ3R3T MAIN R648 RES. 3.3 OHM 1/4W CRD25FJ3R3T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 107 CRD20TJ103T MAIN R810 90M-GO000013R 90M-GO000013R RES. 0.27OHM(*2) ,5W CRF5EKR27HX2K MAIN R811 90M-GO000013R 90M-GO000013R RES. 0.27OHM(*2) ,5W CRF5EKR27HX2K MAIN R812 RES. 47 OHM 1/4W J CRD25TJ470T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 108 CRD20TJ103T MAIN R925 RES. 10K OHM 1/5W J CRD20TJ103T MAIN R926 RES. 10K OHM 1/5W J CRD20TJ103T MAIN R927 RES. 15K OHM 1/5W J CRD20TJ153T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 109 00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT MICRO P JK90 /N1B 90M-YT004320R 90M-YT004320R TERMINAL HEADPHONE JACK HJJ2D003Z MICRO P JK90 /N1S 90M-YT004120R 90M-YT004120R TERMINAL HEADPHONE JACK SILVER HJJ2D003Y NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 110 47K OHM 1/10W J CRJ10DJ473T MLT SPK R411 00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T MLT SPK R412 00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 111 /U1B CER. CAP. 0.047UF 50V Z HCBS1H473ZFT REG.2 IC88 /U1B 00MHC3890609F IC NJM7806FA HVINJM7806FA SELECTOR/ENCODER PWB (CUP11994Z-2) SEL/ENC C841 CER. CAP. 100PF 50V K HCBS1H101KBT NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 112 RES. 1.2K OHM 1/4W CRG14SANCJ122T TR BIAS VR81 90M-RA001100R 90M-RA001100R TRIM. RES. 220 OHM HVN1RA221B01T TR BIAS VR82 90M-RA001100R 90M-RA001100R TRIM. RES. 220 OHM HVN1RA221B01T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 113 VIDEO C475 00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC VIDEO C476 00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T VIDEO C477 00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 114 VIDEO C582 00MOA22701020 ELECT CAP. 220UF 10V CCEA1AH221T VIDEO C583 00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T VIDEO C584 00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 115 C752 00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC VIDEO C753 00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T VIDEO C754 00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 116 KRA102S HVTKRA102S VIDEO Q403 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR VIDEO Q404 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR VIDEO Q405 /N1B 90M-HX800090R 90M-HX800090R CHIP TRS. KRC111S HVTKRC111S NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 117 100 OHM 1/10W J CRJ10DJ101T VIDEO R443 00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T VIDEO R444 00MNN05105610 CHIP RES. 1M OHM 1/10W J CRJ10DJ105T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 118 75 OHM 1/10W J CRJ10DJ750T VIDEO R550 00MNN05750610 CHIP RES. 75 OHM 1/10W J CRJ10DJ750T VIDEO R551 00MNN05750610 CHIP RES. 75 OHM 1/10W J CRJ10DJ750T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 119 90M-JX001400R X'TAL HC-49/U 12PF 4.433619MHZ COX04433D120TF VIDEO X702 90M-JX001220R 90M-JX001220R X'TAL 3.57MHZ H2OX03579D140TF VIDEO X703 90M-FQ000580R 90M-FQ000580R CER. VIB. CERAMINC RESONATOR HVFCSBLA503KECZ XM PWB (CUP12001Z) NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 120 /U1B 90M-HC300940R IC LM1117-ADJ HVILM1117S-ADJ R486 /U1B 00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T R501 /U1B 00MNN05104610 CHIP RES. 100K OHM 1/10W J CRJ10DJ104T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 121 R812 /U1B 00MNM11800020 CHIP RES. 180 OHM 1% CRJ10DF1800T R813 /U1B 00MNM11800020 CHIP RES. 180 OHM 1% CRJ10DF1800T X501 /U1B 90M-JX001410R X'TAL 45.1584MHZ (SMD) COX45158E180S NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.

  • Page 122: About Replace The Microprocessor With A New One

    14. ABOUT REPLACE THE MICROPROCESSOR WITH A NEW ONE When replaced of the U-PRO (Microprocessor) or the Flash ROM, confirm contents of the following. Pos. After Description Remark Name replaced INPUT IC11 HD64F2505 SR4002 INPUT IC40 M29W400DT70N SR4002 After replaced A : Mask ROM (With software).
