Customer's Record
The model number and serial number of this product may be found on its rear panel. You should note this serial
number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of your
purchase to aid in identifi cation in the event of theft or loss, and for Warranty Service purposes.
Model Number
Matsushita Electric Industrial Co., Ltd.
Web Site : http://panasonic.net/
©
2007 Matsushita Electric Industrial Co., Ltd. All Rights Reserved.
Serial Number
Printed in Japan
MBS0407S0
Advertisement
Table of Contents
Related Manuals for Panasonic MBS0407S0
Summary of Contents for Panasonic MBS0407S0
- Page 1 Warranty Service purposes. Model Number Matsushita Electric Industrial Co., Ltd. Web Site : http://panasonic.net/ © 2007 Matsushita Electric Industrial Co., Ltd. All Rights Reserved. Serial Number Printed in Japan MBS0407S0...
-
Page 2: Operating Instructions
English Please read these instructions before operating your set and retain them for future reference. Operating Instructions Plasma Television TH-37PV70AZ Model No. TH-42PV70AZ TH-50PV70AZ The images shown in this manual are for illustrative purposes only. POWER INPUT ASPECT EXIT MENU RETURN SURROUND OPTION... - Page 3 Turn your own living room into a movie theatre! Experience an amazing level of multi-...
-
Page 4: Table Of Contents
media excitement Enjoy rich multi-media Amplifier with DVD Recorder Speaker system Contents Be Sure to Read • Safety Precautions ······································ 4 • (Warning / Caution) • Notes ··························································· 5 Maintenance ··············································· 5 Quick Start Guide Accessories / Options Identifying Controls Camcorder Basic Connection Auto Tuning... -
Page 5: Safety Precautions
Safety Precautions Handling the mains plug and lead Insert the mains plug fully into the socket outlet. (If the mains plug is loose, it could generate heat and cause fire.) Ensure that the mains plug is easily accessible. Ensure the grounding pin on the mains plug is securely connected to prevent electrical shock. Do not touch the mains plug with a wet hand. -
Page 6: Notes
Caution When cleaning the TV, remove the mains plug ( Cleaning an energized TV may cause electrical shock.) When TV will not be used for a long time, remove the mains plug This TV will still consume some power even in the Off mode, as long as the mains plug is still connected to a live socket outlet. -
Page 7: Accessories / Options
Accessories / Options Standard accessories Remote Control Transmitter • EUR7651140 Mains Lead Installing remote’s batteries Hook Note the correct polarity (+ or -) Caution • Incorrect installation may cause battery leakage and corrosion, resulting in • damage to the remote control. •... -
Page 8: Identifying Controls
Identifying Controls Function select • Volume / Contrast / Brightness / Colour / Sharpness / Tint (NTSC mode) / Bass / Treble / Balance / Auto Tuning (p. 23) Mains power On / Off switch Remote control signal receiver Power LED •... -
Page 9: Basic Connection
Basic Connection External equipment and cables shown are not supplied with this TV. Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any leads. When disconnecting the mains lead, be absolutely sure to disconnect the mains plug at the socket outlet fi rst. Example 1 Connecting aerial TV only... -
Page 10: Auto Tuning
Auto Tuning Search and store TV channels automatically. These steps are not necessary if the setup has been completed by your local dealer. POWER INPUT ASPECT EXIT MENU RETURN OPTION DIRECT TV REC TEXT F.P. INDEX HOLD PROGRAMME Note • •... -
Page 11: Language Setting
Language Setting You can change language for on-screen displays. POWER INPUT ASPECT EXIT MENU RETURN SURROUND OPTION RECALL MUTE TEXT F.P. INDEX HOLD POWER PROGRAMME Display the menu MENU Select “Language” Main Menu VIERA Link Picture Sound Setup Language Select EXIT Access RETURN... - Page 12 Many features available on this TV can be accessed via the On Screen Display menu. ■ How to use remote control MENU Open the main menu Move the cursor / select the menu Move the cursor / adjust levels / select from a range of options Access the menu / store settings after adjustments have been made or options have been set RETURN...
-
Page 13: Watching Tv
Watching TV POWER INPUT ASPECT EXIT MENU RETURN OPTION DIRECT TV REC RECALL Volume TEXT F.P. INDEX HOLD PROGRAMME Turn power on POWER Mains power On / Off switch should be On. 1 BBS CH05 5.5MHz Bad Signal Encrypted Information banner Select a channel down •... - Page 14 ■ Other useful functions (Operate after Hold Freeze / unfreeze picture Check or change the current programme status instantly • To change Display the current Teletext Language programme Selects teletext language status Volume Correction Adjusts volume of individual channel or input mode Note •...
-
Page 15: Watching Videos And Dvds
Watching Videos and DVDs Connect the external equipment (VCRs, DVD equipment, etc.) and you can watch the input. To connect the equipment (p. 8) The Remote Control is capable of operating some functions of selected Panasonic external equipment. INPUT ASPECT EXIT MENU RETURN... - Page 16 Panasonic equipment connected to the TV can be directly operated with the remote control. VCR / DVD switch Select VCR to operate Panasonic VCR or DVD equipment Select DVD to operate Panasonic DVD equipment or Player home theatre Standby POWER Set to Standby mode / Turn on Play Playback videocassette / DVD...
-
Page 17: Viewing Teletext
Viewing Teletext You can enjoy teletext broadcasting, including news, weather forecasts and subtitles, if this service is provided by the broadcasters. What is FASTEXT mode? In FASTEXT mode, four differently coloured subjects are situated at the bottom of the screen. To access more information about one of these subjects, press the appropriately coloured button. - Page 18 If you wish to hold the current page without updating Stop or resume automatic updating HOLD ■ HOLD Return to the main index page INDEX INDEX Call up a • F.P. • favourite pages Watch TV and Teletext in two windows at once View in MENU multi...
-
Page 19: How To Use Menu Functions
How to Use Menu Functions Various menus allow you to make settings for the picture, sound, and other functions. INPUT ASPECT EXIT MENU RETURN SURROUND OPTION DIRECT TV REC TEXT F.P. INDEX HOLD PROGRAMME ■ To return to TV at any time EXIT ■... -
Page 20: Viera Link
■ Overview Main Menu VIERA Link Picture Sound Setup Language Select EXIT Access RETURN • Only available items can be selected. VIERA Link Menu VIERA Link Control Recorder Speaker Selection Home Cinema (p. 29) Picture Menu Menu Dynamic Contrast Brightness Colour Sharpness Tint... -
Page 21: Menu List
How to Use Menu Functions ■ Menu list Menu Item VIERA Link Control Speaker Selection Menu Contrast, Brightness, Colour, Sharpness Tint Colour Temperature CH Colour Set Colour Management P-NR MPEG NR 3D-COMB Reset to Default Menu Bass Treble Balance Headphone Volume Surround Volume Correction HDMI1 Input... - Page 22 ■ Menu list Menu Item Selects optional colour system based on video signals in AV mode AV Colour System (Auto / PAL / SECAM / NTSC4.43 / NTSC3.58) Available only with 480p or 576p input signals in a natural colour from digital equipment connected to AV2 / AV3 Component or HDMI1 / HDMI2 terminals Select SD or HD to adjust suitable colour parameters for SD (standard definition) or HD Colour Matrix...
-
Page 23: Editing And Setting Channels
Editing and Setting Channels The current channel settings can be changed according to your needs and reception conditions. INPUT ASPECT EXIT MENU RETURN OPTION DIRECT TV REC TEXT F.P. INDEX HOLD PROGRAMME ■ To return to TV EXIT Channel Selection ■... - Page 24 Automatically set the channels received in the area. If a Child Lock PIN number (p. 24) has been set, it must be entered. Select the channel selection method (Position / Direct) “Channel Selection” (p. 22) Start Auto Tuning Access “Auto Tuning” Auto Tuning All tuning data will be erased EXIT...
-
Page 25: Control Channel Audience
Control Channel Audience You can lock specific channels and control who watches them. (When a channel is selected, a message appears; by entering the PIN number, you can watch the channel.) INPUT ASPECT EXIT MENU RETURN OPTION DIRECT TV REC TEXT F.P. -
Page 26: Restore Settings
Restore Settings Resets the TV to its original condition, i.e. no channels tuned in. All settings (channels, picture, sound quality, etc.) are reset. INPUT ASPECT EXIT MENU RETURN OPTION DIRECT TV REC TEXT F.P. INDEX HOLD PROGRAMME ■ To return to TV EXIT Check the message and initialise Shipping Condition... -
Page 27: Input Labels
Input Labels For easier identification and selection of the input mode, you can label each input terminals or skip terminal that is not connected to any equipment. (To select the input mode INPUT ASPECT EXIT MENU RETURN OPTION DIRECT TV REC TEXT F.P. -
Page 28: Displaying Pc Screen On Tv
Displaying PC Screen on TV The screen of the PC connected to the TV can be displayed on the TV. You can also listen to PC sound with the audio cable connected. To connect PC (p. 30) INPUT ASPECT EXIT MENU RETURN OPTION DIRECT TV REC... -
Page 29: Viera Link "Hdavi Control Tm
VIERA Link “ ∗ Enjoy additional HDMI Inter-Operability with Panasonic products which have “HDAVI Control” function. This TV supports “HDAVI Control 2” function. Connections to some Panasonic equipment (DVD Recorder DIGA, HD Video Camera, Player theatre, etc.) with HDMI cables allow you to interface them automatically. •... - Page 30 You can control some functions of the connected Panasonic equipment with this TV remote control (point the remote control at the TV’s signal receiver). • If you cannot access the menu, check the settings and the equipment (p. 28). Access the menu of the equipment Display “VIERA Link Menu”...
-
Page 31: External Equipment
External Equipment These diagrams show our recommendations for how to connect the TV to your various equipment. For other connections, consult the instructions for each piece of equipment, the table below, and the specifi cations (p. 39). AV4 IN ( M3 stereo mini plug) (VIDEO) (S-VIDEO) -
Page 32: Amplifier With Speaker System
To watch satellite broadcasts Set top box Fully wired HDMI compliant cable To listen with speakers Conversion adapter (if necessary) (Viewing) (Listening) To watch DVDs (Viewing) DVD player (Listening) VIERA Link (p. 28) • Use fully wired HDMI compliant cable. •... -
Page 33: Technical Information
Technical Information System Selection China HK/UK Asia/M.East NZ/INDONES Australia E.Europe SPECL Ver America CH DISPLAY – – – – – – – – – – – – – – – – – – – – – – – – – –... - Page 34 The optimum size and aspect can be chosen, and you can enjoy finer images. (p. 13) 16:9 Signal name PAL 525/60 NTSC 4.43 NTSC 3.58 525(480)/60i 525(480)/60p 625(576)/50i 625(576)/50p 750(720)/50p 750(720)/60p 1125(1080)/50i 1125(1080)/60i 1125(1080)/50p 1125(1080)/60p PC input Note • The ratio varies depending on the programme, etc. If the ratio is greater than the standard "16:9", black bands •...
- Page 35 Technical Information When you receive the stereo / bilingual sound system, sound output modes can be selected by pressing the Stereo / Bilingual Sound Selection button. Audio Signal STEREO Mode Indicator NICAM ...Used in New Zealand, Singapore, Hong Kong etc. Regular broadcast Type of broadcast (Standard Audio)
- Page 36 • A PC may be connected to this TV so that the PC screen is displayed and sound is heard from the TV. PC signals that can be inputted: Horizontal scanning frequency 31 to 69 kHz; vertical scanning frequency • 59 to 86 Hz (more than 1,024 signal lines could result in incorrect display of the image).
-
Page 37: Faqs
FAQs Before requesting service or assistance, please follow these simple guides to resolve the problem. If problem still persists, please contact your local Panasonic dealer for assistance. White spots or shadow images (noise) • Check the position, direction, and connection of the aerial. Neither image nor sound is produced •... - Page 38 Problem Chaotic image, noisy No image can be displayed Blurry or distorted image (no sound or low volume) Unusual image is displayed No sound is produced Sound level is low or sound is distorted Sound is unusual Pictures from external equipment are unusual when the equipment is connected via HDMI...
-
Page 39: Licence
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI • Licensing LLC. HDAVI Control is a trademark of Matsushita Electric Industrial Co., Ltd. PRO-031-F01 Issue: 3.0 WARRANTY - New Zealand only Distributed in New Zealand by Panasonic New Zealand Limited... -
Page 40: Specifications
