Summary of Contents for Vax Energise Vibe C85-E2-Be
- Page 1 Energise Vibe ™ Let’s get started C85-E2-(Be,Pe,Re) vax.co.uk...
- Page 2 Let’s talk safety This vacuum cleaner is intended for household use only and NOT for commercial or industrial use. Basic • Only use the vacuum cleaner indoors on dry surfaces and safety keep the area you’re cleaning well lit. precautions •...
- Page 3 Children shall not play with the vacuum cleaner. Cleaning and user maintenance shall not be made by children without supervision. • Only Vax recommended tools and accessories should be used with this vacuum cleaner. Please keep instructions for further use.
- Page 4 Maintaining your carpets and hard floors will ensure they keep their appearance for longer. You’ve chosen the carpets and hard floors for your home for a reason and Vax will help you take good care of them. Taking care of your Energise Vibe™ product Also inside this guide are instructions on maintaining your new machine, so that it’s always ready...
-
Page 5: Getting Started
Energise Vibe™ Contents (Included with all models) Included with your machine Let’s talk safety Getting to know your machine Hose Getting started Telescopic extension tube Using your machine Combination floorhead Taking care of your machine 3-in-1 Tool Let’s talk technical Pre-motor Accessories filter... -
Page 6: Technical Specification
Wattage See rating label on machine for details Upholstery Tool (type 3) Dusting Brush (Type 5) 1-1-132116-00 1-9-127512-00 Cord Length 5m TurboTool (Type 6) Hard Floor Tool (Type 3)* Weight 4.3kg 1-1-134419-00 1-1-135705-00 To purchase consumables and accessories, please visit vax.co.uk Subject to technical change without notice. -
Page 7: Before You Begin Cleaning
Getting started PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE Before you begin cleaning CAUTION: Always switch off the vacuum cleaner before connecting or disconnecting the hose/attachments, or removing and emptying the dirt container. IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the thermostat will automatically turn the vacuum cleaner off. -
Page 8: Using Your Machine
Using your machine IMPORTANT: The base of the vacuum cleaner should always be positioned flat on the floor when starting and in use. The dirt container should be locked into place before lifting the vacuum cleaner by the carry handle. IMPORTANT: The power cord must always be completely unwound, do not pull further than the yellow marker. -
Page 9: Cleaning The Pre-Motor Filter
Cleaning the pre-motor filter NOTE: Clean the pre-motor filter every time the dirt container is emptied and replace the filters every 12 months. Filters available at www.vax.co.uk Turn the dirt container Lift to remove the Tap the filter against a bin... - Page 10 Taking care of your machine Cleaning the shroud Turn the dirt container Lift to remove the Using central grips lift lid anti-clockwise. pre-motor filter out to remove separator to remove. of dirt container. from dirt container. Twist grips clockwise Tap the separator and remove cap against a bin to from separator.
-
Page 11: Storing Your Vacuum Cleaner
Taking care of your machine Post-motor filter maintenance IMPORTANT: The exhaust filter is designed to offer long life with no maintenance. The filter should be checked periodically and when heavily discoloured it should be replaced. Please do not wash, scrub or brush the filter as this will damage the delicate filter media. - Page 12 Let’s talk technical Removing blockages from the TurboTool (some models only) Slide the locking ring Lift and separate to remove. the housing. Tabs Using a pair of scissors, Line up the tabs on front of remove any threads housing and push together or hair caught around to refit.
- Page 13 Accessories Don’t forget your accessories! Order at: www.vax.co.uk/spares-and-solutions Pro Cleaning Kit (Type 2) 1-1-133326-00 All our best tools all in one kit that makes cleaning your home quicker, easier and with even better results. We’ve taken care of cleaning all of the hard to reach...
-
Page 14: What To Do If It Goes Wrong
What to do if it goes wrong Problem Solution • Check the ‘This pack contains’ panel on the box to make sure the part is included with your vacuum cleaner. Is there an accessory missing? • The dirt container may not be correctly fitted, remove the dirt container from the vacuum cleaner and check it’s assembled correctly, refit ensuring it’s locked into place. - Page 15 Getting in touch * Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling. † Registration required. Terms and conditions apply, see vax.co.uk for details.
- Page 16 Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. © 2014 All rights reserved. VAX®, VAX Lozenge are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
