Page 1: Table Of Contents
8.11. Remote Control Signal Receiving Sound 6 Block Diagram 9 Operating Instructions 7 Wiring Diagram 10 Installation Instructions 8 Operation Details 10.1. Safety Precautions © 2005 Panasonic HA Air-Conditioning (M) Sdn Bhd (11969-T). All rights reserved. Unauthorized copying and distribution is a violation of law. -
Page 2: Features
CS-PW18DKE CU-PW18DKE 10.2. Indoor Unit 14 Technical Data 10.3. Outdoor Unit 14.1. Thermostat Characteristics 14.2. Sensible Capacity Chart 11 Installation And Servicing Air Conditioner Using R410A 14.3. Operation Characteristics 11.1. Outline 11.2. Tools For Installing/Servicing Refrigerant Piping 15 Exploded View (Indoor Unit) 11.3. -
Page 3: Functions
CS-PW18DKE CU-PW18DKE 2 Functions 2.1. Remote Control AUTO SPEED COOL SWING TIMER TIMER OFF/ON MODE FAN SPEED TEMP AIR SWING TIMER CANCEL CANCEL CLOCK RESET ON-TIMER OFF / ON OFF-TIMER Operation Start / Stop Timer Operation Selection MODE • 24-hour, OFF / ON Real Timer Setting. -
Page 4: Indoor Unit
CS-PW18DKE CU-PW18DKE 2.2. Indoor Unit AUTO OFF / ON Automatic Operation Button Airflow Direction Control • Vertical airflow control can be adjusted • Press for < 5 second to operate Automatic automatically or manually by remote control. operation mode. Used when the remote •... -
Page 5: Outdoor Unit
CS-PW18DKE CU-PW18DKE 2.3. Outdoor Unit Compressor Reverse Rotation Deice Control Protection Control • To prevent frosting at outdoor heat • To protect compressor from reverse exchanger during Heating Operation. rotation when there is an instantaneous power failure. 4-Way Valve Control •... -
Page 6: Product Specifications
CS-PW18DKE CU-PW18DKE 3 Product Specifications 3.1. CS-PW18DKE CU-PW18DKE Unit CS-PW18DKE CU-PW18DKE Power Source (Phase, Voltage, Cycle) ø, V, Hz Single, 230, 50 Cooling Capacity kW (BTU/h) 5.10 (17,400) Heating Capacity kW (BTU/h) 5.30 (18,100) Moisture Removal l/h (Pint/h) 2.9 (6.1) - Page 7 CS-PW18DKE CU-PW18DKE Unit CS-PW18DKE CU-PW18DKE Heat Exchanger Description Evaporator Condenser Tube material Copper Copper Fin material Aluminium (Pre Coat) Aluminium (Precoat) Fin Type Slit Fin Corrugated Fin Row / Stage (Plate fin configuration, forced draft) 2 × 15 2 × 20 Size (W ×...
-
Page 8: Dimensions
CS-PW18DKE CU-PW18DKE 4 Dimensions 4.1. Indoor Unit & Remote Control 4.1.1. CS-PW18DKE... -
Page 9: Outdoor Unit
CS-PW18DKE CU-PW18DKE 4.2. Outdoor Unit 4.2.1. CU-PW18DKE... -
Page 10: Refrigeration Cycle Diagram
CS-PW18DKE CU-PW18DKE 5 Refrigeration Cycle Diagram... -
Page 11: Block Diagram
CS-PW18DKE CU-PW18DKE 6 Block Diagram... -
Page 12: Wiring Diagram
CS-PW18DKE CU-PW18DKE 7 Wiring Diagram... -
Page 13: Operation Details
CS-PW18DKE CU-PW18DKE 8 Operation Details 8.1. Heating Operation • Heating operation can be set using remote control. • This operation is applied to warm the room temperature reaches the setting temperature set on the remote control. • The remote control setting temperature, which takes the reading of intake air temperature sensor, can be adjusted from 16°C to 30°C. -
Page 14: Cooling Operation
CS-PW18DKE CU-PW18DKE 8.2. Cooling Operation • Cooling operation can be set using remote control. • This operation is applied to cool down the room temperature reaches the setting temperature set on the remote control. • The remote control setting temperature, which takes the reading of intake air temperature sensor, can be adjusted from 16°C to 30°C. -
Page 15: Soft Dry Operation
CS-PW18DKE CU-PW18DKE 8.3. Soft Dry Operation • Soft Dry operation can be set using remote control. • Soft Dry operation is applied to dehumidify and to perform a gentle cooling to the room. • This operation starts when the intake air temperature sensor reaches the setting temperature on the remote control. -
Page 16: Automatic Operation
CS-PW18DKE CU-PW18DKE 8.4. Automatic Operation • Automatic operation can be set using remote control. • This operation starts to operate with indoor fan at SLo speed for 25 seconds to judge the intake air temperature. • After judged the temperature, the operation mode is determined by referring to the below standard. -
Page 17: Operation Control
CS-PW18DKE CU-PW18DKE 8.5. Operation Control (For 8.5.1 to 8.5.7 information applies only to Cooling and Soft Dry Operation) 8.5.1. Restart Control (Time Delay Safety Control) • When the thermo-off temperature (temperature which compressor stops to operate) is reached during:- − Cooling operation - the compressor stops for 3 minutes (minimum) before resume operation. -
Page 18: Compressor Reverse Rotation Protection Control
CS-PW18DKE CU-PW18DKE 8.5.5. Compressor Reverse Rotation Protection Control • If the compressor is operating continuously for 5 minutes or longer and the temperature difference between intake air and indoor heat exchanger is 2.5°C or less for continuous 2 minutes, compressor will stop and restart automatically. -
Page 19: Way Valve Control
CS-PW18DKE CU-PW18DKE (For 8.5.8 to 8.5.14 information applies only to Heating Operation) 8.5.8. Restart Control (Time Delay Safety Control) • When the thermo-off temperature (temperature which compressor stops to operate) is reached during:- − Heating operation - the compressor stops for 3 minutes (minimum) before resume operation. - Page 20 CS-PW18DKE CU-PW18DKE 8.5.12. Hot Start Control • Hot Start Control is to prevent cool air discharge into the room when heating operation start. • When Heating operation starts, Indoor fan will not start until the indoor heat exchanger reaches 30°C as diagram shown.
- Page 21 CS-PW18DKE CU-PW18DKE a) Normal Deicing Time Diagram (b) Overload Deicing Time Diagram...
-
Page 22: Indoor Fan Speed Control
CS-PW18DKE CU-PW18DKE 8.6. Indoor Fan Speed Control • Indoor Fan Speed can be set using remote control. 8.6.1. Fan Speed Rotation Chart Speed CS-PW18DKE Cool, Dry Heat S Hi 1460 1400 1320 1270 1190 S Lo S Lo SS Lo... - Page 23 CS-PW18DKE CU-PW18DKE • Auto Fan Speed during Soft Dry operation: 1. Indoor fan will rotate alternately between off and Lo-. 2. At the beginning of each compressor start operation, indoor fan will increase fan speed gradually for deodorizing purpose. 3. When compressor at turn off condition for 6 minutes, indoor fan will start fan speed at Lo- to circulate the air in the room.
-
Page 24: Outdoor Fan Speed Control
CS-PW18DKE CU-PW18DKE 8.7. Outdoor Fan Speed Control • There is only one speed for outdoor fan motor. • When the air conditioner is turned on, the compressor and the outdoor fan will operate simultaneously. • Likewise, both compressor and outdoor fan will stop at the same time if the unit is turned off. -
Page 25: Timer Control
CS-PW18DKE CU-PW18DKE 8.9. Timer Control • There are 2 types of timer, ON and OFF timer. • Both ON and OFF timer can be set by pressing ON or OFF button respectively. • By pressing ON/OFF operation button, ON Timer or OFF Timer will not be cancelled. -
Page 26: Operating Instructions
CS-PW18DKE CU-PW18DKE 9 Operating Instructions Thank you for purchasing Panasonic Air Conditioner SAFETY PRECAUTIONS I Definition To prevent personal injury, injury to others and property Installation Precautions Installation Precautions damage, the following instructions must be Warning followed. Do not install, remove and reinstall the unit by yourself. - Page 27 CS-PW18DKE CU-PW18DKE Note: The illustrations in this manual are for explanation purposes only and may differ from the actual unit. It is subjected to change without notice for future improvement. PRODUCT OVERVIEW I About Remote Control Preparation Air intake I ndoor Unit ndoor Unit 1.
- Page 28 CS-PW18DKE CU-PW18DKE HOW TO OPERATE I Operation Details Auto, Heat, Cool, Auto, Heat, Cool, Dr y Dr y AUTO - Automatic Operation • The unit will automatically select the operation mode according to the room temperature. • Once the operation mode is...
- Page 29 CS-PW18DKE CU-PW18DKE HOW TO OPERATE I Operations Details Fan Speed, Air Swing Fan Speed, Air Swing FAN SPEED • To provide you with the various fan speed selections. • There are 3 levels of fan speed in addition to automatic fan speed.
- Page 30 CS-PW18DKE CU-PW18DKE HOW TO OPERATE I Operation Details Timer Timer TIMER • Use the ON timer to turn on the air conditioner at the desired time. This will give you a cooling or warming environment, e.g. when you return from work or wake up.
- Page 31 CS-PW18DKE CU-PW18DKE CARE & CLEANING I Washing Instructions • Do not use benzene, thinner or Switch off the power supply Switch off the power supply scouring powder. before cleaning before cleaning • Use soaps or neutral household ≃ detergent ( pH7) only.
-
Page 32: Installation Instructions
CS-PW18DKE CU-PW18DKE 10 Installation Instructions Required tools for Installation Works 1. Philips screw driver 5. Spanner 9. Gas leak detector 13. Multimeter 2. Level gauge 6. Pipe cutter 10. Measuring tape 14. Torque wrench 18 N.m (1.8 kgf.m) 55 N.m (5.5 kgf.m) 65 N.m (6.5 kgf.m) - Page 33 CS-PW18DKE CU-PW18DKE CAUTION 1. This equipment must be earthed. It may cause electrical shock if grounding is not perfect. 2. Do not install the unit at place where leakage of flammable gas may occur. In case gas leaks and accumulates at surrounding of the unit, it may cause fire.
- Page 34 CS-PW18DKE CU-PW18DKE Attached accessories Indoor/Outdoor Unit Installation Diagram Applicable piping kit CZ-4F5, 7, 10BP Select the best location INDOOR UNIT • There should not be any heat source or steam near the unit. • There should not be any obstacles blocking the air circulation.
-
Page 35: Indoor Unit
CS-PW18DKE CU-PW18DKE 10.2. Indoor Unit 10.2.1. SELECT THE BEST LOCATION 10.2.3. TO DRILL A HOLE IN THE WALL (Refer to “Select the best location” AND INSTALL A SLEEVE OF section) PIPING 1. Insert the piping sleeve to the hole. 10.2.2. HOW TO FIX INSTALLATION 2. - Page 36 CS-PW18DKE CU-PW18DKE 3. For the embedded piping (This can be used for left rear piping & left bottom piping also.)
- Page 37 CS-PW18DKE CU-PW18DKE 10.2.5. CONNECT THE CABLE TO THE INDOOR UNIT 1. The inside and outside connecting cable can be connected without removing the front grille. 2. Connecting cable between indoor unit and outdoor unit shall be approved polychloroprene sheathed 5 × 2.5 mm flexible cord, type designation 245 IEC 57 or heavier cord.
- Page 38 CS-PW18DKE CU-PW18DKE HOW TO TAKE OUT FRONT GRILLE Please follow the steps below to take out front grille if necessary such as when servicing. 1. Open the intake grille. 2. Set the vertical airflow direction louvers to the horizontal position.
-
Page 39: Outdoor Unit
CS-PW18DKE CU-PW18DKE 10.3. Outdoor Unit 10.3.1. SELECT THE BEST LOCATION (Refer to “Select the best location” section) 10.3.2. INSTALL THE OUTDOOR UNIT • After selecting the best location, start installation according to Indoor/Outdoor Unit Installation Diagram. 1. Fix the unit on concrete or rigid frame firmly and horizontally by bolt nut. -
Page 40: Connect The Cable To The Outdoor Unit
CS-PW18DKE CU-PW18DKE 10.3.4. EVACUATION OF THE EQUIPMENT (FOR EUROPE & OCEANIA DESTINATION) WHEN INSTALLING AN AIR CONDITIONER, BE SURE TO EVACUATE THE AIR INSIDE THE INDOOR UNIT AND PIPES in the following procedure. 1. Connect a charging hose with a push pin to the Low and High side of a charging set and the service port of the 3-way valve. -
Page 41: Pipe Insulation
CS-PW18DKE CU-PW18DKE 10.3.6. PIPE INSULATION 1. Please carry out insulation at pipe connection portion as mentioned in Indoor/Outdoor Unit Installation Diagram. Please wrap the insulated piping end to prevent water from going inside the piping. 2. If drain hose or connecting piping is in the room (where dew may form), please increase the insulation by using POLY-E FOAM with thickness 6 mm or above. -
Page 42: Installation And Servicing Air Conditioner Using R410A
CS-PW18DKE CU-PW18DKE 11 Installation And Servicing Air Conditioner Using R410A 11.1. Outline 11.1.1. About R410A Refrigerant 1. Converting air conditioners to R410A Since it was declared in1974 that chlorofluorocarbons (CFC), hydro chlorofluorocarbons (HCFC) and other substances pose a destructive danger to the ozone layer in the earth´s upper stratosphere (20 to 40 km above the earth), measures have been taken around the world to prevent this destruction. -
Page 43: Tools For Installing/Servicing Refrigerant Piping
CS-PW18DKE CU-PW18DKE d. R410A refrigerating machine oil Conventionally, mineral oil or a synthetic oil such as alkylbenzene has been used for R22 refrigerating machine oil. Because of the poor compatibility between R410A and conventional oils like mineral oil, however, there is a tendency for the refrigerating machine oil to collect in the refrigerating cycle. -
Page 44: R410A Tools
CS-PW18DKE CU-PW18DKE 11.2.2. R410A Tools 1. Copper tube gauge for clearance adjustment (used when flaring with the conventional flaring tool (clutch type)) • This gauge makes it easy to set the clearance for the copper tube to 1.0-1.5 mm from the clamp bar of the flaring tool. - Page 45 CS-PW18DKE CU-PW18DKE 5. Charging hose • The pressure resistance of the charging hose has been raised to match the higher pressure of R410A. The hose material has also been changed to suit HFC use, and the size of the fitting has been changed to match the manifold ports.
- Page 46 CS-PW18DKE CU-PW18DKE 8. Electronic scale for refrigerant charging • Because of the high pressure and fast vaporizing speed of R410A, the refrigerant cannot be held in a liquid phase inside the charging cylinder when charging is done using the charging cylinder method, causing bubbles to form in the measurement scale glass and making it difficult to see the reading.
-
Page 47: Refrigerant Piping Work
CS-PW18DKE CU-PW18DKE 11.3. Refrigerant Piping Work 11.3.1. Piping Materials It is recommended that you use copper and copper alloy jointless pipes with a maximum oil adherence of 40 mg/10m. Do not use pipes that are crushed, deformed, or discolored (especially the inside surface). If these inferior pipes are used, impurities may clog the expansion valves or capillaries. - Page 48 CS-PW18DKE CU-PW18DKE Table 11 R410A flaring dimensions Nominal Outside Wall thickness A (mm) diameter diameter (mm) R410A flaring Conventional flaring tool (mm) tool, clutch type Clutch type Wing-nut type 6.35 0 - 0.5 1.0 - 1.5 1.5 - 2.0 9.52 0 - 0.5...
-
Page 49: Refrigerant Piping
CS-PW18DKE CU-PW18DKE b. Copper pipes Use only copper pipes with the thickness given in table 10, and with minimal impurities. Because the surface of the pipe is exposed, you should take special care, and also take measures such as marking the pipes to make sure they are easily distinguished from other piping materials, to prevent mistaken use. -
Page 50: Transferring (Using New Refrigerant Piping)
CS-PW18DKE CU-PW18DKE 11.4.2. Transferring (Using New Refrigerant Piping) 1. Removing the unit a. Collecting the refrigerant into the outdoor unit by pumping down The refrigerant can be collected into the outdoor unit (pumping down) by pressing the TEST RUN button, even when the temperature of the room is low. -
Page 51: Recharging Refrigerant During Servicing
CS-PW18DKE CU-PW18DKE 11.4.5. Recharging Refrigerant During Servicing When recharging is necessary, insert the specified amount of new refrigerant in accordance with the following procedure. 1. Connect the charging hose to the service port of the outdoor unit. 2. Connect the charging hose to the vacuum pump adaptor. At this time, fully open the 2-way valve and 3-way valve. - Page 52 CS-PW18DKE CU-PW18DKE 11.4.6. Brazing As brazing requires sophisticated techniques and experiences, it must be performed by a qualified person. In order to prevent the oxide film from occurring in the pipe interior during brazing, it is effective to proceed with brazing while letting dry nitrogen gas (N ) flow.
-
Page 53: Servicing Information
CS-PW18DKE CU-PW18DKE 12 Servicing Information 12.1. Distinction Of Lead Free (PbF) Printed Circuit Board • Printed circuit boards (manufactured) using lead free solder will have a PbF stamp on the Printed Circuit board. CAUTION • Pb free solder has a higher melting point than standard solder; typically the melting point is 50 - 70°F (30 - 40°C) higher. -
Page 54: Cross Flow Fan And Indoor Fan Motor Removal Procedures
CS-PW18DKE CU-PW18DKE 2. To remove the Electronic Controllers: • Release the 2 Particular Piece. (Fig. 3) • Release the Earth Wire screw. (Fig. 3) • Release the terminal board holder screw. (Fig. 3) • Release the CN-DISP connector. (Fig. 3) •... -
Page 55: Remote Control Reset
CS-PW18DKE CU-PW18DKE 4. Remove the screw at the Cross Flow Fan. (Fig. 7) Fig. 7 5. Remove the Bearing. (Fig. 8) 6. Remove the screws at the left of the Evaporator. (Fig. 8) Fig. 8 7. Push up the Evaporator and pull out the Cross Flow Fan from shaft. -
Page 56: Select Remote Control Transmission Code
CS-PW18DKE CU-PW18DKE 12.5. Auto OFF/ON Button • The “Auto OFF/ON Button” (behind the front grille) is used to operate the air conditioner if remote control is misplaced or mulfunctioning. • Forced cooling operation is possible by pressing the “Auto OFF/ON Button” for more than 5s where “beep” sound is heard then release the button. -
Page 57: Troubleshooting Guide
CS-PW18DKE CU-PW18DKE 13 Troubleshooting Guide 13.1. Refrigeration Cycle System In order to diagnose malfunctions, make sure that there are no electrical problems before inspecting the refrigeration cycle. Such problems include insufficient insulation, problem with the power source, malfunction of a compressor and a fan. -
Page 58: Relationship Between The Condition Of The Air
CS-PW18DKE CU-PW18DKE 13.2. Relationship Between The Condition Of The Air Conditioner And Pressure And Electric Current Cooling Mode Heating Mode Condition of the air conditoner Low Pressure High Pressure Electric current Low Pressure High Pressure Electric current during operation during operation... -
Page 59: Technical Data
CS-PW18DKE CU-PW18DKE 14 Technical Data 14.1. Thermostat Characteristics 14.1.1. CS-PW18DKE... -
Page 60: Sensible Capacity Chart
CS-PW18DKE CU-PW18DKE 14.2. Sensible Capacity Chart G CS-PW18DKE 230V Outdoor Temp. (°C) Indoor wet bulb temp. 17.0°C 5.06 3.83 1.60 4.73 3.68 1.72 4.40 3.53 1.84 4.00 3.36 1.99 19.0°C 5.10 1.75 19.5°C 5.55 4.02 1.63 5.19 3.86 1.676 4.83 3.71... -
Page 61: Operation Characteristics
CS-PW18DKE CU-PW18DKE 14.3. Operation Characteristics 14.3.1. CS-PW18DKE CU-PW18DKE... -
Page 62: Exploded View (Indoor Unit)
CS-PW18DKE CU-PW18DKE 15 Exploded View (Indoor Unit) 15.1. CS-PW18DKE Note: The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts. -
Page 63: Replacement Parts List (Indoor Unit)
CS-PW18DKE CU-PW18DKE 16 Replacement Parts List (Indoor Unit) 16.1. CS-PW18DKE REF. NO. PART NAME & DESCRIPTION QTY. CS-W18DKE REMARKS CHASSY COMPLETE CWD50C1394 FAN MOTOR CWA981149 CROSS FLOW FAN COMPLETE CWH02C1010 SCREW - CROSS FLOW FAN CWH4580304 BEARING ASS’Y CWH64K007 EVAPORATOR... -
Page 64: Exploded View (Outdoor Unit)
CS-PW18DKE CU-PW18DKE 17 Exploded View (Outdoor Unit) 17.1. CU-PW18DKE Note: The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts. -
Page 65: Replacement Parts List (Outdoor Unit)
CS-PW18DKE CU-PW18DKE 18 Replacement Parts List (Outdoor Unit) 18.1. CU-PW18DKE REF. NO. PART NAME & DESCRIPTION QTY. CU-PW18DKE REMARKS CHASSY ASS’Y CWD50K2101 SOUND PROOF MATERIAL CWG302253 FAN MOTOR BRACKET CWD541030 SCREW - FAN MOTOR BRACKET CWH551059 FAN MOTOR AC 30W SINGLE... -
Page 66: Electronic Circuit Diagram
CS-PW18DKE CU-PW18DKE 19 Electronic Circuit Diagram 19.1. Indoor Unit & Outdoor Unit G CS-PW18DKE CU-PW18DKE SCHEMATIC DIAGRAM 1/4 ELECTRONIC CONTROL UNIT CN-SONIC BZ01 INDICATOR COMPLETE IC201 R201 47Ω C201 47µ CN-DISP 6.3V CN-DISP D201 TIMER (ORG) POWER (GRN) D202 0.1µ... - Page 67 CS-PW18DKE CU-PW18DKE SCHEMATIC DIAGRAM 2/4 10Ω 0.01µ 5.1k 6.2k 6.2k P50/A8 RY-PWR DRIVE SIGNAL STEPPING TIMER SHORTEN P51/A9 MOTOR DRIVE P03/NTP3 AUTO OPERATION SIGNAL P52/A10 TEST RUN P02/NTP2 REMOTE CONTROL BUZZER SOUND P53/A11 P01/NTP1 DISPLAY P54/A12 POWER CLOCK INPUT P00/NTP0...
- Page 68 CS-PW18DKE CU-PW18DKE SCHEMATIC DIAGRAM 3/4 IC08 IC09 REGULATOR REGULATOR DB02 3300µ 410µ 100µ 0.01µ 0.01µ DB03 100k 0.22µ 0.22µ 0.1µ 100k 450V 20kΩ PC03 100Ω 3.9k RY-PWR TH01 TH02 1/4W 1/4W 1/4W 1/4W 0.1µ 330k FUSE T 3.15A L 250V...
- Page 69 CS-PW18DKE CU-PW18DKE SCHEMATIC DIAGRAM 4/4 BLK/BLU COIL (4-WAYS VALVE) POWER SUPPLY TEMPERATURE FUSE COMP (VLT) AC1 (WHT) HOT 1 (RED) DEICE (GRY) HOT 2 (BLK) ELECTRONIC CONTROLLER CAPACITOR DB01 DB02 TO OUTDOOR (BRW) BRW or YLW FAN MOTOR CAPACITOR...
- Page 70 CS-PW18DKE CU-PW18DKE...
- Page 71 CS-PW18DKE CU-PW18DKE How to use electronic circuit diagram TIMER TABLE Test Mode Name Time (When test point Remarks Short-circuited) Real Timer 1 hr. 1 min. 10 min. 10 sec. 1 min. 1 sec. Time Delay Safety Control 2 min. 58 sec.
-
Page 72: Remote Control
CS-PW18DKE CU-PW18DKE 19.2. Remote Control... -
Page 73: Print Pattern Indoor Unit Printed Circuit Board
CS-PW18DKE CU-PW18DKE 19.3. Print Pattern Indoor Unit Printed Circuit Board... - Page 74 CS-PW18DKE CU-PW18DKE...
-
Page 75: Print Pattern Outdoor Unit Printed Circuit Board
CS-PW18DKE CU-PW18DKE 19.4. Print Pattern Outdoor Unit Printed Circuit Board... -
Page 76: Print Pattern Indicator & Receiver Printed Circuit Board
CS-PW18DKE CU-PW18DKE 19.5. Print Pattern Indicator & Receiver Printed Circuit Board [PHAAM] Printed in Malaysia...
