User Manual
AQ6
Ultra-compact, full-range system
features
Q
Wide 90° x 90˚ dispersion
Q
6.5" (165mm) direct radiating LF driver &
1" (25mm) horn-loaded dome tweeter
Q
Light weight structural foam enclosure
Q
1st & 2nd fix wall and ceiling brackets available
Q
Five year limited warranty
applications
Q
Clubs, bars and restaurants
Q
Theatres
Q
Places of worship
The AQ6 is a two-way passive loudspeaker designed to fulfill the
requirement for dynamic performance from a very small,
architecturally friendly, vented enclosure. It features a 6.5"
(165mm) direct radiating, long-throw bass driver and a 1"
(25mm) doped fabric dome tweeter coupled to a 90° x 90˚
HF horn.
overall dimensions
technical specifications
TYPE
Ultra-compact, two-way passive,
vented trapezoid
FREQUENCY RESPONSE (5) 80Hz-20kHz ± 3dB
DRIVERS
6.5" (165mm) bass driver
1" (25mm) horn loaded dome tweeter
RATED POWER (2)
100W AES, 400W peak
RECOMMENDED
100-200W into 4 ohms
AMPLIFIER
SENSITIVITY (6)
90dB
MAXIMUM SPL (7)
108dB continuous, 114dB peak
NOMINAL IMPEDANCE
8 ohms
DISPERSION (-6dB)
90º horizontal, 90º vertical
CROSSOVER
3.5kHz passive
ENCLOSURE
9 litre, structural foamed ABS
FINISH
Textured light grey paint
PROTECTIVE GRILLE
Light grey perforated steel
CONNECTORS
Low profile 12 amp push-lock
FITTINGS
4 x M6 inserts for bracket
1 x M6 insert for safety point
OPTIONS
30W 100/70V line transformer
DIMENSIONS
(W) 207mm x (H) 316mm x (D) 207mm
(W) 8.2ins x (H) 12.5ins x (D) 8.2ins
WEIGHT
6kg (13.2lbs)
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: info@martin-audio.com
All information is Copyright © 2003 Martin Audio Ltd.
www.martin-audio.com
