- Page 1 Stapler / Folder Model 61 Operator Manual March 1994 The Belt Stacker shown Part No. 61086 is optional...
-
Page 2: Table Of Contents
Set up for odd paper size 4.10 Reset to standard paper size Only OFF-line 5. Maintenance Cleaning fold rollers Cleaning of rear jogger rollers 6. Problem solving Trouble shooting table 7. Specifications Specification table STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 3: Introduction
Always keep magnets and all devices with power cord from the power source receptacle strong magnetic field away from the machine. and call your customer service engineer to correct the problem. STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 4: Installation
3. Roll the Stapler / Folder up against the Collator make sure that the Collator studs enter the attachment bracket on the Stapler / Folder for the correct paper size. STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 5: Main Components
Press area, machine release (Press here and the Stapler / Folder will be released from the Collator and can be rolled away) Control panel Fold stop assembly Belt stacker (Optional accesory) STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 6: Infeed Section, Upper
5. Side jogger, front 6. Upper guide, side jogger 7. Release handle, side jogger 8. Scale, paper width 9. Anvil 10. Release handle, side jogger 11. Scale upper pressure roller assembly STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 7: Infeed Section, Collator Side
(The connection cable from the Collator connects here) Knob, adjustment for odd paper size (by loosening the knob the attachment bracket can be individually positioned for odd paper sizes) Attachment bracket STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 8: Control Panel
Automatic start ON / OFF (can only be used OFF-line) Time delay (can only be used OFF-line) Manual start button (can only be used OFF-line) * Not included in the conversion kit. STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 9: Operator Instructions
4.2 Set up of Stapler–Folder (folding only) Same procedure as above with the exeption that on item # 11 the switch is set to OFF position and item #9 is not performed. STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... - Page 10 4.4 Set up of Stapler–Folder (folding/OFF-line) Same procedure as above with the exeption that on item # 11 the switch is set to OFF position and item #10 is not performed. STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002...
- Page 11 15. Flip down the fold stop to enable the sets to pass through the machine. 16. Set the power switch to ON position. Note: By using the adapter (optional) either the belt stacker or the delivery tray can be used for stacking of stapled sets STAPLER / FOLDER MODEL 61 OPERATOR MANUAL...
-
Page 12: Set Up Of Stapler-Folder (Block Stapling/Off-Line Option 2)
11. Set the stapling switch to ON position. 12. Set the folding switch to OFF position. 13. Select manual start. 14. Close the top cover. 15. Set the power switch to ON position. STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 13: Operating The Stapler / Folder On-Line
When operating, insert one set at a time. Align the set with your finger tip. When automatic mode is selected, set time delay to allowe careful alignment. NOTE: The manual start button will light up when the next set may be inserted STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 14: Set Up For Odd Paper Size
(green marked side). Lossen the knob for adjustment to odd paper sizes. Slide the attachment bracket back to align it with the chassis in the Stapler–Folder, it will lock into place. STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 15: Maintenance
5. Maintenance 5.1 Cleaning of fold rollers Clean these regularly with an alcoholic based cleaning liquid. 5.2 Cleaning of jogger rollers Clean these regularly with an alcoholic based cleaning liquid. STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 16: Problem Solving
STAPLER / FOLDER MODEL 61 OPERATOR MANUAL T10129 January 2002... -
Page 17: Specifications
