Pentair PB5RO-75 User Manual

Model PB5RO-75 Undersink Reverse Osmosis System
User Manual
OPERATING SPECIFICATIONS
Before installing the system, make certain
WARNING:
your water supply complies with the
following operating specifications. Failure
to do so may reduce the effectiveness
of the system and will void the warranty.
Consult your local water treatment utility or
a certified water testing lab to determine the
quality of your water and use the table below
to record your results for future reference.
PB5RO-75 Specifications
Pressure Range:
Temperature Range:
Total Dissolved Solids
Maximum Hardness* :
†
Sulfide, Iron and Manganese :
†
Chlorine in Water Supply:
Water Supply pH Limits:
Turbidity:
Date of Purchase:
*
If the hardness of your water is above 10 gpg (171 mg/L), lime scale will build
up rapidly on the membrane inside of the RO membrane cartridge. Scale
buildup will plug the RO membrane cartridge and make the system ineffective.
We do not recommend the PB5RO to be used with water in excess of 10 gpg
(171 mg/L) hardness, unless the water is softened prior to the reverse osmosis
system.
†
See your local dealer or water treatment specialist to reduce these substances
in your water.
PB5RO-75 Dimensions:
System Dimensions 13" H x 18.6" W x 4.75" D
(330 x 3472 x 120.6 mm)
Tank Dimensions 14.5" H x 11" Dia
(368 x 279 mm)
System Weight 29 lbs (10.4 kg)
Tank Capacity 3.2 gal (12.1 L)
Your Water
40–100 psi
(2.8–6.9 bar)
40–100°F
(4.4-37.8°C)
< 2000 ppm
10 gpg
(171 mg/L)
< 0.1
< 2 ppm
3-11
5 NTU Max.
Tools Required
• Hand or Electric Drill
• 2 Adjustable Wrenches
• File
• Pencil
• Needle-nose Pliers
• Utility Knife or Tube Cutter
(for plastic tubing)
Optional Materials
(For sinks without extra hole for faucet)
• Hand or Electric Drill
• Drill Bits: 1/4" and 3/4"
• Teflon Tape
®
NOTE: All tools listed will not be necessary for installation.
Read installation procedures before starting to
determine required tools.
Parts Included
• Head Assembly
• Screws for mounting
• Lead-free air gap drinking
water faucet
• Silicone grease
• Tank Valve
• Teflon Tape
®
• 3/8" Plastic Tubing
(red and blue)
• TDS Test Kit
• Filter Cartridges:
PW-S2500R Cartridge Yellow
PW-C5000R Cartridge Blue
PW-RO75R Cartridge Green
PW-C2500R Cartridge Violet
• Phillips Screwdrivers
• Drill Bits: 1/8", 1/4" and 3/8"
• Towel
• Safety Glasses
• Tape Measure
• Center punch
• Respirator
• 1-3/8" Bi-metal or Carbide
Tipped Hole-saw
• Drain Saddle Valve
• Water Supply Adapter
• Quick-connect Fitting
• Storage Tank
• Faucet Adapter
• Change Indication Sticker
• 1/4" Plastic Tubing
(white, red and green)
247181 Rev D JA12
