Graco ULTRA MAX II - MARK V Quick Operator's Manual

WARNING
SETUP
Connect hose to sprayer and gun.
Tighten hose connections with wrench.
Turn prime valve Place siphon tube in pail
to Prime position (down). partially filled with water.
Aim gun at inside
Make sure safety wall of water pail
lever of gun is OFF. and squeeze trigger.
Increase pressure until Keeping gun triggered into
sprayer starts and paint water pail, turn prime valve
comes out of drain tube. to Spray position (horizontal).
OPTIONS
WATCHDOG (Ultra Max II range only)
™ ®
Turn WatchDog switch ON
and WatchDog ON displays.
E-Control (platinum range only)
™
Set pressure high enough to spray. The E-Control
acts in place of the pressure control knob when
the sprayer is in E-Control mode.
www.kbs.se
www.graco.be
ULTRA MAX II - MARK V
®
Premium & Platinum
MARK X
™
Quick Operator's Guide
Unscrew tip & guard from gun.
Turn pressure control knob to
lowest pressure (platinum range
only), and set power switch to ON.
Increase pressure
until sprayer starts.
Keep gun triggered into
water pail for 1 minute.
Release trigger.
When paint comes out of gun,
release trigger and turn safety
lever of gun to ON.
Empty displays/flashes and pump stops when WatchDog
protection system detects an empty material pail.
Press the E-Control UP or DOWN
to increase or decrease the stall
pressure setting by 3 bar.
This procedure is for water-base paints and flushing fluids. For solvent-base paints and flushing
fluids (i.e. mineral spirits), you must read Fire and Explosion Hazard in the Operating Instructions.
* check the Graco operations manual delivered with the unit for more details.
Fill throat packing nut with TSL ™
to prevent premature packing wear.
Increase pressure until
sprayer starts and water
runs out of prime tube.
Let water run out of
prime tube for 15 seconds.
Turn prime Place siphon tube in paint
valve to Prime pail, but leave drain tube
position (down). in water pail.
Transfer drain
tube to paint pail.
Turn WatchDog switch OFF. Add material or reprime sprayer.
Turn pump switch OFF and ON to reset WatchDog protection system.
If the stall pressure reaches
the limit in either direction
the sprayer beeps 3 times.
™
Make sure power Plug electrical cord
switch is set to OFF. into grounded outlet.
Decrease pressure until
sprayer stops. Make sure Turn prime valve
you are not in E-Control* to Spray position
mode. (*platinum range only). (horizontal).
Aim gun at inside
wall of water pail,
and squeeze trigger.
Screw tip & guard onto gun, making sure
arrow-shaped handle of tip is pointing forward.
You can reverse this tip to quickly clear clogs
without taking it apart.
If the E-Control UP or DOWN is pressed
and held, the stall pressure will change
to maximum sprayer setting or 0 bar.
