Page 1: Service Information
5407383 Issue 1 May 2007 HOTPOINT FREESTANDING FREEZERS Model Comm. Covered Code RZ150P 44354 RZ150G 44355 Service Information Indesit Company UK Ltd © 2007 Reg. Office: Peterborough PE2 9JB Registered in London: 106725... - Page 2 Indesit Company HEALTH AND SAFETY For the servicing of refrigeration products, containing Isobutane R600a refrigerant. These instructions are in addition to any other Company procedures already published. Published primarily for Indesit Company engineers working in the UK or Southern Ireland, for which these instructions are MANDATORY.
- Page 3 Indesit Company HEALTH AND SAFETY 19. Working with a naked flame i.e. soldering or brazing is forbidden. Unless otherwise stated, pipework connections must only be made using the Lokring coupling system. 20. Electronic leak detectors with high voltage tips must NOT be used with any Isobutane (R600a). 21.
- Page 4 Indesit Company CONTENTS Health & Safety ........... . .2 - 3 Index &...
- Page 5 Indesit Company MODEL INTRODUCTION The models included in this publication are 1500 and 1700 mm high static freezers that were introduced in March 2007. Models are A Band appliances with similar appearance furniture. For colour information, refer to the Specifications page. The appliance is 'static' design so defrosting is actioned manually.
-
Page 6: Specifications
Indesit Company SPECIFICATIONS Introduction Date - March Colours 2007 Polar White RZ150P Graphite RZ150G GENERAL: Manufactured in Great Britain: Appliance Type Freezer Static / Frost Free Static Door Reversibility Plug/Cable UK / 1.6M Noise Level A band models ~ 43dB - A+ band models 40dB Climate Class (Rating Plate) A band ~ SN.N.ST = 10°C to 38°C... - Page 7 Indesit Company TECHNICAL DATA: Power Supply Voltage: 220/240 V Power Supply Frequency: 50 Hz Absorption Current: Normal Operation 0.7 Amps COMPRESSOR WINDING Ω: Manufacturer: JIAXIPERA Type I/D: ZBT1114CY Winding Resistance Ω: Start: 16.0 Run: 13.3 Refrigerant/ Grams: R600a - Refer to the appliance rating plate ENERGY: Model: RZ150...
-
Page 8: Description Of Appliance
Indesit Company DESCRIPTION OF APPLIANCE: TEMPERATURE CONTROL PANEL POWER TEMPERATURE SUPER FREEZE Indicator Lamp Control Knob Button SUPER FREEZE ALARM Indicator Lamp Indicator Lamp APPLIANCE INTERIOR TEMPERATURE Control FREEZER and STORAGE Compartments STORAGE Compartments LEVELLING Feet Service Manual UK English 8 of 15... - Page 9 Indesit Company NOTES Service Manual UK English 9 of 15...
-
Page 10: Reversing The Doors
Indesit Company REVERSING THE DOORS Important Notes for Guidance: Before commencing any work refer to the Safety Notes at the beginning of this manual. Read the instructions on the next page fully and refer to the diagrams below before carrying out the door reversal. - Page 11 Indesit Company REVERSING THE DOORS Fig 1: Removing the Door and Top Hinge fittings Open the door and ease the hinge cover strip out from above the door seal; starting from the area nearest to the hinge. Also remove the plastic plug button above the hinge pin at the top of the door. Remove the hinge pin, whilst supporting the door.
- Page 12 Indesit Company WIRING CONNECTIONS CONTROL HARNESS PLUG CONTROL HARNESS SOCKET Front View Rear View Foamed in Place 1 ~ Not used 1 ~ Not Used 2 ~ Blue ~ Indicator Lamps Neutral 2 ~ Blue ~ Neutral 3 ~ Not Used 3 ~ Not Used 4 ~ Brown ~ Thermostat (3) 4 ~ Brown ~ Live...
- Page 13 Indesit Company WIRING CONNECTIONS SUPER FREEZE SWITCH ~ Yellow ~ Link from Terminal (3) ~ Orange ~ Super Freeze Indicator Lamp ~ Yellow x 2 ~ Link to Terminal (1) and Control Harness Plug (4) ~ Black ~ Link to Thermostat (4) CONTROL PANEL INDICATOR LAMPS Thermostat (6) Alarm...
- Page 14 Indesit Company THEORETICAL WIRING DIAGRAM ELECTROLUX - (ACC/ZEM) & JIAXIPERA COMPRESSORS THERMOSTAT SUPER FREEZE SWITCH SUPER POWER ALARM FREEZE INDICATOR INDICATOR INDICATOR LAMP OVERLOAD LAMP LAMP CAPACITOR (if fitted) COMPRESSOR Service Manual UK English 14 of 15...
- Page 15 Indesit Company PARTS ACCESSORIES To order parts and accessories contact our National Mail Order Parts Hotline 08709 077 077 Monday to Friday 8.00am to 5.30pm Saturday 8.30am to 12.00 noon or online at : www.theservicecentre.co.uk Service Manual UK English 15 of 15...
