Summary of Contents for Midland GXT2000
-
Page 2: Features
To maintain compliance with FCC’s RF exposure guidelines, for body-worn operation, this radio has been tested and meets the FCC RF exposure guidelines when used with Midland Radio Corp. accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. - Page 3 FCC at 1-888-CALL FCC or go to the FCC’s website: http://www.fcc.gov and request form 605. Exposure To Radio Frequency Energy Your Midland radio is designed to comply with the following national and inter- national standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy:...
-
Page 4: Controls
Model GXT2000/2050 Series LCD DISPLAY 1. BATTERY METER – Indicates the battery level. 2. TRANSMIT (TX) / RECEIVE (RX) ICON – Indicates radio is transmitting (TX) a signal, or radio is receiving (RX) a transmission. 3. CHANNEL NUMBER – Changes from 1~50 on GMRS/FRS band (1~10 on WX band). -
Page 5: Battery Installation
Model GXT2000/2050 Series BATTERY INSTALLATION Your GXT2000/2050 Series radio operates with a Li-Polymer battery pack. The belt clip should be removed (see below) to ease installation or removal of the batteries. To install the batteries: 1. With the back of the radio facing you, remove the belt clip (see... -
Page 6: Charging The Battery Pack
Model GXT2000/2050 Series CHARGING THE BATTERY PACK Your GXT2000/2050 Series is equipped for using a rechargeable Li-Polymer battery pack (BATT12Li) which can be recharged using a 18CVP13 desktop charger. For maximum battery life, we recom- mend charging the battery pack when the low battery icon comes on. -
Page 7: Transmitting And Receiving A Call
Model GXT2000/2050 Series When the battery level is low, the Battery Shell icon and “Lo bt” will flash in the display indicating your batteries should be replaced or recharged if using a rechargeable battery pack. OPERATING YOUR RADIO POWER ON/OFF AND VOLUME Rotate the POWER/VOLUME knob clockwise to turn the radio on and increase the volume level. - Page 8 3 seconds again to get out of MONITOR mode. SCAN Your GXT2000/2050 Series can scan all 50 channels for activity. To enter, quickly press the SCAN button. Repeat the same procedure to exit. Your radio will rapidly scan each of the 50 channels and stop on any active channel.
-
Page 9: Call Alert
Model GXT2000/2050 Series CALL ALERT Your GXT2000/2050 Series can transmit a call alert for a fixed length of time. To send a call alert, press the CALL button. The TX icon will appear while transmitting a call alert and a tone can be heard on the speaker for confirmation. -
Page 10: Setting Privacy Codes
Code can only be set in channels 1~22. TRANSMIT (TX) POWER LEVEL SELECTION Your GXT2000/2050 Series has 3 power level settings. To select the power level on channels 1~7, 15~33 and 38~50, press the MENU button until a “Pr” icon appears blinking on the display. Then... -
Page 11: Silent Operation
PTT key, or press the MENU button again to move to the next feature setting. SILENT OPERATION Your GXT2000/2050 Series has a SILENT OPERATION mode. In this mode, all “beeps” and “tones” are disabled. To turn the SILENT OPERATION mode on, press the MENU button until the display shows a “bP”... -
Page 12: Call Alert Selection
Model GXT2000/2050 Series CALL ALERT SELECTION Your GXT2000 Series has 10 selectable CALL ALERTS (15 for GXT2050). To select, press the MENU button until a “CA” icon appears and to the right of the “CA” icon the current CALL ALERT setting is displayed. -
Page 13: Dual Watch Function
DUAL WATCH FUNCTION Your GXT2000/2050 Series has a DUAL WATCH function, to enable the user to scan 2 channels for any activity. The first channel will be the current channel setting and the second channel will be the selected channel on the MENU. -
Page 14: Noaa Weather Alert
GMRS/FRS radio setting will be displayed and the WX BAND icon will go off. NOAA WEATHER ALERT Your GXT2000/2050 has a NOAA WEATHER ALERT function, to enable you to automatically receive weather alerts from designated NOAA stations. The NOAA WEATHER (WX) ALERT is automatically on during NOAA WEATHER SCAN mode. -
Page 15: External Speaker/Microphone Jack
Model GXT2000/2050 Series EXTERNAL SPEAKER/MICROPHONE JACK Your GXT2000/2050 Series can be used with an optional external speaker/microphone or headset, freeing your hands for other tasks. To use an optional speaker / microphone or headset: l Open the rubber cap on the side of the radio. -
Page 16: Troubleshooting Guide
Model GXT2000/2050 Series TROUBLESHOOTING GUIDE PROBLEM SOLUTION No Power - Check battery installation and/or replace batteries. - Confirm the radios have the same channel settings. - Make sure that you are within range of the other Cannot Receive transceivers. Messages - Buildings and other structures may interfere with your communication. -
Page 17: Specifications
Model GXT2000/2050 Series SPECIFICATIONS Channels 50 GMRS/FRS Channels +142 Privacy Codes 10 NOAA Weather (WX) Band Channels Operating Frequency UHF 462.5500 ~ 467.7125 MHz Power Source 7.4V Rechargeable Li-Poly battery pack GMRS/FRS FREQUENCY CHART (MHz) CH. No CH. Freq CH. No CH. -
Page 18: Privacy Codes Frequency Chart (Hz)
Model GXT2000/2050 Series PRIVACY CODES FREQUENCY CHART (Hz) Code Freq Code Freq Code Freq Code Freq Code Freq 67.0 91.5 118.8 156.7 210.7 71.9 94.8 123.0 162.2 218.1 74.4 97.4 127.3 167.9 225.7 77.0 100.0 131.8 173.8 233.6 79.7 103.5 136.5... - Page 19 Model GXT2000/2050 Series Page 19 www.midlandusa.com...
-
Page 20: Limited Warranty
Model GXT2000/2050 Series LIMITED WARRANTY Midland Radio Corporation will repair or replace, at its option without charge, any Midland FRS/GMRS transceiver which fails due to a defect in material or workmanship within three years following the initial consumer purchase. This warranty does not apply to water damage, battery leak or abuse. - Page 21 Model GXT2000/2050 Series ACCESSORIES Accessories can be purchased at www.midlandusa.com or by filling in the form on the following page and mailing it to our address. AVP-1 AVP-H4 - 2 Ear Wrap - 2 Over the Ear Mic. Headsets Headset w/ PTT - $19.99...
-
Page 22: Tactical Headsets
Model GXT2000/2050 Series TACTICAL HEADSETS - Earphone Mic - Tactical Action with Boom Boom Mic with Tactical PTT - $39.99 - $99.99 - Action Throat - Earphone Mic Mic with with PTT Tactical PTT and Pneumatic Earphone - $29.99 - $109.99 Page 22 www.midlandusa.com... -
Page 23: Accessories Order Form
ACCESSORIES ORDER FORM Please send Money Order or fill in Visa/MasterCard information and mail to the address below. Please DO NOT send cash or checks. Make Money Order payable to Midland Radio Corporation. Name: _________________________________________________________ Address: _______________________________________________________ City: _______________________ State: _________ Zip Code: ____________ Tel: _______________________ Email: ______________________________ CC#: ______________________ Type: ______________ Exp.: ___________... - Page 24 We’d love to hear from you! Let us know what you think of your new Midland product at or by visiting us at www.midlandusa.com Note: Features & Specifications are subject to change without notice. MIDLAND is not responsible for unintentional errors or omissions on its packaging.
