  • Page 1 DSL5018EN 4-PORT ADSL 2/2+ 150 MBPS WIRELESS-N MODEM ROUTER V1.1...
  • Page 2 User Manual © COPYRIGHT 2014 ALL RIGHTS RESERVED No part of this document may be reproduced, republished, or retransmitted in any form or by any means whatsoever, whether electronically or mechanically, including, but not limited to, by way of photocopying, recording, information recording, or through retrieval systems without the express written permission.

  • Page 3: Table Of Contents

    User Manual Contents About the Device ......................4 Minimum System Requirements ................. 5 Package Contents ..................5 Device Design ......................6 Front Panel ..................... 6 Back Panel ..................... 7 Getting Started ......................8 Planning Your Network ................8 Remove or Disable Conflicts ..............10 Internet Sharing, Proxy, and Security Applications .......

  • Page 4: About The Device

    The Aztech DSL5018EN 4-Port ADSL2+ 150Mbps Wireless-N Modem Router with USB host uses complete Ralink chipsets solution that fully complies with ADSL2/ADSL2+ standard. The Aztech DSL5018EN supports 1T1R MIMO technology with PHY rate up to 150Mbps. Targeted the residential and SOHO users that desires high quality triple play...

  • Page 5: Minimum System Requirements

    Package Contents Please check the package contents listed below. For any missing items, please contact your dealer immediately. Product contents vary for different models.  DSL5018EN(1T1R)  Ethernet cable  Telephone cable  DSL Microfilter  12V 1.0A DC Power Adapter ...

  • Page 6: Device Design

    User Manual Device Design Front Panel LABEL ICON ACTION DESCRIPTION No power is supplied to the device Steady green 1. POWER Connected to an AC power supply Error on the device Steady red No Ethernet connection 2. ETHERNET Steady green Connected to an Ethernet port Blinking green Transmitting/Receiving data...

  • Page 7: Back Panel

    User Manual Back Panel LABEL DESCRIPTION 1. 12VDC 12V 1.0A DC Input port 2. ON/OFF Power ON/OFF button Connecting computers and other 3. ETHERNET Ethernet devices (RJ45) Connecting the modem to an ADSL 4. DSL line (RJ11) To setup wireless security with WPS- 5.

  • Page 8: Getting Started

    User Manual Getting Started Setting up the device is easy. The flowchart below provides an outline of the steps needed in order to complete the installation. Brief descriptions appear beside each step. Detailed instructions are provided in the subsequent pages. Plan your Network Remove/Disable You may need to check some settings or...
  • Page 9 User Manual Planning Your Network Before moving ahead to setup your network, it is a good idea to draw out a network diagram to help identify your network devices and plan out how to connect these devices. The illustration below is an example of a network diagram.

  • Page 10: Remove Or Disable Conflicts

    User Manual Remove or Disable Conflicts To ensure that the router installation moves on smoothly, you need to remove or disable conflicts that may interfere with the installation. Probable conflicts may include:  Internet sharing applications  Proxy software  Security software ...

  • Page 11: Configuring Tcp/Ip Settings

    User Manual Configuring TCP/IP Settings Check if your computer uses the default TCP/IP settings. To check the TCP/IP properties: 1. Select Start > Run. The Run dialog box would appear. 2. Enter control ncpa.cpl on the input box, and then click the OK button. This would open the Network Connections window in your computer.

  • Page 12: Removing Temporary Internet Files

    User Manual Removing Temporary Internet Files Temporary Internet files are files from Web sites that are stored in your computer. Delete these files to clean the cache and remove footprints left by the Web pages you visited. To remove temporary Internet files: 1.

  • Page 13: Setup The Device

    User Manual Setup the Device When installing the router, find an area where there are enough electrical outlets for the router, the main computer, and your other computer devices. To setup the router: 1. Plug one end of the Ethernet cable from the router’s Ethernet port and plug the other end into the Ethernet port of your computer.
  • Page 14 User Manual To setup a telephone on the POTS Splitter (DSL Microfilter): a. Locate the phone jack in your house. b. Insert the POTS Splitter into the phone jack. c. Plug one end of the telephone cable from the POTS Splitter’s TEL port and then plug the other end into the telephone.

  • Page 15: The Web User Interface(Gui)

    User Manual The Web User Interface(GUI) The Web User Interface allows you to configure all of your router’s functionalities. The layout and content positioning of the device’s web user interface is mapped below. Accessing the Web User Interface To access your router’s Web User Interface: 1.

  • Page 16: Web User Interface Modes

    User Manual 4. Click the Login button to continue. You will automatically be redirected to the Basic Mode of your Web User Interface. Web User Interface Modes The Web User Interface is subdivided into two (2) different modes: 1. Basic Mode 2.

  • Page 17: Connecting To The Internet

    User Manual Connecting to the Internet You can use the web user interface to quickly setup your Internet connection. To connect to the Internet using Quick Setup: 1. Log in to the Web User Interface. 2. Click the Quick Setup button on the Basic menu. 3.

  • Page 18: Basic Mode

    User Manual Basic Mode The Basic Mode displays your router information and its current configuration. It allows you to quickly configure router settings to have access to the Internet, and also includes a setup wizard that easily guides users to setup their device in a procedural manner.

  • Page 19: Basic - Home

    User Manual Basic – Home The Basic-Home page of the web user interface displays a summary of the overall router information for your Internet Connection, LAN Connection, Wireless Connection and Local Network. In configuring other router features, you may use this page as a reference to the other details that you might need.

  • Page 20: Basic -Wizard

    User Manual Basic -Wizard The Basic – Wizard page of the web user interface is a procedural method of setting up your device. Steps such as setting the Language and Time Zone, configuring the connection type, and configuring your Wireless setting are provided in this area.

  • Page 21: Basic - Quick Setup

    User Manual Basic – Quick Setup The Basic – Quick Setup page of the web user interface allows users to configure their Language and Time Zone settings, the WAN connection, and the Wireless settings.  Region. This section allows you to set the Time Zone and NTP Server (Network Time Protocol) of your router.
  • Page 22 User Manual b. Broadcast SSID. Broadcasts or Hides the Wireless SSID. Do take note that upon disabling the SSID broadcast, you would have to manually input the connection details (e.g. SSID, Encryption mode, and Password) before you can connect wirelessly to your router. c.

  • Page 23: Advanced Mode

    User Manual Advanced Mode The Advanced Mode page can be accessed from the Basic page by clicking on Advanced Mode button located at the upper left corner of your screen. Other router features may easily be accessed and configured in this mode.

  • Page 24: Advanced Mode - Network

    User Manual Advanced Mode – Network The Advanced Mode – Network page allows you to change the default configuration of the modem. The Advanced Mode - Network page is also the default page of the Advanced Mode. The Advanced Mode - Network contains the following sub menus: ...
  • Page 25 User Manual  Local. Allows you to change the modem’s IP address and subnet mask, enable or disable the DHCP, determine the start and range of DHCP server addresses and its Lease time, and enable or disable DNS Relay. Click Apply for the settings to take effect. ...
  • Page 26 User Manual  QoS. Allows you to set/configure the Quality of Service parameters of your modem. Click Add for the settings to take effect.  Routing. Allows you to configure certain routes statically into your system. This will cause overriding of the default gateway or interface that would have been taken for reaching a particular destination host/subnet.
  • Page 27 User Manual Advanced – Wireless The Advanced – Wireless page allows you to change the default configuration settings of your Wireless LAN connection on the modem. The Advanced – Wireless page contains the following sub menus:  Settings  Security ...
  • Page 28 User Manual  Security. Allows you to change the default Wireless Security set on the modem. This page also allows you to enable or disable the WPS feature. Click Apply for the settings to take effect.  MAC Filter. Allows you to control which wireless clients to Allow or Deny access to the modem by entering the MAC address of the wireless client to the Access control list.

  • Page 29: Advanced - Applications

    User Manual Advanced – Applications The Advanced – Applications page allows you to change/set the modem’s application features. The Advanced – Applications page contains the following sub menus:  Port Forwarding  Filtering  DMZ  Access Control  NAT ...
  • Page 30 User Manual  Port Forwarding. Allows you to set a direct incoming traffic from the Internet to a specific computer in your local network.  Filtering. Allows you to easily setup rules to control incoming and outgoing traffic on your modem. ...
  • Page 31 User Manual  Access Control. Allows you to configure access rights to certain core services running on your modem. You can allow or deny access from LAN or WAN connection to meet your security requirements.  NAT. Allows you to enable/disable Network Address Translation set on the modem.

  • Page 32: Advanced - System

    User Manual Advanced – System The Advanced – System page allows you to view system information, back- up and Restore settings, and do Firmware upgrade on the modem. The Advanced – System menu has the following sub menus:  Information ...
  • Page 33 User Manual  Settings. This section allows you to Save, Restore, and Factory default reset your modem’s configuration. a) Back-up. Click Backup button to save romfile.cfg on your computer, this will serve as your modem’s back-up configuration file. b) Restore. Click ‘Browse’ to select romfile.cfg that was saved on your computer to restore your modem to the last saved configuration then click Restore for the settings to take effect.
  • Page 34 User Manual  Password. Allows you to change the password set on the modem to access the Web User Interface. Page 34 of 40...

  • Page 35: Advanced - Status

    User Manual Advanced – Status The Advance – Status page displays various router connection statistics for ADSL, LAN, and WLAN. This page also has the following sub menus:  Statistics  ADSL Status  System Log  Diagnostics  Network Tools Page 35 of 40...
  • Page 36 User Manual  Statistics. Provides statistical information of LAN, ADSL and WLAN interface.  ADSL Status. Displays detailed information of the ADSL quality.  System Log. Displays the modem’s system log. Page 36 of 40...
  • Page 37 User Manual  Diagnostics. Display the test results for the connectivity of the physical layer and protocol for ADSL, ATM, WLAN/LAN port and LAN connection, click Start test to start the test.  Network Tools. Allows you to test the modem’s Internet connectivity. Page 37 of 40...

  • Page 38: Modem Care Tips

    User Manual Modem Care Tips 1. Do not deface the modem. 2. Do not use any power adapters with the modem other than the supplied adapter as it may damage the device rendering it unusable. 3. Do not let the modem get wet, when water gets in contact with the modem, the internal components can corrode which breaks down the modem.

  • Page 39: Safety Precautions

    User Manual Safety Precautions  Do not open, service, or change any component.  Only qualified technical specialists are allowed to service the equipment.  Observe safety precautions to avoid electric shock  Check voltage before connecting to the power supply. Connecting to the wrong voltage will damage the equipment.
  • Page 40 User Manual Copyright © 2014 Aztech Technologies Pte Ltd (CRN:199800635M). All rights reserved. Page 40 of 40...
