PARTS AND FEATURES

This manual may cover several different models.
The model you have purchased may have some
or all of the features shown here. The appearance
of your particular model may differ slightly from
the illustrations in this manual.
A B
A. Door lock system
B. Metal shielded window
C. Glass turntable
A
B
C
The turntable can rotate in either direction to help
cook food more evenly. For best cooking results,
do not operate the microwave oven without having
the turntable in place. See "Assistance or Service"
to reorder any of the parts.
To Install:
1. Install the hub into the hole in the center of the
microwave oven cavity bottom
2. Place the support on the microwave oven cavity
bottom.
3. Place the turntable on the support.
Fit the raised, curved mounds in the center of the
turntable bottom between the three spokes of the
hub.
C D E F G
POPCORN POTATO PIZZA BEVERAGE
DINNER FRESH FROZEN
SOUP PLATE VEGETABLE VEGETABLE
WEIGHT
POWER
DEFROST
1 2 3
TIME
DEFROST
EXPRESS COOK
4 5 5 5 6
KITCHEN
TIMER
7 8 9
0 CLOCK
MEMORY AM/PM
PRE-SET
STOP START
CLEAR +30SEC.
D. Microwave inlet cover
E. Microwave oven light
F. Display
G. Control panel
Turntable
A. Turntable
B. Hub
C. Roller Guide

MICROWAVE OVEN CONTROL

POPCORN
WEIGHT
DEFROST
DEFROST
KITCHEN
MEMORY
When power is first supplied to the microwave oven,
"0:00" will appear in the display. If the "0:00" appears
in the display at any other time, a power failure has
occurred. Reset the clock if needed. See "Clock" section.
When the microwave oven is in use, the display shows
cook time remaining. When the microwave oven is not
in use, the display shows the time of day (if the clock is
set) or Timer countdown.
7
POTATO PIZZA BEVERAGE
FRESH FROZEN
DINNER
SOUP
VEGETABLE VEGETABLE
PLATE
POWER
1 2 3
TIME
EXPRESS COOK
4 5 6
TIMER
7 8 9
0
CLOCK
AM/PM
PRE-SET
STOP START
CLEAR +30SEC.
Display
