Summary of Contents for Atongm Laser Keyboard
- Page 1 LASER KEYBOARD User’s Guide LASER KEYBOARD User’s Guide...
-
Page 2: Table Of Contents
LASER KEYBOARD User’s Guide Content 1. Product Overview……………………………………………………………………………5 2. Package Contents……………………………………………………………………………5 3. How this Product Works…………………………………………………………………..6 4. Identifying Parts and their Functions…………………………………………………7 5. Using Laser Keyboard…………………………………………………….....…….8 6. Mouse Function………………………………………………………………………………15 7. Specification…………………………………………………………………………………..16... -
Page 3: Product Overview
LASER KEYBOARD User’s Guide 1. Product Overview Compact and ultra-portable for mobility English QWERTY keyboard layout Easy connection via Bluetooth 3.0 HID profile or USB Lithium-ion Polymer rechargeable battery, Mini-B Type charge interface Compatible with latest operating systems: ... -
Page 4: How This Product Works
LASER KEYBOARD User’s Guide 3. How this product works When the user presses a key on the projected keyboard, the infrared layer is interrupted. This produces IR reflections that are recognized by the sensor in three dimensions, allowing the system to assign a coordinate. -
Page 5: Laser Keyboard Use
LASER KEYBOARD User’s Guide Laser Keyboard Use: Clear the current Bluetooth pair and search status Note: Please restart the device after clearing the current Bluetooth search status so that Bluetooth start new searching. FN+P Switch on/off key stroke sound Adjusting keyboard brightness: FN+... -
Page 6: Using Laser Keyboard
This device is compatible with all USB HID capable operation system, USB HID connection allows plug-n-play without installing a separate driver. USB HID Connection Instruction Connect laser keyboard and host device using supplied USB cable, and your host device must support USB HID. - Page 7 Turn on Bluetooth by tapping the ON button. iPhone/iPad will now search for pairing device. Laser Keyboard shown as follows: Click “ Laser keyboard ” to pair Successful pairing will be indicated by “Connected” message, and blue LED stop flash.
-
Page 8: Connection To Android Devices
LASER KEYBOARD User’s Guide Connection to Android devices Navigate through Android as follows: Home Main Menu Settings WIRELESS & NETWORKS Bluetooth. Turn on the Bluetooth on Android, From the same screen, with Bluetooth ON, tap on Scan devices. - Page 9 LASER KEYBOARD User’s Guide Click “ Laser keyboard ” to pair A new message will display on your Android device: “Bluetooth pairing request’’, and click “ OK ” to pair with the laser keyboard.
- Page 10 LASER KEYBOARD User’s Guide Upon successful pairing, blue “Laser keyboard connected’’ will be displayed on your Android device.
-
Page 11: Laser Keyboard Key Stroke Sound Adjustment
LASER KEYBOARD User’s Guide Laser keyboard key stroke sound adjustment Press and hold “FN” key and press left arrow key to increase volume Press and hold “FN” key and press right arrow key to decrease volume... -
Page 12: Mouse Function
LASER KEYBOARD User’s Guide Laser Projection Keyboard Multi-touch Mouse Function: mouse mode allows you to use your finger as a mouse. Added mouse feature tracks your natural movements and may reduce stress. on you hands . Mouse Freely control by clicking the mouse arrow keys. -
Page 13: Specification
LASER KEYBOARD User’s Guide 6. SPECIFICATION Pattern Projector Item Description Keyboard light source Red laser diode Keyboard layout Approx.19mm incline, sized QWERTY layout Projection size 250mm(W)*110mm(H) Keyboard location Approx. 100mm from keyboard device Required projection surface Non-reflective, opaque flat surface...
