Mercury 4-Stroke 9.9 HP Installation Manual

9.9 and 15 HP (4-Stroke)
Outboard Installation Manual
NOTICE To INSTALLER
After completing
instructions should be placed with the
product for the owner's future use.
IMPORTANT: If the boat is to be water tested, the
operator should be familiar with the operation
procedures in the Operation and Maintenance
Manual.

Table of Contents

Installing Outboard . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Cable Seal . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Link Rod . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Cable Connections
Shift and Throttle Cable
Propeller Installation . . . . . . . . . . . . . . . . . . . . . . . . .
Printed in U.S.A.
assembly, these
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
Boat Horsepower Capacity
U.S. COAST GUARD CAPACITY
MAXIMUM HORSEPOWER
MAXIMUM PERSON
CAPACITY (POUNDS)
MAXIMUM WEIGHT
CAPACITY
Do not overpower or overload the boat. Most boats
will carry a required capacity plate indicating the max-
imum acceptable power and load as determined by
the manufacturer following certain federal guidelines.
If in doubt, contact your dealer or the boat manufac-
turer.
2
2
Using an outboard that exceeds the maximum
2 horsepower limit of a boat can: 1. cause loss of
boat control 2. place too much weight at the tran-
3
som, altering the designed flotation characteris-
3
tics of the boat or 3. cause the boat to break apart,
particularly around the transom area. Overpow-
4
ering a boat can result in serious injury, death, or
4
boat damage.
6
Start in Gear Protection
The remote control connected to the outboard must
be equipped with a start-in-gear protection device.
This prevents the engine from starting in gear.
Avoid serious injury or death from a sudden un-
expected acceleration when starting your engine.
The design of this outboard requires that the re-
mote control used with it must have a built in
start-in-gear protection device.
Selecting Accessories For
The Outboard
Genuine Quicksilver Parts and Accessories have
been specifically designed and tested for this out-
board.
Some accessories not manufactured or sold by
Quicksilver are not designed to be safely used with
this outboard or outboard operating system. Acquire
and read the Installation, Operation, and Mainte-
nance manuals for all selected accessories.
- 1 -
XXX
XXX
XXX
WARNING
WARNING
90-10203990 398
