Related Manuals for Vornado VH10
Summary of Contents for Vornado VH10
- Page 1 VH10 & VH30 WHOLE ROOM HEATER OWNER’S GUIDE GUÍA DEL PROPIETARIO EL CALENTADOR PARA AMBIENTES READ AND SAVE THESE INSTRUCTIONS LEER Y GUARDAR ESTAS INSTRUCCIONES www.vornado.com...
- Page 2 PERFECT www.vornado.com 800.234.0604 help@vornado.com English...
-
Page 3: Table Of Contents
CONTENTS Important Instructions ................ 4 Reset Heater ..................13 Whole Room Heat ................8 Troubleshooting ................14 Safety Features ................... 9 Warranty .................... 15 Controls ..................... 10 Product Specifications ..............30 How To Use ..................11 Cleaning .................... 12 Español p. 16 Storage .................... -
Page 4: Important Instructions
IMPORTANT INSTRUCTIONS WARNING – When using electrical appliances, basic precau- tions should always be followed to reduce the risk of fire, electric READ ALL INSTRUCTIONS BEFORE USING. shock and injury to persons, including the following: WARNING This owner’s guide and any additional inserts are considered part of the product. - Page 5 - To disconnect heater, turn controls to off, then remove plug high power device, such as a vacuum or circular saw. from outlet. - Do Not use this heater on a circuit that has a variable speed - The VH10/VH30, like any other 1500-watt electric heater, draws English...
- Page 6 3 feet (0.9 m) from the front of the heater and keep them away from the sides and rear. up to 12.5 amps of electric current. If using your VH10/VH30 on Warning: In order to avoid overheating, do not cover the the High Heat mode setting causes your home circuit breaker heater.
-
Page 7: Save These Instructions
If this equipment does cause harmful interference to radio or televi- sion reception, which can be determined by turning the equipment off and on, the user is encouraged to contact Vornado Consumer Service at 1-800-234-0604. SAVE THESE INSTRUCTIONS Please keep all documents for future reference and pass these docu- ments on, together with the product, to any future owner. -
Page 8: Whole Room Heat
WHOLE ROOM HEAT The VH10 and VH30 use Vornado’s signature Whole Room Heat circulation to deliver continuous, uniform heat to the entire room. Be comfortable in the room you’re in. Heat only the rooms that you are in and not the entire house. -
Page 9: Safety Features
SAFETY FEATURES COOL TOUCH CASE Safe to touch, even on high heat setting. FINGER FRIENDLY DESIGN Resists curious fingers. AUTOMATIC SAFETY SHUT OFF SYSTEM If airflow becomes blocked, power to the heater is shut off to prevent overheating. AUTOMATIC TIP-OVER PROTECTION If tipped more than 10 degrees in any direction, the heater will immediately shut down. -
Page 10: Controls
POWER ON/OFF ( ) MODE MODE POWER INDICATOR LIGHT (Model VH30 Only) (Model VH10 Only) To indicate the heater is on, High Heat (1500 watts), or High Heat (1500 watts), Medium Heat the red light will illuminate. (1125 watts) or Low Heat (750 watts). -
Page 11: How To Use
HOW TO USE Before use, check appliance for visible damage. DO NOT USE THIS HEATER if there is evidence of damage. If any damage is found, contact Vornado Air LLC at 1-800-234-0604. 4. Press the power button ( ) 1. Use the integrated handle for and select a Mode ( ). -
Page 12: Cleaning
Because your heater moves a substantial amount of air, it will need regular cleaning. Cleaning the outside of the heater is recommended on a bi-weekly basis. If service is required, return your heater to Vornado (see WARRANTY for instructions). 1. Unplug your heater before cleaning. -
Page 13: Storage
4. Plug in the power cord and place heater in desired position. carton if available. This will prevent the heater from accu- 5. Press the power button on. Your Vornado Heater should now func- mulating dust overtime. tion normally. 3. Store heater in a cool and dry Note: If the safety shut off system location. -
Page 14: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE AND SOLUTION The unit fails to power on. Unit is not plugged in. Plug power cord into electrical outlet. Household circuit breaker / ground fault interrupter has tripped or blown a fuse. Reset circuit breaker / ground fault interrupter, or replace fuse (See IMPORTANT INSTRUCTIONS). -
Page 15: Warranty
Vornado Air LLC Attn: Warranty & Repair 415 East 13th Street Andover, KS 67002. For your able information at time of printing. The contents of this manual may differ slightly from convenience, please have your model number and serial number when contacting the actual product. -
Page 16: Product Specifications
PRODUCT SPECIFICATIONS VH10 and VH30 MODEL 120V~ VOLTAGE 1500W WATTAGE AMPERAGE 12.5A UNIT DIMENSIONS 11.63” (29.5 CM.) x 9.25” (23.5 CM.) x 12.00” (30.5 CM.) ESPECIFICACIONES DEL PRODUCTO VH10 and VH30 MODELO VOLTAJE 120V~ VATIAJE 1500W AMPERAJE 12.5A DIMENSIONES DE LA UNIDAD... - Page 17 Vornado Air, LLC 415 East 13th Street, Andover, Kansas 67002 800.234.0604 | www.vornado.com CL3-0389 R-, V01...
