Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Operation of each Reading this manual ....14 component How to search......15 Pictorial index ......16 3-1. Key information Keys........106 For safety and security 3-2. Opening, closing and locking the doors Doors .........
Page 3 4-5. Using the driving Driving support systems Cruise control ....185 Dynamic radar cruise 4-1. Before driving control......189 Driving the vehicle..... 148 Cargo and luggage.... 155 (Lane Departure Alert)..202 Vehicle load limits ..... 158 Rear view monitor Trailer towing..... 159 system ......
Page 4 TABLE OF CONTENTS ® 5-7. Connecting Bluetooth Audio system Preparations to use wireless communication ....283 5-1. Basic Operations ® Registering a Bluetooth Audio system types ... 248 audio player for the Audio system..... 250 first time......287 Steering wheel audio ®...
Page 5 Interior features Maintenance and care 6-1. Using the air 7-1. Maintenance and care conditioning system Cleaning and protecting and defogger the vehicle exterior ..376 Automatic air conditioning Cleaning and protecting system......332 the vehicle interior ... 379 Seat heaters...... 339 7-2.
Page 6 TABLE OF CONTENTS When trouble arises Vehicle specifications 8-1. Essential information 9-1. Specifications Emergency flashers ..438 Maintenance data (fuel, oil level, etc.) ..498 If your vehicle has to Fuel information....507 be stopped in an emergency ...... 439 Tire information....
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. High voltage parts and cables on the hybrid vehicles emit approximately the...
Page 10 ● Usage of data collected through Safety Connect (U.S.mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 11 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 12 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
Page 15: How To Search
How to search ■ Searching by name • Alphabetical index ..P. 551 ■ Searching installation position • Pictorial index....P. 16 ■ Searching by symptom or sound • What to do if... (Troubleshooting) ..P. 548 ■ Searching by title • Table of contents .....P. 2...
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior Doors ......... . . P. 110 Locking/unlocking .
Page 17 Pictorial index Windshield wipers ....... . . P. 180 Precautions against winter season ..... P. 242 Fuel filler door .
Page 18: Instrument Panel
Pictorial index ■ Instrument panel Power switch ........P. 161 Starting the hybrid system/changing the modes .
Page 19 Pictorial index Parking brake ........P. 171 Applying/releasing .
Page 20 Pictorial index ■ Switches BSM (Blind Spot Monitor) main switch ....P. 231 VSC OFF switch ....... P. 219, 220 LDA (Lane Departure Alert) switch .
Page 21 Pictorial index Audio remote control switches ..... P. 252 Meter control switches ......P. 93 Telephone switches .
Page 22 Pictorial index ■ Interior SRS airbags ........P. 36 Floor mats.
Page 23 Pictorial index Auxiliary boxes ........P. 347 Moon roof switches .
Page 24 Pictorial index...
Page 25: For Safety And Security
For safety and security 1-1. For safe use Before driving...... 26 For safety drive ....28 Seat belts ......30 SRS airbags......36 Front passenger occupant classification system ..49 Safety information for children ......55 Child restraint systems..56 Installing child restraints..
Page 26: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 27 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 28: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 29 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 136, 138) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 30: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 31 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 32 Toyota dealer free of charge. ■ Rear seat belt Use the seat belt after passing it through the guide if the seat belt comes free from...
Page 33 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 34 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 35 1-1. For safe use WARNING ■ Using a seat belt extender ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
Page 36: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 37 1-1. For safe use ◆ SRS side and curtain shield airbags SRS front side airbags Can help protect the torso of the front seat occupants SRS rear side airbags Can help protect the torso of occupants in the rear outer seats SRS curtain shield airbags ●...
Page 38 1-1. For safe use SRS airbag system components Front impact sensors “AIR BAG ON” and “AIR BAG OFF” indicator lights Front passenger occupant classification system (ECU SRS warning light and sensors) Front passenger’s seat belt Knee airbags buckle switch Side impact sensors (front Airbag sensor assembly doors) Side impact sensors (rear)
Page 39 1-1. For safe use WARNING ■ SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
Page 40 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
Page 41 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 42 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Page 43 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillars garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ● Do not place anything, such as a cushion, on the front passenger's seat.
Page 44 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 45 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Bruising and slight abrasions may result from contact with a deploying (inflating) SRS airbag. ● A loud noise and white powder will be emitted. ● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the front seats, parts of the front and rear pillars, and roof side rails, may be hot for several minutes.
Page 46 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 47 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 48 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 49: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. SRS warning light Seat belt reminder light “AIR BAG OFF”...
Page 50 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” indi- “AIR BAG ON” cator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Side airbag on the front...
Page 51 1-1. For safe use ■ Child restraint system with infant “AIR BAG ON” and “AIR BAG OFF” indica- “AIR BAG tor lights OFF” Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Devices...
Page 52 1-1. For safe use ■ There is a malfunction in the system “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights OFF” Indicator/ warning light SRS warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seats Activated Devices...
Page 53 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 54 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 55: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 56: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 57 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing  Infant seat/con- Forward facing  Convertible   vertible seat seat Booster seat ...
Page 58 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 59 1-1. For safe use WARNING ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 60: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 61 1-1. For safe use Installation with LATCH system Widen the gap between the seat cushion and seatback slightly.  Type A Latch the hooks of the lower straps onto LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.
Page 62 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Infant seat/convertible seat ■ Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 63 1-1. For safe use While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 64 1-1. For safe use While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 65 1-1. For safe use Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Secure the child restraint sys- tem using the seat belt or LATCH anchors.
Page 66 1-1. For safe use ■ Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to SAE J1819. WARNING ■...
Page 67 1-1. For safe use WARNING ■ When installing a child restraint system ● When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
Page 68: Exhaust Gas Precautions
Keep the trunk lid closed. ● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 69: Hybrid System
1-2. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and operate it with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving condi- tions, improving fuel efficiency and reducing exhaust emis- sions.
Page 70 1-2. Hybrid system ◆ When stopped/during start off The gasoline engine stops , when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped , and the electric motor (traction motor) is used.
Page 71 For this reason, be sure to drive the vehicle at least once every few months for at least 30 minutes or 10 miles (16 km). If the hybrid battery becomes fully discharged and you are unable to start the hybrid system, contact your Toyota dealer.
Page 72 When in the area surrounding the rear of the vehicle, rather than in front of the vehicle ■ Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself.
Page 73: Hybrid System Precautions
1-2. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it is a high volt- age system (about 650 V at maximum) as well as contains parts that become extremely hot when the hybrid system is operating. Obey the warning labels attached to the vehicle.
Page 74 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.
Page 75 If a warning light comes on, a warning message is displayed, or the 12- volt battery is disconnected The hybrid system may not start. In this case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ Running out of fuel...
Page 76 1-2. Hybrid system WARNING ■ High voltage precautions This vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●...
Page 77 Toyota dealer or a qualified service shop. If the hybrid battery is not dis- posed of properly, it may cause electric shock that can result in death or serious injury.
Page 78: 1-3. Theft Deterrent System
1-3. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 79 1-3. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type immobilizer system. ■ Conditions affecting operation Depending on the surrounding environment and conditions, the immobilizer system may not operate properly. This may prevent the hybrid system from starting.
Page 80: Alarm
1-3. Theft deterrent system  Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door or trunk is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key.
Page 81 1-3. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ● Nobody is in the vehicle. ●...
Page 82 1-3. Theft deterrent system...
Page 83: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......84 Gauges and meters .... 88 Multi-information display ..92 Energy monitor/ consumption screen..98...
Page 84: Instrument Cluster Warning Lights And
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 85 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : For U.S.A.
Page 86: Indicators
There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : If equipped...
Page 87 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 88: Gauges And Meters
2. Instrument cluster Gauges and meters Hybrid System Indicator Displays hybrid system output or regeneration level (P. 90) Multi-information display Presents the driver with a variety of driving-related data. Displays warning messages in case of a malfunction (P. 453) Outside temperature display Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C).
Page 89 2. Instrument cluster Changing the odometer/trip meter display Pressing the button changes the display change button display as follows. ■ Odometer Displays the total distance the vehicle has been driven. ■ Trip meter A /trip meter B Displays the distance the vehicle has been driven since the meter was last reset.
Page 90 2. Instrument cluster ■ The meters and display illuminate when The power switch is in ON mode. ■ The brightness of the instrument panel lights When the tail lights are turned on, the meter’s brightness will be reduced slightly unless the meter brightness level adjustment is set to the brightest setting.
Page 91 2. Instrument cluster ■ Outside temperature display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change. ● When stopped, or driving at low speeds (less than 16 mph [25 km/h]) ●...
Page 92: Multi-Information Display
2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of vehi- cle data. ● Menu icons Displays the following informa- tion when an icon is selected. (P. 93) Some of the information may be displayed automatically depending on the situation.
Page 93 2. Instrument cluster Warning message display Select to display warning messages and measures to be taken if a malfunction is detected. (P. 453) Settings display Select to change the meter display settings. (P. 95) ■ Operating the meter control switches Scroll up/down the screen and move up/down the cur- Switch...
Page 94 2. Instrument cluster Drive information ● Average fuel economy 1, 2 /Tank average fuel economy /Trip aver- age fuel economy Displays the average fuel consumption since the function was reset, the vehicle was refueled, and the hybrid system was started, respectively Use the displayed average fuel consumption as a reference.
Page 95 2. Instrument cluster : Can be registered to Drive information 1 through 3. : Resetting procedures: • Select a function to be reset using the meter control switch and then press and hold the center button to reset. • If there is more than one function that can be reset, check boxes will be displayed next to the functions.
Page 96 2. Instrument cluster ● Speed limit display Select to set the display of speed limit information stored in the navigation system (if equipped) to on with the speed limit caution indicator (yellow) enabled, on with the speed limit caution not enabled, or off.
Page 97 2. Instrument cluster WARNING ■ The information display at low temperatures Allow the interior of the vehicle to warm up before using the liquid crystal information display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed. For example, there is a lag between the driver’s shifting and the new gear number appearing on the display.
Page 98: Energy Monitor/Consumption Screen
2. Instrument cluster Energy monitor/consumption screen You can view the status of your hybrid system on the multi-infor- mation display, the Entune Audio system and/or the navigation system. Entune Audio system or navi- gation system Multi-information display...
Page 99 2. Instrument cluster Energy monitor Entune Audio system with “CAR” button  Press the “CAR” button. If the “Trip Information” or “Past Record” screen is displayed, touch “Energy”.  Entune Audio system or navigation system with “APPS” button Press the “APPS” button. Touch “Eco”...
Page 100 2. Instrument cluster ■ Multi-information display Press meter control switches on the steering wheel several times to select the energy monitor display. Entune Audio system or Multi-information Navigation system display When the vehicle is powered electric motor (trac- tion motor) When the vehicle is powered gasoline engine...
Page 101 2. Instrument cluster Entune Audio system or Multi-information Navigation system display When the vehicle is charging the hybrid battery (traction bat- tery) When there is no energy flow Hybrid battery (trac- tion battery) status Full Full Fuel consumption screen ■ Trip information ...
Page 102 2. Instrument cluster Resetting the consumption data Displays the average vehicle speed since the hybrid sys- tem was started Displays the elapsed time since the hybrid system was started Fuel consumption in the past 15 minutes Cruising range Regenerated energy in the past 15 minutes One symbol indicates 30 Wh.
Page 103 2. Instrument cluster ■ Past record  Entune Audio system with “CAR” button Press the “CAR” button. (P. 99) If the “Energy Monitor” or “Trip Information” screen is displayed, touch “Past Record”. Entune Audio system or navigation system with “APPS” button ...
Page 104 2. Instrument cluster...
Page 105: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........106 3-2. Opening, closing and locking the doors Doors ........ 110 Trunk......... 117 Smart key system ..... 121 3-3. Adjusting the seats Front seats ......128 Rear seats......130 Head restraints....132 3-4.
Page 106: 3-1. Key Information
Pressing the button again within 5 seconds unlocks the other doors. Opens the driver’s window and moon roof (if equipped) (P. 110) Opens the trunk (P. 117) Sounds the alarm (P. 107) : This setting must be customized at your Toyota dealer.
Page 107 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using the other mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 108 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ If a wrong key is used The key cylinder rotates freely to isolate inside mechanism.
Page 109 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle.
Page 110: Doors
Pressing the but- ton again within 5 seconds unlocks the other doors. Press and hold to open the driver’s window and moon roof (if equipped). (P. 140, 144) : This setting must be customized at your Toyota dealer.
Page 111 3-2. Opening, closing and locking the doors ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Driver’s window and moon roof: A buzzer sounds to indicate that the driver’s window and moon roof are open- ing.
Page 112 3-2. Opening, closing and locking the doors Unlocking and locking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 113 3-2. Opening, closing and locking the doors Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 114 3-2. Opening, closing and locking the doors ■ Setting and canceling the functions The automatic door locking and unlocking functions can be set or canceled on the Entune Audio system screen (P. 523) or by fol- lowing the procedure below. Close all the doors and turn the power switch to ON mode.
Page 115 3-2. Opening, closing and locking the doors ■ Switching the door unlock function It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the power switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 116 3-2. Opening, closing and locking the doors WARNING ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 117: Trunk
3-2. Opening, closing and locking the doors Trunk The trunk can be opened using the trunk opener, entry function, wireless remote control. Opening the trunk from inside the vehicle Pull up the lever to release the trunk lid. Opening the trunk from outside the vehicle ◆...
Page 118 3-2. Opening, closing and locking the doors ■ Operation signal A buzzer sounds to indicate that the trunk has been opened. ■ Trunk light The trunk light turns on when the trunk is opened. ■ Function to prevent the trunk being locked with the electronic key inside ●...
Page 119 3-2. Opening, closing and locking the doors WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Before driving ● Make sure that the trunk lid is fully closed. If the trunk lid is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the trunk may be thrown out, causing an accident.
Page 120 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 121: Smart Key System
3-2. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ● Locks and unlocks the doors (P. 110) ●...
Page 122 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the front outside door handles.
Page 123 3-2. Opening, closing and locking the doors ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the 12-volt battery from being discharged while the vehicle is not in operation for a long time. ●...
Page 124 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and immobilizer system from operating properly.
Page 125 3-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 126 3-2. Opening, closing and locking the doors ● The lock sensor may not work properly if it comes into contact with ice, snow, mud, etc. Clean the lock sensor and attempt to operate it again. ● If there is another electronic key in the detection area, it may take slightly longer to unlock the doors after the door handle is gripped.
Page 127 (P. 121) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 128: 3-3. Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Manual seat  Seat position adjustment lever Vertical height adjustment lever (driver’s side only) Seatback angle adjustment lever  Power seat Seat position adjustment Vertical height adjustment switch switch (driver’s side only) Seatback angle adjustment Lumbar support adjustment switch...
Page 129 3-3. Adjusting the seats WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
Page 130: Rear Seats
3-3. Adjusting the seats Rear seats The seatback of the right side rear seat can be folded down. Folding down the rear seatback Pull the seatback lever in the trunk.
Page 131 3-3. Adjusting the seats WARNING ■ When folding the rear seatback down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatback down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to P.
Page 132: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraint up. Down Push the head restraint down while pressing the lock release button. Lock release button ■ Removing the head restraints (front seats) Pull the head restraint up while pressing the lock release button.
Page 133 3-3. Adjusting the seats ■ Adjusting the height of the head restraints (front seats) Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. WARNING ■ Head restraint precautions (front seats) Observe the following precautions regarding the head restraints.
Page 134: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 135 3-4. Adjusting the steering wheel and mirrors WARNING ■ Caution while driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ■...
Page 136: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 137 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror  Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode On/Off When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 138: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 139 3-4. Adjusting the steering wheel and mirrors WARNING ■ Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...
Page 140: Opening And Closing
3-5. Opening and closing the windows Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing (front side windows only) Opening One-touch opening (front side windows only) : To stop the window partway, oper- ate the switch in the opposite direc-...
Page 141 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■...
Page 142 3-5. Opening and closing the windows WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers. In order to prevent accidental operation, especially by a child, do not let a child operate the power windows.
Page 143: Moon Roof
3-5. Opening and closing the windows  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 144 3-5. Opening and closing the windows ■ The moon roof can be operated when The power switch is in ON mode. ■ Operating the moon roof after turning the hybrid system off The moon roof can be operated for approximately 45 seconds after the power switch is turned to ACCESSORY mode or turned off.
Page 145 Check to make sure that the moon roof is completely closed and then release the switch. If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. ■ Moon roof open warning buzzer...
Page 146 3-5. Opening and closing the windows WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Opening the moon roof ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 147: Driving
Driving 4-1. Before driving 4-3. Operating the lights and wipers Driving the vehicle..... 148 Headlight switch....172 Cargo and luggage ... 155 Automatic High Beam ..175 Vehicle load limits ..... 158 Windshield wipers and Trailer towing..... 159 washer ......180 Dinghy towing ....
Page 148: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the hybrid system P. 161 Driving With the brake pedal depressed, shift the shift lever to D. (P. 168) Release the parking brake. (P. 171) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 149 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 150 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the “READY” indicator is illuminated. This prevents the vehicle from creeping. ■...
Page 151 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● Do not drive in excess of the speed limit. Even if the legal speed limit per- mits it, do not drive over 85 mph (140 km/h) unless your vehicle has high- speed capability tires.
Page 152 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 153 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave a door or window open if the curved glass is coated with a metallized film such as a silver-colored one.
Page 154 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 155: Cargo And Luggage
Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (P. 158) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing.
Page 156 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 498) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 157 4-1. Before driving WARNING ■ Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 158: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 159: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the...
Page 160: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground.
Page 161: Driving Procedures
4-2. Driving procedures Power (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the hybrid system or changes power switch modes. Starting the hybrid system Check that the parking brake is set. Check that the shift lever is in P. Firmly depress the brake pedal.
Page 162 4-2. Driving procedures Changing power switch modes Modes can be changed by pressing the power switch with brake pedal released. (The mode changes each time the switch is pressed.) Off* The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 163 If the hybrid system does not start ● The immobilizer system may not have been deactivated. (P. 78) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The hybrid system may not start if the shift lever is displaced out of P.
Page 164 ■ If the “READY” indicator does not come on In the event that the “READY” indicator does not come on even after perform- ing the proper procedures for starting the vehicle, contact your Toyota dealer immediately. ■ If the hybrid system is malfunctioning P.
Page 165 Do not depress the accelerator pedal unnecessarily. ● If the hybrid system becomes difficult to start, have your vehicle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the power switch If the power switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 166: Ev Drive Mode
4-2. Driving procedures EV drive mode In EV drive mode, electric power is supplied by the hybrid bat- tery (traction battery), and only the electric motor (traction motor) is used to drive the vehicle. This mode allows you to drive in residential areas early in the morning and late at night, or in indoor parking lots etc.
Page 167 4-2. Driving procedures ■ Switching to EV drive mode when the gasoline engine is cold If the hybrid system is started while the gasoline engine is cold, the gasoline engine will start automatically after a short period of time in order to warm up. In this case, you will become unable to switch to EV drive mode.
Page 168: Hybrid Transmission
4-2. Driving procedures Hybrid transmission Shifting the shift lever While the power switch is in ON mode, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped. Shift position purpose Shift position Objective or function...
Page 169 4-2. Driving procedures Selecting Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. Turns Eco drive mode on/off When Eco drive mode is turned on, a message indicating the vehicle is in Eco drive mode will be shown on multi-information display.
Page 170: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
Page 171: Parking Brake
4-2. Driving procedures Parking brake Operating instructions To set the parking brake, fully depress the parking brake pedal with your left foot while depress- U.S.A. Canada ing the brake pedal with your right foot. (Depressing pedal again releases the parking brake.) ■...
Page 172: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: The headlights, day- time running lights and lights listed below turn on and off automatically.
Page 173 4-3. Operating the lights and wipers ■ Daytime running light system ● Vehicles with halogen daytime running lights: To make your vehicle more visible to other drivers, the headlight high beams turn on automatically (at a reduced intensity) whenever the hybrid system is started and the parking brake is released.
Page 174 4-3. Operating the lights and wipers ■ Battery-saving function In the following conditions, the remaining lights will go off automatically after 20 minutes in order to prevent the vehicle battery from being discharged: ● The headlights and/or tail lights are on. ●...
Page 175: Automatic High Beam
4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns high beam on or off as necessary. Activating the Automatic High Beam system Turn the headlight switch to Push the lever away from you.
Page 176 4-3. Operating the lights and wipers High beam automatic turning on or off conditions When all of the following conditions are fulfilled, high beam will be automatically turned on: ● Vehicle speed is above approximately 21 mph (34 km/h). ● The area ahead of the vehicle is dark. ●...
Page 177 4-3. Operating the lights and wipers ■ The Automatic High Beam can be operated when The power switch is in ON mode. ■ Camera sensor detection information ● High beam may not be automatically turned off in the following situations: •...
Page 178 Automatic High Beam (headlights) may turn on even the vehicle is stopped. ■ If the Automatic High Beam indicator flashes It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization The Automatic High Beam can be deactivated.
Page 179 Do not install a parking tag or any other accessories near or around the camera sensor. ● Do not overload the vehicle. ● Do not modify the vehicle. ● If the windshield needs to be replaced, contact your Toyota dealer.
Page 180: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows. When intermittent windshield wiper operation is selected, the wiper interval can be also adjusted. Intermittent windshield wiper operation Low speed windshield...
Page 181 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 182: Opening The Fuel Tank Cap
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Close all the doors and windows, and turn the power switch off. ● Confirm the type of fuel. ■...
Page 183: Refueling
4-4. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’s painted surface. Opening the fuel tank cap Pull up the opener to open the fuel filler door.
Page 184 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 185: Cruise Control
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Display Indicators Set speed Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control.
Page 186: Control
4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 187 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer.
Page 188 4-5. Using the driving support systems WARNING ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 189: Dynamic Radar Cruise Control
4-5. Using the driving support systems  Dynamic radar cruise control Summary of functions Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-vehicle distance control. In vehicle-to-vehicle dis- tance control mode, the vehicle automatically accelerates or deceler- ates in order to maintain a set following distance from vehicles ahead. Vehicle-to-vehicle distance but- Indicators Set speed...
Page 190 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will be displayed. Press the button again to deacti- vate the cruise control. Accelerate or decelerate the vehicle to the desired speed, and push the lever down to set...
Page 191 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 192 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance Pressing the button changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short Preceding vehicle mark The vehicle-to-vehicle distance is set automatically to long mode when the power switch is turned to ON mode.
Page 193 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 194 4-5. Using the driving support systems Example of follow-up cruising When following a vehicle driving slower than the set speed The system continues follow-up cruising while adjusting for changes in the speed of the vehicle ahead in order to maintain the vehicle-to-vehicle dis- tance set by the driver.
Page 195 4-5. Using the driving support systems Selecting conventional constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to dirt etc.
Page 196 The windshield wipers are operating at high speed (when the wiper switch is set to the high speed wiper operation position). If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. ■...
Page 197 4-5. Using the driving support systems ■ Radar sensor and grille cover Always keep the sensor and grille cover clean to ensure that the vehicle-to- vehicle distance control operates properly. (Some obstructions, such as snow, ice and plastic objects, cannot be detected by the obstruction sensor.) Dynamic radar cruise control is canceled if an obstruction is detected.
Page 198 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes etc.
Page 199 4-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 200 4-5. Using the driving support systems WARNING ● Motorcycles traveling in the same lane ● When water or snow thrown up by the surrounding vehicles hinders the detecting of the sensor ● When your vehicle is pointing upwards (caused by a heavy load in the trunk, etc.) ■...
Page 201 ● Do not attach accessories or stickers to the sensor, grille cover or sur- rounding area. ● Do not modify or paint the sensor and grille cover. ● If the radar sensor needs to be replaced, contact your Toyota dealer.
Page 202: (Lane Departure Alert)
4-5. Using the driving support systems  LDA (Lane Departure Alert) Summary of function While driving on a road that has lane markers, this system recognizes the lane markers using a camera as a sensor to alert the driver when the vehicle deviates from its lane.
Page 203 4-5. Using the driving support systems Operating conditions ● When the vehicle speed is approximately 32 mph (50 km/h) or more ● When the lane width is more than approximately 8.2 ft. (2.5 m) ● When driving on a straight road or through a curve with a radius of more than approximately 328 ft.
Page 204 4-5. Using the driving support systems ■ Temporary cancelation of the LDA system functions If any of the following occurs, the LDA system functions will be temporarily canceled. The functions will resume after the necessary operating conditions have returned. ● The turn signal lever is operated.
Page 205 4-5. Using the driving support systems ■ Conditions in which the function may not operate correctly In the following situations, the camera sensor may be unable to recognize lane markers causing the lane departure warning function to operate incor- rectly. However, this does not indicate a malfunction. ●...
Page 206 4-5. Using the driving support systems WARNING ■ Before using the LDA system Do not rely solely on the LDA system. The LDA system does not drive the vehicle automatically, nor does it reduce the amount of care you need to take.
Page 207 The direction of the camera sensor is precisely adjusted. ● Do not subject the camera sensor to strong impact or force, and do not disassemble the camera sensor. ● If the windshield needs to be replaced, contact your Toyota dealer.
Page 208: Rear View Monitor System
4-5. Using the driving support systems Rear view monitor system The rear view monitor system assists the driver by displaying guide lines and an image of the view behind the vehicle while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 209 4-5. Using the driving support systems Using the rear view monitor system ■ Screen description Vehicle width guide lines The line indicates a guide path when the vehicle is being backed straight up. The displayed width is wider than the actual vehicle width. Vehicle center guide lines These lines indicate the estimated vehicle center on the ground.
Page 210 4-5. Using the driving support systems Rear view monitor system precautions ■ Area displayed on screen The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. To adjust the image on the rear view monitor system screen.
Page 211 4-5. Using the driving support systems ■ Rear view monitor system camera The camera for the rear view monitor system located above the license plate. ● Using the camera If the camera lens becomes dirty, it cannot transmit a clear image. If water droplets, snow or mud adhere to the lens, rinse it with water and wipe with a soft cloth.
Page 212 4-5. Using the driving support systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehi- cle than the actual distance. Because of this, objects will appear to be farther away than they actually are.
Page 213 4-5. Using the driving support systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of pas- sengers or the distribution of the load, there is a margin of error between the fixed guide lines on the screen and the actual distance/course on the A margin of error...
Page 214 4-5. Using the driving support systems ■ Vehicle width guide lines Visually check the surroundings and the area behind the vehicle. In the case shown below, the truck appears to be outside of the vehi- cle width guide lines and the vehicle does not look as if it hits the truck.
Page 215 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 216 4-5. Using the driving support systems WARNING ■ When using the rear view monitor system The rear view monitor system is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding.
Page 217 ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible.
Page 218: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 219 4-5. Using the driving support systems ◆ EPS (Electric Power Steering) Employs an electric motor to reduce the amount of effort needed to turn the steering wheel ◆ PCS (Pre-Collision System) (if equipped) P. 224 ◆ BSM (Blind Spot Monitor) (if equipped) P.
Page 220 When the message is displayed on the multi-information display show- ing that TRAC has been disabled even if has not been pressed TRAC and hill-start assist control cannot be operated. Contact your Toyota dealer. ■ Sounds and vibrations caused by the ABS, brake assist, TRAC and VSC...
Page 221 4-5. Using the driving support systems ■ Automatic reactivation of TRAC and VSC systems After turning the TRAC and VSC systems off, the systems will be automati- cally re-enabled in the following situations: ● When the power switch is turned off ●...
Page 222 4-5. Using the driving support systems WARNING ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick roads. ■...
Page 223 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 224: (Pre-Collision System)
4-5. Using the driving support systems  PCS (Pre-Collision System) When the radar sensor detects possibility of a frontal collision, brakes are automatically engaged to lessen impact as well as vehicle damage. The alert timing for the pre-collision system can be changed or turned on/off, as necessary, by operating the switch.
Page 225 4-5. Using the driving support systems Changing the pre-collision system ■ Changing the alert timing of the pre-collision system Each time the PCS switch is pressed, the response to the distance changes as follows. Middle Near : Default setting ■ Turning off the pre-collision system Press the PCS switch for 3 or more seconds.
Page 226 4-5. Using the driving support systems ■ The pre-collision system is operational when The pre-collision system is on (P. 225) and the following conditions are met: ● Pre-collision warning: • Vehicle speed is greater than approximately 10 mph (15 km/h). •...
Page 227 4-5. Using the driving support systems ■ Obstacles not detected The sensor cannot detect plastic obstacles such as traffic cones. There may also be occasions when the sensor cannot detect pedestrians, animals, bicy- cles, motorcycles, trees, or snowdrifts. ■ Situations in which the pre-collision system does not function properly The system may not function effectively in situations such as the following: ●...
Page 228 4-5. Using the driving support systems ■ Certification  For vehicles sold in the U.S.A. FCC ID : HYQDNMWR007 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 229 ● Do not attach accessories or stickers to the sensor, grille cover or sur- rounding area. ● Do not modify or paint the sensor and grille cover. ● If the radar sensor needs to be replaced, contact your Toyota dealer.
Page 230 4-5. Using the driving support systems WARNING ■ Cautions regarding the assist contents of the system By means of alarms and brake control, the pre-collision system is intended to assist the driver in avoiding collisions through the process of LOOK- JUDGE-ACT.
Page 231: (Blind Spot Monitor)
4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ●...
Page 232: The Blind Spot
4-5. Using the driving support systems Rear Cross Traffic Alert buzzer (Rear Cross Traffic Alert function only) When a vehicle approaching from the right or left rear of the vehicle is detected, a buzzer sounds from behind the rear seat. ■...
Page 233: The Blind Spot
If the sensor moves even slightly off position, the system may mal- function and vehicles that enter the detection area may not be detected. If the sensor or surrounding area is subject to a strong impact, always have the area inspected by your Toyota dealer. ● Do not disassemble the sensor.
Page 234: The Blind Spot Monitor Function
4-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicles existence via the outside rear view mirror indicator.
Page 235 4-5. Using the driving support systems ■ Conditions under which the Blind Spot Monitor function will not detect a vehicle The Blind Spot Monitor function is not designed to detect the following types of vehicles and/or objects: ● Small motorcycles, bicycles, pedestrians etc. ●...
Page 236: The Rear Cross Traffic Alert Function
4-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 237 4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 238 4-5. Using the driving support systems ■ Conditions under which the Rear Cross Traffic Alert function may not function correctly The Rear Cross Traffic Alert function may not detect vehicles correctly in the following conditions: ● When ice or mud etc. is attached to the rear bumper ●...
Page 239: Driving Tips
4-6. Driving tips Hybrid vehicle driving tips For economical and ecological driving, pay attention to the fol- lowing points: ◆ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accel- erator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 240 4-6. Driving tips ◆ When braking Make sure to operate the brakes gently and in a timely manner. A greater amount of electrical energy can be regenerated when slow- ing down. ◆ Delays Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel economy.
Page 241 4-6. Driving tips ◆ Luggage Carrying heavy luggage will lead to poor fuel economy. Avoid carry- ing unnecessary luggage. Installing a large roof rack will also cause poor fuel economy. ◆ Warming up before driving Since the gasoline engine starts up and cuts out automatically when cold, warming up the engine is unnecessary.
Page 242: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 243 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road con- ditions. When parking the vehicle Park the vehicle and move the shift lever to P without setting the park- ing brake.
Page 244 Repairing or replacing snow tires (vehicles with a tire pressure warn- ing system) Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 245 4-6. Driving tips...
Page 246: Audio System
Audio system 5-1. Basic Operations Audio system types... 248 Audio system ....250 Steering wheel audio switches ......252 USB port/AUX port.... 253 Basic audio operations..255 5-2. Setup Setup menu....... 257 General settings....258 Audio settings ....260 Display settings....261 Voice settings....
Page 247 Audio system ® 5-6. Using an external 5-8. Bluetooth Audio ® device Listening to Bluetooth Listening to an iPod ..274 Audio....... 295 ® Listening to a USB 5-9. Bluetooth phone memory device....278 ® Using a Bluetooth Using the AUX port ... 282 Phone ......
Page 248: 5-1. Basic Operations
5-1. Basic Operations Audio system types Entune Audio  Entune Audio Plus  Owners of this system should refer to the “NAVIGATION AND MULTI- MEDIA SYSTEM OWNER'S MANUAL”.
Page 249 5-1. Basic Operations Entune Premium Audio with Navigation  Owners of this system should refer to the “NAVIGATION AND MULTI- MEDIA SYSTEM OWNER'S MANUAL”.
Page 250: Audio System
5-1. Basic Operations  Audio system Operations such as listening to audio, using the hands-free phone and changing multimedia system settings are started by using the following buttons. Audio system operation buttons “AUDIO” button Display the “Select Audio Source” screen or audio top screen. (P.
Page 251 5-1. Basic Operations Operating the touch screen By touching the screen with your finger, you can control the multime- dia system, etc. ■ Drag Touch the screen with your finger, and move the screen to the desired position. ● Scrolling the lists ■...
Page 252: Steering Wheel Audio Switches
5-1. Basic Operations Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of multimedia sys- tem or navigation system. For details, refer to the manual pro- vided with the multimedia system or navigation system.
Page 253: Usb Port/Aux Port
5-1. Basic Operations USB port/AUX port Connect an iPod, USB memory device or portable audio player to the USB/AUX port as indicated below. Select “iPod”, “USB” or “AUX” on the audio source selection screen and the device can be operated via multimedia system. Connecting using the USB/AUX port ■...
Page 254 5-1. Basic Operations WARNING ■ While driving Do not connect a device or operate the device controls.
Page 255: Basic Audio Operations
5-1. Basic Operations Basic audio operations Basic audio operations and functions common to each mode are explained in this section. Operating the multimedia system Press: Turns the multimedia system on and off. Turn: Adjusts the volume. Ejects a disc. Disc slot Pauses or resumes playing music.
Page 256 5-1. Basic Operations WARNING ■ Laser product This product is a class 1 laser product. Do not open the cover of the player or attempt to repair the unit yourself. Refer servicing to qualified personnel. ● Laser products • Do not take this unit apart or attempt to make any changes yourself. This is an intricate unit that uses a laser pickup to retrieve information from the surface of compact discs.
Page 257: Setup Menu
5-2.Setup Setup menu You can adjust the multimedia system to your desired settings. Display “Setup” screen Press the “SETUP” button to display the “Setup” screen. Select to adjust the settings for operation sounds, screen ani- mation, etc. (P. 258) Select to set the voice settings. (P.
Page 258: General Settings
The animation effect for the screen can be set to on/off. Select to delete personal data (P. 259) Select to update program versions. For details, contact your Toyota dealer. Select to display the software information. Notices related to third party software used in this product are enlisted. (This includes instructions for obtaining such software, where applicable.)
Page 259 5-2. Setup Delete personal data Select “Delete Personal Data” on the “General Settings” screen. Select “Delete”. Check carefully beforehand, as data cannot be retrieved once deleted. A confirmation screen will be displayed. Select “Yes”. The following personal data will be deleted or changed to its default settings.
Page 260: Audio Settings
5-2. Setup Audio settings Settings are available for adjusting the radio operation, cover art, etc. Screen for audio settings Press the “SETUP” button. Select “Audio” on the “Setup” screen. Number of Radio Presets Select the number of radio preset stations. Display Cover Art on/off Automatic Sound Levelizer (P.
Page 261: Display Settings
5-2. Setup Display settings Settings are available for adjusting the contrast and brightness of the screen. Screen for display settings Press the “SETUP” button. Select “Display” on the “Setup” screen. Adjust screen contrast/bright- ness Adjust screen contrast/bright- ness of the rear view monitor camera Changes to day mode.
Page 262: Voice Settings
5-2. Setup Voice settings This screen is used for guidance for voice command systems setting. Adjust the voice guidance vol- ume setting. voice recognition prompts “High”, “Low” or “Off”. Set the train voice recognition. Set the voice prompt interrupt on/off. Set the voice recognition tuto- rial.
Page 263: Using The Multimedia System
5-3.Using the Multimedia system Selecting the audio source Switching between audio sources such as radio and CD are explained in this section. Changing audio source Press the “AUDIO” button to display the audio source selection screen. If the audio source selection screen is not displayed, press the “AUDIO” button again.
Page 264: List Screen Operation
5-3. Using the Multimedia system List screen operation When a list screen is displayed, use the appropriate buttons to scroll through the list. How to scroll : Select to scroll to the next or previous page. : If appears to the right of titles, the complete titles are too long for the display.
Page 265 5-3. Using the Multimedia system ■ Selecting a track/file/song from the track/file/song list Select “Browse” or cover art. Select the desired track/file/ song. When an MP3/WMA/AAC disc or USB memory device is being used, ® the folder can be selected. When a Bluetooth device or iPod is being used, the album can be selected.
Page 266: Optimal Use Of The Multimedia System
5-3. Using the Multimedia system Optimal use of the multimedia system On the “Sound Settings” screen, sound quality (Treble/Mid/ Bass), volume balance can be adjusted. How to adjust the sound settings and sound quality 1 2 3 Select “-” or “+” to adjust the treble, mid or bass to a level between -5 and 5.
Page 267: Using The Radio
5-4.Using the radio Radio operation Select “AM” or “FM” on the audio source selection screen to begin listening to the radio. Audio control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source. Audio source selection screen appears Preset stations...
Page 268 5-4. Using the radio Setting station presets Search for desired stations by turning the “TUNE/SCROLL” knob or pressing the “” or “” button on “SEEK/TRACK”. Select “(add new)”. To change the preset station to a different one, select and hold the preset station.
Page 269: Playing An Audio Cd And Mp3/Wma/Aac Discs
■ Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause Correction procedures • The disc is dirty or •...
Page 270 5-5. Playing an audio CD and MP3/WMA/AAC discs ■ Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration. CDs with copy-protection features may not play correctly.
Page 271 5-5. Playing an audio CD and MP3/WMA/AAC discs ● WMA file compatibility • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates (only compatible with 2-channel playback) Ver. 7, 8: CBR 48-192 (kbps) Ver.
Page 272 5-5. Playing an audio CD and MP3/WMA/AAC discs ● ID3, WMA and AAC tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
Page 273 5-5. Playing an audio CD and MP3/WMA/AAC discs NOTICE ■ Discs and adapters that cannot be used Do not use the following types of CDs. Also, do not use 3 in. (8 cm) CD adapters, Dual Discs or printable discs. Doing so may damage the CD player and/or the CD insert/eject function.
Page 274: Listening To An Ipod
5-6.Using an external device Listening to an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Select “iPod” on the audio source selection screen. When the iPod connected to the system includes iPod video, the system can only output the sound by selecting the browse screen.
Page 275: Using An External Device
5-6. Using an external device ■ About iPod ● “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone, respectively, and has been certified by the developer to meet Apple performance stan- dards.
Page 276 5-6. Using an external device ■ Error messages Message Cause/Correction procedures “Connection error. Please consult your Owner’s Man- This indicates a problem in the iPod or its con- ual for instructions on how nection. to connect the iPod.” This indicates that there is no music data in “No music files found.”...
Page 277 5-6. Using an external device WARNING ■ While driving Do not connect an iPod or operate the controls. NOTICE ■ To prevent damage to the iPod or its terminals ● Do not leave the iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the iPod.
Page 278: Listening To A Usb Memory Device
5-6. Using an external device Listening to a USB memory device Connecting a USB memory device enables you to enjoy music from the vehicle speakers. Touch “USB” on the audio source selection screen. Connecting a USB memory device P. 253 Audio control screen Pressing the “AUDIO”...
Page 279 5-6. Using an external device ■ USB memory functions ● Depending on the USB memory device that is connected to the system, the device itself may not be operable and certain functions may not be avail- able. If the device is inoperable or a function is unavailable due to a mal- function (as opposed to a system specification), disconnecting the device and reconnecting it may resolve the problem.
Page 280 5-6. Using an external device ● MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) •...
Page 281 5-6. Using an external device ● MP3, WMA and AAC playback • When a device containing MP3, WMA and AAC files is connected, all files in the USB memory device are checked. Once the file check is fin- ished, the first MP3, WMA and AAC file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3, WMA and AAC files or create any unnecessary folders.
Page 282: Using The Aux Port
5-6. Using an external device Using the AUX port To use the AUX port, connect a portable player, press the “AUDIO” button, then select “AUX” to display the audio control screen. Connecting a portable audio player P. 253 ■ Operating portable audio players connected to the multimedia system The volume can be adjusted using the vehicle's audio controls.
Page 283: Communication
® 5-7.Connecting Bluetooth Preparations to use wireless communica- tion ® The following can be performed using Bluetooth wireless com- munication: ■ A portable audio player can be operated and listened to via multimedia system ■ Hands-free phone calls can be made via a cellular phone In order to use wireless communication, register and connect a ®...
Page 284: Connecting Bluetooth
® 5-7. Connecting Bluetooth WARNING  ■ Certifications for the Bluetooth FCC ID: BABFT0049B FCC ID: AJDK068 ● CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Expo- sure Guidelines in Supplement C to OET65.
Page 285 ® 5-7. Connecting Bluetooth Device registration/connection flow ® 1. Register the Bluetooth device to be used with multimedia system (P. 287, 288, 289) ® 2. Connect the Bluetooth device to be used (P. 291) To be used for audio To be used for hands-free phone ®...
Page 286 ® 5-7. Connecting Bluetooth Registering and connecting from the “Bluetooth* Setup” screen To display the screen shown below, press the “SETUP” button and select “Bluetooth ” on the “Setup” screen. Select to connect the device to be used with multimedia sys- tem.
Page 287: First Time
® 5-7. Connecting Bluetooth ® Registering a Bluetooth audio player for the first time ® To use the Bluetooth Audio, it is necessary to register an audio player with the system. Once the player has been registered, it is possible to use the ®...
Page 288: Phone For The First Time
® 5-7. Connecting Bluetooth ® Registering a Bluetooth phone for the first time To use the hands-free system, it is necessary to register a ® Bluetooth phone with the system. Once the phone has been registered, it is possible to use the hands-free system.
Page 289: Device
® 5-7. Connecting Bluetooth ® Registering a Bluetooth device ® Bluetooth compatible phones (HFP) and portable audio players (AVP) can be registered simultaneously. You can register up to 5 ® Bluetooth devices. ® How to register a Bluetooth device Display the “Bluetooth* Setup” screen. (P. 286) Select “Add”.
Page 290 ® 5-7. Connecting Bluetooth Select “OK” when the connection status changes from “Connect- ing...” to “Connected”. If an error message is displayed, follow the guidance on the screen to try again. Registration can be performed from screens other than the “Bluetooth* Setup”...
Page 291: Device
® 5-7. Connecting Bluetooth ® Connecting a Bluetooth device ® Up to 5 Bluetooth devices (Phones [HFP] and audio players [AVP]) can be registered. ® If more than 1 Bluetooth device has been registered, select which device to connect to. Press the “SETUP”...
Page 292 ® 5-7. Connecting Bluetooth Manual connection When auto connection has failed or “Bluetooth* Power” is turned off, ® you must connect the Bluetooth device manually. ® Follow the steps in “Connecting a Bluetooth device” from “STEP 1”. (P. 291) : Bluetooth is a registered trademark of Bluetooth SIG, Inc. ®...
Page 293: Device Details
® 5-7. Connecting Bluetooth ® Displaying a Bluetooth device details You can confirm and change the registered device details. ® Bluetooth device registration status Display the “Bluetooth* Setup” screen. (P. 286) Select the device. Select “Device Info”. The following screen is dis- played: Device Name Change connection method...
Page 294: System Settings
® 5-7. Connecting Bluetooth ® Detailed Bluetooth system settings ® You can confirm and change the detailed Bluetooth settings. ® How to check and change detailed Bluetooth settings Display the “Bluetooth* Setup” screen. (P. 286) Select “System Settings”. The following screen is dis- played: ®...
Page 295: Audio
® 5-8.Bluetooth Audio ® Listening to Bluetooth Audio ® The Bluetooth audio system enables the user to enjoy music played on a portable player from the vehicle speakers via wire- less communication. ® When a Bluetooth device cannot be connected, check the connec- tion status on the “Bluetooth* Audio”...
Page 296: Phone
® 5-9.Bluetooth phone ® Using a Bluetooth Phone The hands-free system is a function that allows you to use your cellular phone without touching it. ® ® This system supports Bluetooth . Bluetooth is a wireless data system that allows the cellular phone to wirelessly connect to the hands-free system and make/receive calls.
Page 297 ® 5-9. Bluetooth phone ■ Telephone switch (P. 308) ■ Microphone The vehicle’s built in micro- phone is used when talking on the phone. The person you are speaking to can be heard from the front speakers. ® To use the hands-free system, you must register your Bluetooth phone in the system.
Page 298: Making A Call
® 5-9. Bluetooth phone Making a call ® Once a Bluetooth phone is registered, you can make a call using the following procedure: Dialing Display the phone screen. (P. 296) Select the “Dial Pad” tab and enter a phone number. To delete the input phone number, select For the first digit, you can enter “+”...
Page 299 ® 5-9. Bluetooth phone Press the switch on the steering wheel. If the phonebook is empty, a message will be displayed. ® For a PBAP compatible Bluetooth phone and “Automatic Contact/  History Transfer” is off Select the desired item. Select to transfer new con- tacts from a cellular phone, select “Always”...
Page 300 ® 5-9. Bluetooth phone Calling using favorites list You can make a call using numbers registered in the contact. Display the phone screen. (P. 296) Select “Favorites” tab. Select the desired number to make a call. Dialing from call history You can make a call using the call history, which has the 3 functions below.
Page 301: Receiving A Call
® 5-9. Bluetooth phone Receiving a call When a call is received, the following screen is displayed together with a sound. To answer the phone Press the switch on the steer- ing wheel or select To refuse a call Press the switch on the steering wheel or select To adjust the incoming call volume Turn the “PWR/VOL”...
Page 302: Speaking On The Phone
® 5-9. Bluetooth phone Speaking on the phone The following screen is displayed when speaking on the phone. To adjust the call volume Select “-” or “+”. You can also adjust the volume using the steering switches or the volume knob. To prevent the other party from hearing your voice Select “Mute”.
Page 303 ® 5-9. Bluetooth phone ■ Release Tones ● A continuous tone signal is a character string that consists of numbers and the characters p or w. (e.g.056133w0123p#1) ● When the “p” pause tone is used, the tone data up until the next pause tone will be automatically sent after 2 seconds have elapsed.
Page 304 ® 5-9. Bluetooth phone Call waiting When a call is interrupted by a third party while talking, an incoming call message will be displayed. To talk with the other party: • Press the switch on the steering wheel. • Select To refuse the call: •...
Page 305: Message Function
® 5-9. Bluetooth phone ® Bluetooth phone message function Received messages can be forwarded from the connected ® Bluetooth phone, enabling checking and replying using the multimedia system. ® Depending on the type of Bluetooth phone connected, received messages may not be transferred to the message inbox. If the phone does not support the message function, this func- tion cannot be used.
Page 306 ® 5-9. Bluetooth phone Checking the messages Display the message inbox screen. (P. 305) Select the desired message from the list. Check that the message is dis- played. E-mails: Select “Mark Unread” or “Mark Read” to mark mail unread or read on the message inbox screen.
Page 307 ® 5-9. Bluetooth phone Replying to a message Display the message inbox screen. (P. 305) Select the desired message from the list. Select “Quick Message”. Select the desired message. Select “Send”. ■ Editing quick reply message Select “Quick Message”. Select corresponding to the desired message to edit.
Page 308: Wheel Switches
® 5-9. Bluetooth phone Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone. Operating a telephone using the steering wheel switches ■ Steering wheel switches on the right hand side Off hook switch •...
Page 309: Settings
® 5-9. Bluetooth phone ® Bluetooth phone settings You can adjust the hands-free system to your desired settings. “Phone/Message Settings” screen To display the screen shown below, press the “SETUP” button, and select “Phone” on the “Setup” screen. Set the phone connection (P.
Page 310: Settings
® 5-9. Bluetooth phone Contact/Call History Settings ® The contact can be transferred from a Bluetooth phone to the sys- tem. The contact also can be added, edited and deleted. The call history can be deleted and contact and favorites can be changed.
Page 311: Using A Bluetooth Phone
® 5-9. Bluetooth phone Update contacts from phone Operation methods differ between PBAP compatible and PBAP ® incompatible but OPP compatible Bluetooth phones. If your cellular phone is neither PBAP nor OPP compatible, the con- tacts cannot be transferred. ® ■...
Page 312 ® 5-9. Bluetooth phone ■ Updating the contacts in a different way (From the “Call His- tory” screen) ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Contact/History Transfer” is set to off. (P. 310) Display the phone screen. (P. 296) Select the “Call History”...
Page 313 ® 5-9. Bluetooth phone Editing the contact data ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Contact/History Transfer” is set to off. (P. 310) Select “Edit Contact”. Select the desired contact. Select corresponding to the desired name or number. ...
Page 314 ® 5-9. Bluetooth phone Favorites list setting Up to 15 contacts (maximum of 4 numbers per contact) can be regis- tered in the favorites list. ■ Registering the contacts in the favorites list Select “Add Favorite”. Select the desired contact to add to the favorites list. Dimmed contacts are already stored as a favorite.
Page 315 ® 5-9. Bluetooth phone ■ Deleting the contacts in the favorites list Select “Remove Favorite”. Select the desired contacts and select “Remove”. Select “Yes” when the confirmation screen appears. Check that a confirmation screen is displayed when the opera- tion is complete. ...
Page 316 ® 5-9. Bluetooth phone Message Settings Display the “Phone/Message Settings” screen. (P. 309) Select “Messaging Settings”. Select the desired item to be set. automatic message transfer on/off. automatic message readout on/off. Set the SMS/MMS notifica- tion popup on/off. Set the e-mail notification popup on/off.
Page 317 ® 5-9. Bluetooth phone ■ Displaying the “Messaging Settings” screen in a different way Display the phone screen. (P. 296) Select Select “Settings”. Phone Display Settings Display the “Phone/Message Settings” screen. (P. 309) Select “Phone Display Settings”. Select the desired item to be set.
Page 318: (Troubleshooting)
 For a list of specific devices which operation has been confirmed on this system, check with your Toyota dealer or the following web- site: http://www.toyota.com/entune.html The Bluetooth version of the connected cellular phone may be older than the specified version.
Page 319 ® 5-9. Bluetooth phone When registering/connecting a cellular phone  A cellular phone cannot be registered. An incorrect passcode was entered on the cellular phone.  Enter the correct passcode on the cellular phone. The registration operation has not been completed on the cellular phone side.
Page 320  For a list of specific devices which operation has been confirmed on this system, check with your Toyota dealer or the following web- site: http://www.toyota.com/entune.html Automatic phonebook transfer function on this system is set to off.
Page 321 ® 5-9. Bluetooth phone In other situations  Even though all conceivable measures have been taken, the symptom sta- tus does not change. The cellular phone is not close enough to this system.  Bring the cellular phone closer to this system. The cellular phone is the most likely cause of the symptom.
Page 322: Bluetooth
® 5-10.Bluetooth ® Bluetooth ® ■ When using the Bluetooth audio system ● In the following conditions, the system may not function. • If the portable audio player is turned off • If the portable audio player is not connected •...
Page 323 ® 5-10. Bluetooth ■ ® Bluetooth antenna The antenna is built into the display. If the portable audio player is behind the seat or in the glove box or console box, or is touching or covered by metal objects, the connection status may deteriorate.
Page 324 ® 5-10. Bluetooth ■ Compatible models ® The Bluetooth audio system supports portable audio players with the follow- ing specifications ● ® Bluetooth specifications: Ver. 2.0, or higher (Recommended: Ver. 3.0+EDR or higher) ● Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (Recommended: Ver.
Page 325 ® 5-10. Bluetooth ■ Certification NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 326 ® 5-10. Bluetooth WARNING ■ While driving Do not use the portable audio player, cellular phone or connect a device to ® the Bluetooth system. ■ Caution regarding interference with electronic devices ® ● Your audio unit is fitted with Bluetooth antennas.
Page 327: Voice Command System
5-11.Using the voice command system Voice command system The voice command system enables the hands-free system to be operated using voice commands. Operations of the voice command system can be performed by selecting the menu corresponding to each function on the screen.
Page 328 5-11. Using the voice command system Casual speech recognization Due to natural language speech recognition technology, this system enables recognition of a command when spoken naturally. However, the system cannot recognize every variation of each command. In some situations, it is possible to omit the command for the proce- dure and directly state the desired operation.
Page 329 5-11. Using the voice command system Phone  Command Action Places a call to the phone number of the latest outgo- “Redial” ing call Places a call to the phone number of latest incoming “Call Back” call “Show Recent Displays the call history screen Calls”...
Page 330 5-11. Using the voice command system...
Page 331: Interior Features
Interior features 6-1. Using the air 6-3. Using the storage conditioning system features and defogger List of storage features ..343 Automatic air conditioning • Glove box...... 344 system......332 • Console box....344 Seat heaters...... 339 • Coin holder ....345 6-2.
Page 332: System
6-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls ■ Adjusting the temperature setting To adjust the temperature setting, turn clockwise to increase the temperature and counterclockwise to decrease the tempera- ture.
Page 333 6-1. Using the air conditioning system and defogger ■ Change the airflow mode To change the airflow mode, press outlets used switched each time the button is pressed. Air flows to the upper body. Air flows to the upper body and feet.
Page 334 6-1. Using the air conditioning system and defogger Other functions ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recir- culated air mode (indicator on) each time is pressed. ■...
Page 335 6-1. Using the air conditioning system and defogger Air outlets ■ Location of air outlets The air outlets and air volume change according selected airflow mode. : If equipped ■ Adjusting the position of and opening and closing the air out- lets Front Rear (if equipped)
Page 336 6-1. Using the air conditioning system and defogger ■ Operation of the air conditioning system in Eco drive mode In Eco drive mode, the air conditioning system is controlled as follows to pri- oritize fuel efficiency: ● Engine speed and compressor operation controlled to restrict heating/cool- ing capacity ●...
Page 337 6-1. Using the air conditioning system and defogger ■ When the outside temperature is low The dehumidification function may not operate even when is pressed. ■ Ventilation and air conditioning odors ● To let fresh air in, set the air conditioning system to the outside air mode. ●...
Page 338 6-1. Using the air conditioning system and defogger NOTICE ■ Humidity sensor In order to detect fog on the windshield, a sensor which monitors the temperature of the windshield, the surround humidity, etc. is installed. (P. 336) Follow these points to avoid damaging the sensor: ●...
Page 339: Seat Heaters
6-1. Using the air conditioning system and defogger  Seat heaters WARNING ● Care should be taken to prevent injury if anyone in the following categories comes in contact with the seats when the heater is on: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
Page 340: 6-2. Using The Interior Lights
6-2. Using the interior lights Interior lights list Rear interior/personal lights (vehicles with moon roof) (P. 341) Interior light (vehicles without moon roof) (P. 341) Front interior/personal lights (vehicles with moon roof) or personal lights (vehicles without moon roof) (P. 341) Shift lever light (vehicles with moon roof) Power switch light Door courtesy lights...
Page 341: Interior Lights
6-2. Using the interior lights Interior lights Vehicles without moon roof Vehicles with moon roof   Turns the lights on Turns the lights on/off linked to door positions. Turns the lights on/off linked to door positions. Turns the lights on/off Turns the lights off The rear interior lights will turn on/ off together with the front interior...
Page 342 6-2. Using the interior lights ● Illuminated entry system: The lights automatically turn on/off according to the power switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are open/closed. ● If the following lights are left on when the power switch is turned off, the lights will go off automatically after 20 minutes: •...
Page 343: Using The Storage Features
6-3. Using the storage features List of storage features Auxiliary boxes (P. 347) Cup holders (P. 346) Glove box (P. 344) Open tray (P. 352) Bottle holders/door pockets Console box (P. 344) (P. 345) Coin holder (P. 345) WARNING ● Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: •...
Page 344: Glove Box
6-3. Using the storage features Glove box Open (press the button) Lock with the mechanical key Unlock with the mechanical key Console box Lift the lid while pulling up the lever to release the lock. ● When using the console box lid as an armrest, slide the console box lid for- ward as needed.
Page 345: Coin Holder
6-3. Using the storage features ● The console box is provided with a cut- out that allows cables to be routed from the power outlet in the console box with the lid closed. Coin holder Pull the lid down while pressing down the button.
Page 346: Cup Holders
6-3. Using the storage features NOTICE Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glass or paper cups containing liquid. The contents may spill and glass cups may break. Cup holders Front Rear...
Page 347: Auxiliary Boxes
6-3. Using the storage features Auxiliary boxes Type A Type B   Push the lid. Push the lid.  Type C (if equipped) ■ Cable pass through (type B) The auxiliary box is provided with a groove that allows cables to be routed from the power outlet in the auxiliary box with the lid closed.
Page 348 If the LED indicators flash even though the surface of the tray is not hot, the wireless charger may be malfunctioning. Consult your Toyota dealer. ■ When charging of the wireless charger stops temporarily If any of the following operations are performed with the electronic key present, charging may stop temporarily.
Page 349 Certification for the wireless charger  For vehicles sold in the U.S.A. This device complies with Part 18 of the FCC Rules. Toyota Motor Sales, U.S.A., Inc. 19001 S. Western Avenue Torrance, CA 90501  For vehicles sold in Canada This ISM device complies with Canadian ICES-001.
Page 350 6-3. Using the storage features WARNING ■ Items unsuitable for storing (type A only) Do not store items heavier than 0.4 lb. (0.2 kg). Doing so may cause the auxiliary box to open and the items inside may fall out, resulting in an accident. ■...
Page 351 If in situations other than above the wireless charger does not operate prop- erly or the operation indicator light is blinking, the wireless charger may be malfunctioning. Contact your Toyota dealer. ■ To prevent failure or damage to data (vehicles with a wireless charger) ●...
Page 352: Open Tray
6-3. Using the storage features Open tray WARNING Observe the following precautions when putting items in the open tray. Fail- ure to do so may cause items to be thrown out of the tray in the event of sudden braking or steering. In these cases, the items may interfere with pedal operation or cause driver distraction, resulting in an accident.
Page 353: Trunk Features
6-3. Using the storage features Trunk features Grocery bag hooks NOTICE To prevent damage to the hooks, do not apply too much load to the hooks.
Page 354: 6-4. Other Interior Features
6-4. Other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 355: Clock
6-4. Other interior features Clock The clock on the Entune Audio can be adjusted by the following pro- cedure. For vehicles with a navigation system or Entune Audio Plus, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MAN- UAL”. Press the “SETUP” button and select “General” and then select “Clock”.
Page 356: Ashtray
6-4. Other interior features Ashtray (if equipped) An ashtray can be installed in the cup holder. (P. 346) WARNING ● When not in use, keep the ashtray closed. In the event of sudden braking, an accident may occur due to an occupant being struck by the open ash- tray or ash flying out.
Page 357: Power Outlets
6-4. Other interior features Power outlets Please use as a power supply for electronic goods that use less than 12 VDC/10 A (power consumption of 120 W). When using electronic goods, make sure that the power consumption of all the connected power outlets is less than 120 W. ...
Page 358: Armrest
6-4. Other interior features Armrest Fold down the armrest for use. NOTICE To prevent damage to the armrest, do not apply too much load on the arm- rest. Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat.
Page 359: Coat Hooks
6-4. Other interior features Coat hooks Coat hooks are provided on the rear assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
Page 360: Garage Door Opener
6-4. Other interior features  Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices.  The garage door opener (HomeLink Universal Transceiver) is manu- ...
Page 361 6-4. Other interior features Press and hold one of the  HomeLink buttons and the transmitter button. When the  HomeLink indicator light changes from a slow to a rapid flash, you can release both buttons.  If the HomeLink indicator light comes on but does not flash, or flashes rapidly for 2 seconds...
Page 362 6-4. Other interior features ■ Programming a Rolling Code system (for U.S. owners) If your device is Rolling Code equipped, follow the steps under the heading  ” before proceeding with the steps listed below. “Programming HomeLink Locate the learn button on the ceiling mounted garage door opener motor.
Page 363 6-4. Other interior features ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your Toyota dealer for assistance. ■ Reprogramming a button  The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 364 6-4. Other interior features ■ Before programming ● Install a new battery in the remote control transmitter. ● The battery side of the remote control transmitter must be pointed away  from the HomeLink button. ■ To prevent 12-volt battery discharge ...
Page 365: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Connect service is subject to such then-applicable Terms and Conditions.
Page 366 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection availabil- ity, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 367 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunction (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services ■...
Page 368 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. ■ Emergency Assistance Button (“SOS”) In the event of an emergency on the road, push the “SOS”...
Page 369 6-4. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. ■ Exposure to radio frequency signals The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 370: Compass
6-4. Other interior features  Compass The compass on the inside rear view mirror indicates the direc- tion in which the vehicle is heading. Operation To turn the compass on or off, press and hold the switch for 3 seconds. Displays and directions Display Direction...
Page 371 6-4. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 372 6-4. Other interior features ■ Circling calibration When “C” appears on the dis- play, drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed. If there is not enough space to drive in a circle, drive around the block until a direction is dis- played.
Page 373 6-4. Other interior features NOTICE ■ To avoid compass malfunctions Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause the compass sensor to malfunction. ■ To ensure normal operation of the compass ●...
Page 374 6-4. Other interior features...
Page 375: Maintenance And Care
Maintenance and care 7-1. Maintenance and care Cleaning and protecting the vehicle exterior..376 Cleaning and protecting the vehicle interior... 379 7-2. Maintenance Maintenance requirements ....382 General maintenance..385 Emission inspection and maintenance (I/M) programs......389 7-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 376: Maintenance And Care Cleaning And Protecting
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 377 ■ Precaution regarding the rear bumper with Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, avoid using the system and consult your Toyota dealer.
Page 378 7-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 379: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 380 7-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 381 7-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 382: Maintenance Maintenance Requirements
Toyota recommends the following main- tenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 383 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 384 7-2. Maintenance WARNING ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. ■ Handling of the 12-volt battery ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 385: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 386 7-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should Accelerator pedal move smoothly (without uneven pedal effort or catching). • When parked on a slope and the Hybrid transmission “Park” mecha- shift lever is in P, is the vehicle nism securely stopped? •...
Page 387 7-2. Maintenance Items Check points • Do seat belts operate smoothly? Seat belts • The seat belts should not be dam- aged. • Do the seat controls operate prop- Seats erly? • Does the steering wheel rotate smoothly? • Does the steering wheel have the Steering wheel correct amount of free play? •...
Page 388 7-2. Maintenance WARNING ■ If the hybrid system is operating Turn the hybrid system off and ensure that there is adequate ventilation before performing maintenance checks.
Page 389: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 390: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
• Rag or paper towel (P. 400) • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- life hybrid organic acid technology Engine/power U.S.A.:...
Page 391 7-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Make sure that the “READY”...
Page 392: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. WARNING ■...
Page 393: Positioning A Floor Jack
7-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 394: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment Fuse boxes (P. 425) Power control unit coolant radiator (P. 398) Engine oil filler cap (P. 396) Condenser (P. 399) Engine oil level dipstick (P. 395) Electric cooling fans Brake fluid reservoir Engine coolant reservoir (P.
Page 395 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 396 7-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 397 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 398 U.S.A.: “Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deion- ized water. (Minimum temperature: -31F [-35C]) Canada: “Toyota Super Long Life Coolant” is a mixture of 55% coolant and 45% deion- ized water.
Page 399 If the coolant level drops within a short time of replenishing Visually check the radiators, hoses, engine/power control unit coolant reser- voir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. WARNING ■...
Page 400 7-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. “MAX” “MIN” ■ Adding fluid Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Item...
Page 401 7-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi-information display, washer tank may be empty. Add washer fluid. (P. 461) WARNING ■ When adding washer fluid Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the hybrid sys- tem etc.
Page 402: 12-Volt Battery
7-3. Do-it-yourself maintenance 12-volt battery Location The 12-volt battery is located on the right-hand side of the trunk. Removing the 12-volt battery cover Pull the 12-volt battery cover while pressing down on the tab. Installing the 12-volt battery cover Install the cover Lift the tab to secure to the trunk liner...
Page 403 12-volt battery was disconnected. Make sure to turn off the power before disconnecting the 12-volt battery. Take extra care when connecting the 12-volt battery if the power switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer.
Page 404 When replacing the 12-volt battery Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explosion. For replacement of the 12-volt battery, contact your Toyota dealer.
Page 405 7-3. Do-it-yourself maintenance NOTICE ■ When recharging the 12-volt battery Never recharge the 12-volt battery while the hybrid system is operating. Also, be sure all accessories are turned off.
Page 406: Tires
Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the Front same interval as tire inspection. Do not fail to initialize the tire pressure warning system after tire rotation.
Page 407 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valves and transmitter ID codes registered by your Toyota dealer. (P. 408) ◆ Initializing the tire pressure warning system ■...
Page 408 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by your Toyota dealer.
Page 409 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels (vehicles with a tire pressure warning...
Page 410 7-3. Do-it-yourself maintenance ■ Tire types ● Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 411 ● In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equip- ment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 412 7-3. Do-it-yourself maintenance ■ The initialization operation (vehicles with a tire pressure warning system) ● Make sure to carry out initialization after adjusting the tire inflation pres- sure. Also, make sure the tires are cold before carrying out initialization or tire inflation pressure adjustment.
Page 413 After performing initialization, the tire pressure warning light blinks for 1 minute then stays on while driving. If the inflation pressure of each tire is still not displayed, have the vehicle inspected by your Toyota dealer. ■ Tire pressure warning system certification...
Page 414 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 415 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 416: Tire Inflation Pressure
7-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (P. 505)
Page 417 Driving with incorrect tire inflation pressure may result in the following: ● Reduced fuel efficiency ● Reduced driving comfort and tire life ● Reduced safety ● Damage to the drivetrain If a tire needs frequent inflating, have it checked by your Toyota dealer.
Page 418 7-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 419: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 420 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 421: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the power switch off. Open glove remove the glove box cover inside the glove box. Remove the filter cover. Remove the air conditioning fil- ter and replace it with a new one.
Page 422 7-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Schedule maintenance guide”...
Page 423: Electronic Key Battery
7-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2032 Replacing the battery Take out the mechanical key. Remove the cover.
Page 424 7-3. Do-it-yourself maintenance ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace the battery only with the same or equivalent type recommended by the manufacturer.
Page 425: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the power switch off. Open the fuse box cover. Engine compartment (type A) Engine compartment (type B) ...
Page 426  Normal fuse Blown fuse Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C: Contact your Toyota dealer.
Page 427 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 428) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 428: Light Bulbs
Light bulbs You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 429 7-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight high beams/daytime running light (halogen bulb) Turn the bulb base counter- clockwise. Pull the bulb out while press- ing the lock release of the connector. When installing, reverse the steps listed.
Page 430 7-3. Do-it-yourself maintenance ■ Headlight low beams Turn the bulb base counter- clockwise. Pull the bulb out while press- ing the lock release of the connector. When installing, reverse the steps listed. ■ Front side marker lights Turn the bulb base counter- clockwise.
Page 431 7-3. Do-it-yourself maintenance ■ Front turn signal/parking lights (bulb type) To ensure enough space to perform work, turn the steer- ing wheel to rotate the front wheel away from the bulb to be replaced. Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac-...
Page 432 7-3. Do-it-yourself maintenance Remove the light bulb. When installing, reverse the steps listed. ■ Stop/tail/rear side marker lights and rear turn signal lights Open trunk remove the luggage trim cover clips. (P. 436) Pull the hook while depress- ing the button. Partly remove the luggage trim cover.
Page 433 7-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Rear turn signal light Stop/tail/rear side marker light Remove the light bulb. Rear turn signal light Stop/tail/rear side marker light When installing, reverse the steps listed.
Page 434 7-3. Do-it-yourself maintenance ■ Back-up lights Open trunk remove the clips. (P. 436) Then partly remove the trunk panel cover. Unplug the connector while depressing the lock release. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 435 Remove the light bulb. When installing, reverse the steps listed. ■ Replacing the following bulbs If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Parking lights/daytime running lights (LED type) ● High mounted stoplights...
Page 436 Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Contact your Toyota dealer for more information in the following situations: ● Large drops of water have built up on the inside of the lens.
Page 437: When Trouble Arises
When trouble arises 8-1. Essential information Emergency flashers ..438 If your vehicle has to be stopped in an emergency ...... 439 8-2. Steps to take in an emergency If your vehicle needs to be towed ......440 If you think something is wrong ......
Page 438: Emergency Flashers
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 439: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 440: Steps To Take In An Emergency If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 441 Release the parking brake. Use a towing dolly under the front wheels. Using a flat bed truck If your Toyota is transported by a flatbed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
Page 442 8-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle Be sure to transport the vehicle with the front wheels raised or with all four wheels raised off the ground.
Page 443: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 444: If A Warning Light Turns On Or A Warning Buzzer Sounds
 Immediately stop the vehicle in a safe place and con- (Canada) tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Brake system warning light in yellow Indicates a malfunction in: •...
Page 445 Indicates a malfunction in: • The SRS airbag system; • The front passenger occupant classification system; or • The seat belt pretensioner system  Have the vehicle inspected by your Toyota dealer immediately. ABS warning light Indicates a malfunction in: •...
Page 446 Toyota dealer. When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system  Have the system checked by your Toyota dealer.
Page 447 8-2. Steps to take in an emergency : Parking brake engaged warning buzzer: P. 455 : If equipped : Driver’s seat belt buzzer: The driver’s seat belt buzzer sounds to alert the driver that his or her seat belt is not fastened. Once the power switch is turned to ON mode, the buzzer sounds for 6 seconds.
Page 448 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 449 1 minute (vehicles with a tire pressure warning system) If the tire pressure warning light frequently comes on after blinking for 1 minute when the power switch is turned to ON mode, have it checked by your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard because of noisy place or an audio sound.
Page 450 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 451 8-2. Steps to take in an emergency WARNING ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 452 8-2. Steps to take in an emergency NOTICE ■ To ensure the tire pressure warning system operates properly (vehicles with a tire pressure warning system) Do not install tires with different specifications or makers, as the tire pressure warning system may not operate properly.
Page 453: If A Warning Message Or Indicator Is Displayed
Multi-information display If any of the warning message or indicator comes on again after the following actions have been performed, contact your Toyota dealer. Warning message and warning buzzer list Warning message Details/Actions Indicates that: •...
Page 454 8-2. Steps to take in an emergency Warning message Details/Actions Indicates that one or more of the doors is not fully closed The system also indicates which doors are not fully closed. If the vehicle reaches a speed of 3 mph (5 km/h), flashes and a buzzer sounds to indicate that the door(s) are not yet fully...
Page 455 Indicates a malfunction in the EPS (Electric Power Steering) system A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer. Indicates that the vehicle is being driven at 3 mph (5 km/h) or more with the parking brake still engaged A buzzer also sounds.
Page 456 Indicates a malfunction in: • The ABS; or • The brake assist system (U.S.A.) A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer. (Canada) Indicates a malfunction in the VSC (Vehicle Sta- bility Control) system.  Have the vehicle inspected by your Toyota dealer.
Page 457 • The dynamic radar cruise control system (if equipped) Press the “ON-OFF” button once to deactivate the system, and then press the button again to reactivate the system. A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer.
Page 458 Warning message Details/Actions Indicates a malfunction in the LDA (Lane Depar- ture Alert) system A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer. (If equipped) Indicates a malfunction in the PCS (Pre-Collision system) A buzzer also sounds.
Page 459  Stop and check. (P. 491) Indicates a malfunction in the Automatic High Beam system A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer. (If equipped) Indicates that the tire inflation pressure is low  Check the tire inflation pressure, and adjust to the appropriate level.
Page 460 If the tire pressure warning indicator flashes for 1 minute then illuminates, there is a malfunction in the system. Have the vehicle inspected by your Toyota dealer. (If equipped) Indicates that the tire position information can- not be recognized  Drive for a short while and check if the display updates.
Page 461 8-2. Steps to take in an emergency Warning message Details/Actions Indicates that the washer fluid level is low  Add washer fluid. Indicates that remaining fuel is approximately 2.6 gal. (9.7 L, 2.1 Imp. gal.) or less  Refuel the vehicle. Indicates that the TRAC (Traction Control) sys- tem has been deactivated ...
Page 462 8-2. Steps to take in an emergency Warning message Details/Actions Indicates that, since the VSC (Vehicle Stability Control) system was turned off, the pre-collision brake system operation is stopped  Turn the VSC on. (P. 220) (If equipped) Indicates that the PCS (Pre-collision system) is not currently functional because the grille cover or the sensor is dirty ...
Page 463  Have maintenance performed on the hybrid system (traction battery) cooling compo- nent at Toyota dealer. Indicates that the EV drive mode is not avail- able The reason the EV drive mode is not available...
Page 464 8-2. Steps to take in an emergency Warning message Details/Actions Indicates that the EV drive mode has been auto- matically canceled The reason the EV drive mode is not available (the hybrid battery [traction battery] charge is low, speed is higher than the EV drive mode operating speed range, accelerator pedal is depressed too much) may be displayed.
Page 465 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The driver’s door was opened Con- when the shift lever was not in  tinu- P and the power switch was not turned off.  Shift the shift lever to P. (Flashes) The driver’s door was opened and closed while the electronic...
Page 466 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to exit the vehicle with the electronic key and lock the doors without Contin- Once first turning the power switch off uous when the shift lever was in P.
Page 467 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to lock the doors using the smart key system while the electronic key Contin-  was still inside the vehicle. uous  Retrieve the electronic key from the vehicle and lock the doors again.
Page 468 Indicates a malfunction in the smart key system  Once  Have the vehicle inspected by your Toyota dealer. (Flashes) • When doors were unlocked with the mechanical key and then the power switch was pressed, the elec-...
Page 469 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to start the hybrid system with the shift lever in an incorrect position.  Once  Shift the shift lever to P and start the hybrid sys- tem.
Page 470 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer During a hybrid system starting procedure in the event that the electronic key was not function- ing properly (P. 485), the  Once power switch was touched with the electronic key.
Page 471: If You Have A Flat Tire
8-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 406 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 472 8-2. Steps to take in an emergency WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 473 8-2. Steps to take in an emergency Secure the luggage floor cover using the hook provided. Remove the jack. Taking out the spare tire Lift up the hook of the luggage floor cover on the trunk floor. Secure the luggage floor cover using the hook provided.
Page 474 8-2. Steps to take in an emergency Remove the tool tray. Loosen the center fastener that secures the spare tire. When taking out or stowing the spare tire, make sure to firmly hold opposite ends of the tire. WARNING ■ When storing the spare tire Be careful not to catch fingers or other body parts between the spare tire and the body of the vehicle.
Page 475 8-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 476 8-2. Steps to take in an emergency Turn the tire jack portion “A” by hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel. They indicate the jack point positions. Raise the vehicle until the tire is slightly raised off the ground.
Page 477 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the...
Page 478 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 479 8-2. Steps to take in an emergency Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Stow the flat tire, tire jack and all tools. ■...
Page 480 8-2. Steps to take in an emergency WARNING ■ When using the compact spare tire ● Remember that the compact spare tire provided is specifically designed for use with your vehicle. Do not use your compact spare tire on another vehicle. ●...
Page 481 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and...
Page 482: If The Hybrid System Will Not Start
8-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate procedure: The hybrid system will not start even though the correct starting procedure is being followed.
Page 483 ● The 12-volt battery may be discharged. (P. 487) ● One or both of the 12-volt battery terminals may be disconnected. (P. 402) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 484: If The Shift Lever Cannot Be Shifted From P
(a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.
Page 485: If The Electronic Key Does Not Operate Properly
(turn and hold) Unlocks the door Turning the key rearward unlocks the driver's door. Turning the key once again unlocks the other doors. Opens the windows and moon roof (turn and hold) : This setting must be customized at your Toyota dealer.
Page 486 8-2. Steps to take in an emergency Starting the hybrid system Ensure that the shift lever is in P and firmly depress the brake pedal. Touch the Toyota emblem side of the electronic key to the power switch. When electronic detected, a buzzer sounds and the power switch will turn to ON mode.
Page 487: If The Vehicle 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid sys- tem if the vehicle’s 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 488 ON mode, then start the vehicle's engine. Make sure the “READY” indicator comes on. If the indicator does not come on, contact your Toyota dealer. Once the hybrid system has started, remove the jumper cables in the exact reverse order from which they were connected.
Page 489 8-2. Steps to take in an emergency ■ Starting the hybrid system when the 12-volt battery is discharged The hybrid system cannot be started by push-starting. ■ To prevent 12-volt battery discharge ● Turn off the headlights and the audio system while the hybrid system is off. ●...
Page 490 8-2. Steps to take in an emergency WARNING ■ Avoiding 12-volt battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the 12-volt battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 491: If Your Vehicle Overheats
(radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir. Reservoir “F” line “L”...
Page 492 (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the hybrid system immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 493 Start the hybrid system and check for the multi-information dis- play. If the message does not disappear: Stop the hybrid system and contact your Toyota dealer. If the message is not displayed: Have the vehicle inspected at the nearest Toyota dealer.
Page 494 8-2. Steps to take in an emergency WARNING ■ When inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns. ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided.
Page 495: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the hybrid system. Set the parking brake and shift the shift lever to P.
Page 496 8-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components ● Avoid spinning the front wheels and depressing the accelerator pedal more than necessary. ● If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed.
Page 497: Vehicle Specifications
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.) ..498 Fuel information ....507 Tire information ....510 9-2. Customization Customizable features ..523 9-3. Items to initialize Items to initialize ....532...
Page 498: (Fuel, Oil Level, Etc.)
9-1.Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 190.9 in. (4850 mm) Overall width 71.7 in. (1820 mm) Overall height 57.9 in. (1470 mm) Wheelbase 109.3 in. (2775 mm) 62.4 in. (1585 mm) Front 62.8 in. (1595 mm) Tread 62.0 in.
Page 499 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 500 9-1. Specifications Engine Model 2AR-FXE Type 4-cylinder in line, 4-cycle, gasoline 3.54  3.86 in. (90.0  98.0 mm) Bore and stroke Displacement 152.2 cu. in. (2494 cm Valve clearance Automatic adjustment (engine cold) Fuel Fuel type Unleaded gasoline only Octane rating 87 (Research Octane Number 91) or higher Fuel tank capacity...
Page 501 5 minutes, and check the oil level on the dipstick. ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 502 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 503 7.6 qt. (7.2 L, 6.3 Imp. qt.) Power control unit 3.4 qt. (3.2 L, 2.8 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and...
Page 504 : The fluid capacity is a reference quantity. If replacement is necessary, con- tact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may ulti- mately damage the transmission of your vehicle. Brakes Pedal clearance 3.62 in. (92 mm) 0.04 ...
Page 505 9-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels  Type A Tire size P205/65R16 94S, T155/70D17 110M Driving under normal conditions Front: 35 psi (240 kPa, 2.4 kgf/cm bar) Rear: 35 psi (240 kPa, 2.4 kgf/cm bar) Spare: Tire inflation pressure...
Page 506 9-1. Specifications Light bulbs Light bulbs Bulb No. Type Headlights  Low beam High beam 9005 Front side marker lights Front turn signal/ parking lights 7444NA 28/8 Exterior (bulb type) Rear turn signal lights WY21W Stop/tail/rear side 7443 21/5 maker lights License plate lights Back-up lights Front...
Page 507: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 508 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 509 9-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used, the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 510: Tire Information
9-1. Specifications Tire information Typical tire symbols  Full-size tire  Compact spare tire...
Page 511 9-1. Specifications Tire size (P. 513) DOT and Tire Identification Number (TIN)(P. 512) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators(P. 406) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 512 9-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 513 9-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits)
Page 514 9-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer...
Page 515 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
Page 516 9-1. Specifications ■ Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 517 9-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
Page 518 9-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim A metal support for a tire or a tire and tube...
Page 519 9-1. Specifications Tire related term Meaning A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass rubber which, when inflated, bears the load The breaking away of pieces of the tread or...
Page 520 9-1. Specifications Tire related term Meaning A tire designated by its manufacturer as pri- Light truck (LT) tire marily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry Load rating for a given inflation pressure The load rating for a tire at the maximum per- Maximum load rating...
Page 521 9-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 522 9-1. Specifications Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
Page 523: Customization
Your vehicle includes a variety of electronic features that can be personalized to suit your preferences. The settings of these fea- tures can be changed by using the meter control switches, the Entune audio system screen or at your Toyota dealer. Customizing vehicle features ■...
Page 524: Customization Customizable Features
Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Settings that can be changed on the Entune Audio system screen Settings that can be changed by the meter control switches Definition of symbols: O = Available, —...
Page 525 9-2. Customization Customized set- Function Default setting ting On with the speed On with the speed limit caution indi- limit caution indi- cator (yellow) not Speed limit display — O cator (yellow) enabled enabled Maintenance system ini- — O tialization : For details about each function: P.
Page 526 Settings that can be changed using the Entune Audio system Settings that can be changed using the Entune Audio Plus system or Entune Premium Audio with Navigation system Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, — = Not available ■...
Page 527 9-2. Customization ■ Smart key system and wireless remote control (P. 110, 117) Customized set- Function Default setting ting Operation signal — O O (Emergency flashers) Operation signal — — O (Buzzer) Operation buzzer vol- Level 5 Off to level 7 O O O Time elapsed...
Page 528 9-2. Customization ■ Wireless remote control (P. 106, 110, 117) Customized set- Function Default setting ting Wireless remote control — — O Driver’s door unlocked in one All doors Unlocking operation step, all doors unlocked in one O O O unlocked in two step steps...
Page 529 9-2. Customization ■ Turn signal lever (P. 170) Customized set- Function Default setting ting The number of times the turn signal lights flash automatically when the turn signal lever — — O 4 to 7 moved to the first posi- tion during lane...
Page 530 9-2. Customization ■ Vehicle Proximity Notification System (P. 70) Customized set- Function Default setting ting The volume of Vehicle Level 2 Proximity Notification Level 1 O O O Level 3 System sound ■ Automatic air conditioning system (P. 332) Customized set- Function Default setting ting...
Page 531 9-2. Customization WARNING ■ During customization As the hybrid system needs to be operating during customization, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 532: 9-3. Items To Initialize
9-3. Items to initialize Items to initialize The following items must be initialized for normal system opera- tion after such cases as maintenance being performed on the vehicle: Item When to initialize Reference Message indicating mainte- After the maintenance is per- nance is required P.
Page 533: For Owners
For owners Reporting safety defects for U.S. owners......534 Seat belt instructions for Canadian owners (in French) ....... 535 SRS airbag instructions for Canadian owners (in French) ....... 537...
Page 534: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800- 331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 535: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 536 AVERTISSEMENT ■ Dommage et usure de la ceinture de sécurité Inspectez la ceinture de sécurité périodiquement. Vérifiez si elles ne sont pas entaillées, effilochées et que leurs ancrages ne sont pas desserrés. N’utilisez pas une ceinture de sécurité défectueuse avant qu’elle ne soit remplacée.
Page 537: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. ◆...
Page 538 ◆ Coussins gonflables latéraux et rideaux SRS Coussins gonflables latéraux avant SRS Participent à la protection du torse des occupants de siège avant Coussins gonflables latéraux arrière SRS Participent à la protection du torse des occupants des sièges latéraux arrière Coussins gonflables rideaux SRS ●...
Page 539 Composants du système de coussins gonflables SRS Capteurs d'impact avant Témoins indicateurs “AIR BAG ON” et “AIR BAG OFF” Système de classification de l'occupant du siège passager Témoin d'avertissement SRS avant (ECU et capteurs) Contact de boucle de ceinture Coussins gonflables de sécurité...
Page 540 Votre véhicule est équipé de COUSSINS GONFLABLES INTELLI- GENTS conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). L'ensemble de capteurs de coussins gonflables (ECU) régule le déploiement des coussins gon- flables sur la base des informations qu'il reçoit des capteurs, etc., indi- qués ci-dessus dans le schéma illustrant les composants du système.
Page 541 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS • Inclinez légèrement le dossier du siège. Bien que les véhicules aient une conception différente, un grand nom- bre de conducteurs peuvent s'asseoir à une distance de 10 in. (250 mm), même avec le siège conducteur complètement avancé, simple- ment en inclinant un peu le dossier de siège.
Page 542 Un nourrisson ou un enfant trop petit pour utiliser une ceinture de sécurité doit être correctement attaché au moyen d'un siège de sécurité enfant. Toyota recommande vivement d'installer tous les nour- rissons et enfants sur les sièges arrière du véhicule et de prévoir pour eux des systèmes de retenue adaptés.
Page 543 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS ● Ne fixez rien et ne posez rien sur des emplacements tels que la planche de bord, la garniture du volant et la partie inférieure du tableau de bord. Ces éléments peuvent se transformer en projectiles lorsque les coussins gon- flables conducteur, passager avant et genoux SRS se déploient.
Page 544 Si les parties renfermant les coussins gonflables SRS, comme les garnitu- res du volant et des montants avant et arrière, sont endommagées ou cra- quelées, faites-les remplacer par votre concessionnaire Toyota. ● Ne placez rien sur le siège du passager avant, comme un coussin par exemple.
Page 545 SRS Ne mettez pas votre véhicule au rebut et ne procédez à aucune des modifi- cations suivantes sans consulter votre concessionnaire Toyota. Les cous- sins gonflables SRS peuvent ne pas fonctionner correctement ou se déployer (se gonfler) accidentellement, provoquant la mort ou de graves blessures.
Page 547: Index
Index What to do if... (Troubleshooting) ....548 Alphabetical index ..... 551 Vehicles with a navigation system or Entune Audio Plus: For details of equipment related to the navigation sys- tem or Entune Audio Plus, such as the audio system, refer to the “NAVIGATION AND MULTIMEDIA SYS- TEM OWNER'S MANUAL”.
Page 548 Toyota dealer. (P. 107) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly. Contact your Toyota dealer immediately. (P. 109) The doors cannot be locked or unlocked ● Is the key battery weak or depleted? (P. 423) ●...
Page 549 What to do if... (Troubleshooting) If you think something is wrong The hybrid system does not start ● Did you press the power switch while firmly depressing the brake pedal? (P. 161) ● Is the shift lever in P? (P. 163) ●...
Page 550 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and the front passenger wearing the seat belts? (P. 446) ● The brake system warning light is on Is the parking brake released? (P.
Page 551: Alphabetical Index
Alphabetical index Alphabetical index Antennas (smart key system) ....121 A/C ..........332 Anti-lock Brake System Air conditioning filter ..... 421 (ABS) ........218 Function........ 218 (Anti-lock Brake System)..218 Warning light......445 Function ........ 218 Armrest........358 Warning light......445 Assist grips......
Page 552 Alphabetical index Back-up lights Care ........376, 379 Replacing light bulb ....434 Aluminum wheels ....377 Wattage ........ 506 Exterior ......... 376 Battery (12-volt battery) ..402 Interior ........379 Battery checking ....402 Seat belts......380 If the vehicle has discharged Cargo capacity......
Page 553 Alphabetical index Child safety ........ 55 12-volt battery Daytime running light precautions....404, 490 system........173 Airbag precautions....39 Defogger Battery precautions..404, 490 Outside rear view Child restraint system ..... 56 mirrors ........ 334 How your child should wear Rear window......
Page 554 Alphabetical index Driving ........148 If your vehicle becomes Break-in tips......149 stuck........495 Correct posture ....... 28 If your vehicle has to be stopped in an emergency... 439 Hybrid vehicle driving tips ..239 Procedures ......148 If your vehicle needs to be Winter drive tips ....
Page 555 Alphabetical index Entune Audio system .... 248 Audio input......253 Flat tire ........471 AUX port/USB port....253 Floor mats ........26 ® Bluetooth audio....295 Fluid CD player......269 Brake ........504 iPod........274 Hybrid transmission ....504 MP3/WMA disc ..... 269 Washer .........
Page 556 Alphabetical index Hybrid system......69 Emergency shut off system ..74 Garage door opener ....360 Energy monitor/ Gauges ........88 consumption screen ..... 98 Glove box ......... 344 EV drive mode ...... 166 Grocery bag hooks....353 High voltage components ..73 Hybrid System Indicator ..
Page 557 Alphabetical index Inside rear view mirror .... 136 Instrument panel light Lane Departure Alert (LDA) ..202 control ........89 LATCH anchors ......61 Interior lights......340 LDA (Lane Departure Alert) ..202 Switch ........341 Lever Wattage ........ 506 Auxiliary catch lever....
Page 558 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance... 390 Noise from under vehicle ... 8 General maintenance ... 385 Maintenance data ....498 Maintenance Odometer ........88 requirements ...... 382 Resetting the message Engine oil......501 indicating maintenance is Opener required ......383 Fuel filler door.......
Page 559 Alphabetical index Parking brake......171 Radar cruise control (dynamic Operation ......171 radar cruise control) ..... 189 Parking brake engaged Radiator........399 warning buzzer ... 444, 455 Radio ........267 Parking brake engaged Rear interior lights ....341 warning message ....455 Wattage ........
Page 560 Alphabetical index Sensor Automatic headlight Safety Connect ......365 system........ 173 Seat belt reminder light... 446 Automatic High Beam Seat belts........30 system........ 179 Adjusting the seat belt .... 31 Humidity sensor....338 Automatic Locking Inside rear view mirror ..137 Retractor (ALR) ....
Page 561 Alphabetical index Spark plug ........ 503 Eco drive mode switch..169 Specifications ......498 Emergency flasher switch..438 Speech command system EV drive mode switch ... 166 Garage door opener Speedometer......88 Steering lock switches ......360 Column lock release ..... 164 Ignition switch .......
Page 562 Alphabetical index Size........505 Snow tires......244 Tail lights........172 Spare tire ......471 Light switch ......172 Tire pressure warning Replacing light bulbs..... 432 system........ 407 Wattage ........ 506 Warning light......446 Talk switch ......327 Warning message..459, 460 Telephone switches ....
Page 563 Alphabetical index Warning lights ......85 ABS ........445 USB port ......... 253 Brake system......444 Electric power steering system........ 445 Vanity lights ......354 Low fuel level......446 Wattage ........ 506 Malfunction indicator lamp..444 Vanity mirrors ......354 Master warning light .....
Page 564: Gas Station Information
17.0 gal. (64.35 L, 14.2 Imp. gal.) (Reference) Fuel type P. 182, 500 Cold tire inflation P. 505 pressure Engine oil capacity (Drain and refill — P. 501 reference) “Toyota Genuine Motor Oil” or equivalent Engine oil type P. 501...

Toyota Camry Owner's Manual

For Safety and Security

1-1. for Safe Use

Hybrid System Precautions

1-3. Theft Deterrent System

Instrument Cluster

Instrument Cluster Warning Lights and

Operation of each Component

3-1. Key Information

3-2. Opening, Closing and

3-3. Adjusting the Seats

3-4. Adjusting the Steering

Opening and Closing

Driving

4-1. before Driving

Driving Procedures

4-3. Operating the Lights

Refueling

4-5. Using the Driving

Driving Tips

Audio System

5-1. Basic Operations

5-2. Setup

Using the Multimedia System

Using the Radio

Playing an Audio CD and MP3/WMA/AAC Discs

Using an External Device

Audio

5-9. Bluetooth Phone

5-10. Bluetooth

5-11. Using the Voice

Interior Features

6-1. Using the Air

6-2. Using the Interior Lights

Using the Storage Features

6-4. Other Interior Features

Maintenance and Care

Maintenance and Care Cleaning and Protecting

Maintenance Maintenance Requirements

Do-It-Yourself Maintenance Do-It-Yourself Service Precautions

When Trouble Arises

8-1. Essential Information

Steps to Take in an Emergency if Your Vehicle Needs to be Towed

Vehicle Specifications

Specifications Maintenance Data

Customization

9-3. Items to Initialize

For Owners

Quick Links

Troubleshooting

Related Manuals for Toyota Camry

Summary of Contents for Toyota Camry
