Page 1
All rights reserved. No part of this publication may by reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronics, mechanical, photocopying, or otherwise without the prior permission of Philips 3141 785 30483 Version 1.3...
Page 2
Start up the device. • Follow all screen instructions to complete the Connect the device via USB to the computer and start up the Philips Device Manager (DM). firmware upgrade. • The Device Manager will close automatically once Click RESTORE to format and rebuild the database of the new HDD.
Page 3
1.0 TECHNICAL SPECIFICATION and SERVICE HINTS micro jukebox by clicking on the icon in your task tray bar. When prompted, “The USB Mass Storage Device can now be safely removed from the system”, click OK and unplug your micro jukebox. Once the GoGear micro jukebox is disconnected from the computer, the display will show “Firmware Upgrading”...
Page 4
2.0 SAFTETY INSTRUCTIONS WAARSCHUWING WARNING Alle IC’s en vele andere halfgeleiders zijn All ICs and many other semi-conductors are gevoelig voor electrostatische ontladingen susceptible to electrostatic discharges (ESD). (ESD). Careless handling during repair can reduce life Onzorgvuldig behandelen tijdens reparatie kan drastically.
Page 5
3.0 Instructions for use Overview of controls and connections USB cable connector Headphones jack 5V DC Charging socket HOLD slider To disable key press LCD display Dynamically displays menu, options and track information VIEW To switch between root menu, library and now playing screens Scroll;...
Page 6
4.0 MECHANICAL INTRUCTIONS Set Disassembly 1. Remove the Cosmetic screw with an Allen key 2. Use a screwdriver to carefully lift up the back cover of the device. 3. Gently open up the back cover. 4. Remove 4 x screws. See arrows...
Page 7
4.0 MECHANICAL INTRUCTIONS 5. Open up and remove the bottom part. 6. Remove the battery pack and then the hard disk 7. Take out the 2 screws on the PCB assembly to replace the board from the casing. Overview of the disassembly parts Hard Disk Mainboard /...
Page 25
• Include content on HDD082/17 • Chapter 5 Changes in the service 12NC on the following parts FRONT CAB. ASSY HDD084 SILVER (314017750142) COVER-REAR LAQ ASSY HDD084 SIL (314017750172) REAR CABINET ASSY HDD084 (314017750132) • Chapter 5 Adding of the following new service parts HDD 1"...
