WINDOW TYPE ROOM AIR CONDITIONER USER MANUAL HW-18CH2N HW-18CH3N HW-18CT3N HW-18CH2CNA HW-18CH3CNA HW-18CT3CNA Please read this operation manual before using the air conditioner. Please keep it attentively. P/No. HA 0500025... - Page 2 Dear Friend, At the outset, we at Haier thank you for your interest in our range of products. A unique and international range of appliances designed solely with the purpose of making modern life simpler. But how! The entire Haier range of appliances,...
-
Page 3: Table Of Contents
Contents ........................4 Parts Names Parts & Functions ......................5 Operation Guide ......................6-9 ........................10 Usage Musts ......................11-12 Maintenance ..........................13 Cautions ......................14 Trouble Shooting ....................15 Installation Instructions ......................16 Installation Guide... -
Page 4: Parts Names
Parts Names Machine body Air inlet (outdoor side) Front panel Air outlet (indoor side) Air inlet (indoor side) Operation panel Cabinet Remote Controller Operation Panel ENERGY SWING SAVER TEMP. TEMP POWER COOL SLEEP TIMER MODE SPEED T.ON T.OFF... -
Page 5: Parts & Functions
Parts and Functions TEMP T.ON T.OFF 1. Down(-) 2. Up(+) 3. Power 4. Fan Speed 5. Turbo 6. Mode 7. Swing 8. Hr/Min 9. Sleep 10. Timer On 11. Timer Off 12. Set 13. Clock Button... -
Page 6: Operation Guide
Operation Guide POWER Press the ON/OFF key on the Control Panel or Remote Control to turn the unit On/Off. The A/C starts with the previous setting. MODE The unit can be operated in any one of the following modes : 1) Cool : The temperature setting is adjustable between 16°C and 30°C. - Page 7 Operation Guide...
- Page 8 Operation Guide (THIS FEATURES IS AVAILABLE IN SELECTED MODEL)
-
Page 9: Operation Guide
Operation Guide... -
Page 10: Usage Musts
Usage musts Suitable indoor temperature. Cleaning of the air filter. Close the doors and windows during Use the timer reasonably. running. Do remember the following: Do not spray water on the machine. No obstructions allowed at the air inlet and outlet. Do not pull the power line with hands. -
Page 11: Maintenance
Maintenance Air filter cleaning: Please clean the air filter every two weeks When dirt accumulates in the air filter, air circulation will be blocked, and causes poor cooling. It is advisable to clean the air filter every two weeks for efficient operation. Removal of air filter 1. -
Page 12: Maintenance
Maintenance Do not clean the machine with Before cleaning please pull off the power plug. following material in order to decrease pollution: petrol, detergent. Do not pour water on the machine to Hot water above 40°C may cause prevent electric shock or mechanical discoloration of the shell or trouble. -
Page 13: Cautions
Cautions Avoid opening doors and windows Keep heat sources away from the as much as possible. air conditioner. Keep away from me Use curtain or blinds. Before operating the mode selection Direct sunlight may reduce cooling switch, check whether the air inlet effect, so always use window curtain. -
Page 14: Trouble Shooting
Trouble Shooting Condition Check Item Corrective Action Doesn't Is plug firmly inserted? Restore power or replace operate Is fuse burned out? fuse. Is there power failure? Is thermostat switch Adjust the themostate. incorrectly adjusted? Is there direct sunlight Use curtain or blinds. into the room? Is mode selection switch Select cool mode. -
Page 15: Installation Instructions
Installation Instructions Selection of the installation position 1. Select position where the structure is firm. 2. Select position where the air inlet and outlet are not blocked by obstacles. 3. Select position where the cooled air can be blown to every corner of the room. -
Page 16: Installation Guide
Installation Guide Installation of air conditioner (only for reference) 1. Make a wooden frame. (Fig.1) Metal support Model 440mm 670mm 1.5Tr/2.0Tr WAC Thickness of wall Fig.1 2. Attach a metal support (not provided by manufacturer) in a firm location with expanding screws or bolts. -
Page 17: Product Warranty
HAIER WARRANTY HAIER Appliances (India) P.Ltd (hereinafter referred to as “the company”) hereby offers the following warranty to the original domestic purchaser commencing from the date of the purchase. Product Warranty Period Parts not coverd 12 Months Remote, Cabinet Colour TV... - Page 18 12) In case of DVD player, the customer will have to bring it to the nearest authorized Haier Service Center other wise visit charges will be applicable. 13) Demo for Direct Cool Refrigeration, Semi Automatic Washing Machine, CTV below 74cm and DVD will be on chargeable basis by the company, however the call center can provide support over telephone.
