Linear XR-D Installation Instructions

XR-D
X
TENDED RANGE
SERIAL DATA
OUTPUT
SUPERVISED
STATIONARY
RECEIVER
For Use With Linear's
XR Series Xtended
Range Transmitters
Installation
Instructions
(760) 438-7000 • FAX (760) 438-7043
USA & Canada (800) 421-1587 & (800) 392-0123
Toll Free FAX (800) 468-1340
www.linearcorp.com
3. COMPONENT LOCATIONS
SINGLE-PACKET OPTION JUMPER
(USE AS SHOWN FOR NEW DATA ONLY PACKET
PER TRANSMISSION, PLACE ON
OTHER PINS FOR ALL PACKETS
FOR EACH TRANSMISSION)
TEST
BUTTON
RF SIGNAL
INDICATOR
(RED)
POWER
INDICATOR
(GREEN) SIGNAL
AUDIO
LEVEL
OUTPUT
TEST POINTS
POWER & DATA OUTPUT
TERMINAL BLOCK
1. PRODUCT DESCRIPTION
WARNING: THIS
Linear's Xtended Range FM receivers and transmitters are designed for use in various
PRODUCT SHOULD NOT
wireless remote control applications. The Model XR-D serial data output receiver is used for
BE USED IN LIFE
specialty O.E.M. data acquisition and processing systems. When the Model XR-D receiver
SAFETY APPLICATIONS.
detects a signal from its companion transmitter(s), it will output 9600 baud ASCII serial data
FCC Rules allow
through its RS-232 style interface in "real-time" (no buffering) as the transmitted data is
unlicensed high-power
received.
transmissions at or near
the operating frequency
The XR-D receiver's serial data output contains all of the information that can be sent from
of this product which
any type of Linear's Xtended Range transmitters. In a typical installation, the receiver's output
may interfere with, or
terminals would be connected to a computer through a user supplied custom made cable.
even disable, normal
The computer would run user supplied software written to suit the needs of the application.
operation of this radio
It could display and log the transmitted unit number, channel number, bank number, alarm
device.
state, battery condition, status reports, and transmitter type. Alternately, the XR-D could be
connected directly to a line printer for specialty or diagnostic purposes.
Power for the XR-D receiver can come from an external regulated 12 VDC power supply
(Linear Model T-124DC) or from a 12-volt battery. A diode protects the unit from reverse
power polarity. The XR-D draws about 30 mA current.
Two antennas (sold separately) are available for the XR-D. The Model ANT-1A is an 8-inch
"rubber duck" antenna for short range applications (less than 1 mile). The ANT-1A requires
a CON-180A (straight) connector to mate the antenna to the transmitter. For a right angle
antenna, use the CON-180A plus the CON-90A.The Model ANT-2 is a 3-foot whip antenna
for use in long range or difficult installations where more range from the XR-D is required. A
common 9-foot 1/4 wave CB whip antenna can also be used with the XR-D for maximum
range.
The receiver is housed in a rugged weather-resistant metal enclosure with a sturdy SO-239
antenna connector and a water-tight wiring strain relief bushing. Two indicators are visible through
a window on the case. The green power indicator lights when the receiver has power. During
reception, the red RF indicator lights. A two-position single-packet option jumper allows selection
of one round of only new data for each transmission or all data sent for each transmission. Two
internal test points are provided for signal strength and audio monitoring.
Data Specification:
Baud Rate: 9600
Stop Bits: 1
Parity: None
4. INSTALLATION TIPS
ANTENNA
CONNECTOR
(HIDDEN) USE ANT-1A ANTENNA FOR
SHORT RANGE APPLICATIONS
(LESS THAN 1 MILE)
8-INCH
ANT-1A
ANTENNA
GOOD INSTALLATION
LINE-OF-SIGHT
BETWEEN THE
TRANSMITTER AND
RECEIVER ANTENNAS
WILL PROVIDE THE
BEST RANGE
ANTENNAS ARE MOUNTED
VERTICALLY, ON HIGH POINTS
OF BUILDINGS
MOUNT ANTENNA AS HIGH AS POSSIBLE
GROUND
AT LEAST 9 FEET
ABOVE GROUND IS
RECOMMENDED
3-FOOT
ANT-2
ANTENNA
RIGHT ANGLE
CONNECTOR
(CON-90A)
MOUNTING BRACKET
18-FOOT CABLE
STRAIGHT-THRU
CONNECTOR
USE ANT-2 ANTENNA FOR MAXIMUM
(CON-180A)
RANGE OR DIFFICULT APPLICATIONS
BAD INSTALLATION
TRANSMITTING THROUGH
STRUCTURES, METAL AND
GEOGRAPHIC OBSTACLES WILL
REDUCE RADIO RANGE
GOOD ANTENNAS NEED GOOD GROUNDS
METAL ROOF
3'
POOR
9 FEET
WHEN MOUNTING ON
THE SIDE OF A IDEALLY, A GROUND
STRUCTURE, USE A PLANE WITH A RADIUS
MINIMUM OF A 3-FOOT OF NINE FEET MINIMUM
IS DESIRED
SPACER TO DISTANCE
ANTENNA LOCATION IS
THE ANTENNA FROM
OF PRIMARY CONCERN
THE STRUCTURE
2. OPEN RECEIVER
REFERENCE
CARD FITS IN
1ST SLOT
BOARD FITS IN
3RD SLOT UP
END CAP STAYS
ATTACHED TO
THE CIRCUIT
BOARD
5. MOUNT RECEIVER CASE
If using the ANT-1A antenna: For best range mount the XT/XR unit to a metal plate with a
minimum size of 12" x 12". The ANT-1A antenna should extend above the mounting plate
and be free of obstructions. If the ANT-1A antenna cannot be mounted in the open, consider
using an extension coaxial cable with PL-259 connectors to move the antenna's location.
The XT/XR series of radios operate in the 27 MHz Citizens Band (CB) and may use any CB
antennas or CB antenna accessories. Antennas, PL-259 extension cables and other adapters
are available at Radio Shack® or other electronics stores.
UNIVERSAL
OK
FAIR
REMOVE FOUR
CASE SCREWS AND
SLIDE OUT CIRCUIT
BOARD
CASE SCREWS
MOUNT UNIT WITH
TWO BOTTOM SCREWS
(DON'T INSTALL TOP
SCREWS UNTIL WIRING
IS COMPLETE)
UNIT SHOULD BE
MOUNTED IN SHELTERED
LOCATION WITH ACCESS
TO ANTENNA CO-AX AND
POWER/SIGNAL WIRES
