Iridium Adapter
SD-66K
Owner's Manual
English

Advertisement

Table of Contents
loading

Summary of Contents for Kyocera SD-66K

  • Page 1 Iridium Adapter SD-66K Owner's Manual English...
  • Page 2 Introduction Accessories Thank you for purchasing the SD-66K Iridium Adapter. The components listed below are provided as standard accessories. Read this manual thoroughly first to ensure you use your phone with the Iridium Adapter safely and correctly. Name Appearance The screens and illustrations shown in this manual are for explanation purposes only. Note that the actual product and screens may differ in some respects from the images depicted here.
  • Page 3 The designations below indicate the severity of the injury Pull over and park in a safe place before using by KYOCERA for use with the Iridium Adapter. Prohibited or damage that may be incurred if the designated The use of a battery or charger other than that the phone.

  • Page 4: Precautions When Using The Battery

    Precautions When Using Your Precautions When Using the Battery Phone with the Iridium Adapter CAUTION DANGER WARNING When the phone (with or without the Iridium Do not dispose of the battery by throwing it in If there are any noticeable changes in the Adapter) is used in some types of automobile, a fire, as this could cause the battery to ignite battery while being used, charged, or stored...
  • Page 5 The battery has a limited life. Essential General Notes on Cleaning and Maintenance KYOCERA lithium ion batteries use the latest low power consumption technology and can be used for far longer Do not place any container of water (such as periods than conventional batteries.
  • Page 6 • Do not use a battery charger other than those specified Switch off your phone in any areas where you are in the KYOCERA catalog. Use of any other type of requested to turn off radio transmission devices, such as...
  • Page 7 Overview of Features and Controls q Extendable antenna This section identifies each part of the Iridium Adapter. Extend this antenna when calling. w Phone release levers You can remove your phone from the Iridium Adapter by pushing these two levers at the same time. e Interface terminal Exchanges information between adapter and telephone set.
  • Page 8 SIM Card About the SIM Card To use the Iridium Adapter, you must insert a valid SIM card into the Adapter. The SIM card is supplied by your Iridium service provider. The SIM card contains Iridium Network subscription information and your personal information such as your subscription ID number and your phone number.

  • Page 9: About The Antenna

    About the antenna To ensure optimum communication performance when using your Bend the top of the antenna to the right or left until it stops. phone, extend the antenna as described below. If you bend it to the right, the antenna will lock in position. Grasp the top of the antenna.
  • Page 10 Attaching Your Phone Attaching the Phone Unit Removing the Phone Unit Push the phone release levers on both sides of the Iridium Adapter at Remove the terminal cover at the bottom of the phone and attach it to the same time, then lift the phone unit off the Adapter. the adapter terminal connector.

  • Page 11: Removing The Battery

    The battery has a limited life. While the lifetime of the battery will depend on how frequently you use your phone with the Iridium Adapter, you should replace the battery once a year. When you replace the battery, always purchase a new KYOCERA lithium-ion battery of the same type.

  • Page 12: Charging The Battery

    Charging the Battery Plug the AC charger connector into the charging socket in the base of CAUTION! If you charge the battery in a foreign country, check the voltage in that the Iridium Adapter. country and adjust the voltage of your AC charger as required before charging.
  • Page 13 CAUTION! Power outlets vary from country to country. Use the plug provided for use in the particular country. Unlock Lock Spare battery This indicator shows the charging status when the battery mounted on the AC charger is to be charged (charging requires 3 to 4 hours).
  • Page 14 Separate Vibrator The separate vibrator will vibrate when it detects incoming or outgoing Attaching the belt clip calls. It also vibrates when the phone is accessing the network, for Insert the hook of the belt clip in the slot and push the clip in the direction of example when settings are being updated.
  • Page 15 How to attach the Grip Belt Using a grip belt can help you hold the phone. Before using the separate vibrator Fasten the grip belt screw on the top of the adapter using a coin. Power switch Switch on the separate vibrator before use. Stop button Press this button to stop vibration.

  • Page 16: Specifications

    Specifications Optional Accessories Iridium Adapter The following optional accessories are available for use with this product. Accessory names and designs are subject to change without notice. Dimensions Height (excluding the antenna) ......146 mm Width .
  • Page 17 Quick Reference for Troubleshooting If you are having trouble with your phone with the Iridium Adapter, check the following list of symptoms. If you cannot solve the problem yourself, contact Service Information Window. Symptom Possible cause User response No power •...
  • Page 18 Country Codes for International Calls Alaska ..............+1 Chad ..............+235 Gibraltar ..............+350 Albania ..............+355 Chile..............+56 Greece ..............+30 Armenia, Republic of...........+374 China..............+86 Greenland ............+299 Algeria..............+213 Cocos Islands ............+61 Grenada ..............+1 American Samoa ..........+684 Colombia...............+57 Guadeloupe Island..........+590 Andorra ...............+376 Comoros .............+269 Guam ..............+1 Angola..............+244 Congo ..............+242 Guatemala ............+502...
  • Page 19 Macao ..............+853 Peru ..............+51 Togo..............+228 Macedonia ............+389 Philippines.............+63 Tonga..............+676 Madagascar ............+261 Poland..............+48 Trinidad and Tobago..........+1 Madeira Islands...........+351 Portugal...............+351 Tunisia ..............+216 Malawi..............+265 Puerto Rico .............+1 Turkey ..............+90 Malaysia..............+60 Qatar ..............+974 Turkmenistan ............+993 Maldives..............+960 Reunion...............+262 Turks and Caicos Islands........+1 Mali ..............+223 Romania..............+40 Tuvalu ..............+688 Malta ..............+356 Rossian Federation..........+7...
  • Page 20 Iridium, and Iridium World Service are registered trade-mark of Iridium LLC. 0499DP 5KKTP29DEGXB Printed in Japan C...
