Lincoln Electric Making Fillet Welds Specification Sheet

APPLICATION
W A V E F O R M C O N T R O L
Making Fillet Welds with Power Wave AC/DC 1000™ System
Welding Guide
Now from Lincoln - the power
to increase productivity with
Power Wave technology!
Lincoln Power Wave technology
based upon the new Power Wave
AC/DC 1000™ power source
provides the opportunity to
significantly lower the cost of
making fillet welds and at the
same time, makes many of the
issues that cause weld defects
a thing of the past. In some
respects, the Power Wave AC/DC
1000™ describes both a new
generation of equipment and
a new technology for
controlled welding.
Now, from a single power source
it is possible to choose the very
best type of arc characteristic for
the particular job at hand. The
Power Wave AC/DC 1000™
system allows the choice of the
appropriate voltage-current
relationship at the mere "flick
of a switch".
T h e f u t
© Copyright 2005 The Lincoln Electric Company. All rights reserved.
T E C H N O L O G Y T M
CHOICE AT THE "FLICK OF A SWITCH"
• Constant current (sometimes referred to as variable voltage).
• Constant voltage.
• Square Wave AC.
UNLIMITED AC OUTPUT TAILORING
• Choice of AC frequency (from 10 Hz to 100 Hz).
• Wave balance control to allow more or less DC
positive component.
• Offsetting the AC wave to change the magnitude of the
negative or positive component.
REDUCTION IN DEFECTS
• Virtual elimination of arc-striking problems.
• Virtual elimination of arc blow.
LOWER COSTS
• Documented productivity increases over conventional
submerged arc welding.
Patented. This product is protected by one or more of the following United States patents: 6,809,292;
6,795,778; 6,700,097; 6,697,701; 6,683,278; 6,660,966; 6,600,134; 6,683,278; 6,596,570; 6,570,130;
6,536,660; 6,489,952; 6,472,634; 6,636,776; 6,486,439; 6,441,342; 6,365,874; 6,291,798; 6,207,929;
6,111,216; 4,927,041; 4,861,965 and other pending U.S. patents. Similar patents are maintained in
other countries.
u r e o f
a d v a
w e l d i n g
40% Increase in Travel Speed
5/16" (8mm) Horizontal Fillet Weld
5/32" (4mm) Dia. Electrode
525 Amperes (Both Welds)
n t a g e s
i s h e r
NX-3.50 5/05
®
