Service Manual
©
Copyright 2002 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by BB 0205 Service Audio
Version 1.0

Technical Specifications

Mains Voltage
Mains Frequency
Output Power (55Hz, 10% THD)
Input Sensitivity
S/N Ratio (100Hz, 200mV)
Minimum Volume Hum & Noise
Frequency Response (-3dB)
Distortion (100Hz, 200mV)
* at Output level of 2V across 4 ohm load
Printed in The Netherlands
Subject to modification
: 230V
: 50Hz
: 40W at 4 ohm load
: < 220mV
: > 60dB*
: < 3mV
Low
: <40Hz
High
: 120Hz - 140Hz
: < 1%*
SW968/
00S
(3139 118 79790)
GB
3139 785 30047
