- Page 1 ® Bluetooth Speaker User Manual...
- Page 2 Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of BenQ Corporation to notify any person of such revision or changes. This user manual aims to provide the most updated and accurate information to customers, and thus all contents may be modified from time to time without prior notice.
-
Page 3: Table Of Contents
Pairing and connecting Bluetooth® devices ..........3 System status indicators ................4 Music playing variations ................5 Tips on making the most of the speaker ..........6 Using BenQ Audio ............7 Initial setup ....................7 Bluetooth® connection ................8 Playing ......................8 Maintenance and care ..........13 Troubleshooting .................. -
Page 4: Introduction
Introduction Overview ® Thank you for purchasing the BenQ treVolo Bluetooth speaker. Indulge in music streaming from your smart devices, computers, or any other ® Bluetooth devices without cables. Features • No physical connection required. • Rechargeable battery provides hours of performance. -
Page 5: Operation
Play/pause Micro USB port (Answer) Connecting to AC outlet Please charge the battery for 3 hours for the first time using your BenQ ® treVolo Bluetooth speaker by connecting it with the power adapter plugging into a live AC (main) outlet. You can begin to use the speaker while the battery in charge. -
Page 6: Pairing And Connecting Bluetooth® Devices
Flip out both speaker panes and enjoy your music. If the paired device comes with phone feature, BenQ treVolo will become a speakerphone. To answer incoming calls, press play/pause button. To hang up, press mode button. To suspend the current call and switch to the new incoming call, press play/pause button. -
Page 7: System Status Indicators
The circle of power button will blink in blue. Turn on ® Bluetooth of your device to discover and pair with “BenQ treVolo” Speaker memory The speaker can remember up to eight paired devices. If there is an additional device to be paired, no longer the least recent connected device is paired with the speaker. -
Page 8: Music Playing Variations
® Streaming via Bluetooth By attaching an audio cable to your treVolo speaker from line out jack plugging into your home audio system as illustrated above, you can use your ®... -
Page 9: Tips On Making The Most Of The Speaker
• Phone calls override music playing via connected devices. • You can also use BenQ treVolo as a USB audio terminal. Simply plug the cable from USB audio source into micro USB port of BenQ treVolo, and BenQ treVolo will be turned on automatically. -
Page 10: Using Benq Audio
BenQ Audio. Initial setup For the very first time of using BenQ Audio, you will be prompted to enter an e-mail address. Validity of e-mail format will be checked. Once passed, no longer will this initial setup be required at the device. -
Page 11: Bluetooth® Connection
® Be sure to turn on Bluetooth at your device to stream audio content to BenQ treVolo. Exclusively for devices come with Android™ 4.2 or above, ® BenQ Audio can automatically turn on Bluetooth for your by switching on... - Page 12 View in genres •Press to begin play the first track in the list. Press to randomly play tracks in the list. •By pressing dots icon , tracks can be added into a playlist or deleted from the device. Using BenQ Audio...
- Page 13 Drag the white dot anywhere in the bar to set the volume for minimum to maximum. Tap to set sleep timer. Tap to go back to previous page. Tap to advance to right panel of the app. Using BenQ Audio...
-
Page 14: Sleep Timer
Right panel Once is tapped or simply drag the whole screen to the left, the right panel will be displayed. Drag it to the right to go back to previous page. Using BenQ Audio... - Page 15 By tapping on the album art, the current can be played/paused. • In the purple area in the middle, information such as remaining battery power about BenQ treVolo will be revealed. • In the red are at the bottom, tap on EXIT will quit the app.
-
Page 16: Maintenance And Care
Contact certified service representatives if requires. Troubleshooting Problem Solution 1.Make sure you are using the BenQ AC power adapter shipped with the speaker. Speaker will not 2.The speaker is connected to a working AC (mains) turn on outlet to restore the battery to operational mode and charge the battery. - Page 17 ® •Remove “BenQ treVolo” from the paired Bluetooth device list on your device. Pair and connect over again. •Press the power button for 7 seconds or more to force the speaker to shut down. Turn on the speaker and pair with your device.
-
Page 18: Cleaning The Speaker
• Do not use solvents, chemicals, or sprays. • Do not allow liquids to spill or objects to drop into any of the openings. Contact customer service ® For questions about BenQ’s treVolo Bluetooth speaker, contact your local dealer. For contact information, visit http://www.benq.com. -
Page 19: Specification
Specification Performance Other information Built-in microphone Frequency Other 60 Hz ~ 20 kHz for speakerphone response feature function Micro USB x1, Line-in 12 hours (depends on Play time I/O port x1, Line-out x1, Power user scenarios) Jack x1 Connection Input power DC 12V 2A rating ®...
