- Page 1 Sno-Thro ® Parts Manual Models 924119 -1028 924120 -1024 924333 -1024 924334 -1128 924502 -1332 924503 -1336 924504 - 936 02487800D 2/01 Supercedes 02487800, A,B,C Printed in USA...
- Page 2 • Record Unit Model and Serial numbers here: • Record Engine Model and Serial numbers here: UNAUTHORIZED REPLACEMENT PARTS Use only Ariens replacement parts. The replacement of any part on this vehicle with anything other than an Ariens authorized replacement part may adversely affect the performance, durability, or safety of this unit and may void the warranty.
-
Page 3: Table Of Contents
Wiring Diagram (502, 503)) ....35 Continuity & Wiring Diagrams (119, 120, 504) ..36 © Copyright 2000, 2001 Ariens Company... -
Page 4: Decals
Decal- 1028 Front Panel (119) 08084400 Decal- 1128 Front Panel (334) 08084500 Decal- 1332 Front Panel (502) 08084600 Decal- 1336 Front Panel (503) 07746400 Decal-Ariens Jewel 07733900 Decal-Primer 07797600 Decal- Cast Iron Bore 07751100 Decal-A+ 62447800 Decal-Set-Danger (119, 120, 333, 334, 502, 503) - Page 5 Activar el embrague de la transmisión de dirección de la tracción antes del embrague del accesorio. 07797600 Item Part No. Qty. Description 08084800 Decal- 936 Dash 08084700 Decal- 936 Front Panel 07746400 Decal-Ariens Jewel 07733900 Decal-Primer 07797600 Decal- Cast Iron Bore 07751100 Decal-A+ 07873100 Decal, Caution 07864400...
-
Page 6: Ngine And
Model 924119, 120, 333, 334, 502, 503, 504 Item Part No. Qty. Description 06529800 Nut-Locking-Center .31-18 06310500 Washer-Lock Internal .31 08262200 Engine, 10HP L Head Tecumseh - 120 Volt (119) 08260700 Engine, 10HP OHV Tecumseh- 120 Volt (120) 08260800 Engine, 10HP OHV Tecumseh- 12 Volt (333) 08261000 Engine, 11HP Tecumseh OHV 12 Volt (334) 08261100... - Page 7 Item Part No. Qty. Description 10 06601800 Key-Straight .25 x 1.75 x .25 11 07412000 Screw-Tap .25-20 x .50 12 02489000 Belt Cover 13 07238500 V-Belt (119) 07238400 V-Belt (120, 333, 334, 504) 07238300 V-Belt (502) 07236200 V-Belt (503) 14 07325700 Pulley-V 8.40 x 1.0 with Key 15 07211200 V-Belt -Traction Drive (119, 120, 333, 334, 504)
-
Page 8: Speed Selector And Frame
Model 924119, 120, 333, 334, 502, 503, 504 PEED ELECTOR AND RAME PS0485... - Page 9 Item Part No. Qty. Description 07516700 Hole Plug 05708600 Ring-Retainer-External .500 x .015 07509600 Knob 02444851 08318400 Spring, Tension .055 x .33 x 1.31 05947700 Bolt-Hex .25-20 x 1.00 06529800 Nut-Locking-Center .312-18 02462600 Pivot 06529700 Nut-Locking-Center .25-20 10 05948000 Bolt-Hex .31-18 x 3.50 11 06713500 Pin-Hair Internal .08 x .18 x 1.18 12 02487600...
-
Page 10: Wheels And Axle
Model 924119 Model 924120, 333, 334, 502, 503, 504 HEELS AND PS0800 PS0790... - Page 11 Item Part No. Qty. Description 07150300 Tire/Wheel Assembly 16 x 6.50 - 8 (119) 07150500 Wheel 6.50 x 8.00 (119) 07121800 Tire 4.80-8 (120, 333) 07121600 Tire 16 x 6.50-8 (119, 334, 502, 503, 504) 02483200 Shaft, Axle (119) 05718400 Ring, Retaining .875 x .050 (119) 02439600 Spur Gear (119)
-
Page 12: Reduction Drive
Model 924119, 120, 333, 334, 502, 503, 504 Item Part No. Qty. Description 02477300 Hex Shaft 06437200 Washer-Flat-Steel .344 x .688 x .065 02476800 Hex Shaft 05531600 Spacer .450 x .75 x 1.60 06436600 Washer-Flat-Steel .505 x .880 x .072 00308500 Bearing Flange 05435200... -
Page 13: Friction Wheel Drive
Item Part No. Qty. Description 07411500 Screw-Tapping .312-18 x .50 02445500 Spindle Hub 00300300 Friction Disc 02445400 Disc Hub 05702100 Ring-Retaining-Internal 1.750 x .062 06436900 Washer-Flat-Steel .880 x 1.250 x .062 05502600 Bushing-Flange .625 x .750 x .500 x .875 05512600 Bushing-Sleeve .882 x 1.250 x .531 06530500... -
Page 14: Handlebars And Controls
Model 924119, 120, 333, 334, 502, 503, 504 ANDLEBARS AND ONTROLS PS0812... - Page 15 Item Part No. Qty. Description 53209400 Handlebar, Upper Right Hand (Includes Hand Warmer) 53209500 Handlebar, Upper Left Hand (Includes Hand Warmer) 02487300 Handlebar, Lower 06529700 Nut-Lock-Center .25-20 02464700 Handle Pivot 07511200 Bushing-Snap (119, 120, 333, 334) 02462100 Lever-Clutch-Coated 07411800 Screw-Tapping 12-14 x 1.50 07511800 Bumper 10 02486451...
- Page 16 Model 924119, 120, 333, 334, 502, 503, 504 Item Part No. Qty. Description 42 06707000 Pin-Cotter .09 x 1.00 43 02406900 Fork Pivot Rod 44 08309400 Spring-Tension .080 x .73 x 3.06 45 02427200 Clutch Fork 46 06307400 Washer-Locking .312 x .097 Heavy 47 52404700 Spring Assembly 48 06529800...
-
Page 17: Headlight
Part No. Qty. Description 02485900 AR Headlight (Contains 2-9) 06307200 Washer-Lock-External .313 x .030 06216100 Bolt-Round Head Square Neck .312-18 x 1.00 05952600 Bolt-Hex .31-18 x 2.50 Grade 2 06529200 Nut-Hex .312-18 02464900 Lens 02465000 Bulb 06530400 Nut-Flange .312-18 06307400 Washer-Lock .312 10 07517300 Cable Tie... -
Page 18: Auger And Battery
Model 924119, 120, 333, 334, 502, 503 UGER AND ATTERY 45 46 36 53 PS0437... - Page 19 Item Part No. Qty. Description 09032300 Cover, Battery (333, 334, 502, 503) A/R Battery Recommend 340 to 350 CCA at 0° F. Size U1R or U1L (333, 334, 502, 503) 02484559 Battery Tray (503) 02488659 Battery Tray (333, 334, 502) 06220400 Bolt-Round Head Square Neck .25-20 x 7.00 (333, 334, 502, 503) 06437300...
- Page 20 Model 924119, 120, 333, 334, 502, 503 Item Part No. Qty. Description 28 51001500 Shear Bolt Service Assembly (Includes Item 25) 29 00301700 Bearing Flange (119,120, 333, 334, 502) 03086200 Bearing Flange (503) 30 06211800 Bolt-Round Head Square Neck .38-16 x .75 (119, 502, 503) 06211800 Bolt-Round Head Square Neck .38-16 x .75 (120, 333, 334) 31 06212000...
-
Page 21: Gear Case-Aluminum
Bushing-Flange .502 x 1 x .750 23 02479300 Rake Shaft 28" 24 06219800 Bolt-Round Head Square Neck .25-20 x 1.00 25 06442500 Washer-Fiber .437 x .656 x .032 26 00008000 Ariens 16 Oz. Bottle of L2 Lube (2 oz. capacity) LUMINUM Model 924119 PS0692... -
Page 22: Gear Case-Cast Iron
Model 924120, 333, 334, 502, 503 PS0472... - Page 23 Washer-Flat-Steel 1.625 x 2.500 x .012 28 02406400 Gear Case Shaft 29 02400200 Gear Case 30 52408200 AR Case Set Large Bore 31 00008000 Ariens 16 oz. Bottle of L2 Lube (5 oz. capacity) Model 924120, 333, 334, 502, 503...
-
Page 24: Discharge Chute Crank
Model 924119, 120, 333, 334 924120, 333, 334 924119 ISCHARGE HUTE RANK PS0603... - Page 25 Item Part No. Qty. Description 01019800 Cap, 3/8 Rod 07508300 Knob 02480600 Crank, Chute 07412000 Screw .25-20 x .50 Hex Washer Head Self Tapping 03223000 Cover, Gear 06714500 Pin-Spring Clip 03222900 Gear, Chute 06224400 Bolt-Round Head Square Neck .38-16 x 2.50 Grade 5 53204400 Pinion Gear w/Bracket (Contains Items 11-13) 10 06436100...
-
Page 26: Electric Discharge Chute
LECTRIC ISCHARGE HUTE Model 924502, 503 PS0860... - Page 27 Item Part No. Qty. Description 02486959 Ring, Cover 06530100 Nut-Locking-Flange .250-20 07411900 Screw-Tapping 12-24 x .50 Hex Washer Head 02487100 Cover, Motor 05947400 Bolt-Hex .25-20 x 1.25 Grade 5 02488251 Bracket, Electric Motor 02486300 Motor, Electric Right Hand- Chute 06437300 Washer-Flat-Steel .281 x .62 x .065 02487000 Clamp, Chute...
-
Page 28: Brush Head
Model 924504 RUSH 18 19 PS0592... - Page 29 Item Part No. Qty. Description 01061300 Chain Tightener 01060900 Sprocket 02468300 Chain, Assembly #40 x 106 05946800 Bolt-Hex .25-20 x .75 Grade 5 05946900 Bolt-Hex .31-18 x 1.00 Grade 5 05963700 Bolt-Hex .31-18 x 2.25 Grade 5 05957900 Bolt-Hex .38-16 x 1.50 Grade 5 05947000 16 Bolt-Hex .31-18 x .75 Grade 5 06437300...
-
Page 30: Brush Drive Unit
Model 924504 RUSH RIVE PS0581... - Page 31 Item Part No. Qty. Description 05947500 Bolt-Hex .31-18 x 1.25 Grade 5 02404800 Retainer 06307200 Washer-Locking-Internal .313 x .030 02404900 Pivot, Center 02471751 Plate, Top Mount 02470900 T-Lock Handle 00597000 Washer-Cupped Serrated .38 02470151 Guard, Shaft 02405051 Frame, Adapter 10 06529800 Nut-Locking-Top .31-18 11 06215700 Bolt-Round Head Square Neck .31-18 x .75 Grade 5...
-
Page 32: Continuity Diagram (333, 334)
Model 924333, 334 The diagrams below show the various states of connection for electrical components. The solid lines on switches show continuity. NOTE: All switches are viewed from the rear. Key Switch (02739600) Solenoid (Top View) (03679000) NOT ENERGIZED ONTINUITY IAGRAM Hand Warmer Switch (02485700) -
Page 33: Wiring Diagram (333, 334)
A.C. LIGHTING YELLOW ENGINE D.C. CHARGE PURPLE MAGNETO WHITE / BLACK STARTER BATTERY BLACK FUSE 15 AMP COIL 2 COIL 1 STARTER SOLENOID BLACK Item Part No. Qty. Description 08260800 AR Engine, 10HP OHV Tecumseh- 12 Volt 08261000 AR Engine, 11HP OHV Tecumseh- 12 Volt 02485900 AR Headlight 07532900... -
Page 34: Continuity Diagram (502, 503)
Model 924502, 503 The diagrams below show the various states of connection for electrical components. The solid lines on switches show continuity. NOTE: All switches are viewed from the rear. Key Switch (02739600) Solenoid (Top View) (03679000) NOT ENERGIZED ONTINUITY IAGRAM Hand Warmer Switch (02485700) -
Page 35: Wiring Diagram (502, 503))
A.C. LIGHTING YELLOW ENGINE D.C. CHARGE MAGNETO STARTER BATTERY BLACK FUSE 15 AMP COIL 2 COIL 1 ROWN STARTER SOLENOID BLACK Item Part No. Qty. Description 08261100 AR Engine, 13 HP OHV Tecumseh- 12 Volt 08261000 AR Engine, 11 HP OHV Tecumseh- 12 Volt 02485900 AR Headlight 07532900... -
Page 36: Continuity & Wiring Diagrams (119, 120, 504)
Model 924119, 120, 504 A.C. LIGHTING ENGINE YELLOW D.C. CHARGE Item Part No. Qty. Description 08262200 Engine, 10HP L Head Tecumseh - 120 Volt (119) 08260700 Engine, 10HP OHV Tecumseh- 120 Volt (120) 08261200 Engine, 9HP Tecumseh OHV (504) 02485900 Headlight 07532900 Handle Hand Warmer with Terminal... - Page 38 Ariens Company 655 West Ryan Street P.O. Box 157 Brillion, WI 54110-0157 920-756-2141 Fax 920-756-2407 www.ariens.com...
