Page 1 FORD FOCUS Owner's Manual...
Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2011 All rights reserved. Part Number: (CG3568en) 08/2011 20110622085519...
Page 3: Table Of Contents
Table of Contents Introduction Alarm About This Manual...........7 Principle of Operation........39 Symbols Glossary..........7 Arming the alarm...........40 Parts and Accessories........7 Disarming the alarm........40 At a Glance Steering Wheel At a Glance............10 Adjusting the Steering Wheel.....41 Audio Control............41 Child Safety Voice Control...........42 Child Seats............17 Wipers and Washers Child Seat Positioning........18...
Page 4 Table of Contents Exterior Mirrors..........64 Glasses Holder..........112 Electric exterior mirrors........65 Childminder Mirror.........112 Auto-Dimming Mirror........66 Auxiliary input (AUX IN) socket....113 Blind Spot Monitor........66 USB port............113 Satellite Navigation Unit Holder....113 Instrument Cluster Floor Mats............113 Gauges...............69 Starting and Stopping the Warning Lamps and Indicators....71 Engine Audible Warnings and Indicators....73 General Information........114...
Page 5 Table of Contents Using Adaptive Cruise Control....150 Transmission Forward alert function........152 Manual Transmission........129 Automatic Transmission......129 Speed Limiter Principle of Operation.........153 Brakes Using the speed limiter.......153 Principle of Operation.........132 Hints on Driving With Anti-Lock Driver Alert Brakes............132 Parking Brake..........132 Principle of Operation.........154 Using driver alert...........154 Stability Control Lane Departure Warning...
Page 6 Table of Contents Brake and Clutch Fluid Check....200 Driving Hints Washer Fluid Check........200 Running-In............176 Technical Specifications......201 Cold Weather Precautions......176 Driving Through Water........176 Vehicle Care Cleaning the Exterior........204 Roadside Emergencies Cleaning the Interior........204 First Aid Kit............177 Repairing Minor Paint Damage....205 Warning Triangle..........177 Vehicle battery Fuses Jump-Starting the Vehicle.......206...
Page 7 Table of Contents Bluetooth setup...........245 Audio system security Telephone setup..........245 Security code..........234 Telephone controls........246 Audio unit operation Using the telephone........246 On/off control..........235 Voice control Sound button..........235 Principle of Operation........249 Waveband button........235 Using voice control........249 Station tuning control........235 Audio unit commands.......250 Station preset buttons......236 Telephone commands.......257 Autostore control.........236...
Page 8 Table of Contents Using TMC............285 Map updates Map updates..........286 Appendices Type approvals..........287 Type approvals..........287 Type approvals..........287 Type approvals..........288 Type approvals..........288 Type approvals..........289 Electromagnetic compatibility....289...
Page 9: Introduction
PARTS AND ACCESSORIES Note: Some of the illustrations in this manual may be used for different models, Now you can be sure that your Ford so may appear different to your vehicle. parts are Ford parts However, the essential information in the Your Ford has been built to the highest illustrations is always correct.
Page 10 Now it is easier to tell if you have really been given Ford Original Parts. The Ford logo is clearly visible on the following parts if they are Ford Original Parts. If your vehicle has to be repaired, look for the clearly visible Ford branding and make sure that only Ford Original Parts have been used.
Page 11 Introduction E132327 Lighting Rear lamps Headlamp E132328...
Page 12: At A Glance
At a Glance Front exterior overview E133220 See Locking and Unlocking (page 32). See Keyless Entry (page 34). See Automatic Main Beam Control (page 48). See Driver Alert (page 154). See Lane Departure Warning (page 156). See Lane Keeping Aid (page 158). See Traffic Sign Recognition (page 160).
Page 13 At a Glance See Changing a Bulb (page 55). Tyre pressures. See Technical Specifications (page 218). See Changing a Road Wheel (page 208). Vehicle interior overview E133222 See Transmission (page 129). See Locking and Unlocking (page 32). See Power Windows (page 63). See Electric exterior mirrors (page 65).
Page 14 At a Glance See Head Restraints (page 106). See Fastening the seat belts (page 25). See Rear Seats (page 109). See Manual Seats (page 105). See Power Seats (page 108). See Parking Brake (page 132). See Opening and Closing the Bonnet (page 190). Instrument panel overview Left-hand drive E132738...
Page 15 At a Glance Right-hand drive E132739 Air vents. See Air Vents (page 94). Direction indicators. See Direction Indicators (page 52). Main beam. See Lighting Control (page 47). Left-hand drive vehicles with voice control - Information display control. See Information Displays (page 75). Left-hand drive vehicles without voice control - Information display control.
Page 16 At a Glance Instrument cluster. See Gauges (page 69). See Warning Lamps and Indicators (page 71). Left-hand drive vehicles with voice control - Information and entertainment display control. Left-hand drive vehicles without voice control - Audio control. See Audio Control (page 41). Right-hand drive vehicles with voice control - Information display control.
Page 17 At a Glance Rear exterior overview E133221 See Changing the Wiper Blades (page 45). See Changing a Bulb (page 55). See Changing a Bulb (page 55). See Fuel filler flap (page 124). See Changing a Road Wheel (page 208). Tyre pressures. See Technical Specifications (page 218).
Page 18 At a Glance See Towing Points (page 188). See First Aid Kit (page 177). See Warning Triangle (page 177). See Tyre Repair Kit (page 213). Spare wheel. See Changing a Road Wheel (page 208). Jack. See Changing a Road Wheel (page 208). Wheel brace. See Changing a Road Wheel (page 208).
Page 19: Child Safety
Child Safety CHILD SEATS WARNINGS Do not leave unattended children in your vehicle. If your vehicle has been involved in an accident, have the child restraints checked by properly trained technicians. Note: Mandatory use of child restraints E133140 varies from country to country. Only child restraints certified to ECE-R44.03 (or later) have been tested and approved for use in your vehicle.
Page 20: Child Seat Positioning
WARNINGS belt without slack remaining, adjust the Please consult your Dealer for the seatback to the fully upright position and latest details relating to Ford raise the height of the seat. See Seats recommended child seats. (page 105). Mass group categories...
Page 21 At time of publishing the recommended Group O+ ISOFIX baby safety seat is the Britax Roemer Baby Safe. Please consult your Dealer for the latest details relating to Ford recommended child seats. At time of publishing the recommended Group 1 ISOFIX child seat is the Britax Roemer Duo.
Page 22: Booster Seats
Child Safety Booster seat (Group 2) BOOSTER SEATS WARNINGS Do not install a booster seat or a booster cushion with only the lap strap of the seat belt. Do not install a booster seat or a booster cushion with a seat belt that is slack or twisted.
Page 23: Isofix Anchor Points
Child Safety Top tether anchor points - 4 door ISOFIX ANCHOR POINTS vehicles WARNING Use an anti-rotation device when using the ISOFIX system. We recommend the use of a top tether or support leg. Note: When you are purchasing an ISOFIX restraint, make sure that you know the correct mass group and ISOFIX size class for the intended seating locations.
Page 24: Child Safety Locks
Child Safety E87145 2. Push the child seat back firmly to engage the ISOFIX lower anchor points. E78298 3. Tighten the tether strap in line with the child seat manufacturer's instructions. Left-hand side Turn anti-clockwise to lock and clockwise CHILD SAFETY LOCKS to unlock.
Page 25 Child Safety E124779...
Page 26: Occupant Protection
Occupant protection Front airbags PRINCIPLE OF OPERATION Airbags WARNINGS Do not modify the front of your vehicle in any way. This could adversely affect deployment of the airbags. Extreme Hazard! Do not use a rearward facing child restraint on a seat protected by an airbag in front of it! E74302...
Page 27: Fastening The Seat Belts
Occupant protection Side airbags WARNINGS Never use a seat belt for more than one person. Use the correct buckle for each seat belt. Do not use a seat belt that is slack or twisted. Do not wear thick clothing. The seat belt must fit tightly around your body to achieve its optimum effect.
Page 28: Seat Belt Height Adjustment
Occupant protection SEAT BELT HEIGHT ADJUSTMENT E74124 E87511 Note: Lifting the slider slightly while pressing the locking button makes it easier to release the locking mechanism. To raise or lower, press the locking button on the adjuster and move as necessary. SEAT BELT REMINDER WARNING The occupant protection system will...
Page 29: Using Seat Belts During Pregnancy
Occupant protection Rear seat belt reminder WARNING Position the seat belt correctly for WARNING your safety and that of your unborn If multiple belts are unfastened child. Do not use only the lap strap within a few seconds of each other, or the shoulder strap.
Page 30 Occupant protection Note: The key switch is located in the glove compartment with an airbag deactivation lamp in the overhead console. If the airbag warning lamp illuminates or flashes when you are driving, this indicates a malfunction. See Warning Lamps and Indicators (page 71).
Page 31: Keys And Remote Controls
Keys and Remote Controls Note: Further remote controls may be GENERAL INFORMATION ON programmed at this stage. RADIO FREQUENCIES 4. Press any button on each additional remote control within 10 seconds of CAUTIONS each other. The radio frequency used by your remote control can also be used by Reprogramming the unlocking other short distance radio...
Page 32 Keys and Remote Controls Remote control without a folding Insert a screwdriver in the position key blade shown and gently push the clip. 2. Press the clip down to release the battery cover. E128810 E87964 3. Carefully remove the cover. Press and hold the pushbuttons on the edges to release the cover.
Page 33 Keys and Remote Controls E119190 4. Carefully insert the screwdriver in the position shown to open the remote control. E125860 CAUTION Do not touch the battery contacts or the printed circuit board with the screwdriver. 5. Carefully prise out the battery with the screwdriver.
Page 34: Locks
Locks Double locking with the key LOCKING AND UNLOCKING Turn the key to the lock position twice CAUTION within three seconds. Check your vehicle is locked before Double locking with the remote control leaving it unattended. Press the button twice within three seconds.
Page 35 Locks Locking and unlocking Locking the doors individually with confirmation the key Note: If your vehicle has double locking, the Note: If the central locking function fails to direction indicators will flash once after you operate, the doors can be individually locked have activated central locking, followed by using the key in the position shown.
Page 36: Keyless Entry
Locks Passive key KEYLESS ENTRY The vehicle can be locked and unlocked General information with the passive key. The passive key can also be used as a remote control. See WARNING Locking and Unlocking (page 32). The keyless entry system may not Locking the vehicle function if the key is close to metal objects or electronic devices such as...
Page 37: Unlocking The Vehicle
Locks Note: Once activated, the vehicle will remain locked for approximately three seconds. When the delay period is over, the doors can be opened again, provided the passive key is within the respective detection range. Two short flashes of the direction indicators confirms that all the doors and the luggage compartment lid have been locked and that the alarm has been armed.
Page 38: Global Opening And Closing
Locks Global opening In order to use these passive keys again, they have to be enabled. To enable all your passive keys, unlock the vehicle using a passive key or the remote control unlocking function. All passive keys will then be enabled if the ignition is turned on or the vehicle is started using a valid key.
Page 39 Locks To close all the windows, press and hold the remote control lock button for at least three seconds. Press the lock or unlock button to stop the closing function. The anti-trap function is also active during global closing. Vehicles with keyless entry E87384 WARNING Take care when using global closing.
Page 40: Engine Immobiliser
If you lose a key, you can obtain a replacement from your Ford Dealer. If possible, provide them with the key number from the tag provided with the original keys. You can also obtain additional keys from your Ford Dealer.
Page 41: Alarm
Alarm Battery back-up sounder PRINCIPLE OF OPERATION The battery back-up sounder is an extra Alarm system alarm system which will sound a siren when the alarm is triggered. It is armed Your vehicle may be equipped with one of directly when you lock the vehicle. The the following alarm systems: sounder has its own battery and will sound Perimeter alarm.
Page 42: Arming The Alarm
Alarm Note: False alarms can also be triggered ARMING THE ALARM by the auxiliary heater See Auxiliary Heater (page 102). If you are using the auxiliary To arm the alarm, lock the vehicle. See heater, direct the air flow towards the Locks (page 32).
Page 43: Steering Wheel
Steering Wheel ADJUSTING THE STEERING WARNING WHEEL Make sure that you fully engage the locking lever when returning it to its original position. WARNING Never adjust the steering wheel AUDIO CONTROL when the vehicle is moving. Select the required source on the audio Note: Make sure that you are sitting in the unit.
Page 44: Voice Control
Steering Wheel Type 2 VOICE CONTROL E129463 E129464 Volume up Pull the button to select or deselect voice control. See Voice control (page 249). Seek up or next Volume down Seek down or previous Seek, next or previous Press the seek button to: tune the radio to the next or previous stored preset play the next or the previous track.
Page 45: Wipers And Washers
Wipers and Washers Automatic wiper system WINDSCREEN WIPERS Some models without autowipers are fitted with a speed-dependent front screen wiper system. When the vehicle is slowed to walking speed or is brought to a standstill, the wiper speed will automatically switch to the next lower wiper speed setting.
Page 46: Windscreen Washers
Wipers and Washers WARNING Do not operate the washer for more than 10 seconds at a time, and never when the reservoir is empty. Whilst the lever is pulled towards the steering wheel the washer will work in conjunction with the wipers. After releasing the lever, the wipers operate for a short time.
Page 47: Headlamp Washers
Wipers and Washers Reverse gear wipe CHECKING THE WIPER BLADES The rear wiper will be activated automatically when selecting reverse gear if the rear wiper is not already switched on and the front wiper is operating. Rear window washer E66644 Run the tip of your fingers over the edge of E129194 the blade to check for roughness.
Page 48 Wipers and Washers Rear window wiper blade Service position Lift the wiper arm. E75184 E86456 2. Position the wiper blade at right angles to the wiper arm. 3. Disengage the wiper blade from the E129986 wiper arm. Switch off the ignition and move the wiper 4.
Page 49: Lighting
Lighting One side LIGHTING CONTROL Lighting control positions E130139 Right-hand side E132706 Left-hand side Main and dipped beam Side and tail lamps Headlamps Parking lamps WARNING Prolonged use of the parking lamps will discharge the battery. Switch off the ignition. E130140 Both sides Push the lever forward to switch between...
Page 50: Autolamps
If the lights of oncoming vehicles are hidden by obstacles (for example guard rails) the system may not deactivate the main beam. Always fit Ford Original Parts when replacing headlamp bulbs. Other bulbs may reduce system performance. E132707...
Page 51 Lighting Activating the system CAUTIONS Check and replace wiper blades Switch on the system using the information regularly to ensure the camera sensor display and autolamps. See Information has a clear view through the Displays (page 75). See Autolamps windscreen. Replacement wiper blades (page 48).
Page 52: Front Fog Lamps
Lighting Manually overriding the system E133632 Push or pull the lever to switch between E132709 main and dipped beam. Note: This is a temporary override and the REAR FOG LAMPS system will return to automatic operation after a short period. WARNINGS To permanently deactivate the system use Only use the rear fog lamps when...
Page 53: Adjusting The Headlamps - Vehicles With: Adaptive Front Lighting/Xenon Headlamps
Lighting ADJUSTING THE HEADLAMPS - VEHICLES WITH: ADAPTIVE FRONT LIGHTING/XENON HEADLAMPS To adjust the headlamps for driving on the left or right hand side of the road, see your dealer. HEADLAMP LEVELLING Note: Vehicles with Xenon headlamps are equipped with automatic headlamp E132711 levelling.
Page 54: Direction Indicators
Lighting Note: Tap the lever up or down to make the DIRECTION INDICATORS direction indicators flash only three times. E130141 CORNERING LAMPS E72898 Headlamp beam Cornering lamp beam...
Page 55: Interior Lamps
Lighting The cornering lamps illuminate the inside If you press switch B all lamps remain off of a corner when you are turning. when the door is opened. Press the switch again to reverse. INTERIOR LAMPS You can control all lamps using switch C. Centre mounted lamp Interior lighting Note: Individual lamps may be switched on...
Page 56: Removing A Headlamp
Lighting Type 1 Open the bonnet. See Opening and Closing the Bonnet (page 190). Ambient lighting illuminates several areas, for example footwells, cup holders and doors with a single colour and can be switched on and off using the information display menu.
Page 57: Changing A Bulb
Lighting Note: When fitting the headlamp, make sure that you reconnect the electrical connector properly. Note: When fitting the headlamp, make sure that you fully engage the headlamp in the lower fixing point. Note: When fitting the headlamp, make sure that the screw is located in the headlamp moulding before you install it.
Page 58 Lighting Headlamp main beam CAUTION Do not touch the glass of the bulb. Remove the headlamp. See Removing a Headlamp (page 54). E133106 2. Remove the cover. 3. Disconnect the electrical connector. 4. Release the clip and remove the bulb. E133105 Side Lamp 2.
Page 59: Side Repeater
Lighting Side repeater E133426 Carefully remove the cover. E133109 4. Remove the bulb holder. 5. Remove the bulb. Approach lamp CAUTION When removing the mirror glass, take care not to break it. Note: Position the mirror glass as far inwards as possible. E133427 2.
Page 60: Rear Lamps - 5 Door
Lighting Insert your fingers into the gap between the mirror housing and the mirror glass and pull gently to remove the mirror glass. E133717 2. Remove the lamp. E133107 Note: You cannot separate the fog lamp E133718 bulb from the bulb holder. 3.
Page 61 Lighting E133113 E133112 5. Remove the bulb holder. 2. Remove the wing nuts and detach the clip. 6. Gently press the bulb into the bulb 3. Remove the lamp. holder, turn it anti-clockwise and remove it. A. Brake lamp B. Reversing lamp C.
Page 62 Lighting 6. Gently press the bulb into the bulb holder, turn it anti-clockwise and remove it. A. Tail and fog lamp B. Direction indicator Brake and reversing lamp Open the luggage compartment lid. E133703 2. Remove the wing nuts and detach the clip.
Page 63 Lighting Number plate lamp 3. Remove the wing nut and detach the 2 clips. Note: These are not serviceable items, 4. Remove the lamp. please consult your dealer if they fail. Interior lamps Vehicles with LED lamps Note: The LED board is not a serviceable item, please consult your dealer if this fails.
Page 64: Bulb Specification Chart
Lighting BULB SPECIFICATION CHART Lamp Specification Power (watt) Front direction indicator PY21W Headlamp main beam Headlamp dipped beam Cornering lamp Front fog lamp Side lamp Side repeater WY5W Approach lamp Rear direction indicator PY21W Brake and tail lamp P21/5W 21/5 Tail lamp Rear fog lamp P21W...
Page 65: Windows And Mirrors
Windows and Mirrors Opening and closing the windows POWER WINDOWS automatically WARNING Press or lift the switch to the second action point and release it completely. Press or Do not operate the electric windows lift it again to stop the windows. unless they are free from obstruction.
Page 66: Exterior Mirrors
Windows and Mirrors The electric windows will stop 3. Lift the switch again for one more automatically while closing and reverse second. some distance if there is an obstacle in the 4. Push and hold the switch until the way. window is fully open.
Page 67: Electric Exterior Mirrors
Windows and Mirrors Electric folding mirrors ELECTRIC EXTERIOR MIRRORS Automatic folding and unfolding Note: If the mirrors have been folded using the manual fold button they can only be unfolded using the manual fold button. The mirrors will fold automatically when you lock the vehicle with the key, the remote control or a keyless entry system request.
Page 68: Auto-Dimming Mirror
Windows and Mirrors If you press the switch again while the The system is a convenience feature that mirrors are moving, they will stop and aids the driver in detecting vehicles that reverse the direction of movement. may have entered the blind spot zone (A). The detection area is on both sides of the Note: When the mirrors are operated often vehicle extending rearwards from the...
Page 69 Windows and Mirrors Note: On vehicles with automatic Detection limitations transmission, the system is active only in S, There may be certain instances where D and N. vehicles entering and exiting the blind spot The system is only active when you exceed zones may not be detected.
Page 70 Windows and Mirrors When you turn the system off no further Trailer towing false alerts alerts will be received. The BLIS warning CAUTION indicator will illuminate. See Warning Lamps and Indicators (page 71). Vehicles fitted with a trailer tow module not approved by us may not Detection errors correctly be detected.
Page 71: Instrument Cluster
Instrument Cluster GAUGES Type 1 E132065 Information display. See Information Displays (page 75). Speedometer Engine coolant temperature gauge Tripmeter reset button Fuel gauge Tachometer...
Page 72 Instrument Cluster Type 2 and 3 E130149 Information display. See Information Displays (page 75). Speedometer Engine coolant temperature gauge Fuel gauge Tachometer If the needle enters the red section, the Engine coolant temperature gauge engine is overheating. Stop the engine, switch the ignition off and determine the All vehicles cause once the engine has cooled down.
Page 73: Warning Lamps And Indicators
Instrument Cluster Brake system lamp WARNING LAMPS AND INDICATORS It illuminates when the parking brake is engaged. The following warning lamps and indicators illuminate when the ignition is WARNING switched on: Reduce your speed gradually and Airbag stop your vehicle as soon as it is safe to do so.
Page 74 Instrument Cluster Forward alert warning indicator Lane departure warning indicator It will illuminate when this It will illuminate when this feature is switched off or in feature is switched off or in conjunction with a message. conjunction with a message. See Forward alert function (page 152).
Page 75: Audible Warnings And Indicators
Instrument Cluster Rear fog lamp indicator Press the left arrow button on the steering wheel to enter the main menu. It will illuminate when you switch 2. Highlight Settings with the up and the rear fog lamps on. down arrow buttons and press the right arrow button.
Page 76 Instrument Cluster Door open A warning chime will sound when any door is opened if the vehicle exceeds a relatively low speed. Lights on A warning chime will sound if the driver’s door is opened with the exterior lights switched on and the ignition switched off. Low fuel A warning chime will sound when the remaining fuel is less than approximately...
Page 77: Information Displays
Information Displays Phone GENERAL INFORMATION Note: The information display will remain Settings on for several minutes after you switch off the ignition. Various systems on your vehicle can be controlled using the information display Controls controls on the steering column. Corresponding information is displayed in Press the up and down arrow buttons to the information display.
Page 78 Information Displays Trip Computer Trip odometer Dist to empty Instant fuel Ford EcoMode Average fuel Gear shifting Anticipation Speed Ford EcoMode Average speed Outside air All values Information Seatbelts Auto StartStop Driver Alert Traffic signs Settings Driver assist Traction ctrl...
Page 79 Information Displays Display Navigation info Always on On demand Always off Language English Deutsch Italiano Français Español Türkçe Pyccкий Nederlands Polski Svenska Português l/100km Measure unit Miles/Gallon Temp unit °Celsius °Fahrenheit Chimes Park slot found Information Warning Convenience Aux heater Park heater Time 1 Time 2...
Page 80 Information Displays Menu structure - information and You can access the menu using the entertainment display buttons on the audio or navigation unit. All vehicles Radio FM AST DAB1 DAB2 AM AST Auxiliary iPOD Bluetooth audio Line in Phone Dial number Phone book Call lists Bluetooth...
Page 81 Information Displays Menu structure - information and You can access the menu using the entertainment display Information and entertainment display control. For item location: See At a Glance (page 10).
Page 82 Information Displays Vehicles with navigation system Navigation Active guidance Route Route sections list Block next section Unblock rt sectn Country Destination input City/postcode Street District Start guidance Traffic TMC messages Block next section Route sections list Unblock rt sectn Start guidance Home address Change address Last destinations...
Page 83 Information Displays Eco settings Trailer Roof box Dynamic Motorway Tunnel Ferry/motorail Toll Seasonal roads Toll sticker Special functions GPS info System info Enter position Demo mode See separate menu structure Radio See separate menu structure Auxiliary See separate menu structure Phone See separate menu structure Menu...
Page 84: Trip Computer
Information Displays Assistance options Signs/lanes Speed limits Nav icons in lists Clear last destination Personal data Clear favourites Delete home address Clear all Reset all settings Audio Settings See separate menu structure See separate menu structure Clock Settings E130536 Outside air temperature TRIP COMPUTER Shows the outside air temperature.
Page 85: Information Messages
Information Displays Measure units To toggle between metric and imperial units, scroll to this display and press the OK button. Toggling the units of measure using this display will affect the following displays: Distance to empty. Average fuel consumption. Instantaneous fuel consumption. Average speed.
Page 86 Information Displays Active City Stop Message Indicator Action Active City Stop Sensor amber See Using Active City Stop (page 162). blocked Clean screen Active City Stop not amber See Using Active City Stop (page 162). available Active City Stop Auto See Using Active City Stop (page 162).
Page 87: Climate Control
Information Displays Battery and charging system Message Message Action indicator Stop your vehicle as soon as it is safe to do so and Electrical system over switch off the ignition. Have the system checked voltage stop safely by a properly trained technician as soon as possible.
Page 88 Information Displays Cruise control and Adaptive cruise control (ACC) Message Indicator Action Front radar sensor amber blocked check hand- See Adaptive cruise control (ACC) (page 148). book Forward Alert not avail- amber See Adaptive cruise control (ACC) (page 148). able ACC not available amber See Adaptive cruise control (ACC) (page 148).
Page 89 Keyless entry Message Message Action indicator Ford KeyFree key not See Keyless Entry (page 34). inside car Ford KeyFree key inside amber See Keyless Entry (page 34). vehicle Ford KeyFree Place key See Keyless Entry (page 34).
Page 90 Information Displays Lane keeping aid Message Indicator Action Lane keeping aid amber Have the system checked by a properly trained malfunction Service technician as soon as possible. required Lighting Message Message Action indicator Headlamp malfunction Have the system checked by a properly trained amber service required technician as soon as possible.
Page 91 Information Displays Maintenance Message Message Action indicator Stop your vehicle as soon as it is safe to do so and High engine temper- switch off the ignition. Have the system checked ature stop safely by a properly trained technician as soon as possible.
Page 92 Have the system checked by a properly trained amber service now technician. Stability control (ESP) Message Indicator Action Traction control off amber See General Information (page 75). Starting the engine Message Message Action indicator Ford KeyFree switch ignition off press See Keyless Starting (page 116). POWER...
Page 93 Information Displays Message Message Action indicator Drive to clean exhaust amber See Diesel Particulate Filter (page 118). filter check handbook Engine malfunction amber See Diesel Particulate Filter (page 118). service now Press brake to start See Keyless Starting (page 116). Press clutch to start See Keyless Starting (page 116).
Page 94 Information Displays Transmission Message Message Action indicator Under certain driving conditions it is possible that the clutches in the transmission can overheat. In these circumstances it is necessary to press the brake pedal and stop the vehicle to prevent further Transmission too hot overheating.
Page 95 Information Displays Message Message Action indicator Transmission not in See Automatic Transmission (page 129). See Park select P Starting and Stopping the Engine (page 114). See Automatic Transmission (page 129). See To start press brake Starting and Stopping the Engine (page 114). Press brake pedal See Automatic Transmission (page 129).
Page 96: Climate Control
Climate Control Warming the interior PRINCIPLE OF OPERATION Direct the air towards your feet. In cold or Outside air humid weather conditions, direct some of the air towards the windscreen and the Keep the air intakes forward of the door windows. windscreen free from obstruction (snow, leaves etc.) to allow the climate control Cooling the interior...
Page 97: Manual Climate Control
Climate Control Side air vent MANUAL CLIMATE CONTROL Air distribution control E132996 E74660 Face level Face level and footwell Footwell Footwell and windscreen Windscreen You can set the air distribution control to any position between the symbols.
Page 98 Climate Control Blower Ventilation E129885 Set the air distribution control, blower and air vents to suit your requirements. Air conditioning Switching the air conditioning on and E75470 Note: If you switch the blower off, the windscreen may mist up. If you turn the blower off, the air conditioning will turn off.
Page 99: Automatic Climate Control
Climate Control With the heater control in this position, the If you move the air distribution control to air conditioning and recirculated air will a position other than windscreen, the A/C switch on automatically. will remain on. You can switch the air conditioning and You can switch the air conditioning and recirculated air on and off.
Page 100: To Switch Mono Mode Off
Climate Control To switch mono mode off Note: Avoid adjusting the settings when the vehicle interior is extremely hot or cold. Select a temperature for the passenger’s The automatic climate control adjusts to side with the rotary control on the the current circumstances automatically.
Page 101 Climate Control Air distribution The blower speed and the temperature control operate automatically and cannot To adjust air distribution, press the desired be adjusted manually. The blower is set to button. Any combination of settings can high speed and the temperature to HI. be selected simultaneously.
Page 102: Heated Windows And Mirrors
Climate Control When switched off, the heating, ventilation ELECTRIC SUNROOF and air conditioning system is switched off and recirculated air is selected. WARNING Before operating the electric sunroof HEATED WINDOWS AND you should verify it is free of MIRRORS obstructions and ensure that children and/or pets are not in the proximity of the sunroof opening.
Page 103 Climate Control Opening and closing the sunroof To open or close the sunroof automatically press either side of the switch to the second action point and release it completely. Press again to stop. When the closed position is reached, the sunroof stops automatically.
Page 104: Auxiliary Heater
Climate Control Sunroof safety mode AUXILIARY HEATER WARNING Parking heater The anti-trap function is not active WARNINGS during this procedure. Make sure that there are no obstacles in the way of The parking heater must not be the closing sunroof. operated at filling stations, near sources of combustible vapours or dust or in enclosed spaces.
Page 105 Climate Control It preheats the interior of the vehicle. It keeps the windows clear of ice in the Park Heater event of frost and prevents condensation. Program 1 It avoids cold starts and allows the engine to reach operating temperature Program 2 sooner.
Page 106 Climate Control Fuel operated heater (depending Use the arrow buttons on the steering on country) wheel to enter the main menu. 2. Select the first programme time list. WARNING 3. Highlight the day on which the heater The fuel operated heater must not should warm up the vehicle.
Page 107: Seats
Seats bend your legs slightly so that you can SITTING IN THE CORRECT press the pedals fully. POSITION position the shoulder strap of the seat belt over the centre of your shoulder and position the lap strap tightly across your hips. Make sure that your driving position is comfortable and that you can maintain full control of your vehicle.
Page 108: Head Restraints
Seats Adjusting the lumbar support Adjusting the angle of the seatback E78058 E130250 Adjusting the height of the driver s seat HEAD RESTRAINTS Adjusting the head restraint WARNINGS Raise the rear head restraint when the rear seat is occupied by a passenger.
Page 109 Seats E135437 E135401 Adjust the head restraint so that the top of it is level with the top of your head. Removing the head restraint Press the locking buttons and remove the head restraint.
Page 110: Power Seats
Seats POWER SEATS E78060...
Page 111: Rear Seats
Seats REAR SEATS WARNINGS When folding the seatbacks down, take care not to get your fingers caught between the seatback and seat frame. Make sure that the seats and the seatbacks are secure and fully engaged in their catches. Folding the rear seatbacks E135628 forwards CAUTION...
Page 112: Heated Seats
Seats Folding the seatbacks up WARNING When folding the seatbacks up, make sure that the belts are visible to an occupant and not caught behind the seat. HEATED SEATS CAUTION Operating this function with the engine off will drain the battery. E135646 Note: Hold the cushion edge to avoid the ISOFIX anchor points and brackets.
Page 113: Convenience Features
CLOCK Note: You can use the socket to power 12 volt appliances that have a maximum current rating of 10 Amperes. Use only Ford See Information Displays (page 75). accessory connectors or connectors specified for use with SAE standard sockets.
Page 114: Cup Holders
Convenience features CUP HOLDERS WARNING Do not place hot drinks in the cup holders when the vehicle is moving. Rear seat armrest E91508 CHILDMINDER MIRROR E132505 GLASSES HOLDER E75192 E75193...
Page 115: Auxiliary Input (Aux In) Socket
Convenience features AUXILIARY INPUT (AUX IN) SATELLITE NAVIGATION UNIT SOCKET HOLDER Adjusting the holder E132422 See Auxiliary input (AUX IN) socket (page 243). USB PORT E112711 Unlock. 2. Adjust the holder to the desired position. 3. Lock. Note: Make sure that the navigation unit holder is locked in position.
Page 116: Starting And Stopping The Engine
Starting and Stopping the Engine II The ignition is switched on. All electrical GENERAL INFORMATION circuits are operational. Warning lamps and indicators illuminate. This is the key General points on starting position when driving. You must also select If the battery has been disconnected the it when being towed.
Page 117: Starting A Petrol Engine
Starting and Stopping the Engine Flooded engine STARTING A PETROL ENGINE Vehicles with manual transmission Note: You can only operate the starter for a maximum of 30 seconds at a time. Fully depress the clutch pedal. 2. Fully depress the accelerator pedal and Cold or hot engine hold it there.
Page 118: Starting A Diesel Engine
Starting and Stopping the Engine Starting at low ambient If the battery has been disconnected or temperatures after the fuel type has been changed, the idle speed may be irregular. This will When the temperature is lower than -10°C improve after 10 to 30 seconds. (14°F) and the vehicle is filled with E85, an engine block heater should be used to STARTING A DIESEL ENGINE...
Page 119 Starting and Stopping the Engine Starting with manual transmission WARNINGS Always check that the steering wheel Note: Releasing the clutch pedal during lock is deactivated before engine start will stop the engine cranking attempting to move your vehicle. and return to ignition on. See Steering Wheel Lock (page 114).
Page 120: Diesel Particulate Filter
Starting and Stopping the Engine Press and hold the start button for two seconds, or press twice within two seconds. DIESEL PARTICULATE FILTER The DPF forms part of the emissions reduction systems fitted to your vehicle. It filters harmful diesel particulates (soot) from the exhaust gas.
Page 121: Switching Off The Engine
Starting and Stopping the Engine If you drive only short distances or your journeys contain frequent stopping and starting, where there is increased acceleration and deceleration, occasional trips with the following conditions will assist the regeneration process: Drive your vehicle at a constant speed, preferably on a main road or motorway, for up to 20 minutes.
Page 122: Start-Stop
Start-Stop Note: If you stall the engine, and then PRINCIPLE OF OPERATION depress the clutch pedal within a couple of seconds, the system will automatically CAUTION restart the engine. For vehicles with Start-stop the Note: The Start-stop indicator will battery requirement is different. It illuminate green when the engine shuts must be replaced by one of exactly down.
Page 123 Start-Stop Low engine operating temperature. Low brake system vacuum. If a road speed of 5 km/h (3 mph) has not been exceeded. To re-start the engine Note: The gear lever must be in the neutral position. Depress the clutch pedal. The system may automatically restart the engine under certain conditions, for example:...
Page 124: Eco Mode
Eco Mode Anticipation PRINCIPLE OF OPERATION Adjusting your vehicle speed and the The system assists the driver to drive more distance to other vehicles without the need efficiently by constantly monitoring for heavy braking or acceleration will characteristics of gear changing, improve fuel consumption.
Page 125: Fuel And Refuelling
Fuel and Refuelling SAFETY PRECAUTIONS CAUTIONS Do not use leaded petrol or petrol with additives containing other metallic WARNINGS compounds (e.g. manganese-based). Stop refuelling after the fuel nozzle They could damage the emission system. stops the second time. Additional fuel will fill the expansion space in Do not use methanol instead of E85.
Page 126: Catalytic Converter
Note: We recommend that you use only Do not switch the ignition off when high quality fuel. driving. Note: The use of additives or other engine treatments not approved by Ford is not FUEL FILLER FLAP recommended. Note: We do not recommend the prolonged WARNINGS...
Page 127 Fuel and Refuelling Type 2 2. Insert the fuel nozzle up to and including the first notch on the nozzle A. Keep it resting on the cover of the fuel pipe opening. WARNING Stop refuelling after the fuel nozzle stops the second time. Additional fuel will fill the expansion space in the fuel tank which could lead to fuel overflowing.
Page 128: Refuelling
Fuel and Refuelling Type 1 E119081 5. Slightly raise the fuel nozzle to remove E139204 Refuelling with a fuel can Type 2 Use the funnel which is located in the glove box. REFUELLING CAUTION Do not attempt to start the engine if you have filled the fuel tank with the incorrect fuel.
Page 129: Fuel Consumption
Your Ford dealer can give you advice on improving your fuel consumption. TECHNICAL SPECIFICATIONS Focus Fuel Consumption Figures...
Page 130 Fuel and Refuelling CO2 Emis- Urban Extra-Urban Combined sions Variant l/100 km l/100 km l/100 km g/km (mpg) (mpg) (mpg) 2.0L Duratec-HE - MI4 Stage V, vehicles with 9.6 (29.4) 5 (56.5) 6.7 (42.2) manual transmission 2.0L Duratec-HE - MI4 Stage V, vehicles with auto- 9.1 (31) 4.9 (57.6)
Page 131: Transmission Manual Transmission
Transmission MANUAL TRANSMISSION AUTOMATIC TRANSMISSION Selecting reverse gear Selector lever positions CAUTION Do not engage reverse gear when the vehicle is moving. This can cause damage to the transmission. E133124 Park E99067 Reverse On some vehicles it is necessary to raise Neutral the collar whilst selecting reverse gear.
Page 132: Brakes
Transmission The transmission will select the WARNINGS appropriate gear for optimum performance Apply the parking brake and based on ambient temperature, road select park before leaving your gradient, vehicle load and driver input. vehicle. Make sure that the selector lever is latched in position. Sport mode and manual shifting Sport Mode Note: An audible warning will sound if you...
Page 133 Transmission Moving off Release the parking brake. 2. Release the brake pedal and press the accelerator pedal. Stopping Release the accelerator pedal and press the brake pedal. 2. Apply the parking brake. 3. Select neutral or park. E133129 Note: The lever is white. Kickdown 4.
Page 134: Principle Of Operation
Brakes you take corners too fast. PRINCIPLE OF OPERATION the road surface is poor. Note: Depending on applicable laws and regulations in the country for which your PARKING BRAKE vehicle was originally built, the brake lamps may flash if you brake heavily. WARNING Note: Occasional brake noise is normal and Vehicles with an automatic...
Page 135: Principle Of Operation
Stability Control Stability control (ESP) warning lamp PRINCIPLE OF OPERATION The ESP warning lamp will flash when the Electronic stability programme system is operating. See Warning Lamps (ESP) and Indicators (page 71). WARNING Emergency brake assist ESP does not relieve you of your WARNING responsibility to drive with due care and attention.
Page 136: Principle Of Operation
Hill Start Assist PRINCIPLE OF OPERATION WARNINGS At all times you are responsible for The system makes it easier to pull away controlling the vehicle, supervising when the vehicle is on a slope without the the system and intervening, if need to use the parking brake.
Page 137 Hill Start Assist Wait for a short time until the system deactivates automatically. If a forward gear was selected when the system became active, select reverse gear. If reverse gear was selected when the system became active, select a forward gear.
Page 138: Principle Of Operation
Parking Aids Note: The outer sensors may detect the PRINCIPLE OF OPERATION side walls of a garage. If the distance between the outer sensor and the side wall WARNING remains constant for three seconds, the The system does not relieve you of tone will switch off.
Page 139: Using The Parking Aid - Vehicles With: Front And Rear Parking Aid
Parking Aids E130180 E130178 A trailer symbol indicates there is a trailer attached and the system is disabled. Distance Indicator. As the distance decreases the indicator USING THE PARKING AID - moves towards the vehicle. VEHICLES WITH: FRONT AND A continuous tone will start at a distance REAR PARKING AID of less than 30 centimetres (11 inches) to the rear bumper.
Page 140 Parking Aids Manoeuvring with the parking aid You will hear an alternating tone from the front and rear if obstacles are closer than 30 centimetres (11 inches) to the front and rear bumpers. E130382 Distance Indicator. E130381 As the distance decreases the indicator Reverse gear selected moves towards the vehicle.
Page 141 Parking Aids E130180 A trailer symbol indicates there is a trailer attached and the rear sensors are disabled.
Page 142: Rear View Camera
Rear view camera PRINCIPLE OF OPERATION The camera is a visual aid for use when reversing. WARNING The system does not relieve you of your responsibility to drive with due care and attention. CAUTIONS If you use a high pressure spray to wash your vehicle, only spray the camera briefly from a distance not E99105...
Page 143 Rear view camera Using the display CAUTIONS Obstacles above the camera position will not be shown. Inspect the area behind your vehicle if necessary. Marks are for general guidance only, and are calculated for vehicles in maximum load conditions on an even road surface.
Page 144 Rear view camera Green - 0.6 - 0.9 metre (24 - 35 inches) Amber - centre line of the projected vehicle path Note: The green line is extended from 0.9 metre (35 inches) up to a distance of 3.2 metres (126 inches). Note: When reversing with a trailer, the lines on the screen are not shown.
Page 145: Active Park Assist
Active Park Assist The system will detect a suitable parallel PRINCIPLE OF OPERATION parking space and steer the vehicle into the space. The system controls the WARNINGS steering while the driver controls the The system does not relieve you of accelerator, transmission and brakes.
Page 146 Active Park Assist Move forwards at a maximum speed of 30 Note: If no selection is made via the km/h (18 mph). Press the active park assist direction indicator lever the system will switch. See At a Glance (page 10). Use default to the passenger side of the vehicle.
Page 147 Active Park Assist You can take control of the manoeuvre by holding the steering wheel. A message may appear that the system can be resumed. To accept this message press the active park assist switch. See At a Glance (page 10).
Page 148: Cruise Control
Cruise Control Setting a speed PRINCIPLE OF OPERATION Press the SET+ switch or the SET- switch WARNING to store and maintain your current speed. The cruise control indicator will illuminate. The system does not relieve you of See Warning Lamps and Indicators your responsibility to drive with due (page 71).
Page 149 Cruise Control Note: The system will no longer control your speed. The cruise control indicator will not illuminate but the system will retain the speed that you previously set. Resuming the set speed Pull the RES switch. The cruise control indicator will illuminate and the system will attempt to resume the speed that you previously set.
Page 150: Adaptive Cruise Control (Acc)
Adaptive cruise control (ACC) Note: When adaptive cruise control is PRINCIPLE OF OPERATION activated, you may hear some unusual sounds during automatic braking. This is WARNINGS normal and caused by the automatic The system is not a collision warning braking system. or avoidance system.
Page 151: Adaptive Cruise Control (Acc)
Adaptive cruise control (ACC) Detection beam issues Automatic braking with ACC WARNINGS You must take immediate action once alerted, as the adaptive cruise control braking will not be sufficient to keep a safe distance to the vehicle in front. In some cases there may be no warning or the warning may be delayed.
Page 152: Using Adaptive Cruise Control
Adaptive cruise control (ACC) Changing the set speed USING ADAPTIVE CRUISE CONTROL Note: Vehicle speed may be increased and decreased at intervals of 5 km/h or 5 mph. The system is operated by adjustment Note: If the system does not react to these controls mounted on the steering wheel.
Page 153 Adaptive cruise control (ACC) The distance between you and the vehicle Press the brake pedal or pull switch F to detected in front is maintained by a cancel the system. The system will return variable setting. There are five steps which to standby mode allowing you full manual are represented by horizontal bars control of the vehicle.
Page 154: Forward Alert Function
Adaptive cruise control (ACC) brake temperature being too high, for Note: The collision alerts will only occur if example when driving on mountainous the system is switched on, however the or hilly roads brake support is always on and cannot be turned off.
Page 155: Speed Limiter
Speed Limiter Switching the system on and off PRINCIPLE OF OPERATION Press switch B. The information display WARNING will prompt for a speed to be set. When you are going downhill, your Setting the speed limit speed may increase above the set speed.
Page 156: Driver Alert
Driver Alert Note: Keep the windscreen free from PRINCIPLE OF OPERATION obstructions such as bird droppings, insects and snow or ice. WARNINGS Note: The system is intended as a driver aid The system does not relieve you of when driving on fast main roads and your responsibility to drive with due motorways.
Page 157 Driver Alert System display Resetting the system When active the system will run You can reset the system by either: automatically in the background and only Switching the ignition off and on. issue warnings if required. You can view Stopping the vehicle and then opening the status at any time using the and closing the driver's door.
Page 158: Lane Departure Warning
Lane Departure Warning Note: The system is intended as a driver aid PRINCIPLE OF OPERATION when driving on fast main roads and motorways. WARNINGS Note: The system may not operate during The system does not relieve you of hard braking or acceleration and, when you your responsibility to drive with due are intentionally steering the vehicle.
Page 159 Lane Departure Warning Activate and deactivate the system using The lane markings are colour coded as the button on the indicator stalk. follows: Green - The system is ready to warn Press the button to turn the system off. you of any unintentional lane Press the button twice to turn the system departure.
Page 160: Lane Keeping Aid
Lane Keeping Aid Note: Keep the windscreen free from PRINCIPLE OF OPERATION obstructions such as bird droppings, insects and snow or ice. WARNINGS Note: The system is intended as a driver aid The system does not relieve you of when driving on fast main roads and your responsibility to drive with due motorways.
Page 161 Lane Keeping Aid Red - The vehicle is approaching or is too close to the detected lane boundary. A warning is given in the form of a vibration felt through the steering wheel. Take immediate safe action to reposition the vehicle. Grey - The relevant lane boundary will E132099 be suppressed.
Page 162: Traffic Sign Recognition
System display If your vehicle is fitted with a suspension kit not approved by us, the system may not function correctly. Always fit Ford Original Parts when replacing headlamp bulbs. Other bulbs may reduce system performance. Note: Keep the windscreen free from...
Page 163 Traffic Sign Recognition 3. After a predetermined distance they will be shown greyed out. 4. After another predetermined distance they will be deleted. If a supplementary traffic sign is detected, for example a reduced speed limit in wet road conditions sign, it will not be shown but will appear as an empty box underneath the respective sign.
Page 164: Active City Stop
Active City Stop PRINCIPLE OF OPERATION CAUTIONS If your vehicle is fitted with a windscreen not approved by us, the WARNINGS system may not function correctly. The system does not relieve you of your responsibility to drive with due If the engine stops after the system care and attention.
Page 165 Active City Stop Switching the system on and off Note: The system is per default on. Note: In certain situations, it may be advisable to disable the system, for example driving off road when objects may cover the windscreen. Activate and deactivate the system using the information display.
Page 166: Load Carrying
Load Carrying GENERAL INFORMATION WARNINGS Use load securing straps to an approved standard, e.g. DIN. Make sure that you secure all loose items properly. Place luggage and other loads as low and as far forward as possible within the luggage or loadspace. Do not drive with the tailgate or rear E97377 door open.
Page 167: Cargo Nets
Load Carrying To install the cargo retention net cassette: Remove the luggage cover. Push the sliders on the cassette towards each other and insert the telescopic bar into the holes on the sidewall behind the rear seatbacks. Ensure that the end caps with the anti-rotation pin are correctly fitted in the side trim.
Page 168: Dog Guard
Load Carrying Installing behind the front seats Reinstall the luggage cover. Remove in the reverse order. Cargo net E86848 Push the ends of the bar on the grille towards each other and insert them into the retainers on the roof. Push the bar forwards into the narrow section of the retainers.
Page 169 Load Carrying Push the ends of the bar on the grille towards each other and insert them into the retainers on the roof. Push the bar forwards into the narrow section of the retainers. E87783 3. Attach the grille to the lower bar with the handwheels.
Page 170: Roof Racks And Load Carriers
Remove the crossbars before entering an automatic car wash. Note: The side mounting tracks are designed such that crossbars (for bicycle carriers, ski carriers etc.) from the Ford accessories range can be fitted.
Page 171 Load Carrying 4 Nm 4N m E135138 2. Insert the key. Turn the key anti-clockwise. 3. Remove the cover. E135139 4. Loosen the screws. Note: Make sure there is no gap between crossbar and rail(A). 6. Install the crossbars. Tighten the screws until you hear a distinct click.
Page 172: Towing
Towing Change down a gear before you reach a TOWING A TRAILER steep downhill gradient. WARNINGS RETRACTABLE TOW BALL Do not exceed 100 km/h (62 mph). WARNING The rear tyre pressures must be You will hear a warning tone when increased by 0.2 bar (3 psi) above the tow ball arm is not in one of the specification.
Page 173: Swivelling The Tow Ball Arm Out
Towing Note: If the release process is interrupted, for example an obstacle in the way or loss of power supply, the system will need to be reset. To reset the system, repeat the release process. Note: The lamp in the switch illuminates when the system is activated.
Page 174 Towing Swivelling the tow ball arm in Fault conditions If the tow ball arm release button is CAUTION illuminated or you hear a warning tone Before swivelling the tow ball arm in, when the ignition switch is in position II, always unhitch the trailer or dismantle repeat the release process.
Page 175: Tow Ball
Towing Unlocking the tow ball arm TOW BALL mechanism WARNINGS When not in use, always transport the tow ball arm securely fastened in the luggage compartment. Take special care when fitting the tow ball arm as the safety of the vehicle and the trailer depends on this.
Page 176 Towing Inserting the tow ball arm Driving with a trailer E71331 WARNING If any of the below conditions cannot be met, do not use the tow bar and have it checked by a properly trained technician. Before starting your journey, make sure E71330 that the tow ball arm is properly locked.
Page 177 Towing Removing the tow ball arm Driving without a trailer E94771 Remove the tow ball arm. 2. Insert the plug into its seat (1). E71332 WARNING Unhitch the trailer. Never unlock the tow ball arm with 2. Remove the protecting cap. Press the the trailer attached.
Page 178: Driving Hints
Driving Hints In an emergency, the vehicle can be driven RUNNING-IN through water to a maximum depth of 200 millimetres (8 inches) and at a maximum Tyres speed of 10 km/h (6 mph). Extra caution should be exercised when driving through WARNING flowing water.
Page 179: Roadside Emergencies
Roadside Emergencies FIRST AID KIT Space is provided in the luggage compartment. WARNING TRIANGLE Space is provided in the luggage compartment.
Page 180: Fuse Box Locations
Fuses Load compartment fuse box FUSE BOX LOCATIONS 4-door Engine compartment fuse box This fuse box is located in the engine compartment See Maintenance (page 190). Passenger compartment fuse box E135336 5-door E130170 E135337 E130171 Pinch the retaining clips to release the cover.
Page 181: Changing A Fuse
Fuses Estate CHANGING A FUSE WARNINGS Do not modify the electrical system of your vehicle in any way. Have repairs to the electrical system and the replacement of relays and high current fuses carried out by a properly trained technician. Switch the ignition and all electrical equipment off before touching or attempting to change a fuse.
Page 182: Fuse Specification Chart
Fuses FUSE SPECIFICATION CHART Engine compartment fuse box E129925 Ampere Fuse Circuits protected rating ABS pump, Electronic Stability Program (ESP) pump Electronic Stability Program (ESP) valve Heated rear window Heater blower Start-stop module Engine management systems Starter relay Heated windscreen (right-hand side) Transmission control module...
Page 183 Fuses Ampere Fuse Circuits protected rating Heated windscreen (left-hand side) Auxiliary heater Windscreen wipers ABS, Electronic Stability Program (ESP) module Horn Brake lamp switch Battery monitoring system Relay coils, lighting control switch module Rear power outlet Electric exterior mirrors Transmission control module Air conditioning clutch Adaptive cruise control Headlamp washer...
Page 184 Fuses Ampere Fuse Circuits protected rating Electric power assisted steering Body Control Module Rear window wiper Headlamp levelling Adaptive cruise control Heated washer jets Electric windows (front) Heated exterior mirrors Vaporizer...
Page 185 Fuses Passenger compartment fuse box E129926 Ampere Fuse Circuits protected rating Fuel pump supply...
Page 186 Fuses Ampere Fuse Circuits protected rating Not used Not used Passive anti theft system (PATS) supply Interior lamps, driver's door switch pack, glove box, ambient lighting, electric sunroof Cigar lighter, rear power outlet Rain sensor module, humidity sensor, auto-dimming mirror Adaptive cruise control Not used Luggage compartment lid release...
Page 187 Fuses Ampere Fuse Circuits protected rating Washer pump ground Central locking ground Driver's door lock and double locking ground Climate control heater, passenger airbag deactivation switch, heated seats switch, auxiliary heater, manual air conditioning heater module Restraint system, passenger airbag deactivation system Not used Not used Not used...
Page 188 Fuses Ampere Fuse Circuits protected rating Door module (right-hand front) (electric windows, central locking, electric folding mirrors, heated exterior mirrors) Door module (left-hand rear) (electric windows) Door module (right-hand rear) (electric windows) Alarm system Electric driver's seat Not used Not used Air conditioning module (with start-stop module) Instrument cluster (with start-stop module) Information and entertainment display, GPS module (with...
Page 189 Fuses Ampere Fuse Circuits protected rating Blind spot monitor, lane keeping aid, active city stop, rear view camera (without start-stop module) Parking aid module Not used Not used Not used Heated driver's seat Heated front passenger seat Not used Electric sunroof Not used Not used Not used...
Page 190: Vehicle Recovery
Vehicle recovery Rear towing eye TOWING POINTS Towing eye location The screw-in towing eye is located in the spare wheel well. The towing eye must always be carried in the vehicle. Installing the towing eye CAUTION The screw-in towing eye has a left-hand thread.
Page 191 Vehicle recovery CAUTIONS Too much tension in the tow rope could cause damage to your vehicle or the vehicle that is towing. Select neutral when your vehicle is being towed. In the event of a breakdown or mechanical failure do not use individual axle carriers.
Page 192: Maintenance
Have your vehicle serviced regularly to help (page 198). maintain its roadworthiness and resale Brake fluid level. See Brake and value. There is a large network of Ford Clutch Fluid Check (page 200). Authorised Repairers that are there to help you with their professional servicing Washer fluid level.
Page 193: Closing The Bonnet
Maintenance E133239 E87786 Move the yellow catch to the right. Open the bonnet and support it with the strut. Closing the bonnet WARNING Make sure that the bonnet is closed properly. Lower the bonnet and allow it to drop from under its own weight for the last 20 –...
Page 194: Under Bonnet Overview - 1.6L Duratec-16V Ti-Vct (Sigma)
Maintenance UNDER BONNET OVERVIEW - 1.6L DURATEC-16V TI-VCT (SIGMA) E130030 Engine coolant reservoir : See Engine Coolant Check (page 199). Brake and clutch fluid reservoir (right-hand drive) : See Brake and Clutch Fluid Check (page 200). Engine oil filler cap : See Engine Oil Check (page 198).
Page 195: Under Bonnet Overview - 1.6L Ecoboost Scti (Sigma)
Maintenance UNDER BONNET OVERVIEW - 1.6L ECOBOOST SCTI (SIGMA) E132729 Brake and clutch fluid reservoir (right-hand drive). See Brake and Clutch Fluid Check (page 200). Engine oil filler cap . See Engine Oil Check (page 198). Brake and clutch fluid reservoir (left-hand drive). See Brake and Clutch Fluid Check (page 200).
Page 196: Under Bonnet Overview - 1.6L Duratorq-Tdci (Dv) Diesel
Maintenance Screen washer fluid reservoir. See Washer Fluid Check (page 200). Engine coolant reservoir. See Engine Coolant Check (page 199). The filler caps and the engine oil dipstick are coloured for easy identification. UNDER BONNET OVERVIEW - 1.6L DURATORQ-TDCI (DV) DIESEL E130031 Engine coolant reservoir : See Engine Coolant Check (page 199).
Page 197: Under Bonnet Overview - 2.0L Duratec-He (Mi4)
Maintenance Engine compartment fuse box: See Fuses (page 178). Air cleaner: No maintenance necessary. Engine oil dipstick : See Engine Oil Check (page 198). Screen washer fluid reservoir : See Washer Fluid Check (page 200). For easy identification, filler caps and the engine oil dipstick are marked in colour. UNDER BONNET OVERVIEW - 2.0L DURATEC-HE (MI4) E139960...
Page 198 Maintenance Engine coolant reservoir : See Engine Coolant Check (page 199). Brake and clutch fluid reservoir (right-hand drive) : See Brake and Clutch Fluid Check (page 200). Engine oil filler cap : See Engine Oil Check (page 198). Brake and clutch fluid reservoir (left-hand drive) : See Brake and Clutch Fluid Check (page 200).
Page 199: Under Bonnet Overview - 2.0L Duratorq-Tdci (Dw) Diesel
Maintenance UNDER BONNET OVERVIEW - 2.0L DURATORQ-TDCI (DW) DIESEL E130032 Engine coolant reservoir : See Engine Coolant Check (page 199). Brake and clutch fluid reservoir (right-hand drive) : See Brake and Clutch Fluid Check (page 200). Engine oil dipstick : See Engine Oil Check (page 198). Brake and clutch fluid reservoir (left-hand drive) : See Brake and Clutch Fluid Check (page 200).
Page 200: Engine Oil Dipstick - 1.6L Duratec-16V Ti-Vct (Sigma)
Maintenance ENGINE OIL DIPSTICK - 1.6L ENGINE OIL DIPSTICK - 2.0L DURATEC-16V TI-VCT (SIGMA) DURATEC-HE (MI4) E95540 E134040 ENGINE OIL DIPSTICK - 1.6L ENGINE OIL DIPSTICK - 1.6L ECOBOOST SCTI (SIGMA) DURATORQ-TDCI (DV) DIESEL/2.0L DURATORQ-TDCI (DW) DIESEL E134114 E95543 ENGINE OIL CHECK CAUTION Do not use oil additives or other engine treatments.
Page 201: Engine Coolant Check
CAUTIONS mark. In an emergency, you can add just water to the cooling system to reach Top up with fluid that meets the Ford a vehicle service station. Have the specification. See Technical system checked by a properly trained Specifications (page 201).
Page 202: Brake And Clutch Fluid Check
Note: The brake and the clutch systems are mark. supplied from the same reservoir. Top up with fluid that meets the Ford Top up with a 50/50 mixture of coolant specification. See Technical and water using fluid that meets the Ford Specifications (page 201).
Page 203: Technical Specifications
4925 Class 6 Fluid Your engine has been designed to be used with Castrol and Ford Engine Oil, which gives a fuel economy benefit whilst maintaining the durability of your engine. For petrol engines only, Ford and Castrol have developed a low friction SAE-5W-20 oil which offers further fuel economy benefits over the standard SAE-5W-30 oil.
Page 204 Maintenance Capacities Variant Item Capacity in Litres (gallons) Vehicles with a petrol Fuel tank 55 (12.1) engine 1.6L Duratorq-TDCi - DV Fuel tank 53 (11.7) 2.0L Duratorq-TDCi - DW Fuel tank 60 (13.2) Windscreen washer system 4.5 (1) - with headlamp washers Windscreen washer system - without headlamp 3 (0.7)
Page 205 Maintenance Engine oil top up capacities Engine Capacity in litres (gallons) 1.6L Duratec-16V Ti-VCT - Sigma 0.8 (0.2) 1.6L EcoBoost - Sigma 0.8 (0.2) 2.0L Duratec-HE - MI4 0.9 (0.2) 1.6L Duratorq-TDCi - DV 1.6 (0.4) 2.0L Duratorq-TDCi - DW 1.8 (0.4)
Page 206: Vehicle Care
Vehicle Care Cleaning the chrome trim CLEANING THE EXTERIOR CAUTION WARNING Do not use abrasives or chemical If you use a car wash with a waxing solvents. Use soapy water. cycle, make sure that you remove the wax from the windscreen. Body paintwork preservation CAUTIONS CAUTIONS...
Page 207: Repairing Minor Paint Damage
You should repair paintwork damage caused by stones from the road or minor scratches as soon as possible. A choice of products is available from your Ford Dealer. Read and follow the manufacturer’s instructions.
Page 208: Vehicle Battery
Vehicle battery To connect the booster cables JUMP-STARTING THE VEHICLE WARNING Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. CAUTIONS Connect batteries with only the same nominal voltage. Always use booster cables with insulated clamps and adequate size cable.
Page 209: Changing The Vehicle Battery
Vehicle battery BATTERY CONNECTION CAUTIONS Do not connect to the negative (–) POINTS terminal of the flat battery. CAUTION Make sure that the cables are clear of any moving parts and fuel delivery Do not connect to the negative (–) system parts.
Page 210: Wheels And Tyres
Wheels and Tyres Refer to the following information before GENERAL INFORMATION changing the road wheel. CAUTIONS WARNINGS Use only approved wheel and tyre Drive the shortest possible distances. sizes. Using other sizes could damage the vehicle and will make the National Do not fit more than one spare wheel Type Approval invalid.
Page 211 Wheels and Tyres Note: Vehicles with a tyre repair kit are not Vehicles without tyre repair kit equipped with a vehicle jack or a wheel Your vehicle jack, wheel brace, screw-in brace. towing eye and wheel trim remover are It is recommended to use a workshop type located in the spare wheel well.
Page 212 Wheels and Tyres Assembling the wheel brace Type one WARNING When returning the wheel brace extension to its original position, take care not to get your fingers caught. Note: Make sure that the wheel brace is fully extended. E93302 Small arrow-shaped marks on the sills A show the location of the jacking points.
Page 213 Wheels and Tyres Removing the wheel trim WARNINGS If your vehicle has a manual Type one transmission, select first or reverse gear. If it has an automatic Insert the flat end of the wheel brace transmission, select park. between the rim and the trim and carefully remove the trim.
Page 214 Wheels and Tyres CAUTION Do not install alloy wheels using wheel nuts designed for use with steel wheels. Note: The wheel nuts of alloy wheels and spoked steel wheels can also be used for the steel spare wheel for a short time (maximum two weeks).
Page 215: Tyre Repair Kit
Wheels and Tyres Drive with caution and avoid WARNING making sudden steering or driving Have the wheel nuts checked for manoeuvres, especially if the vehicle tightness and the tyre pressure is heavily loaded or you are towing a checked as soon as possible. trailer.
Page 216 Wheels and Tyres Leave the engine running while the kit CAUTION is in use, but not if the vehicle is in an Screwing the bottle onto the bottle enclosed or poorly ventilated area (for holder will pierce the seal of the example, inside a building).
Page 217 Wheels and Tyres Remove the power plug G from the Power plug with cable cigar lighter socket or auxiliary power Compressor switch socket. Label Quickly unscrew the hose C from the tyre valve and replace the protective Bottle lid cap A. Fasten the valve cap again. Sealant bottle Leave the sealant bottle K in the bottle holder E.
Page 218: Tyre Care
Wheels and Tyres 3. If the pressure of the sealant-filled tyre Empty sealant bottles can be disposed of is 1.3 bar (19 psi) or more, adjust it to together with normal household waste. the specified pressure. See Technical Return remains of sealant to your dealer Specifications (page 218).
Page 219: Using Winter Tyres
Wheels and Tyres USING WINTER TYRES TYRE PRESSURE MONITORING SYSTEM CAUTION WARNINGS Make sure that you use the correct wheel nuts for the type of wheel the The system does not relieve you of winter tyres are fitted to. your responsibility to regularly check the tyre pressures.
Page 220: Technical Specifications
Wheels and Tyres System reset Apart from a too low tyre pressure or a damaged tyre, the following situations can Note: Do not reset the system when the affect the rolling circumference: vehicle is moving. Vehicle load is uneven. Note: You should reset the system When using a trailer or travelling up and following any adjustment to the tyre down an incline.
Page 221 Wheels and Tyres Up to 160 km/h (100 mph) Normal load Full load Variant Tyre size Front Rear Front Rear bar (psi) bar (psi) bar (psi) bar (psi) 2.1 (31) 2.1 (31) 2.4 (35) 2.8 (41) 205/55 R 16 1.6L Duratec-16V Ti- VCT - Sigma, 1.6L EcoBoost - Sigma, 2.1 (31)
Page 222 Wheels and Tyres Continuous speed in excess of 160 km/h (100 mph) Normal load Full load Variant Tyre size Front Rear Front Rear bar (psi) bar (psi) bar (psi) bar (psi) 1.6L Duratec-16V Ti- VCT - Sigma, 1.6L 205/55 R 16 2.1 (31) 2.1 (31) 2.4 (35)
Page 223: Vehicle Identification
Vehicle identification Note: The vehicle identification plate VEHICLE IDENTIFICATION design may vary to that shown. PLATE Note: The information shown on the vehicle identification plate is dependant upon market requirements. E135662 Model Variant Engine designation Emission level Vehicle identification number Gross vehicle weight Gross train weight Maximum front axle weight...
Page 224: Vehicle Identification Number
Vehicle identification VEHICLE IDENTIFICATION NUMBER E87496 The vehicle identification number is stamped into the floor panel on the right-hand side, beside the front seat. It is also shown on the left-hand side of the instrument panel.
Page 225: Capacities And Specifications
Capacities and Specifications TECHNICAL SPECIFICATIONS Vehicle dimensions 4-door Dimension description Dimension in mm (inches) Maximum length 4534 (178.5) Overall width including exterior mirrors 2010 (79.1) Overall height - EC kerb weight 1451 - 1484 (57.1 - 58.4) Wheelbase 2648 (104.3) Front track 1544 - 1559 (60.8 - 61.4) Rear track...
Page 226 Capacities and Specifications Dimension description Dimension in mm (inches) Rear track 1534 - 1549 (60.4 - 61) Towing equipment dimensions E132737...
Page 227 Capacities and Specifications 4-door Item Dimension description Dimension in mm (inches) Bumper – centre of tow ball 77 - 80 (3 - 3.1) Attachment point – centre of tow ball 5 (0.2) Wheel centre – centre of tow ball 1068 - 1071 (42 - 42.2) Centre of tow ball –...
Page 228 Capacities and Specifications Item Dimension description Dimension in mm (inches) Centre of tow ball – side member 590 (23.2) Distance between side members 1179 (46.4) Centre of tow ball – centre 1. attachment 474 (18.7) point Centre of tow ball – centre 2. attachment 719 (28.3) point...
Page 229: Audio Introduction
Audio introduction IMPORTANT AUDIO INFORMATION WARNINGS Due to technical incompatibility, E66257 recordable (CD-R) and rewritable Disc labels (CD-RW) discs may not function correctly. Audio CD These CD radio units will play compact discs that conform to the International Red Book standard audio specification.
Page 230: Audio Unit Overview
Audio unit overview Note: Units have an integrated multi function display situated above the CD aperture. This shows important information regarding control of your audio unit. Additionally, there are various icons placed around the display screen which light up when a function is active (for example CD, Radio or Aux.) Type 1 E130324...
Page 231 Audio unit overview Seek up. CD track selection. See Station tuning control (page 235). See Track selection (page 240). On/off and volume control. Seek down. CD track selection. See Station tuning control (page 235). See Track selection (page 240). Menu select. Sound button.
Page 232 Audio unit overview E130142 CD eject. See Compact disc player (page 240). Navigation arrows. CD aperture. See Compact disc player (page 240). Information. Traffic announcement. See Traffic information control (page 236). Sound button. See Sound button (page 235). Telephone keypad and station presets. See Using the telephone (page 246). See Station preset buttons (page 236).
Page 233 Audio unit overview On/off and volume control. Seek down. CD track selection. See Station tuning control (page 235). See Track selection (page 240). Function 2. Function 1. Menu select. Phone menu. See Telephone (page 245). Auxiliary, USB and iPod select. See Auxiliary input (AUX IN) socket (page 113).
Page 234 Audio unit overview E129074 On/off control. Display select. Telephone keypad and station presets. See Using the telephone (page 246). See Station preset buttons (page 236). CD aperture. See Compact disc player (page 240). Navigation arrows. DSP select. See Digital signal processing (DSP) (page 238). CD eject.
Page 235 Audio unit overview Traffic announcement. See Traffic information control (page 236). Function 4. Sound button. See Sound button (page 235). Function 3. Function 2. Menu select. Function 1. Phone menu. See Telephone (page 245). Auxiliary select. See Auxiliary input (AUX IN) socket (page 113). See Auxiliary input (AUX IN) socket (page 243).
Page 236: Audio System Security
Audio system security SECURITY CODE Each unit incorporates a unique code that is linked to the vehicle identification number (VIN). The system will automatically check that the audio unit and vehicle match before allowing operation. If a security code message appears, please see your dealer.
Page 237: Audio Unit Operation
Audio unit operation Note: The system will automatically ON/OFF CONTROL change to another corresponding station if the current one becomes unavailable, for Press the on/off control. This will also example when leaving the coverage area. operate the unit for up to one hour with the ignition turned off.
Page 238: Station Preset Buttons
Audio unit operation 2. Select RADIO mode and then SCAN. AUTOSTORE CONTROL 3. Use the seek buttons to scan up or Note: This will store up to a maximum of down the selected waveband. the 10 strongest signals available, either 4.
Page 239 Audio unit operation Note: When you are listening to a non TA station and turn TA off and on again a TP seek will occur. Traffic announcement volume Traffic announcements interrupt normal broadcasts at a preset minimum level that is usually louder than normal listening volumes.
Page 240: Audio Unit Menus
Audio unit menus AUTOMATIC VOLUME NEWS BROADCASTS CONTROL Some audio units interrupt normal reception to broadcast news bulletins from When available, automatic volume control stations on the FM waveband or radio data (AVC) adjusts the volume level to system (RDS) and enhanced other compensate for engine noise and road network (EON) linked stations, in the same speed noise.
Page 241: Regional Mode (Reg)
Audio unit menus It will restore radio reception when it finds one or, if one is not found, the unit will return to the original stored frequency. When selected, ‘AF’ will be shown in the display. Press the MENU button. 2.
Page 242: Compact Disc Player
Compact disc player COMPACT DISC PLAYBACK SHUFFLE/RANDOM Note: During playback, the display indicates Random track playback, also known as the disc, track and time that has elapsed shuffle, plays all tracks on the CD in since the start of the track. random order.
Page 243: Compact Disc Track Scanning
Compact disc player When an MP3 CD is playing, options When a CD containing audio is inserted include REPEAT for the track, or to repeat into the CD player the disc's directory all the tracks in the folder. Repeat presses structure is read in.
Page 244: Ending Compact Disc Playback
Compact disc player Note: If the ID3 information selected is unavailable, NO MP3 TAG will be shown in the display. CD text display options When an audio disc with CD text is playing, limited information encoded in each track can be displayed. Such information will normally include: The disc name The artist name...
Page 245: Auxiliary Input (Aux In) Socket
Auxiliary input (AUX IN) socket Note: For optimum performance when using any auxiliary device set the volume on the device high. This will reduce audio interference when charging the device via the vehicle power supply socket. When fitted the Auxiliary input (AUX IN) socket permits an auxiliary device, such as an MP3 player, to be linked into the vehicle audio system.
Page 246: Audio Troubleshooting
Audio troubleshooting Audio unit display Rectification PLEASE CHECK CD General error message for CD fault conditions, such as cannot read the CD, data-CD inserted, etc. Ensure disc is loaded correct way up. Clean and re-try, or replace disc with known music disc. If error persists contact your dealer.
Page 247: Telephone
Compatibility of phones 2. In the Bluetooth menu on your phone, CAUTION search for Ford Audio and select it. As no common agreement exists, 3. Enter the code number shown on the mobile phone manufacturers are able vehicle display using the phone keypad.
Page 248: Telephone Controls
Telephone Bond another Bluetooth phone After start up access to the phonebook list can be delayed for several minutes, Bond a new Bluetooth phone as described depending upon the size. in the requirements for a Bluetooth connection. Phonebook categories Phones stored in the system are accessible The category is indicated as an icon: by using the phone list on the audio unit.
Page 249: Voice Control
Telephone Note: You can exit the phone menu by Dialling a number using the telephone pressing any source button CD, RADIO or keypad AUX. Press the PHONE button. Note: When referred to, the use of the 2. Dial the number using the telephone up/down arrow buttons, seek up and seek keypad on the audio unit.
Page 250 Telephone Receiving an incoming call Muting the microphone Note: During a call, it is possible to mute Accepting an incoming call the microphone. Whilst muted, confirmation Incoming calls can be accepted by pressing will appear in the display. the seek down button, or by pressing the Press function button 1.
Page 251: Voice Control
Voice control If you are not sure how to continue say PRINCIPLE OF OPERATION "HELP" for assistance or "CANCEL" if you do not wish to continue. CAUTION The "HELP" function provides only a Using the system with the engine off subset of the available voice commands.
Page 252: Audio Unit Commands
Voice control Start communicating with the system Store up to 20 name tags per function. The average recording time for each Before you can start talking to the system name tag is approximately 2-3 you first have to press the VOICE button seconds.
Page 253 Voice control Steps User says System answer "CD PLAYER" "CD PLAYER" "TRACK NUMBER PLEASE" "TRACK" "TRACK <number>" "<a number between 1 and 99>" * Can be used as a shortcut. ** Additionally, numbers can be spoken as up to four single digits (for example "2", "4", "5"...
Page 254 Voice control "RADIO" "PLAY" * Can be used as a shortcut. Tune frequency This function allows you to tune your radio by voice commands. Steps User says System answer "RADIO" "RADIO" "AM" "AM FREQUENCY PLEASE" "FM" "FM FREQUENCY PLEASE" "TUNE <frequency>" "<frequency>"...
Page 255 Voice control Tune name This function allows you to call up a stored radio station. Steps User says System answer "RADIO" "RADIO" "NAME PLEASE" "TUNE NAME" "<name>" "TUNE <name>" * Can be used as a shortcut. Delete name This function allows you to delete a stored radio station.
Page 256 Voice control Steps User says System answer "RADIO" "RADIO" "DELETE DIRECTORY" "DELETE DIRECTORY" "CONFIRM YES OR NO" "YES" "RADIO DIRECTORY DELETED" "NO" "COMMAND CANCELLED" Play This function switches the audio source to the radio mode. Steps User says System answer "RADIO"...
Page 257 Voice control "EXTERNAL DEVICE", "USB" "PLAY" "TRACK" "PLAYLIST" "FOLDER" "SHUFFLE ALL" "SHUFFLE FOLDER" "SHUFFLE PLAYLIST" "SHUFFLE OFF" "REPEAT TRACK" "REPEAT FOLDER" "REPEAT OFF" * Can be used as a shortcut. ** Playlists and folders activated by voice control must be assigned special filenames. See General Information (page 265).
Page 258 Voice control Steps User says System answer "EXTERNAL DEVICE" "EXTERNAL DEVICE" "USB" "USB" "TRACK" "TRACK NUMBER PLEASE" "TRACK <number>" "<a number between 1 and 99>" * Additionally, numbers can be spoken as up to four single digits (for example "2", "4", "5"...
Page 259: Telephone Commands
Voice control iPod Track You can choose a track off the all titles list of your iPod directly. Steps User says System answer "EXTERNAL DEVICE" "EXTERNAL DEVICE" "IPOD" "IPOD" "TRACK NUMBER PLEASE" "TRACK" "TRACK <number>" "<a number between 1 and 99>" * Can be used as a shortcut.
Page 260 Voice control "PHONE" "HELP" "MOBILE NAME" "DIAL NUMBER" "DIAL NAME" "DELETE NAME" "DELETE DIRECTORY" "PLAY DIRECTORY" "STORE NAME" "REDIAL" "ACCEPT CALLS" "REJECT CALLS" * Can be used as a shortcut. Phone functions Dial number Phone numbers can be dialled after giving the name tag voice command.
Page 261 Voice control Dial name Phone numbers can be dialled after giving the name tag voice command. Steps User says System answer "PHONE" "PHONE" "NAME PLEASE" "DIAL NAME" "<name>" "DIAL <name>" "CONFIRM YES OR NO" "YES" "DIALLING" "NO" "COMMAND CANCELLED" * Can be used as a shortcut. Redial This function allows you to redial the last dialled phone number.
Page 262 Voice control DTMF (Tone dialling) Note: DTMF can only be used during an ongoing call. Operate the VOICE button and This function transfers spoken numbers wait for the system prompt. into DTMF tones. For example, to make a Can only be used with vehicles installed with remote enquiry to your home answering a dedicated VOICE button.
Page 263 Voice control Steps User says System answer "PHONE" "PHONE" "DELETE NAME" "NAME PLEASE" "<name>" "DELETE <name>" "CONFIRM YES OR NO" "YES" "<name> DELETED" "NO" "COMMAND CANCELLED" Play directory Use this function to let the system tell you all stored entries. Steps User says System answer...
Page 264: Climate Control Commands
Voice control Steps User says System answer "PHONE" "PHONE" "REJECT CALLS" "REJECT CALLS" "ACCEPT CALLS" "ACCEPT CALLS" * use this command to turn the reject mode off Overview CLIMATE CONTROL The overview below shows the available COMMANDS voice commands. The following lists will give further information about the Climate complete command menu in selected...
Page 265 Voice control Steps User says System answer "CLIMATE" "CLIMATE" "FAN SPEED PLEASE" "‘FAN" "MINIMUM" "FAN MINIMUM" "<a number between 1 and 7>" "FAN <number>" "MAXIMUM" "FAN MAXIMUM" * Can be used as a shortcut. On vehicles fitted with an English language module the "FAN" shortcut is not available.
Page 266 Voice control Steps User says System answer "MAXIMUM" "TEMPERATURE MAXIMUM" * Can be used as a shortcut. Auto mode Steps User says System answer "CLIMATE" "CLIMATE" "AUTO MODE" "AUTO MODE" * Can be used as a shortcut. Can be deactivated by selecting a different temperature or fan speed.
Page 267: Connectivity
Cover the socket connection when not in use. iPod media players (refer to Only use USB Mass-Storage device www.ford-mobile compliant devices. -connectivity.com for latest compatibility list). Always switch your audio unit to a different source (for example the The system is USB 2.0 full speed...
Page 268: Connecting An External Device
Plug in the device, and if necessary secure below: it to prevent movement within the vehicle. Create folders named with the structure "Ford<*>" where <*> is a Connecting an iPod number 1-10. For example "Ford3" For optimum convenience and audio without an extension.
Page 269: Using A Usb Device
Connectivity Bonding the device Folder To connect the device to the system follow E100022 the same procedure as for Bluetooth hands Playlist free phones. See Bluetooth setup (page 245). E100023 Operating the device Album Note: The seek buttons and file information E100024 will only work on certain phones and Artist...
Page 270: Using An Ipod
Connectivity The display will show the track folder name information, together with other important file name. information described below: A vertical scroll bar on the right side of USING AN IPOD the display shows the current position of the folder view. Various icons are used to identify types of ">"...
Page 271 Connectivity The iPod menu list for browsing contents Press the INFO button or function button will be available through the radio display. 4 to display the following: Navigation of the contents follows the title same principles as for iPod standalone use artist (for example search by artist, title, etc.).
Page 272: Navigation Introduction
Navigation introduction GENERAL INFORMATION CAUTIONS Use only 12 cm (4.7 inches) discs or 8 Press the relevant button on the unit bezel cm (3.1 inches) discs with a suitable to access the system functions. This will adaptor. take you into the selected mode. Do not attempt to open the unit.
Page 273 Read and follow all stated safety precautions. Failure to do so may increase your risk of collision and personal injury. Ford Motor Company shall not be liable for any damages of any type arising from failure to follow these guidelines.
Page 274: Navigation Unit Overview
Navigation unit overview Descriptions for function buttons Function buttons 1 to 4 are context dependent, and change according to the current unit mode. Descriptions for the functions are shown at the bottom of the screen display. E104157...
Page 275 Navigation unit overview Vehicles with CD-SD navigation system E129241 CD eject. Navigation arrows. CD aperture. Information. Map select. See Route displays (page 284). Menu select. See System settings (page 280). Telephone keypad and station presets. See Audio unit operation (page 235). See Audio unit menus (page 238).
Page 276 Navigation unit overview Function 3. Seek up. CD track selection. See Station tuning control (page 235). See Track selection (page 240). On/off and volume control. See On/off control (page 235). Seek down. CD track selection. See Station tuning control (page 235). See Track selection (page 240).
Page 277 Navigation unit overview Vehicles with Sony CD-SD navigation system E129242 On/off control. See On/off control (page 235). Navigation select. See System settings (page 280). Telephone keypad and station presets. See Audio unit operation (page 235). See Audio unit menus (page 238). See Telephone (page 245). CD aperture.
Page 278: Loading The Navigation Data
Navigation unit overview Home select. See System settings (page 280). Traffic announcement. See Traffic Message Channel (page 285). Function 4. Sound select. See Sound button (page 235). Function 3. Function 2. Menu select. See System settings (page 280). Function 1. Phone select.
Page 279: Navigation Quick Start
GPS receiver. system performance. To avoid this Note: The Ford Mobile Navigation must be situation, only recommended phones installed and activated on your mobile should be used.
Page 280 E114213 and down arrow buttons to view the 2. Switch your mobile phone on and start remainder of the selection list. the "Ford Mobile Navigation". 2. Press the OK button to confirm your 3. Choose "Select Destination". selection. 4. Choose "Enter Address".
Page 281 Navigation Quick start Starting from the top, select the country followed by either the postcode if available or city and street name. Use the alphanumeric keypad and selection lists to select your address details. Once sufficient information has been entered, scroll to Start guidance and press the OK button to activate your selection.
Page 282: System Settings
System settings Most of the important settings for your Last destinations navigation unit can be accessed via the This feature allows quick access to a MENU or NAV button. The following history of previous destinations entered in section describes the various options and the system.
Page 283 System settings Special functions Nav audio mixing This feature allows you to select GPS and This feature allows you to adjust the system information or a demonstration of volume mix between the navigation voice the system functionality. output and audio source. Map display DSP settings This feature allows you to change the way...
Page 284 System settings Clock settings Set time This feature allows you to manually adjust the time. Set date This feature allows you to manually adjust the date, month and year. GPS time This feature allows you to, if in a suitable coverage area, automatically adjust the date and time using GPS.
Page 285: Navigation System
Navigation system Eco settings ROUTE OPTIONS MENU Trailer You can set a number of options which alter the way a route is planned. Use this feature to change the economy settings of your journey relating to whether Using the up, down, left and right arrow or not you are towing a trailer and if so the buttons, you can select from the list which size of trailer being towed.
Page 286: Route Displays
Navigation system Seasonal roads Junction zoom When switched on the system will look for This feature will automatically increase seasonal roads on your route and the zoom on the map display at times automatically update your route distance when you are required to make a turn, or and timings.
Page 287: Traffic Message Channel
Traffic Message Channel You may either select a view which shows PRINCIPLE OF OPERATION messages only affecting your programmed route, or a view which shows all messages Traffic message channel (TMC) stations received. Press function button 1 to change are broadcast on the FM waveband. TMC the view.
Page 288: Map Updates
Map updates The road network is constantly changing due to new roads, changes in road classification, etc. Therefore, it is not always possible to exactly match the map data in the system to the current road network. Map information is regularly updated, but all areas are not necessarily covered to the same level of detail.
Page 289: Appendices
The Bluetooth word mark and logos are FCC/INDUSTRY CANADA NOTICE owned by the Bluetooth SIG, Inc. and any use of such marks by Ford Motor Company This device complies with Part 15 of the is under license. Other trademarks and FCC Rules.
Page 290: Type Approvals
Appendices E114220 TYPE APPROVALS TYPE APPROVALS Laser sensor E97713 E97714 SD Logo is a trademark. E132582...
Page 291: Type Approvals
Appendices WARNINGS WARNINGS Invisible laser radiation. Do not view IEC 60825-1: 1993 + A2:2001. directly with optical instruments Complies with FDA performance (magnifiers). Class 1M laser product. standards for laser products except for deviation pursuant to Laser Notice No. 50, dated July 26th, 2001. Item Specification Max average power...
Page 292 Appendices WARNINGS WARNINGS Keep antenna and power cables at any electronic modules and airbags. least 10 centimetres (4 inches) from E85998 Frequency Band Maximum output power Watt (Peak Antenna Positions RMS) 1 – 30 50 W 3, 4 30 – 54 50 W 1, 2, 3 68 –...
Page 293 Appendices Check that electromagnetic fields generated inside the vehicle cabin by the transmitter installed do not exceed applicable human exposure requirements.
Page 295 Index Audible Warnings and Indicators....73 Automatic transmission........73 Door open..............74 Frost................73 See: Climate Control..........94 Key outside car............73 About This Manual...........7 Lights on..............74 Low fuel..............74 See: Brakes............132 Seat belt reminder..........74 ABS driving hints Switching the chimes on and off....73 See: Hints on Driving With Anti-Lock Audio Control............41 Brakes..............132 Type 1.................41...
Page 296 Index Automatic Transmission......129 Emergency park position release lever..............131 Capacities and Specifications....223 Hints on driving with an automatic Technical Specifications.........223 transmission............130 Cargo Nets............165 Selector lever positions........129 Cargo net...............166 Sport mode and manual shifting....130 Luggage retention net........165 Automatic volume control.......238 Car Wash Autostore control.........236 See: Cleaning the Exterior......204 Autowipers............43...
Page 297 Index Child Safety Locks..........22 Electric child safety locks........22 Manual child safety locks........22 Diesel Particulate Filter.......118 Child Seat Positioning........18 Regeneration............118 Child Seats............17 Digital signal processing (DSP).....238 Child restraints for different mass Changing the DSP settings......238 groups..............17 DSP equaliser............238 Cigar Lighter............111 DSP occupancy..........238 Cleaning the Exterior........204 Direction Indicators........52 Body paintwork preservation.......204...
Page 298 Index Engine Coolant Check........199 Fuse Box Locations........178 Checking the coolant level......199 Engine compartment fuse box......178 Topping up............199 Load compartment fuse box......178 Engine immobiliser........38 Passenger compartment fuse box....178 Fuses..............178 Principle of Operation........38 Engine Oil Check..........198 Fuse Specification Chart......180 Checking the oil level........199 Engine compartment fuse box.....180 Topping up............199 Load compartment fuse box......185...
Page 299 Index Hill Start Assist..........134 Instrument Lighting Dimmer......111 Interior Lamps..........53 Principle of Operation........134 Hints on Driving With Anti-Lock Ambient lighting...........53 Brakes.............132 Interior lighting............53 Introduction............7 iPod connection See: Hill Start Assist..........134 See: Using hill start assist.......134 See: Connecting an external device...266 See: Connecting an external device - Vehicles With: Bluetooth..........266 iPod Ignition Switch..........114...
Page 300 Index Manual Seats..........105 Adjusting the angle of the seatback...106 Adjusting the height of the driver’s Lane Departure Warning......156 seat..............106 Principle of Operation........156 Adjusting the lumbar support.......106 Lane Keeping Aid..........158 Moving the seats backwards and Principle of Operation........158 forwards............105 Lighting Control..........47 Manual Transmission........129 Headlamp flasher..........47 Selecting reverse gear........129...
Page 301 Look for the Ford logo on the following parts ...............8 See: Programming the remote control..29 Removing a Headlamp........54 Now you can be sure that your Ford parts Repairing Minor Paint Damage....205 are Ford parts............7 Personalised Settings........82 Repeat compact disc tracks....240 Chime deactivation..........83...
Page 302 Index Steering Wheel Lock........114 Vehicles with keyless starting......114 Vehicles without keyless starting....114 Safety Precautions........123 Steering Wheel..........41 Satellite Navigation Unit Holder....113 Sunroof Adjusting the holder..........113 See: Electric sunroof.........100 Seat belt height adjustment......26 Switching Off the Engine......119 Seat belt reminder.........26 Vehicles with a turbocharger......119 Deactivating the seat belt reminder....27 Symbols Glossary..........7 Rear seat belt reminder........27...
Page 303 Index Tow Ball............173 Tyre Pressures Driving with a trailer...........174 See: Technical Specifications......218 Tyre Repair Kit..........213 Driving without a trailer........175 Inserting the tow ball arm........174 Checking the tyre pressure......215 Maintenance............175 General information...........213 Removing the tow ball arm......175 Inflating the tyre..........214 Unlocking the tow ball arm Using the tyre repair kit........213 Tyres mechanism............173...
Page 304 Index Using Cruise Control........146 Using the speed limiter.......153 Cancelling the set speed.........146 Intentionally exceeding the set speed Changing the set speed........146 limit..............153 Resuming the set speed........147 Setting the speed limit........153 Setting a speed...........146 Switching the system on and off....153 Switching cruise control off......147 System warnings..........153 Using the telephone........246 Switching cruise control on......146...
Page 305 Index Warning Lamps and Indicators....71 ABS warning lamp..........71 Airbag warning lamp..........71 Blind spot monitor indicator......71 Brake system lamp..........71 Cruise control indicator........71 Direction indicators..........71 Engine warning lamp...........71 Forward alert warning indicator......72 Front fog lamp indicator........72 Frost warning lamp..........72 Glow plug indicator..........72 Headlamp indicator..........72 Ignition warning lamp.........72 Lane departure warning indicator....72...
Page 308 (CG3568en)

Ford Focus Owner's Manual

Introduction

At a Glance

Child Safety

Occupant Protection

Keys and Remote Controls

Locks

Engine Immobiliser

Alarm

Steering Wheel

Wipers and Washers

Lighting

Windows and Mirrors

Instrument Cluster

Information Displays

Climate Control

Seats

Convenience Features

Starting and Stopping the Engine

Start-Stop

Eco Mode

Fuel and Refuelling

Transmission Manual Transmission

Brakes

Stability Control

Hill Start Assist

Parking Aids

Rear View Camera

Active Park Assist

Cruise Control

Adaptive Cruise Control (ACC)

Speed Limiter

Driver Alert

Lane Departure Warning

Lane Keeping Aid

Traffic Sign Recognition

Active City Stop

Load Carrying

Towing

Driving Hints

Roadside Emergencies

Fuses

Vehicle Recovery

Maintenance

Vehicle Care

Vehicle Battery

Wheels and Tyres

Vehicle Identification

Capacities and Specifications

Audio Introduction

Audio Unit Overview

Audio System Security

Audio Unit Operation

Audio Unit Menus

Compact Disc Player

Auxiliary Input (AUX IN) Socket

Audio Troubleshooting

Telephone

Quick Links

Related Manuals for Ford Focus

Summary of Contents for Ford Focus
