- Page 1 Part No. 44836 Instructions of operation and installation mini-ovens CRAMER Model CMBO Variants: CMBOK, CMBOA, CMBOC, CMBOB CMBOD, CMBODS, CMBODSV CMBOGDS, CMBOGDSV GB, IE, IS Identification No. of product CE-1015BP0202...
- Page 2 Important warnings This device as an appliance of the 3 class is intended to be built into a kitchen block. Oven output (Hs) 1,1 kW (Mn = 80 g/h, propane/butane) Grill output (Hs) 1,6 kW (Mn = 115 g/h, propane/butane) (It is ensured and technically impossible that the two burners be turned on at the same time.) In case the gas tap may be hardly turned or if it gets jammed, it should be either replaced or the...
- Page 3 ATTENTION: ACCORDING TO APPLICABLE STANDARDS, THE DEVICE SHOULD BE INSTALLED BY AN EXPERT. IMPORTANT: TO AVOID ANY POSSIBLE ACCIDENT, IT IS NECESSARY TO INSTALL THE DEVICE ACCORDING TO THESE INSTRUCTIONS. LOSS OF WARRANTY IS A CONSEQUENCE OF INEXPERT INSTALLATION „ANY MODIFICATION TO THE APPLIANCE MAY BE DANGEROUS, AND IS THEREFORE NOT PERMITTED !“...
-
Page 4: Gas Cylinders
3. GAS CYLINDERS It is necessary to use such gas cylinders that are usually sold in the country of sale of the appliance. Kind of gas used is clearly indicated on the packaging and on an indelible type plate on the rear side of the oven. UNSUITABLE OPERATION CONDITIONS OF THE FACILITY MAY BE A CONSEQUENCE OF USING ANOTHER PRESSURE OR GAS THAN STATED IN THE INSTRUCTIONS. -
Page 5: Visual Inspection Of Flame
4. VISUAL INSPECTION OF FLAME a) The flame should burn quietly. It should be prevailingly blue, having clear outlines. b) When the flame is not burning cleanly, there should be checked, whether openings of air inlet (Venturi tube) are clear. If it is not the case, particles causing obstruction should be removed. - Page 6 7. INSTALLATION OF THE DEVICE 7.1 ATTACHMENT OF THE DEVICE TO FURNITURE In order to install the device, there should be created a space of dimensions shown in Figure 1 depending on the respective model of device (look at type plate of the device). Figure 1 Variant X (Width)
- Page 7 Minimum distance from inflammable surfaces on the right and left sides: 20 mm. Minimum distance from inflammable upper surfaces: 50 mm. Minimum distance of the waste gas exhaust case from inflammable surfaces: 50 mm. All walls or constituent parts that are at a smaller than minimum distance from the appliance should be either lined or protected with non-flammable materials.
- Page 8 Roof chimney Truma, art.No. 30700-03 Ventilation chimney tube Truma O55 atr. No. 39320-00 Exhaust box Figure 4 Installation of oven with exhaust of waste gases upward through a chimney across the wall. Chimney across the wall Truma, art.No. 34011-08 Ventilation chimney tube Truma O55 atr.
- Page 9 Exhaust box...
- Page 10 Figure 6 Installation of oven with gas exhaust pipe at the back through roof chimney. Roof chimney Truma, art.No. 30700-03 Ventilation chimney tube Truma O55 atr. No. 39320-00 Exhaust box Figure 7 Installation of oven with exhaust of waste gases at the back through a chimney across the wall. Chimney across the wall Truma, art.No.
-
Page 11: Protection From Overheating
Exhaust of waste gases through the chimney should be of continuously ascending placing. Maximum length of waste gas outlet is 2,000 mm. The maximum difference of height between the upper edge of the oven for baking and the outlet of waste gases is 1,500 mm. For ducting the exhaust gases over a side wall stack, the minimum elevation difference is 150 mm, and 200 mm for a Truma roof stack. - Page 12 done with the turn button at its "Grill" position (the button turned to the right after pressing). c) Release the button and turn it to the desired position. The oven is equipped with an automatic thermostat. Various settings of the revolving button correspond to temperatures within the range up to 250 In case of an excessive deviation of temperature of the oven, the thermostat should be repaired.
-
Page 13: Instructions For Cleaning
INSTRUCTIONS FOR CLEANING Exclusively non-aggressive cleaning agents for households may be used for cleaning. In no case, agents for scrubbing and bleaching may be used. - Page 14 DOMETIC CRAMER SR s. r. o. Tehelná 8 SK – 986 01 Fiľakovo Phone: +421-47 4319100 ● ● ● ● Fax: +421-47 4319144, 4319166 ● ● E-mail: cramer@cramer.sk ● ● Internet: www.cramer.sk www.dometic.com ● ● ●...
