Samsung GT-C3590 User Manual

GT-C3590

user manual

• Some content may differ from your device depending on the region
or service provider.
• Third party services may be terminated or interrupted at any time,
and Samsung makes no representation or warranty that any
content or service will remain available for any period of time.
• This product includes certain free/open source software. The exact
terms of the licences, disclaimers, acknowledgements and notices
are available on the Samsung's website opensource.samsung.com.
• Content (high quality content) that requires high CPU and RAM
usage will affect the overall performance of the device. Applications
related to the content may not work properly depending on the
device's specifications and the environment that it is used in.
www.samsung.com
Printed in Korea
GH68-39513A
English (EU). 06/2013. Rev. 1.0
Charging the battery
To electric socket
1. Plug the small end of the charger into the
multipurpose jack of the device, and plug the large
end of the charger into an electric socket.
2. After fully charging, disconnect the device from the
charger. First unplug the charger from the device,
and then unplug it from the electric socket.
• Use only Samsung-approved chargers,
batteries, and cables. Unapproved chargers
or cables can cause the battery to explode or
damage the device.
• Do not remove the battery before removing
the charger. This may damage the device.
To save energy, unplug the charger when not
in use. The charger does not have a power
switch, so you must unplug the charger from the
electric socket when not in use to avoid wasting
power. The device should remain close to the
electric socket while charging.
ABC mode
Press an appropriate alphanumeric button until the
character appears on the display.
Number mode
Press an appropriate alphanumeric button to enter a
number.
Symbol mode
Press an appropriate alphanumeric button to enter a
symbol.
Other features for text input
Press the
Navigation Move the cursor.
button
Press <Clear> Delete characters one by one.
Press and hold
Delete characters quickly.
<Clear>
Press [0] Insert a space.
Press [1] Enter punctuation marks.
Browsing the web
<Menu> → Internet
When users access Internet for the first time,
users might be prompted to create an Internet
profile.
Navigating webpages
Buttons Function
Navigation
Scroll up or down on a web page.
button
Confirm button Select an item.
<Back> Return to the previous page.
<Options> Open browser options.
Bookmarking webpages
1. Press < Options> → Bookmarks → Options →
<Add bookmark>.
2. Enter details and press the Confirm button.
Device layout
5
1
2 6
7
3
8
4
Inserting a memory card (optional)
The device accepts memory cards with maximum
capacities of 32 GB. Depending on the memory card
manufacturer and type, some memory cards may not be
compatible with the device.
Memory card
Insert the memory card as shown in the drawing.
• Formatting the memory card on a computer
might cause incompatibility with your device.
Format the memory card only on the device.
• Frequent writing and erasing of data will
shorten the lifespan of memory cards.
• Do not use sharp tools to remove the memory
card from the device.
Making or answering a call
• To make a call, enter a phone number and press [ ].
• To end a call, press [ ].
• To call a recently dialled number, press [ ] to select
a number, and press [ ] again to dial the number.
• To make a call using the phonebook, press < Menu> →
Contacts, select a contact and press [ ].
• To answer an incoming call, press [ ].
Sending and viewing messages
<Menu> → Messages
Sending messages
1. Press Create message.
2. Press Add to open the phonebook.
3. Select a contact and press Add.
Or, enter a contact number.
4. Scroll down and enter a text message.
See "Entering text".
5. To attach files with the message, press < Options>
→ Add media and select files.
6. Press Send.
Viewing messages
Press Inbox and select a message to read.
Using the alarm
<Menu> → Alarms
Setting alarms
1. Press < Create>.
2. Enter details and press < Save>.
Stopping alarms
When an alarm rings,
• Press < Confirm> to stop the alarm.
• Press < Snooze> to silence the alarm for the snooze
period.
Deactivating alarms
Select an item and press <Options> → Deactivate
alarm.
1 6
Navigation button Power button
In the Menu screen, scroll Turn the device on or off
through menu options (press and hold); End a call;
In the Menu screen, cancel
2
an input and return to the
Dial button
Home screen
Make or answer a call; From
7
the Home screen, retrieve
recently dialled, missed, or Confirm button
received numbers From the Home screen,
access the Menu screen; In
3
the Menu screen, select the
Voicemail button highlighted menu option, or
From the Home screen, confirm an input
access voicemails (press
The key might perform
and hold)
differently, depending on
the region
4
8
Alphanumeric buttons
Silent mode button
5
From the Home screen,
Softkeys
activate or deactivate the
Perform actions indicated at
silent mode (press and hold)
the bottom of the display
Turning the device on or off
Turning the device on
Press and hold [ ], and then enter the PIN and press
<OK>, if necessary.
Turning the device off
Press and hold [ ].
If the battery is fully discharged or removed from
the device, the time and date will be reset.
Managing contacts
Save data, such as names, phone numbers and
personal information in the device memory, SIM card, or
the memory card.
<Menu> → Contacts
Users can change the memory location by
pressing <Menu> → Contacts → <Options> →
Settings → Save new contact to and selecting
a memory location.
Adding new contacts
Create → a memory location (if necessary).
1. Press
2. Enter contact information and press the Confirm
button.
Editing contacts
1. Select a contact and press the Confirm button.
2. Edit items and press the Confirm button to save.
Deleting contacts
Select a contact and press <Options> → Delete.
Managing calendar
<Menu> → Calendar
Creating events
1. Press < Options> → Create and select an event
type.
2. Enter details of the event and press < Save>.
Viewing events
Select a date and press the Confirm button. To change
the calendar view, press <Options> → Week view or
Month view.
The device displays the following status indicators at the
top of the screen:
Icon Description Icon Description
Normal profile
No SIM card
activated
No signal
Silent profile
Signal strength
activated
Network searching
Bluetooth feature
GPRS network
activated
connected
Browsing the web
EDGE network
Connected to
connected
computer
Battery power level
Alarm activated
Call in progress
Music playback in
Call diverting
progress
activated
Music playback
New text message
paused
(SMS)
FM radio on
New multimedia
Roaming (outside of
message (MMS)
normal service area)
New voicemail
Memory card
message
inserted
New push message
Current time
10:00
Accessing menus
To access the device's menus or options,
Navigation
Scroll to each menu.
button
Confirm button Launch a menu or an application.
<Menu> Open the Menu screen.
<Back> Return to the previous screen.
Close the menu or application and
[ ]
return to the Home screen.
• When you access a menu requiring the PIN2,
you must enter the PIN2 supplied by the SIM
card. For details, contact your service provider.
• Samsung is not responsible for any loss of
passwords or private information or other
damage caused by illegal software.
Using the camera
<Menu> → Camera
Taking photos
1. Rotate the device anti-clockwise to landscape view.
2. Aim the lens at the subject and make any
adjustments by pressing <Options>.
3. Press the Confirm button to take a photo. Photos
are saved automatically.
Recording videos
1. Press < Options> → Camcorder.
Or, press [1] to change from Camera to Camcorder.
2. Rotate the device anti-clockwise to landscape view.
3. Aim the lens at the subject and make any
adjustments by pressing <Options>.
4. Press the Confirm button to start recording.
5. Press < Stop> to end recording. Videos are saved
automatically.
Viewing photos and videos
From the Home screen, press <Menu> → My Files →
Images or Videos and select an item to view.
Listening to the FM radio
<Menu> → FM Radio
Activating the FM radio
1. Plug a headset into the device.
2. Press the Confirm button to turn on the FM radio.
3. Press < Yes> to start automatic tuning.
Users may be asked to start automatic tuning when
accessing the FM radio for the first time.
4. Control the FM radio using the following buttons:
Buttons Function
Confirm button Turn the FM radio on or off.
• Left/Right: Fine-tune the
frequency; Search for the next
Navigation
available station (press and
button
hold).
• Up/Down: Adjust the volume.
Adding radio stations to the favourites list
1. Plug a headset into the device.
2. Press < Options> → Add to → Favourites.
3. Assign a button and press < Select>.
Installing the SIM card and battery
1. Remove the back cover and insert the SIM card.
SIM card
Back cover
• Do not bend or twist the back cover
excessively. Doing so may damage the cover.
• Do not remove the back cover with the folder
open. Doing so may damage the cover.
• Do not remove the back cover with the
headset attached. Doing so may damage the
headset jack.
2. Insert the battery and replace the back cover.
Battery
Entering text
Changing the text input mode
Change to uppercase, lowercase, or
Press [ ]
switch to number mode.
Switch between T9 and ABC mode.
Press and Depending on the region, users might
hold [ ] be able to use an input mode for specific
language.
Press [ ] Switch to symbol mode.
Press and Select an input mode or change the
hold [ ] input language.
T9 mode
1. Press the appropriate alphanumeric buttons to enter
an entire word.
2. When the word displays correctly, press [ 0] to insert
a space. If the word does not display, press the
Navigation button up or down to select an alternate
word.
Listening to music
<Menu> → Music
Buttons Function
Confirm button Play, pause, or resume music.
• Left: Skip backwards (press);
Scan backwards in a file (press
and hold).
Navigation
button • Right: Skip forwards (press); Scan
forwards in a file (press and hold).
• Up/Down: Adjust the volume.
1 Rate the current track.
2 Change the sound effect.
3 Change the repeat mode.
4 Turn shuffle mode on or off.
Using the Bluetooth feature
<Menu> → Bluetooth
Turning on the Bluetooth feature
1. Press < Options> → Settings and set Bluetooth
to On.
2. Set My phone's visibility to allow other devices to
search for the device.
Finding and pairing with other Bluetooth devices
1. Press the Confirm button to find other Bluetooth
devices.
2. Select a device and press the Confirm button.
3. Press < Yes> to match the PIN between the
devices.
4. When the other device accepts the connection,
pairing is complete.
Users might have to enter a PIN, depending on
the device.
Turning off the Bluetooth feature
Select <Options> → Settings and set Bluetooth to
Off.
Sending data using the Bluetooth feature
1. Select items to send from one of the device's
applications.
2. Press < Options> → Send via → Bluetooth.
