Installing / Removing the Base Stand
• The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure
that no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO
NOT exert pressure on the front of the TV at any time because the screen could crack.
• It is recommended that two people take part in the base installation.
1. Disconnect all cables connected to the TV.
2. Lay the TV down on a flat surface with the back side facing up, and ideally at the edge of a table so that the base of the TV
slightly overhangs on it. Please make sure a soft cushioned material (such as a pillow or thick piece of foam) is placed beneath
the screen.
Installing the Base Stand
3. To install the TV stand, first attach the stand supports to
the TV base by using 4 screws. Align with the screw holes
then use screws to fix the stand support to the TV base.
4. To install the stand assembly, align the screw holes, then
secure with a screw driver (not included) using the 4
screws provided.
Mounting the TV to a Wall
Remove the stand assembly before mounting the TV onto the wall.
1. To remove the stand assembly, untighten the screws
holding the stand assembly to the rear of the TV. Remove
the stand assembly out.
Keep all the spare screws should you want to use
the stand assembly option.
2. Mounting on the wall. This TV is designed to be wall-mounted
with a standard 200 mm x 100 mm mounting kit (sold
separately) designed for flat-panel TVs. Mount this TV according
to the instructions included in the mounting kit. Due to space
restrictions, we recommend that you make all connections (refer
to page 15-18 and page 45 for details) before mounting on to the
wall.
Please read this instruction manual carefully while setting up your TV.
stand
support
stand
base
screw in
unscrew
200 mm
Four mounting holes
(size M6x9 screw)
Preparation
2
9
