G3000
115 39 96-38 (010)
G
G
B
B
OWNER'S MANUAL
CHAIN SAWS
G3000
GB-1

Advertisement

Table of Contents
loading

Related Manuals for Zenoah G3000

Summary of Contents for Zenoah G3000

  • Page 1 G3000 115 39 96-38 (010) OWNER’S MANUAL CHAIN SAWS G3000 GB-1...

  • Page 2: Table Of Contents

    G3000 EXPLANATION OF SYMBOLS AND SAFETY WARNINGS Read operator's instruction Wear head, eye and ear book before operating this protection. machine. Use the chain saw Warning! Danger of with two hands. kickback. Use appropriate protections Read, understand and for foot-leg and hand-arm.

  • Page 3: For Safe Operation

    G3000 1. For safe operation WARNING This chainsaw has been especially designed for tree maintenance and should therefore only be used by trained operators when working on trees. 1. Never operate a chain saw when you are fatigued, ill, or upset, or under the 10.
  • Page 4 G3000 20. Operate the chain saw only in well front handle, when the engine is run- ventilated areas. Never start or run ning. Use a firm grip with thumbs the engine inside a closed room or and fingers encircling the chain saw building.
  • Page 5 G3000 WORKING WITH TREE SERVICE CHAIN-SAWS The saw should only be attached to the recommended FROM A ROPE AND HARNESS attachment points on the harness. These may be at This chapter sets out working practices to reduce the mid-point (front or rear) or at the sides. Where possible...
  • Page 6 G3000 One-hand use of the chainsaw Operators should not use tree service chainsaws one- handed in place of unstable work positioning or in preference to a handsaw when cutting small diameter wood at the branch tips. Tree service chainsaws should only be used one- handed where: • the operator cannot gain a work position enabling...

  • Page 7: Explanation Of Symbols On The Machine

    G3000 2. Explanation of Symbols on the Machine For safe operation and maintenance, symbols are carved in relief on the machine. WARNING According to these indications, please be careful not to make any mistake. The port to refuel “MIX GASOLINE”...

  • Page 8: Installing Guide Bar And Saw Chain

    G3000 3. Installing Guide Bar and Saw Chain A standard saw unit package contains the items as illustrated. Plug wrench Bar protector (Hexagon socket (S13/S19) + Power unit Slotted driver) Guide bar Saw chain Open the box and install the guide bar and the saw WARNING chain to the power unit as follows.

  • Page 9: Fuel And Chain Oil

    2. Put fuel into the fuel tank to 80% of the full capacity. 3. Fasten the fuel cap securely and wipe up any fuel spillage around the unit. • The Zenoah engines are lubricated by oil specially WARNING formulated for air-cooled 2-cycle gasoline engine use.

  • Page 10: Operating The Engine

    G3000 5. Operating the Engine 5. Pull out the choke knob to the closed position. WARNING It is very dangerous to run a chainsaw that mounts broken parts or lacks any parts. Before starting engine, make sure that all the parts in- cluding bar and chain are installed properly.
  • Page 11 G3000 ■ ADJUSTING CARBURETOR NOTE H needle L needle The oil tank should become nearly empty by the time fuel in the tank is used up. Be sure to refill the oil tank every time when refueling the saw. ■ STOPPING ENGINE 1.

  • Page 12: Sawing

    G3000 6. Sawing ■ FELLING A TREE • Before proceeding to your job, read the section “For Safe Felling direction Operation”. It is recommended to first practice sawing easy logs. This also helps you get accustomed to your unit. Notch cut Felling cut • Always follow the safety regula- 1.
  • Page 13 G3000 Cutting the limbs of Fallen Tree Pruning of Standing Tree First check to which side the limb is bent. Then make the initial cut from the bent side and finish by sawing from the opposite side. Cut up from the bottom, finish down from the top.

  • Page 14: Maintenance

    G3000 7. Maintenance OIL STRAINER WARNING Drain the oil tank and remove the oil strainer located Before cleaning, the inspecting or repairing the unit, near the spark plug. Check the condition and clean if make sure that engine has stopped and is cool. Discon- necessary.

  • Page 15: Maintenance Of Saw Chain And Guide Bar

    G3000 8. Maintenance of Saw Chain and Guide Bar ■ Saw Chain WARNING Be sure to round off the front edge to reduce the chance WARNING of kickback or tie-strap breakage. It is very important for smooth and safe operation to always keep the cutters sharp.

  • Page 16: Troubleshooting Guide

    G3000 9. Troubleshooting Guide Case 1. Starting failure Case 3. Oil does not come out Check oil for sub- WARNING Replace. standard quality. Make sure the icing prevention system is not working. Check fuel for water Check oil passage Replace with proper or substandard mix- Clean.

  • Page 17: Specifications

    G3000 11. Specifications Power unit: Displacement (cm ): ............................28.5 Fuel: ......................Mixture (Gasoline 50 : Two-cycle oil 1) (when using ZENOAH genuine oil) Fuel tank capacity (cm ): ...........................220 Chain oil: ..........................Motor oil SAE# 10W-30 Oil tank capacity (cm ): .............................130 Carburetor: ............................ Diaphragm type lgnition system:: ............................Solid State...

  • Page 18: Limited Warranty

    WHICH HAVE BEEN DAMAGED BY NEGLIGENCE OF THE PURCHASER SHALL BEAR COSTS OF TRANS- INSTRUCTION LISTED IN THE OWNER/OPERATOR PORTING THE UNIT TO AND FROM THE ZENOAH MANUAL FOR PROPER USE AND MAINTENANCE OF DEALER. THE UNITS ACCIDENT MISHANDLING, ALTERATION,...
