1. Manuals
  2. Brands
  3. Craftsman Manuals
  4. Lawn Mower
  5. 917.4791B
  6. Owner's manual

Craftsman 917.4791B Owner's Manual

Craftsman 917.4791b rotary lawn mower, 149cc kohler engine, 21" multi-cut
Hide thumbs Also See for 917.4791B:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual See also: Owner's Manual
Enlarged version
Get it fixed, at your home or ours!
For repair – in your home – of all major brand appliances,
lawn and garden equipment, or heating and cooling systems,
no matter who made it, no matter who sold it!
For the replacement parts, accessories and
owner's manuals that you need to do-it-yourself.
For Sears professional installation of home appliances
and items like garage door openers and water heaters.
1-800-4-MY-HOME
(1-800-469-4663)
www.sears.com
For repair of carry-in products like vacuums, lawn equipment,
and electronics, call or go on-line for the nearest
Sears Parts and Repair Center.
1-800-488-1222
To purchase a protection agreement (U.S.A.)
or maintenance agreement (Canada) on a product serviced by Sears:
1-800-827-6655
(U.S.A.)
Para pedir servicio de reparación
a domicilio, y para ordenar piezas:
®
1-888-SU-HOGAR
(1-888-784-6427)
© Sears Brands, LLC
TM
® Registered Trademark /
Trademark /
TM
® Marca Registrada /
Marca de Fábrica /
MC
Marque de commerce /
MD
Marque déposée de Sears Brands, LLC
441990 Rev. 1 02.14.11 BY
Your Home
®
Anytime, day or night
(U.S.A. and Canada)
www.sears.ca
Our Home
Anytime, day or night (U.S.A. only)
www.sears.com
1-800-361-6665
(Canada)
Au Canada pour service en français:
1-800-LE-FOYER
MC
(1-800-533-6937)
www.sears.ca
SM
Service Mark of Sears Brands, LLC
SM
Marca de Servicio de Sears Brands, LLC
Printed in U.S.A.
Owner's Manual
ROTARY LAWN MOWER
149cc Kohler Engine
21" Multi-Cut
Model No.
917.4791B
• Español, p. 19
CAUTION:
Read and follow all
Safety Rules and In struc tions
before operating this equipment
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
Visit our Craftsman website: www.sears.com/craftsman

Advertisement

Chapters

Table of Contents
loading

Related Manuals for Craftsman 917.4791B

Summary of Contents for Craftsman 917.4791B

  • Page 1 Marca de Fábrica / Marca de Servicio de Sears Brands, LLC Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. Marque de commerce / Marque déposée de Sears Brands, LLC Visit our Craftsman website: www.sears.com/craftsman 441990 Rev. 1 02.14.11 BY Printed in U.S.A.

  • Page 2: Table Of Contents

    If this Craftsman Lawn Mower fails due to manufacturer defects in material or workmanship within two years from the date of purchase, return it to any Sears store, Parts & Repair Center or other Craftsman outlet for free repair (or replacement if repair proves impossible).
  • Page 3 I. GENERAL OPERATION • Always wear safety goggles or safe ty SERVICE NOTES glasses with side shields when op er at ing • Read, understand, and follow all mower. in struc tions on the machine and in the manual(s) before starting. Be thor ough ly II.

  • Page 4: Product Specifications

    KOHLER 4-CYCLE ENGINE MODEL NUMBER XT149-3311-ED • Never fi ll containers inside a vehicle, on • Keep nuts and bolts, especially blade a truck or trailer bed with a plastic liner. attachment bolts, tight and keep equip- Always place containers on the ground ment in good condition.
  • Page 5 Repair Protection Agreements Congratulations on making a smart pur- • Fast help by phone – phone sup- chase. Your new Craftsman® product is port from a Sears representative on designed and manufactured for years of products requiring in-home repair, plus dependable operation.

  • Page 6: Assembly / Pre-Operation

    KOHLER 4-CYCLE ENGINE MODEL NUMBER XT149-3311-ED ASSEMBLY / PRE-OPERATION Read these instructions and this manual in Operator MOWING its entirety before you attempt to assemble presence POSITION control bar or operate your new lawn mower. OIL PAN/LUBRICATION BLOWER HOUSING & BAFFLES IMPORTANT: This lawn mower is shipped LIFT WITHOUT OIL OR GASOLINE in the engine.

  • Page 7: Operation

    KOHLER 4-CYCLE ENGINE MODEL NUMBER XT149-3311-ED OPERATION KNOW YOUR LAWN MOWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OP ER AT ING YOUR LAWN MOWER. Compare the illustrations with your lawn mower to familiarize yourself with the location of various controls and adjustments. Save this manual for BLOWER OIL PAN / LUBRICATION future reference.
  • Page 8 KOHLER 4-CYCLE ENGINE MODEL NUMBER XT149-3311-ED • To convert to mulching or dis charg ing The operation of any lawn operation, remove grass catch er and mower can result in foreign close rear door. objects thrown into the eyes, which can result in severe Pivot pins Rear Grass...
  • Page 9 KOHLER 4-CYCLE ENGINE MODEL NUMBER XT149-3311-ED IMPORTANT: • Check oil level before each use. Add oil if needed. Fill to full line on dipstick. • Change the oil after every 25 hours of operation or each season. You may need to change the oil more often ENGINE CONTROLS CRANKSHAFT under dusty, dirty conditions.
  • Page 10 TO STOP ENGINE MULCHING MOWING TIPS • To stop engine, release operator pres- IMPORTANT: For best performance, ence con trol bar. keep mower housing free of built-up grass and trash. See “CLEANING” in the Maintenance section of this manual. TO START ENGINE •...

  • Page 11: Maintenance Sched Ule

    REPAIR PARTS MAINTENANCE BEFORE AFTER EVERY EVERY EVERY BEFORE EACH EACH 25 HOURS STORAGE HOURS OR SEASON HOURS Check for Loose Fasteners Clean / Inspect Grass Catcher * Check Tires Check Drive Wheels *** Clean Lawn Mower **** Clean under Drive Cover *** Check Drive Belt / Pulleys *** Check / Sharpen / Replace Blade Lubrication...
  • Page 12 SOLUCIÓN DE PROBLEMAS - Vea la sección apropiada en el manual amenos que LAWN MOWER IMPORTANT: Blade bolt is heat treated. If bolt needs replacing, replace only with esté dirigido a un centro de servico Sears. Always observe safety rules when per- approved bolt shown in the Repair Parts form ing any main te nance.
  • Page 13 ACEITE DEL MOTOR 1. Disconnect spark plug wire from spark CAUTION: Petroleum solvents, such • Si es posible, guarde su unidad en un recinto plug and place wire where it cannot Drene el aceite (con el motor caliente) y cámbielo as ker o sene, are not to be used to clean cerrado y cúbrala para protegerla contra el con aceite de motor limpio.

  • Page 14: Service And Adjustments

    SERVICE AND ADJUSTMENTS ALMACENAMIENTO Inmediatamente prepare su segadora para el Barra de control POSICIÓN WARNING: To avoid serious injury, Mowing Mowing que exige la PARA almacenamiento al fi nal de cada temporada o si position position before performing any service and presencia del SEGAR la unidad no se va a usar por 30 días o más.

  • Page 15: Storage

    SERVICIO Y AJUSTES STORAGE ADVERTENCIA: Para evitar lesiónes serias, Immediately prepare your lawn mower for Operator MOWING Posición Posición antes de dar calquier servico o de hacer storage at the end of the season or if the presence POSITION para segar para segar ajustes: unit will not be used for 30 days or more.

  • Page 16: Trou Ble Shoot Ing

    ENGINE OIL • Replace your gasoline can if your can 1. Desconecte el alambre de la bujía y PRECAUCIÓN: Los solventes de petróleo, póngalo de modo que no pueda entrar en starts to rust. Rust and/or dirt in your Drain oil (with engine warm) and replace tales como el keroseno, no se deben usar para contacto con ésta.
  • Page 17 SEGADORA IMPORTANTE: El perno de la cuchilla es tratado TROUBLESHOOTING - See appropriate section in manual unless directed a calo. Si es necesario sustituir los pernos, Siempre observe las reglas de seguridad cu- to a Sears Parts & Repair Center. sustituirlos sólo con pernos aprobados mostrados ando haga el mantenimiento.

  • Page 18: Garantía

    Sears, al Centro de Repuestos y Reparación, o a otro comercio donde se vendan los equipos Craftsman, a efectos de que se la reparen sin costo (o bien se la reemplacen, Cambiar el Aceite del motor en caso que no sea posible repararla).
  • Page 19 PARA PARAR EL MOTOR CONSEJOS PARA SEGAR Y ACOL- I. OPERACION • Siempre use gafas de seguridad o anteojos con protección lateral cuando opere la sega- • Para parar el motor, suelte la barra de con- CHAR • Antes de empezar, debe familiarizarse dora.

  • Page 20: Especifi Caciones Del Producto

    PASOS SIMPLES DE RECORDAR • Nunca repostar la máquina al interior de un • Mantenga las tuercas y los pernos, espe- AVISO: El terraplén inicial del aceite requiere local. cialmente los pernos del accesorio de la solamente 18 onzas debido al aceite residual CUANDO CONVIERTA SU SEGADORA •...
  • Page 21 Congratulaciones por su buena compra. Su • Ayuda rápida por teléfono – soporte tele- puerta trasera. salten objetos extraños dentro de nuevo producto Craftsman® está diseñado fónico por parte de un representento Sears sus ojos, lo que puede producir Pasador del quincio...

  • Page 22: Montaje / Pre-Operación

    MONTAJE / PRE-OPERACIÓN OPERACIÓN FAMILIARICESE CON SU SEGADORA Lea estas instrucciones y este manual comple- Barra de control POSICIÓN LEA ESTE MANUAL DEL DUENO Y LAS REGLAS DE SEGURIDAD ANTES DE OPARAR SU tamente antes de tratar de montar u operar su que sxige la PARA SEGADORA.

Table of Contents
