HIGH WALL DUCT-FREE • FLEX MULTI SPLIT • DUAL & TRI ZONE
ELECTRICAL & REFRIGERATION
Zone
Type
Flex Multi Split
A/C
Indoor Units
A/C
A/C
A/C
A/C
H/P
H/P
H/P
H/P
H/P
Outdoor Units
A/C
A/C
H/P
H/P
All equipment single phase.
NOTE: Please see local electrical codes for proper wire specifications.
Type
Model
LMN090CE
A/C
Flex Multi Split
LMAN090CNS
A/C
LMN120CE
A/C
LMAN120CNS
A/C
LMAN121CNM
A/C
LMN090HE
H/P
LMAN090HNS
H/P
LMN120HE
H/P
LMAN120HNS
H/P
LMAN121HNM
H/P
***Dual Zone: exterior unit has sufficient refrigerant for charging two indoor coils and a 25 ft. line set per indoor unit.
Tri Zone: exterior unit has sufficient refrigerant for charging three indoor coils and a 25 ft. line set per indoor unit.
NOTE: Systems having the outdoor unit mounted above the indoor unit (e.g. basement installations) have the
following additional requirement:
For systems with maximum elevation of 25 ft. (see chart above and Figure A), refrigerant lines must be oil
trapped between 8 ft. and 16.4 ft. of elevation.
For systems with elevation of greater than 25 ft. (see chart above), refrigerant lines must be oil trapped at least
every 16.4 ft. of elevation.
23
•
QUICK REFERENCE
Electrical Specifications
Model
BTUs
LMN090CE
9,000
LMAN090CNS
9,000
LMN120CE
12,000
LMAN120CNS
12,000
LMAN121CNM
12,000
LMN090HE
9,000
LMAN090HNS
9,000
LMN120HE
12,000
LMAN120HNS
12,000
LMAN121HNM
12,000
LMU240CE
24,000
LMU360CE
36,000
LMU240HE
24,000
LMU360HE
36,000
Refrigerant Line & Formula Specifications***
Pipe size
Liquid
BTUs
1/4"
9,000
9,000
1/4"
1/4"
12,000
1/4"
12,000
1/4"
12,000
1/4"
9,000
9,000
1/4"
1/4"
12,000
1/4"
12,000
1/4"
12,000
Voltage
Rated
Indoor
Outdoor
Amps
36V DC
—
0.5
36V DC
—
1.3
36V DC
—
0.5
36V DC
—
1.3
36V DC
—
0.5
36V DC
—
0.5
36V DC
—
1.3
36V DC
—
0.5
36V DC
—
1.3
36V DC
—
0.5
230/208
11.1
230/208
16.6
230/208
11.1
230/208
16.6
**Maximum Overcurrent Protection
Wire Size
Minimum AWG
Indoor/Outdoor Connecting Cable Minimum AWG
Additional
Max. length
Suction
Refrigerant
each pipe
3/8"
0.21 oz./ft.
50'
3/8"
0.21 oz./ft.
50'
3/8"
0.21 oz./ft.
50'
3/8"
0.21 oz./ft.
50'
3/8"
0.21 oz./ft.
50'
3/8 "
0.21 oz./ft.
50'
3/8"
0.21 oz./ft.
50'
3/8"
0.21 oz./ft.
50'
3/8"
0.21 oz./ft.
50'
3/8"
0.21 oz./ft.
50'
MCA*
MOP**
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
20
20
20
30
20
20
20
30
*Minimum Circuit Ampacity
14-3
18-4
Max.
elevation
25'
25'
25'
25'
25'
25'
25'
25'
25'
25'
OUTDOOR UNIT
OIL TRAP
INDOOR UNIT
25' maximum
8' minimum
16.4' maximum
Figure A.
Example: 25 ft. maximum elevation.
