- Page 1 LevelOne Broadband Routers FBR-1100TX FBR-1400TX FBR-1401TX FBR-1700TX User's Guide...
-
Page 3: Table Of Contents
CHAPTER 1 INTRODUCTION ... 1 Features of your LevelOne Broadband Router... 1 Package Contents ... 4 FBR-1100TX ... 4 FBR-1400TX ... 8 FBR-1401TX ...10 FBR-1700TX ...12 CHAPTER 2 INSTALLATION ...15 Requirements ...15 Installation Procedure - FBR-1100TX ...15 Installation Procedure - FBR-1400TX ...16 Installation Procedure - FBR-1401TX ...18... - Page 4 Routing ...78 APPENDIX A TROUBLESHOOTING...82 Overview...82 General Problems ...82 Internet Access ...82 Printing ...83 APPENDIX C SPECIFICATIONS ...86 FBR-1100TX ...86 FBR-1400TX ...87 FBR-1401TX ...88 FBR-1700TX ...89 P/N: 9560DT00A0 Copyright 2002. All Rights Reserved. Document Version: 1.0 All trademarks and trade names are the properties of their respective owners.
-
Page 5: Chapter 1 Introduction
Network Printer - LAN users can share the printer attached to the LevelOne Broadband Router (For LevelOne 1 Port Broadband Router with 4 LAN Port, Printer Server and Leve- lOne 1 Port Broadband Router with 7 LAN Port only) 10/100BaseT LAN... -
Page 6: Advanced Internet Functions
1401TX incorporate a 4-port 10/100BaseT switching hub, while the FBR-1700TX incorpo- rates a 7-port 10/100BaseT switching hub. • DHCP Server Support. address to PCs and other devices upon request. The LevelOne Broadband Router can act as a DHCP Server for devices on your local LAN. • Multi Segment LAN Support. -
Page 7: Security Features
LAN. And, if the Internet connection exists, it can also (optionally) be configured via the Internet. • UPnP Support. UPnP (Universal Plug and Play) allows automatic discovery and con- figuration of the LevelOne Broadband Router. UPnP is by supported by Windows ME, XP, or later. Security Features • Password - protected Configuration prevent unauthorized users from modifying the configuration data and settings. -
Page 8: Package Contents
LevelOne Broadband Router User Guide Package Contents The following items should be included: • The LevelOne Broadband Router Unit • Power Adapter • Quick Installation Guide • CD-ROM containing the on-line manual and Print Port Driver for Windows The Print Port Driver for Windows is provided only for the FBR-1401TX and the FBR-1700TX. - Page 9 Components - FBR-1100TX Figure 2: Components - FBR-1100TX LED Link Indicator (WAN Port) WAN port (10BaseT) LAN port (Auto-sensing 10/100BaseT) LED Link Indicator (LAN Port) Reset Button On - WAN connection (to broadband modem) is established. Off - No WAN connection (to broadband modem) Flashing - Data is being transmitted or received via the WAN port.
-
Page 10: Dip Switches
• • • The LevelOne Broadband Router will now reset, and the Red Status LED flash. The follow- ing changes will have been made. (Other configuration data is unchanged.) • IP Address set to its default value of 192.168.0.1 •... - Page 11 Introduction You can now connect to the LevelOne Broadband Router and make any configuration changes required...
-
Page 12: Fbr-1400Tx
Figure 3: Rear Panel - FBR-1400TX Reset Button This button has three (3) functions: • Reboot. When pressed and released, the LevelOne Broadband Router will reboot (restart). • Diagnostic print-out. If held down for 3 seconds, a diagnostic print-out will be sent to the attached printer. - Page 13 LAN connections these ports. Note: Any LAN port on the LevelOne Broadband Router will automatically function as an "Uplink" port when required. Just connect any port to a normal port on the other hub, using a standard LAN cable. Power port (12V) Connect the supplied power adapter here.
-
Page 14: Fbr-1401Tx
LevelOne Broadband Router User Guide FBR-1401TX LEDs - FBR-1401TX Power On - Power on. Off - No power. Status (Red) On - Error condition. Off - Normal operation. Blinking - This LED blinks during start up. LAN: On - LAN connection is using 10BaseT. - Page 15 LAN connections these ports. Note: Any LAN port on the LevelOne Broadband Router will automatically function as an "Uplink" port when required. Just connect any port to a normal port on the other hub, using a standard LAN cable. Power port (12V) Connect the supplied power adapter here.
-
Page 16: Fbr-1700Tx
LevelOne Broadband Router User Guide FBR-1700TX LEDs - FBR-1700TX Power ON - power on OFF - no power Status (Red) ON indicates an error condition. Blinking - during start up, this LED will blink. WAN: Link ON - WAN connection is established. - Page 17 Components - FBR-1700TX Figure 5: Rear Panel - FBR-1700TX Power port (9V) Connect the supplied power adapter here. Uplink Port Use the "Uplink" port ONLY to connect to a normal port on another hub. If the "Uplink" port is used, port 7 can not be used. 10/100BaseT Use standard LAN cables (RJ45 connectors) to connect this port LAN connectors...
- Page 18 • • • The LevelOne Broadband Router will now reset, and the Red Status LED flash. The follow- ing changes will have been made. (Other configuration data is unchanged.) • IP Address set to its default value of 192.168.0.1 •...
-
Page 19: Chapter 2 Installation
Installation Procedure - FBR-1100TX 1. Choose an Installation Site Select a suitable place on the network to install the LevelOne Broadband Router. Ensure the LevelOne Broadband Router and the DSL/Cable modem are powered OFF. 2. Connect LAN Cables Connect a standard LAN cable from a 10BaseT or 100BaseT Hub on your LAN to the "LAN"... -
Page 20: Installation Procedure - Fbr-1400Tx
LevelOne Broadband Router User Guide 3. Connect WAN Cable Connect the DSL or Cable modem to the WAN port on the LevelOne Broadband Router. Use the cable supplied with your DSL/Cable modem. If no cable was supplied, use a stan- dard cable. -
Page 21: Check The Leds
3. Connect WAN Cable If you have a DSL modem or Cable modem, connect it to the WAN port on the LevelOne Broadband Router. Use the cable supplied with your modem. If no cable was supplied, use a standard LAN cable. -
Page 22: Installation Procedure - Fbr-1401Tx
3. Connect WAN Cable If you have a DSL modem or Cable modem, connect it to the WAN port on the LevelOne Broadband Router. Use the cable supplied with your modem. If no cable was supplied, use a standard LAN cable. -
Page 23: Installation Procedure - Fbr-1700Tx
Ensure the LevelOne Broadband Router and the DSL/Cable modem are powered OFF. 2. Connect LAN Cables • Use standard LAN cables to connect PCs to the Switching Hub ports on the LevelOne Broadband Router. Both 10BaseT and 100BaseT connections can be used simultaneously. •... - Page 24 LevelOne Broadband Router User Guide 3. Connect WAN Cable Connect the DSL or Cable modem to the WAN port on the LevelOne Broadband Router. Use the cable supplied with your DSL/Cable modem. If no cable was supplied, use a stan- dard cable.
-
Page 25: Chapter 3 Setup
PCs on your local LAN may also require configuration. For details, see Chapter 4 - PC Con- figuration. Other configuration may also be required, depending on which features and functions of the LevelOne Broadband Router you wish to use. Use the table below to locate detailed instruc- tions for the required functions. To Do this: Configure PCs on your LAN. -
Page 26: Configuration Program
Network Places (previously called Network Neighborhood). • Double - click the icon for the LevelOne Broadband Router (either on the Desktop, or in My Network Places) to start the configuration. Refer to the following section Setup Wizard for details of the initial configuration process. - Page 27 255.255.255.0. See Chapter 4 - PC Configuration for details on checking your PC's TCP/IP settings. • Ensure that your PC and the LevelOne Broadband Router are on the same network segment. (If you don't have a router, this must be the case.) Setup...
-
Page 28: Setup Wizard
LevelOne Broadband Router User Guide Setup Wizard The first time you connect to the LevelOne Broadband Router, the Setup Wizard will run auto- matically. (The Setup Wizard will also run if the LevelOne Broadband Router's default setting are restored.) Step through the Wizard until finished. -
Page 29: Home Screen
Other Modems (e.g. Broadband Wireless) Type Details Dynamic Your IP Address is allocated IP Address automatically, when your con- nect to you ISP. Static (Fixed) Your ISP allocates a permanent IP Address IP Address to you. Home Screen After finishing the Setup Wizard, you will see the Home screen. When you connect in future, you will see this screen when you connect. -
Page 30: Lan Screen
TCP/IP IP Address IP address for the LevelOne Broadband Router, as seen from the local LAN. Use the default value unless the address is already in use or your LAN is using a different IP address range. In the latter case, enter an unused IP Address from within the range used by your LAN. -
Page 31: What Dhcp Does
You can only use one (1) DHCP Server per LAN segment. If you wish to use another DHCP Server, rather than the LevelOne Broadband Router's, the following procedure is required. Disable the DHCP Server feature in the LevelOne Broadband Router. This setting is on the LAN screen. -
Page 32: Password Screen
LevelOne Broadband Router User Guide Password Screen The password screen allows you to assign a password to the LevelOne Broadband Router. Once you have assigned a password to the LevelOne Broadband Router (on the Password screen above) you will be prompted for the password when you connect, as shown below. (If no password has been set, this dialog will not appear.) -
Page 33: Chapter 4 Pc Configuration
Sharing the Printer connected to the LevelOne Broadband Router. The first step is to check the PC's TCP/IP settings. The LevelOne Broadband Router uses the TCP/IP network protocol for all functions, so it is essential that the TCP/IP protocol be installed and configured on each PC. -
Page 34: Using Dhcp
Windows setting. Using this is recommended. By default, the LevelOne Broadband Router will act as a DHCP Server. Restart your PC to ensure it obtains an IP Address from the LevelOne Broadband Router. Using "Specify an IP Address" If your PC is already configured, check with your network administrator before making the... - Page 35 • On the Gateway tab, enter the LevelOne Broadband Router's IP address in the New Gate- way field and click Add, as shown below. Your LAN administrator can advise you of the IP Address they assigned to the LevelOne Broadband Router.
-
Page 36: Checking Tcp/Ip Settings - Windows Nt
LevelOne Broadband Router User Guide Checking TCP/IP Settings - Windows NT4.0 Select Control Panel - Network, and, on the Protocols tab, select the TCP/IP protocol, as shown below. Figure 18: Windows NT4.0 - TCP/IP Click the Properties button to see a screen like the one below. - Page 37 Specify an IP Address If your PC is already configured, check with your network administrator before making the following changes. The Default Gateway must be set to the IP address of the LevelOne Broadband Router. To set this: • Click the Advanced button on the screen above.
- Page 38 LevelOne Broadband Router User Guide Figure 20 - Windows NT4.0 - Add Gateway The DNS should be set to the address provided by your ISP, as follows: • Click the DNS tab. • On the DNS screen, shown below, click the Add button (under DNS Service Search...
- Page 39 PC Configuration Figure 21: Windows NT4.0 - DNS...
-
Page 40: Checking Tcp/Ip Settings - Windows
LevelOne Broadband Router User Guide Checking TCP/IP Settings - Windows 2000: Select Control Panel - Network and Dial-up Connection. Right - click the Local Area Connection icon and select Properties. You should see a screen like the following: Figure 22: Network Configuration (Win 2000) Select the TCP/IP protocol for your network card. - Page 41 Windows setting. Using this is recommended. By default, the LevelOne Broadband Router will act as a DHCP Server. Restart your PC to ensure it obtains an IP Address from the LevelOne Broadband Router. Using a fixed IP Address ("Use the following IP Address") If your PC is already configured, check with your network administrator before making the following changes.
-
Page 42: Checking Tcp/Ip Settings - Windows Xp
LevelOne Broadband Router User Guide Checking TCP/IP Settings - Windows XP Select Control Panel - Network Connection. Right click the Local Area Connection and choose Properties. You should see a screen like the following: Figure 24: Network Configuration (Windows XP) Select the TCP/IP protocol for your network card. - Page 43 Windows setting. Using this is recommended. By default, the LevelOne Broadband Router will act as a DHCP Server. Restart your PC to ensure it obtains an IP Address from the LevelOne Broadband Router. Using a fixed IP Address ("Use the following IP Address") If your PC is already configured, check with your network administrator before making the following changes.
- Page 44 Setup is now completed. Accessing AOL To access AOL (America On Line) through the LevelOne Broadband Router, the AOL for Windows software must be configured to use TCP/IP network access, rather than a dial-up connection. The configuration process is as follows: •...
-
Page 45: Printer Setup For Windows
• Print Port Driver. After installing the Print Port Driver, Windows users can print directly to the LevelOne Broadband Router. Print jobs are spooled (queued) on each PC. The supplied Print Port Driver supports Windows 95/98, Windows ME, Windows NT4.0, Windows 2000 and Windows XP. -
Page 46: Port Options
Print jobs can be managed like any Windows printer. Open the Printers folder (Start - Settings - Printers) and double-click any printer to see the current print jobs. • If the printer attached to the LevelOne Broadband Router is changed, just run this program again, and select the correct printer. •... - Page 47 • The User Name will be printed on the banner page. Retry Sets how often Windows will poll the LevelOne Broadband Interval Router to establish a connection when the printer is busy. In- crease this value if you get too many warning messages.
- Page 48 To use LPD printing, Microsoft TCP/IP Printing must be installed and enabled. This can be checked using Start-Settings-Control Panel-Network - Services. To install LPD printing using the LevelOne Broadband Router, follow this procedure: Go to Start-Settings-Printer and invoke the Add Printer wizard.
-
Page 49: Windows 2000 Server Configuration
Windows 2000 Server Configuration The LPD/LPR Port is not enabled by default. To enable it, use this procedure: In Control Panel, select Add/Remove Programs, then Windows Components. Select Other Network File and Print Services, then click the Details button. Figure 28: Adding LPD/LPR Port (Win 2000) Enable Print Services for Unix, and click OK. -
Page 50: Client Pc Setup For Lpd/Lpr Printing
LevelOne Broadband Router User Guide Figure 29: Windows 2000: Select Port In the Dialog requesting Name or Address of server providing lpd, enter the IP address of the LevelOne Broadband Router. For Name of printer or print queue on that server, enter L1 Click OK, and then Next, and continue the Wizard. -
Page 51: Macintosh Clients
Macintosh Clients From your Macintosh, you can access the Internet via the LevelOne Broadband Router. The procedure is as follows. Open the TCP/IP Control Panel. Select Ethernet from the Connect via pop-up menu. Select Using DHCP Server from the Configure pop-up menu. The DHCP Client ID field can be left blank. -
Page 52: Linux Clients
LevelOne Broadband Router User Guide Linux Clients To access the Internet via the LevelOne Broadband Router, it is only necessary to set the LevelOne Broadband Router as the "Gateway". Ensure you are logged in as "root" before attempting any changes. -
Page 53: Other Unix Systems
Other Unix Systems Internet Access • Ensure the "Gateway" field for your network card is set to the IP Address of the LevelOne Broadband Router. • Ensure your DNS (Name Server) settings are correct. -
Page 54: Chapter 5 Operation And Status
This Chapter details the operation of the LevelOne Broadband Router and the status screens. Operation Once both the LevelOne Broadband Router and the PCs are configured, operation is auto- matic. However, there are some situations where additional Internet configuration may be required: •... - Page 55 Data - Status Screen The "Printer" section on this screen is only included on LevelOne Broadband Routers which include a printer port (FBR-1401TX and the FBR-1700TX). Internet Connection Method This indicates the current connection method, as set in the Setup Wizard.
- Page 56 LevelOne Broadband Router User Guide Printer Printer Status This shows the status of the p rinter. Click the "Refresh Screen" button to update this information. "Abort Current Print Click this button to terminate the current print job. This button Job" Button should be used if the current print job is not printing correctly.
-
Page 57: Connection Status - Pppoe
Connection Status - PPPoE If using PPPoE (PPP over Ethernet), a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 31: PPPoE Status Screen Data - PPPoE Status Screen Connection Physical Address The hardware address of this device, as seen by remote devices on the Internet. -
Page 58: Connection Log Messages
LevelOne Broadband Router User Guide Buttons Connect If not connected, establish a connection to your ISP. Disconnect If connected to your ISP, hang up the connection. Clear Log Delete all data currently in the Log. This will make it easier to read new messages. -
Page 59: Connection Status - Pptp
Connection Status - PPTP If using PPTP (Peer-to-Peer Tunneling Protocol), a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 32: PPTP Status Screen Data - PPTP Status Screen Connection Physical Address The hardware address of this device, as seen by remote devices on the Internet. - Page 60 LevelOne Broadband Router User Guide Disconnect If connected to your ISP, hang up the connection. Clear Log Delete all data currently in the Log. This will make it easier to read new messages. Refresh Update the data on screen.
-
Page 61: Connection Details - Fixed/Dynamic Ip Address
• If the ISP's DHCP Server has NOT allocated an IP Address for the "Release" LevelOne Broadband Router, this button will say "Renew". Click- ing the "Renew" button will attempt to re-establish the "Renew" connection and obtain an IP Address from the ISP's DHCP... - Page 62 LevelOne Broadband Router User Guide Server. • If an IP Address has been allocated to the LevelOne Broadband Router (by the ISP's DHCP Server), this button will say "Re- lease". Clicking the "Release" button will break the connection and release the IP Address.
-
Page 63: Chapter 6 Advanced Features
Chapter 6 Advanced Features This Chapter explains when and how to use the LevelOne Broadband Router's "Advanced" Features. Overview The following advanced features are provided. • Special Applications • • Virtual Servers • Dynamic DNS • Remote Management Advanced Internet Screen This screen allows configuration of all advanced features relating to Internet access. -
Page 64: Conferencing & Telephony
LevelOne Broadband Router User Guide Conferencing & Telephony Most applications are supported transparently by the LevelOne Broadband Router. But some- times it is not clear which PC should receive an incoming connection. This problem could arise with the following Conferencing & Telephony applications: •... -
Page 65: Special Applications
If you use Internet applications which use non-standard connections or port numbers, you may find that they do not function correctly because they are blocked by the LevelOne Broadband Router's firewall. In this case, you can define the application as a "Special Application". -
Page 66: Using A Special Application
LevelOne Broadband Router User Guide Data - Special Applications Screen Checkbox Use this to Enable or Disable this Special Application as required. Name Enter a descriptive name to identify this Special Application. • Type - Select the protocol (TCP or UDP) used when you receive data Incoming from the special application or service. -
Page 67: Dmz
This feature, if enabled, allows one (1) computer on your LAN to be exposed to all users on the Internet, allowing unrestricted 2-way communication between the "DMZ PC" and other Internet users or Servers. • This allows almost any application to be used on the "DMZ PC". •... - Page 68 LevelOne Broadband Router User Guide Data - URL Filter Screen Filter Strings Current Entries This lists any existing entries. If you have not entered any values, this list will be empty. Add Filter String To add an entry to the list, enter it here, and click the "Add" button.
-
Page 69: Virtual Servers
Virtual Servers This feature allows you to make Servers on your LAN accessible to Internet users. Normally, Internet users would not be able to access a server on your LAN because: • Your Server does not have a valid external IP Address. •... -
Page 70: Virtual Servers Screen
LevelOne Broadband Router User Guide Virtual Servers Screen The Virtual Servers screen is reached by the Virtual Servers link on the Advanced screen. An example screen is shown below. Figure 38: Virtual Servers Screen This screen lists a number of pre-defined Servers, and allows you to define your own Servers. -
Page 71: Defining Your Own Virtual Servers
External Port No. The port number used by Internet users when connecting to the Server. This is normally the same as the Internal Port Number. If it is different, this device will perform a "mapping" or "translation" function, allowing the server to use one port address, while clients use a different port address. -
Page 72: Dynamic Dns (Domain Name Server)
Domain name. Enter your data from www.dyndns.org in the LevelOne Broadband Router's DDNS screen. The LevelOne Broadband Router will then automatically ensure that your current IP Ad- dress is recorded at http://www.dyndns.org From the Internet, users will be able to connect to your Virtual Servers (or DMZ PC) using... -
Page 73: Dynamic Dns Screen
Dynamic DNS Screen Select Advanced on the main menu, then Dynamic DNS, to see a screen like the following: Data - Dynamic DNS Screen DDNS Service • DDNS Service You must sign up first to create a new account before using the service. -
Page 74: Remote Management
Ensure your Internet connection is established, and start your Web Browser. In the "Address" bar, enter "HTTP://" followed by the Internet IP Address of the LevelOne Broadband Router. If the port number is not 80, the port number is also required. (After the IP Address, enter ":"... -
Page 75: Chapter 7 Advanced Configuration
Chapter 7 Advanced Configuration This Chapter explains the settings available via the Advanced configuration section of the "Advanced" menu. Overview Normally, it is not necessary to use these screens, or change any settings. These screens and settings are provided to deal with non-standard situations, or to provide additional options for advanced users. -
Page 76: Pc Database Screen
By default, non-Server versions of Windows act as "DHCP Clients"; this setting is called "Obtain an IP Address automatically". • The LevelOne Broadband Router uses the "Hardware Address" to identify each PC, not the name or IP address. The "Hardware Address" can only change if you change the PC's network card or adapter. - Page 77 Delete Delete the selected PC from the list. This should be done in 2 situations: • The PC has been removed from your LAN. • The entry is incorrect. Refresh Update the data on screen. Generate Report Display a read-only list showing full details of all entries in the PC database.
-
Page 78: Options
If Disabled, UPnP users can only view the configuration. But tion... currently, this restriction only applies to users running Windows XP, who access the Properties via UPnP. (e.g. Right - click the LevelOne Broadband Router in My Network Places, and select Properties) Figure 42: Options Screen... - Page 79 But currently, this restriction only applies to users running Windows XP, who access the Properties via UPnP. (e.g. Right - click the LevelOne Broadband Router in My Network Places, and select Properties) Firewall If enabled, DoS (Denial of Service) attacks will be detected and blocked.
-
Page 80: Printer Port
LevelOne Broadband Router User Guide Printer Port This screen is available for the FBR-1401TX and FBR-1700TX only. Normally, the settings on this screen do not need to be changed. Figure 43: Printer Port Screen Logical Printers No (L1, L2, L3) Logical printer configuration is only required if using LPD printing under Linux or Unix. -
Page 81: Mac Address
• If your ISP has already recorded a MAC address, you can change the address used by the LevelOne Broadband Router to match the address recorded by your ISP. MAC Address Screen Select MAC Address from the Advanced menu to reach a screen like the example below. -
Page 82: Routing
If you don't have other Routers or Gateways on your LAN, you can ignore the "Routing" page completely. • If the LevelOne Broadband Router is only acting as a Gateway for the local LAN segment, ignore the "Routing" page even if your LAN has other Routers. •... - Page 83 For class "C" networks, the default mask is 255.255.255.0 • Gateway IP Address - The IP Address of the Gateway or Router which the LevelOne Broadband Router must use to communicate with the destination above. (NOT the router attached to the re- mote segment.) •...
-
Page 84: Configuring Other Routers On Your Lan
Configuring Other Routers on your LAN It is essential that all IP packets for devices not on the local LAN be passed to the LevelOne Broadband Router, so that they can be forwarded to the external LAN, WAN, or Internet. To achieve this, the local LAN must be configured to use the LevelOne Broadband Router as the Default Route or Default Gateway. - Page 85 Router B (192.168.1.90) (192.168.2.70) For the LevelOne Broadband Router's Routing Table For the LAN shown above, with 2 routers and 3 LAN segments, the LevelOne Broadband Router requires 2 entries as follows. Entry 1 (Segment 1) Destination IP Address Network Mask...
-
Page 86: Appendix A Troubleshooting
This Appendix covers the most likely problems and their solutions. Overview This chapter covers some common problems that may be encountered while using the LevelOne Broadband Router and some possible solutions to them. If you follow the suggested steps and the LevelOne Broadband Router still does not function properly, contact your dealer for further advice. -
Page 87: Printing
Some applications do not run properly when using the LevelOne Broadband Router. Solution 2: The LevelOne Broadband Router processes the data passing through it, so it is not transparent. Use the Special Applications feature to allow the use of Internet applica- tions which do not function correctly. - Page 88 LevelOne Broadband Router User Guide The printer wizard will display a message stating that “The Network Printer is off-line”. This is OK. Continue the Add Printer Wizard until finished. When finished, go to Control Panel-Printers. The printer icon will be grayed out indicating the printer is not ready.
- Page 89 Click OK to see the Print Port Configuration screen, as shown below. Click the Browse Device button, select the desired Multi-function LevelOne Broadband Router, and click OK. 10. Click OK to return to the Printers folders, and right-click on the Printer.
-
Page 90: Appendix C Specifications
Appendix C Specifications FBR-1100TX (LevelOne 1 Port Broadband Router with 1 LAN Port) Model FBR-1100TX - LevelOne 1 Port Broadband Router with 1 LAN Port Dimensions 120mm(W) * 93mm(D) * 30mm(H) Operating Tempera- 0° C to 40° C ture Storage Tempera- -10°... -
Page 91: Fbr-1400Tx
FBR-1400TX (LevelOne 1 Port Broadband Router with 4 LAN Port) Model FBR-1400TX - LevelOne 1 Port Broadband Router with 4 LAN Port Dimensions 215mm(W) * 150mm(D) * 36mm(H) Operating Temperature 0° C to 40° C Storage Temperature -10° C to 70° C... -
Page 92: Fbr-1401Tx
LevelOne Broadband Router User Guide FBR-1401TX (LevelOne 1 Port Broadband Router with 4 LAN Port, Printer Server) Model FBR-1401TX - LevelOne 1 Port Broadband Router with 4 LAN Port, Printer Server Dimensions 215mm(W) * 150mm(D) * 36mm(H) Operating Temperature 0° C to 40° C Storage Temperature -10°... -
Page 93: Fbr-1700Tx
FBR-1700TX (LevelOne 1 Port Broadband Router with 7 LAN Port, Printer Server) Model FBR-1700TX - LevelOne 1 Port Broadband Router with 7 LAN Port Dimensions 250mm(W) * 180mm(D) * 40mm(H) Operating Temperature 0° C to 40° C Storage Temperature -10° C to 70° C...
