Aiwa CT-Z110 Service Manual

Stereo car cassette receiver
Hide thumbs Also See for CT-Z110:
Table of Contents

Advertisement

Quick Links

Download this manual
CT-Z110
YJ(S)
SERVICE MANUAL
STEREO CAR
BASIC TAPE MECHANISM : TN-715-DH-116
CASSETTE RECEIVER
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
(S/M Code No. 09-005-344-9T1).
S/M Code No. 09-005-344-9R1

Advertisement

Table of Contents
loading

Related Manuals for Aiwa CT-Z110

Summary of Contents for Aiwa CT-Z110

  • Page 1 CT-Z110 YJ(S) SERVICE MANUAL STEREO CAR BASIC TAPE MECHANISM : TN-715-DH-116 CASSETTE RECEIVER This Service Manual is the "Revision Publishing" and replaces "Simple Manual" (S/M Code No. 09-005-344-9T1). S/M Code No. 09-005-344-9R1...

  • Page 2: Specifications

    SPECIFICATIONS RADIO SECTION TAPE SECTION Tape Speed: 4.8 cm/sec. (1 ips) (FM) S/N Ratio: 50 dB Frequency Range: 87.5 MHz–108 MHz Frequency Response: 40 Hz–14,000 Hz (50-kHz steps) Stereo Separation: 40 dB 87.5 MHz-108 MHz FF/REW Time: 190 sec. (C-60) (100-kHz steps) AUDIO SECTION Usable Sensitivity:...

  • Page 3: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C402 87-010-401-080 CAP, ELECT 1-50V C403 87-010-401-080 CAP, ELECT 1-50V C404 87-010-401-080 CAP, ELECT 1-50V 87-A21-191-010 IC,KIA6225S C405 87-010-184-080 CHIP CAPACITOR 3300P(K) 8Z-KT1-622-010 C-IC,LC75374E C406 87-010-184-080 CHIP CAPACITOR 3300P(K)

  • Page 4: Chip Resistor Part Code

    REF. NO PART NO. KANRI DESCRIPTION L702 87-003-149-080 COIL,47UH SW901 87-A91-152-010 SW,SL 1-1-2 SSSS212-11-A TUN101 8A-KC8-624-010 TU UNIT, FAE347-A16 X701 87-A70-175-010 VIB,XTAL 4.5MHZ AT-49 FRONT C.B D801 87-017-827-070 C-LED,SEC1201C,RED D802 87-017-827-070 C-LED,SEC1201C,RED D803 87-017-827-070 C-LED,SEC1201C,RED D804 87-A40-813-040 C-LED,SEC1E01C BLUE D805 87-A40-813-040 C-LED,SEC1E01C BLUE D806...

  • Page 5: Transistor Illustration

    TRANSISTOR ILLUSTRATION IC BLOCK DIAGRAM-1 IC, LC75374E E C B E C B B C E KTC3198 DTC343TS 2SD2395 KRA111S KTC3203 KRA104M KTA1046 KRA226S KRA226M KRC102S KRC102M KRC111S KTA1267 KTA1273 IC, KIA6225S...

  • Page 6: Schematic Diagram

    SCHEMATIC DIAGRAM...
  • Page 7 WIRING-1...
  • Page 8 WIRING-2 IC BLOCK DIAGRAM-2 IC, TA8259H...

  • Page 9: Lcd Display

    IC DESCRIPTION LCD DISPLAY IC, LC72336 Pin No. Pin Name Description X-IN System clock oscillator. TEST2 Device test input. Rotary encoder input 1. CLK-AVR Clock output to electronic VR (LC75374) DATA EVR CE output to electronic VR (LC75374) CE EVR Chip enable output to electronic VR (LC75374) LED CONT LED control.

  • Page 10: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1/1 TN-715-DH-116 CHAS,SIDE-L HT-SINK, A-UO FRONT C.B LCD801 MAIN C.B CHAS,SIDE-R AUX C.B SH,PWB...

  • Page 11: Color Name Table

    MECHANICAL MAIN PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 8A-KTF-020-010 KNOB,RTRY NON RUBBER 26 8Z-KT1-231-010 HLDR,HALF-T 2 8A-KT5-021-010 RING,RTRY A 27 8A-KTG-201-010 HLDR,LCD G 3 8A-KTH-008-010 WINDOW,LCD Z110 35W 28 8A-KTG-203-010 LENS,LCD G 4 8A-KTF-005-010 WINDOW,R F...

  • Page 12: Mechanism Exploded View

    MECHANISM EXPLODED VIEW 1/1...
  • Page 13 MECHANISM MAIN PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 S6-405-040-020 PUSH SW SW-230-2 26 S1-960-030-030 P.GEAR 2 S1-960-063-120 MG PLATE Z ASSY 27 S1-940-141-150 MIDDLE PULLEY 3 S6-405-010-360 SW,OAS-1229-4 28 S1-960-140-020 TA,SPRING 4 S1-960-140-140 P.P SPRING...
  • Page 14 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 931196 Printed in Singapore...
